PRODUCT MANUAL
Designed, Manufactured and Supported in the USA
SECURITY & COMMUNICATION
Features
The K-1270 Entry Phone is a two-way, handsfree
telephone with 12 buttons for calling individual
residences in an apartment building with an
integrated 125 KHz Proximity Card Reader. The
rugged stainless steel faceplate has a printed
directory housed in a waterproof, scratch-resistant
lens. Each button is beside the tenants name in the
directory so there are no confusing codes to deal
with. Calling a particular tenant is as easy as
pressing a single button. The K-1270 has a built in
speed dialer that can handle up to 12 primary
phone numbers, each with 22 digits. If there is no
answer at the first number, a second number can
be called automatically. Once the tenant answers
their phone, a single touch tone command can
activate the door strike relay. For “no phone line”
applications, the K-1270 is compatible with the
C-3000 no CO (phone line) controller.
The K-1270-EWP shares all of the features of the
K-1270 in addition to Enhanced Weather
Protection (EWP) for outdoor installations where
the unit is exposed to precipitation or
condensation. EWP products feature foam rubber
• Built-in 125KHz 26-bit Wiegand proximity card reader with LED,
beep card read confirmation, and EWP board protection
• Compatible with the following Viking Proximity Cards and Fobs:
PRX-C, PRX-C-ISO and PRX-FOB (DOD# 198)
• Vandal Resistant Features: 14 gauge louvered 316 stainless
steel faceplate with permanent laser etched graphics, heavy duty
metal keypad and T-10 Torx Security mounting screws.
• Weather Resistant Features: Marine grade 316 stainless steel
faceplate and screws. Internally sealed keypad. Mylar speaker.
Self-draining mic mount. Faceplate, keypad, mic and speaker
gaskets.
• Designed to meet IP66 Ingress Protection Rating (see DOD 859)
• Operates on 12 to 24 volts AC/DC
• 12 speed dial buttons (22 digits each)
• 12 alternate number positions (22 digits each)
• One button operation (no call button)
• Hang up on CPC, busy, silence, time-out or dial tone
• Touch tone restriction from microphone
• Integral relays for camera control and door strike
• Works with C-1000B for increased security
• Works with C-3000 for “No CO” (phone line) operation
• 50 keyless entry codes
• See model K-1205 for integral camera
• Postal lock input
• Optional VE-5x10 surface mount box, sold separately (DOD 424)
• Small apartment buildings
• Professional buildings
• Gated communities
Power: 12 to 24 Volts AC or DC, 12VDC adapter provided
Proximity Card Reader Power: 5 to 14V DC @ 60mA maximum
Note: To assure operation during a power outage, a UPS
should be used.
Dimensions: 127mm x 254mm x 63.5mm (5" x 10" x 2.5")
Shipping weight: 2.2 kg (4.8 lbs.)
Standard K-1270 Environment: -34° C to 65° C (-30° F
to 150° F) with 5% to 95% non-condensing humidity
K-1270-EWP Environment: -34° C to 65° C (-30° F to
150° F) with up to 100% condensing humidity
Relay Contact Rating:
Door Strike: 5A @ 30VDC/250VAC maximum
Camera: 0.5A @ 125 VAC, 1.0A @ 30VDC
Connections: (16) gel-filled butt connectors (3M
Scotchlok UR2)
Applications
Specifications
www.vikingelectronics.com
Information: [phone]
VIKING
gaskets and boots, sealed connections, gel-filled
butt connectors, as well as urethane or thermal
plastic potted circuit boards with internally sealed,
field-adjustable trim pots and DIP switches for easy
on-site programming.
12 Button Apartment Entry Phone with Built-In
Door Strike Relay and Proximity Card Reader
“Brushed 316 Stainless Steel”
(similar to brushed nickel)
K-1270 Series
Entry Phones with Keypads
and Proximity Card Readers
July 5, 2017
(shown in optional
VE-5x10-SS, not included)

Power: 5 to 14V DC @ 60mA maximum
Maximum Cable Length: 500 ft 24 Awg stranded shielded
(Belden 9537)
Frequency: 125KHz
Format: 26 bit Wiegand
Read Range: 1.25” to 2.0”
Technologies Supported: Viking PRX-C, PRX-C-ISO,
PRX-FOB, LRT-4, certain legacy HID® proximity protocols*
and certain AWID 125Khz proximity protocols**
Transducer: Beeps during card read
LED: Red, turns off during card read
Humidity: Up to 100% (fully potted EWP)
Operating Temperature: -34° C to 65° C (-30° F to 150° F)
* HID and the HID logo are registered trademarks of HID
Global Corporation, an ASSA ABLOY company. All other
trademarks are the property of their respective owners.
** AWID is a trademark of Applied Wireless Identification Group.
Proximity Card Reader Specifications
Fea tures Overview
Keypad: Push to initiate call,
push again to disconnect. Zinc
Die cast with Satin Chrome
Finish, internally sealed per
IP67.
Speaker Screen: Speaker
screen with 0.018" wide slots
to prevent punctures from
paperclips, etc.
Faceplate Material: 14 gauge
316 stainless steel with #4
brushed finish.
Speaker: Mylar speaker with
rubber gasket to maintain
water-tight seal and eliminate
water deterioration.
Blue Call LED: Lights steady
to help locate the button in low
light.
Microphone: Omni-directional
microphone with protective
water-resistant cloth.
Front View of the
K-1270 Entry Phone
Condensation Drain Hole
Mounting Screws: (8) 6-32 X
3/4” Marine grade 316
stainless steel, flat head, T-10
Torx security screws and drive
bit (included).
Laser Etched Graphics: For
long lasting easy to read
graphics.
VIKING ©
1
2
3
4
5
6
7
8
9
0
#
*
#
*
0
9
8
7
6
5
4
3
2
1
12
34
5
6
78
90
#
*
Proximity Card Reader:
26-bit Wiegand, 125KHz, red
LED turns off and transducer
will beep during card read.
Fully potted EWP. Read range
1.25" to 2.0". Impact resistant
polycarbonate lens with
water-tight gasket.
2

Installation
IMPORTANT: Electronic devices are susceptible to lightning and power station electrical surges from both the AC
outlet and the telephone line. It is recommended that a surge protector be installed to protect against such surges.
A. Mounting
VIKING
©
1
2
3
4
5
6
7
8
9
0
#
*
9
0
#
*
8
7
6
5
4
3
2
1
Optional VE-5x10 Surface Mount
Box (not included), see DOD# 424
10.0"
9.5"
4.50"
2.596"
5.00"
8.65"
0.425"
0.952"
Front View
of the K-1270
9.12"
2.5"
4.5"
Zinc-Plated Steel
Rough-In Box
(included)
Side View
of the K-1270
(8) #6-32 x 1/2" Stainless
Steel, 5/64" T-10 Torx
Security Screws
(included)
14 Gauge Marine
Grade 316 Stainless
Steel Faceplate
10.14"
3.69"
5.22"
- OR -
B. Changing the Directory
Paper Directory
Directory
Lens
C. Wiring
Color Function
Black Power In
Black Power In
Green Phone Line In
Red Phone Line In
Brown Door Strike Relay common
Orange Door Strike Relay NC
Yellow Door Strike Relay NO
Blue Camera Relay common
Violet Camera Relay NC
White Camera Relay NO
The K-1270 is designed to be installed in a sheltered location, and is not meant to be used outdoors. For outdoor
applications use the K-1270-EWP. The K-1270 can either be installed as a flush mount unit using the included
rough in box, or as a surface mount unit using an optional VE-5x10. The rough in box uses the inner set of four
holes on the face plate while the VE-5x10 uses the outside set of holes. A set of dummy screws and nuts are
provided to fill the unused mounting holes.
To install a directory, remove the four screws that mount
the directory lens to the front of the K-1270 using the
included Allen wrench. Insert a paper directory behind the
lens and secure the two back onto the front panel being
careful to align the names with the front panel graphics.
For your convenience, the back of this document has pre-
printed directory forms.
Note: To print directory forms for the K-1270, go to
www.vikingelectronics.com and enter “930” in the DOD
field at the top of the page for a direct link to the PDF.
The K-1270 can be powered from any source supplying 12
to 24 volts, AC or DC. A 12 volt DC adapter is supplied with
the product. When using the included adapter, the plug on
the adapter cord will have to be removed. The power
connections to the K-1270 (black wires) are not polarity
sensitive.
There are also 8 more wires connected to the K-1270
controller board. Two wires are for the incoming phone line,
three are from the high current door strike relay and the last
three are from the camera relay. Gel filled butt connectors
are provided for easier connection to building wiring. The
table at the right describes each wire’s function.
3

4
D. Wiring the K-1270 Proximity Card Reader
Back View of
the K-1270
- Black (GND)
+ Red (5-14VDC)
Green (Date 0)
White (Data 1) * Up to 500 ft
3-Wire Gel-Filled Butt
Connectors included
(3M Scotchlok UR2)
24 Awg Stranded
Shielded Cable
(Belden 9537)
Black
Red
Green
White
Black
Red
Green
White
To Viking model
ES-1 or
Equivalent 26-Bit
Wiegand Card
Reader Controller
xxxxxxx
VIKING
Model:
Complieswith FCC Part 15 & 68
VikingElectronics, Inc. [phone]
1531 Industrial St., Hudson, WI 54016
P/N: xxxxxxx DEV:
S/N:xxxxxxxx
RoHS
xxxxxxxxxxxxxx
Reg. No:
REN: xxxx
www.vikingelectronics.com DOD# xxx
Viking Model ES-1 (not included,
see DOD# 193 for more information)
VIKING©
VIKING
ELECTRONICS
HUDSON, WI 54016
STAND ALONE
DOOR CONTROLLER
ENTRY SYSTEM
POWER 12V DC
MODEL ES-1
1
POWER
PROGRAM
PHONE
LOG
BUS
2345
GANG
PROG
6789
WIEGAND
DEVICE
10 11
DOOR STRIKE
N.O.
2 1
L
H
COM
N.C.
BLK
RED
GRN
WHT
Doorstrike
12V DC
Adapter
(included
with ES-1)
OR
Share power with
12-24V AC/DC door
strike with 200mA
available current or use
the included 12V DC
adapter.
Touch Tone
Programming Phone
(not included)
Remote Touch Tone
Programming Phone
(not included)
OR
RAD-1A Remote Access
Device (not included,
see DOD# 410)
Doorstrike
Power Supply
12-24V AC or DC
IMPORTANT: Electronic devices are susceptible to lightning and power station electrical surges from
both the AC outlet and the telephone line. It is recommended that a surge protector be installed to protect
against such surges.

Blue (COM)
Violet (NC)
White (NO)
Camera
Controller
(not included)
OR
Rear View
of the K-1270
Green
Red
** Gel-Filled Butt
Connectors (included)
Black
Black
* Ferrite Core
(included)
CO Line
120V AC
xxxxxxx
VIKING
Model:
Complies with FCC Part 15 & 68
Viking Electronics, Inc. [phone]
1531 Industrial St., Hudson, WI 54016
P/N: xxxxxxx DEV:
S/N:xxxxxxxx
RoHS
xxxxxxxxxxxxxx
Reg. No:
REN: xxxx
www.vikingelectronics.com DOD# xxx
5
Applications
Important: To operate the K-1270 during a power failure, a UPS should be installed.
A. Connecting a Doorstrike to the K-1270 Internal Relay
The K-1270 provides a dry contact output that can be used for operation of a door strike. To use this feature, the
Door Strike Code and Door Strike Time must be set in programming. In this mode, when the Door Strike Code is
detected, the K-1270 will energize the relay for the period of time selected in the Door Strike Time (see
Programming section E, G and H).
If a Postal Lock is required, connect the normally open contacts of the lock to the two white wires coming from the
two pin connector on the lower portion of the control board. When the postal lock is momentarily actuated, the
door strike will energize for the programmed Door Strike Time.
* Note: To prevent unwanted radio interference, route the connecting wires through the included ferrite core.
** Note: The gel-filled (water-tight) butt connectors are designed for insulation displacement on 19-26 gauge wire
with a maximum insulation of 0.082 inches. Cut off stripped ends prior to terminating.
Rear View
of the K-1270
CO Line
Yellow (N.O.)
Brown (COM)
Green
Red
** Gel-Filled Butt Connectors (included)
Black
Black
* Ferrite Core
(included)
White
White
Postal Lock
Switch (N.O.)
Orange (N.C.)
120V AC
Doorstrike / Magnetic Lock
120V AC
xxxxxxx
VIKING
Model:
Complies with FCC Part 15 & 68
Viking Electronics, Inc. [phone]
1531 Industrial St., Hudson, WI 54016
P/N: xxxxxxx DEV:
S/N:xxxxxxxx
RoHS
xxxxxxxxxxxxxx
Reg. No:
REN: xxxx
www.vikingelectronics.com DOD# xxx
B. Connecting Camera Control to the K-1270 Internal Relay
Another internal relay in the K-1270 can be used to trigger a camera controller. When the K-1270 makes a call,
it will energize the relay and hold it on until the call is done.
* Note: To prevent unwanted radio interference, route the connecting wires through the included ferrite core.
** Note: The gel-filled (water-tight) butt connectors are designed for insulation displacement on 19-26 gauge wire
with a maximum insulation of 0.082 inches. Cut off stripped ends prior to terminating.

6
C. Using the K-1270 with a C-1000B
In some instances it may be a concern that the Door Strike relay is outside the door. In this situation, a second
controller such as a C-1000B can be used. Be sure to disable the door strike code for the K-1270 (see
Programming section H).
Notes: 1. The C-1000B must be in the “Analog Station Mode” (refer to the C-1000B Product Manual).
2. The K-1270 keyless entry codes can not be used in this application.
3. The K-1270 will hang up during doorstrike activation.
DOOR ENTRY / CCTV VIDEO
CONTROLLER
VIKING©MODEL C-1000B
PWR 13.8 VAC
DOOR
STRIKE 1
DOOR
STRIKE 2
DOORBOX 2
DOORBOX
PWR OUTPUT
DOORBOX 1
123456789
10 11 12 13 14 15 16 17 18 19
EARTH GND
PHONE LINE INPUT
LINE OUT TO PHONES KEYLESS CONTACT CLOSURE INPUT
VIKING
ELECTRONICS
HUDSON, WI 54016
EARTH
GND
C.O. LINE
INPUT
OUT TO
PHONES
KEYLESS
C.C. INPUT
DOOR
BOX 1
DOORBOX
13VAC PWR
DOOR
BOX 2
N.O. COM N.C.
DOOR STRIKE 1
SIG GND
VIDEO 1 IN
SIG GND
VIDEO 2 IN
SIG GND
VIDEO OUT
N.O. COM N.C.
DOOR STRIKE 2
TALK BATTERY
OFF ON
C
LED1
C
LED2
C
LED3
ON
1 2 3
COM N.O. N.C. - - - - AUX.
CONTACT
OUTPUT
13.8V AC
Adapter
(included)
Talk Battery Switch
OFF ON
CO line or Analog
PABX/KSU Station
Earth
Ground
5A@30V DC/
250V AC maximum
Red
Green
ON
1 2 3
DIP Switches
Model K-1270
ON
OFF
Model C-1000B
(not included)
Doorstrike / Magnetic Lock
120V AC
120V AC
120V AC
D. Using the K-1270 with a C-3000
For a “No CO” installation, a Viking C-3000 No CO controller can be used with the K-1270. Note, the K-1270 will
need to be programmed on a separate CO line or use the Viking DLE-200B. The door strike can be controlled by
the K-1270 or the internal relay on the C-3000, just be sure to disable the door strike feature in the other unit. The
keyless entry feature of the C-3000 can not be used. If not using keyless entry codes, use the C-3000 to control
the doorstrike. If using keyless entry codes (up to 50), use the K-1270 to control the doorstrike. The K-1270 speed
dial position should be programmed with the C-3000 line selection command “1” to “12”. (Refer to the C-3000
Technical Practice for more details, DOD# 162).
Model K-1270
120V AC
VIKING©
MODEL C-3000
VIKING
ELECTRONICS
HUDSON, WI 54016
12 UNIT APARTMENT
ENTRY CONTROLLER MODULE
POWER
13.8 VAC
3456712
DOOR
STRIKE
1
DOOR
STRIKE
2
DIP
SWITCH
1 2 3
RJ21X
12 APARTMENT LINES IN/OUT
8
ENTRY
PHONE 1
MULTI-MODULE
INTERCONNECTS
POSTAL
LOCK
INPUT
ENTRY
PHONE 2 OUT IN
PWR
IN
USE
PROGRAM PHONE
O
N
O
F
F
Red
Red
Green
Green
Model C-3000
(not included)
120V AC
120V AC
Model K-1270
Notes: 1. In this application, the C-3000 keyless entry feature is not available. Use the keyless entry
feature of the K-1270 and wire both door strike relays in parallel.
2. The K-1270 will hang up during the doorstrike activation.

7
K-1270
Entry Point 4
Entry Point 2
K-1270
Entry Point 1
Local
Programming
Phone
13.8V AC
Adapter
Included
120V AC
Optional "Push to Open / Request to Exit" Button
available for each entry point (not included)
N.O. COM N.C.
DOOR STRIKE 1
VIKING
©
MODEL C-4000
VIKING
ELECTRONICS
HUDSON, WI 54016
APARTMENT OR OFFICE
ENTRY CONTROLLER
PROGRAM
PHONE
POWER
13.8 VAC
DOOR STRIKE RELAYS
WIEGAND INPUTS
C
LED1
N.O. COM N.C.
DOOR STRIKE 2
N.O. COM N.C.
DOOR STRIKE 3
N.O. COM N.C.
DOOR STRIKE 4
BLK RED GRN WHT
ENTRY 1
BLK RED GRN WHT
ENTRY 2
BLK RED GRN WHT
ENTRY 3
BLK RED GRN WHT
ENTRY 4
C.O. LINE
INPUT
AUX
LINE
ENTRY
PHONE 1
ENTRY
PHONE 2
ENTRY
PHONE 3
ENTRY
PHONE 4
REX
1
REX
2
REX
3
REX
4
H L
LOG BUS
RS-232 PORT
PROGRAM
PHONE
5A @ 30V DC
maximum
(not included)
Doorstrike
Power Supply
Doorstrike 1
5A @ 30V DC
maximum
(not included)
Doorstrike
Power Supply
Doorstrike 2
5A @ 30V DC
maximum
(not included)
Doorstrike
Power Supply
Doorstrike 3
5A @ 30V DC
maximum
(not included)
Doorstrike
Power Supply
Doorstrike 4
*
*
*
Entry Point 3
K-1275
K-1275
*
E. Add Relay Control for up to 4 K-1270/75 Proximity Card Readers
IMPORTANT: Electronic devices are susceptible to lightning and power station electrical surges from
both the AC outlet and the telephone line. It is recommended that a surge protector be installed to
protect against such surges.
* Note: Maximum Wiegand run length is 300 feet using 24 gauge wire. Run length is reduced to half if two share
the same wire run from the same C-4000 entry point. Run lengths can be doubled by doubling up on the BLACK
and RED 24 gauge wire, or using 21 gauge (or larger) wire. Certain electrically noisy locations might require
shielded wire.

8
Programming
1. Accessing the Programming Mode with the Security Code
Step 1 Move DIP switch 1 to the ON position (sets unit to answer incoming calls).
Step 2 From a touch tone phone, call the line attached to the K-1270.
Step 3
When the K-1270 answers, listen for the beep(s) and then enter a “#“ followed by the 6-digit security
code (factory set to 845464). A double beep should be heard indicating you have entered the
programming mode.
A. Accessing the Programming Mode
2. Accessing the Programming Mode without the Security Code
Step 1 Move DIP switch 1 to the ON position (sets unit to answer incoming calls).
Step 2 Move DIP switch 4 to the ON position (incoming calls enter programming without security code, see
section B).
Step 3 From a touch tone phone call the line attached to the K-1270.
Step 4 When the K-1270 answers, a double beep should be heard indicating you have entered the
programming mode.
Step 5 When finished programming, move DIP switch 4 back to the OFF position.
This six digit number can be used to access the programming mode. The security code has been factory set to
845464 (V-I-K-I-N-G). It is recommended that you change the security code to a personal 6 digit number. To
change the security code, access programming (see Programming section A). Enter six digits 0-9 followed by
#47. If you have forgotten your security code, follow the steps in Programming section A, 2. Accessing the
Programming Mode Without the Security Code). Note: The security code must be six digits in length and can
NOT contain a Q or #.
B. Security Code (memory location #47)
3. Forced Answer to Enter Programming
If the ring signal produced by the central office is non-standard or of low amplitude, the K-1270 might not
detect ring and answer the line, which would prevent the user from entering programming. If this happens,
check to see that DIP switch 1 is ON so the unit is set to answer incoming calls. Then turn DIP switch 4 ON
to allow accessing programming without the security code. Call the line attached to the K-1270. With the phone
ringing, press the “0” button on the K-1270 keypad. The K-1270 should answer the line and you should hear
two beeps indicating that you are in the programming mode. To leave programming, just hang up, or enter
“##7” to disconnect the line immediately. Be sure to turn DIP switch 4 OFF when through with programming.
The access code comes into play when Tenant Initiated Entry is enabled (see Operation). It is a 1 to 6 digit code
making it possible for tenants to allow a visitor to enter in the special case where the tenant calls the K-1270 and
converses with the visitor rather than the visitor starting the entry process by pressing a directory button. The
access code has been factory set to 123456. It is recommended that you change the access code to a personal
1-6 digit number. To change the access code, enter programming (see Programming section A). Enter 1-6 digits
followed by #48. To disable the access code, enter just #48 without any preceding digits. Note that disabling the
access code removes a level of security (see O. Tenant Initiated Entry). Also note that an access code is
required only if Tenant Initiated Entry is allowed (see Programming section O).
C. Access Code (memory location #48)
The K-1270 can be programmed with up to 50 keyless entry codes. This feature allows a visitor to let themselves
in by entering a preprogrammed code on the K-1270 keypad. Each keyless code can contain from 1 to 6 digits
and is programmed by entering the digits into any of the locations #50 to #99. To clear a location enter “#” followed
by the position number without any preceding number. The “Q” and “#” keys can also be used in the keyless codes
by substituting “#20” and “#21” (respectively) when programming a keyless position.
D. Keyless Entry Codes

9
E. Quick Programming Features
A one or two digit door strike code can be entered by
programming position #41. When in programming, enter the
one or two digit code followed by “#41”. Note: “Q” and “#”
can be entered as valid characters of the door strike code by
substituting “#20” and #21” (respectively) when programming
the door strike code (see section D). To disable the door
strike relay, enter “#41” without any preceding numbers.
Examples of door strike code entries are shown to the right.
H. Door Strike Code
Description Enter Digits + Location
Speed dial numbers ................................................................................................................. 0-46 digits** + #01 - #12
Door strike time in sec (factory 05, 00 =.5 sec)*........................................................................ 2 digits + #40
Door strike code (factory 6, no digits disables) ......................................................................... 1-2 digits + #41
Maximum call time in min (factory 3, 0 = .5 min, no digits disables)* ...................................... 1 digit + #42
Maximum ring time in sec (factory 20, 00 disables)* ............................................................... 2 digits + #43
Silence Time Out in sec (factory 10, 00 disables)* ................................................................. 2 digits + #44
Talk/listen delay time in .1 sec (factory 2)* .............................................................................. 1 digit + #45
Security code (factory 845464)* ............................................................................................... 6 digits + #47
Access code (factory set to 123456)* ....................................................................................... 1-6 digits + #48
Keyless entry codes .................................................................................................................. 1-6 digits + #50 - #99
Dial a (Q) .................................................................................................................................. #20
Dial a (#) ................................................................................................................................... #21
Add a 4 second pause ............................................................................................................. #22
Add a 1 second pause ............................................................................................................. #23
Second phone number selector ............................................................................................... #24
Normal dialing speed (factory setting) ..................................................................................... #30
Fast dialing speed ..................................................................................................................... #31
Hang up on dial tone enable (factory setting) .......................................................................... #32
Hang up on dial tone disable ................................................................................................... #33
Disable tenant initiated entry (factory setting) ........................................................................... #37
Enable tenant initiated entry ..................................................................................................... #38
Reset all programming to factory default settings ................................................................... ###
Hang up from programming ..................................................................................................... ##7
* Cannot contain “Q“ or “#“ (see #20 and #21) ** 45 digits maximum if two numbers are programmed in one memory location
Notes: 1. A single or double beep indicates a valid entry, three beeps indicate an error.
2. “Q“ or “#“, pauses or second phone number selector occupy one digit of memory.
The K-1270 is programmed through the incoming phone line. The programming commands are structured so
that they do not interfere with the commands of a C-1000B controller.
The K-1270 Entry Controller can be programmed with up to twelve 46 digit numbers. Each number can also be
programmed with special features such as pauses, and the Touch Tones “Q” and “#”. Each of the special characters count
as a single digit. Each of the speed dial positions #01 to #12 pertain to the corresponding button on the front of the K-
1270. The button “0” uses position #10, the “Q” uses position #11 and the “#” uses position #12. To program a speed dial
position, enter programming (see section A) then enter the desired number followed by the selected position. To clear a
position, only enter a “#“ followed by the position number with out any preceding number.
The K-1270 also has the capability to dial a second phone number if there is no answer or busy at the first number. This
can be used if the tenant wants the visitor to call their cell phone if they are not at home. To program a second number, be
sure that position #43 is programmed with the desired maximum ring time, then enter the first number to be dialed, followed
by “#24”. A single beep should be heard. Next enter the second number to be dialed followed by “#“ plus the memory
location. The total number of digits cannot exceed 46 for each position (45 digits if two numbers are programmed). The
following are examples of speed dial number entries:
F. Speed Dial Numbers
To Program the K-1270 to... Step 1 (see section A) Step 2 - Enter Digits
...store 555-1234 at the first button position Enter programming 5551234#01
...store a 9, a 1 second pause, then 333-4444 in the seventh button position Enter programming 9#233334444#07
...store a 23Q# in the eight position Enter programming 23#20#21#08
...store a first number of 22 and a second number of 33 in the “#“
button position Enter programming 22#24 (beep) 33#12
The actual time the door strike relay is energized is controlled by location #40. The time can be set from 00 to 99 seconds,
(an entry of “00” gives 0.5 seconds). In order to use this feature, be sure the relay door strike code is set (see section H).
G. Door Strike Time
To Program the
Door Strike Code to...
Step 1
(see section A)
Step 2
Enter Digits
“99” Enter programming 99#41
“3” Enter programming 3#41
“QQ”Enter programming #20#20#41
“#1” Enter programming #211#41
“Q”Enter programming #20#41

10
This timer sets the maximum amount of time the K-1270 will look for the call to be answered. If this timer expires
and the tenant has not answered, the call will be terminated or the K-1270 will dial a second phone number (if
programmed). The factory setting is 20 seconds, and to disable this feature, enter “00” into position 43.
J. Maximum Ring Time
This time out is started once the call has been connected and is reset every time audio is detected on the phone
line. If it expires, the call will be terminated. This is useful on systems that are silent when the tenant hangs up to
assure the K-1270 disconnects. It is factory set to 10 seconds and can be disabled by entering “00” in position
44.
K. Silence Time Out
This time represents the amount of time the K-1270 will delay before switching back to the microphone mode
after it was in the speaker mode (VOX switching time). It is in 100 msec increments and stored in position 45.
L. Talk/Listen Delay
On some phone lines, a faster rate of dialing is allowed. The dialing speed of the K-1270 can be altered to take
advantage of this faster rate. The normal dialing speed is 5 digits per second and is selected by entering “#30”
(factory setting) while in programming. To increase the speed to 10 digits per second, enter “#31”. If the faster
rate is selected, be sure to test each number to assure proper operation.
M. Dialing Speed
The K-1270 is factory set to hang up if continuous audio is detected after dialing. In most situations this would
happen if the tenant hung up and the service that the K-1270 is connected to provides a dial tone following the
hang up. In some instances due to noisy lines or loud background noise, the call may be terminated before the
tenant hangs up. If this occurs, enter “#33” when in programming. This will disable return to dial tone feature and
stop the K-1270 from hanging up prematurely. To enable this feature enter “#32” when in programming.
N. Hang Up on Return to Dial Tone
See Operation for a functional description of this feature. Tenant Initiated Entry is disabled by default. To enable
it, enter programming (see Programming section A). Enter #38. Also, DIP switch 1 must be turned ON and left
in this position to enable the K-1270 to answer incoming calls. To disable Tenant Initiated Entry, enter #37.
Security considerations with Tenant Initiated Entry: The K-1270 door entry system is designed with security
in mind, which is the reason an access code is recommended in cases where Tenant Initiated Entry is allowed.
To understand the need for an access code, consider the following example. A person walks up to the entry and
pushes one of the directory buttons on the K-1270. The unit looks up the number associated with that directory
position and dials it. The phone inside the tenant’s apartment rings, and is answered by someone who happens
to be a guest in the tenant’s apartment. The guest notices that the tenant’s phone is displaying the caller ID of
the number that just called, which is the number of the K-1270. They jot the number down. The guest can now
call the K-1270 at a later time, if DIP switch 1 is on, Tenant Initiated Entry is allowed, the access code is disabled,
and they know the door strike code, they can let themselves into the building. Note that by default, Tenant Initiated
Entry is not allowed, but if this feature is allowed, it is important to program an access code (see C. Access Code
(memory location #48).
O. Tenant Initiated Entry
To clear all speed dial positions and set all modes back to factory setting, enter “###“ while in programming.
Caution, all previous programming will be lost. Normally when the K-1270 is in the programming mode, it will
hang up the line if no commands are detected for 20 seconds. To hang up immediately, enter “##7”.
P. Special Commands
In some installations, it maybe desirable to limit the length of the call to the tenant. This can be done by
programming position #42. The maximum call time can be set from 1 minute to 9 minutes by entering the
appropriate number in position #42. A “0” will yield a 30 second time. To disable the call timer enter “#42” without
any preceding digit.
I. Maximum Call Time

When a visitor is at the K-1270, they just need to find the name of the tenant they want to visit on the
directory and press the associated button. The K-1270 will then seize the phone line and speed dial
the number programmed for that name. When the tenant answers the call, they can let the visitor in by
entering the Door Strike Code on their telephone keypad. The tenant can converse with the visitor for
up to 10 seconds after the Door Strike Code is dialed (to verify the visitor has been granted entry). The
K-1270 is able to determine if the door strike command is coming from the apartment or the caller, to
prevent entry using a hand held touch tone dialer. If the tenant chooses not to let the visitor in, they can
simply hang up the phone. The K-1270 will drop the line when busy, reorder, CPC signals are detected,
when programmable maximum call time out, silence time out, maximum ring timers expire or 10
seconds after a door strike activation. Only the buttons that have a programmed phone number are
active (except “#” when used for keyless entry). After a button is pressed, and the call is initiated, it can
be canceled by momentarily pressing any button on the panel.
If a second number is programmed for the selected tenant, and there is no answer or busy after dialing
the first number, the K-1270 will hang up, pause, seize the line, and then dial this second number. In
this manner the call can be routed to a cell phone if the tenant is not at home. The tenant can still let
the visitor in using the Door Strike Code.
It is also possible to talk to a visitor before they press a directory button, and to let them in if Tenant
Initiated Entry has been enabled. Make sure DIP switch 1 is on (Auto Answer, see section Q), and
then call the number of the K-1270. The unit will answer and send a single or double beep. After a
single beep, if Tenant Initiated Entry is not enabled the tenant can converse with the visitor but is not
able to use the doorstrike code to let them in. If Tenant Initiated Entry is enabled, the tenant can enter
the access code following the single beep, hear two acknowledgement beeps, and then either let the
visitor in using the doorstrike code or hang up to terminate the call. A double beep after the unit answers
indicates both that Tenant Initiated Entry is enabled and that the access code is disabled, so the user
can let the visitor in using the doorstrike code without having to enter the access code, or terminate the
call by hanging up.
To use the keyless entry feature, momentarily press or press and hold the “#“ key on the K-1270 keypad.
When momentarily pressed, 1 beep will be heard and if held for 2 seconds (or longer), 2 beeps will be
heard. In either case, the K-1270 is then ready to accept the keyless code. Continue by entering one
of the previously programmed keyless codes. The K-1270 will pause a few seconds to make sure there
are no more keypad entries, and then actuates the Door Strike relay if valid. If an incorrect code is
entered, the K-1270 will beep 3 times and the user has to start over and enter a correct code.
If a Postal Lock is used, a momentary closure of the postal lock switch will energize the door strike for
the programmed Door Strike Time. 11
Two POTs are provided to increase or decrease speaker volume and microphone sensitivity. In certain noisy
locations the microphone sensitivity may need to be decreased as shown below. Caution: Setting the microphone
gain too high may cause distorted audio, prevent the distant party from breaking over and inhibit second number
redialing.
Q. DIP Switch Programming / Speaker and Microphone Adjustments
Microphone
Sensitivity POT
ON
OFF
1 2 3 4
Speaker
Volume POT
123
on
4
Turn POTS clockwise to increase
(as viewed from the back of the board).
Switch Position Description
1 ON Incoming calls answered (factory setting)
1 OFF Incoming calls not answered
2 & 3 ON Audio Detection normal (factory setting)
2 & 3 OFF Audio Detection more sensitive
4 ON
Learn Mode - Any incoming calls are
automatically entered into the
programming mode, no security code
required. Use this option if you have
forgotten your security code.
4 OFF Normal operation mode (factory setting)
Note: On some phone lines, busy and ring back tones may be very soft. In these installations, set DIP switches
2 and 3 to OFF.
Operation

12
Printed in the U.S.A.
DOD# 184
ZF303920 Rev A
Due to the dynamic nature of the product design, the information contained in this document is subject to change without notice. Viking Electronics, and its affiliates
and/or subsidiaries assume no responsibility for errors and omissions contained in this information. Revisions of this document or new editions of it may be issued
to incorporate such changes.
Product Support: [phone]
If trouble is experienced with the K-1270/EWP, for repair or warranty information, please contact:
Viking Electronics, Inc., 1531 Industrial Street, Hudson, WI 54016 [phone]
If the equipment is causing harm to the telephone network, the telephone company may request
that you disconnect the equipment until the problem is resolved.
Connection to Party Line Service is subject to State Tariffs. Contact the state public utility
commission, public service commission or corporation commission for information.
WHEN PROGRAMMING EMERGENCY NUMBERS AND (OR) MAKING TEST CALLS TO
EMERGENCY NUMBERS:
Remain on the line and briefly explain to the dispatcher the reason for the call. Perform such
activities in the off-peak hours, such as early morning or late evenings.
It is recommended that the customer install an AC surge arrester in the AC outlet to which this
device is connected. This is to avoid damaging the equipment caused by local lightning strikes
and other electrical surges.
PART 15 LIMITATIONS
This equipment has been tested and found to comply with the limits for a Class Adigital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
FCC REQUIREMENTS
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA.
On the side of this equipment is a label that contains, among other information, a product identifier in
the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone
company.
The REN is used to determine the number of devices that may be connected to a telephone line.
Excessive REN's on a telephone line may result in the devices not ringing in response to an incoming
call. In most but not all areas, the sum of the REN's should not exceed five (5.0) To be certain of the
number of devices that may be connected to a line, as determined by the total REN's, contact the
local telephone company. For products approved after July 23, 2001, the REN for this product is part
of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by ## are
the REN without a decimal point (e.g., 03 is a REN of 0.3). For earlier products, the REN is separately
shown on the label.
The plug used to connect this equipment to the premises wiring and telephone network must comply
with the applicable FCC Part 68 rules and requirements adopted by the ACTA. If your home has
specially wired alarm equipment connected to the telephone line, ensure the installation of this K-
1270/EWP does not disable your alarm equipment. If you have questions about what will disable alarm
equipment, consult your telephone company or a qualified installer.
If the K-1270/EWP causes harm to the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be required. But if advance notice isn't practical,
the telephone company will notify the customer as soon as possible. Also, you will be advised of your
right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations, or procedures that
could affect the operation of the equipment. If this happens, the telephone company will provide
advance notice in order for you to make the necessary modifications to maintain uninterrupted service.
IF YOU HAVE A PROBLEM WITH A VIKING PRODUCT, CONTACT: VIKING TECHNICAL SUPPORT AT [phone]
Our Technical Support Department is available for assistance Monday 8am - 4pm and Tuesday through Friday 8am - 5pm central time. So that we can give you
better service, before you call please:
1. Know the model number, the serial number and what software version you have (see serial label).
2. Have your Product manual in front of you.
3. It is best if you are on site.
RETURNING PRODUCT FOR REPAIR
The following procedure is for equipment that needs repair:
1. Customer must contact Viking's Technical Support Department at 715-386-8666 to obtain a Return Authorization (RA) number. The customer MUST have a
complete description of the problem, with all pertinent information regarding the defect, such as options set, conditions, symptoms, methods to duplicate problem,
frequency of failure, etc.
2. Packing: Return equipment in original box or in proper packing so that damage will not occur while in transit. Static sensitive equipment such as a circuit board
should be in an anti-static bag, sandwiched between foam and individually boxed. All equipment should be wrapped to avoid packing material lodging in or sticking
to the equipment. Include ALL parts of the equipment. C.O.D. or freight collect shipments cannot be accepted. Ship cartons prepaid to: Viking Electronics, 1531
Industrial Street, Hudson, WI 54016
3. Return shipping address: Be sure to include your return shipping address inside the box. We cannot ship to a PO Box.
4. RA number on carton: In large printing, write the R.A. number on the outside of each carton being returned.
RETURNING PRODUCT FOR EXCHANGE
The following procedure is for equipment that has failed out-of-box (within 10 days of purchase):
1. Customer must contact Viking’s Technical Support at 715-386-8666 to determine possible causes for the problem. The customer MUST be able to step through
recommended tests for diagnosis.
2. If the Technical Support Product Specialist determines that the equipment is defective based on the customer's input and troubleshooting, a Return Authorization
(R.A.) number will be issued. This number is valid for fourteen (14) calendar days from the date of issue.
3. After obtaining the R.A. number, return the approved equipment to your distributor, referencing the R.A. number. Your distributor will then replace the product over
Viking using the same R.A. number.
4. The distributor will NOT exchange this product without first obtaining the R.A. number from you. If you haven't followed the steps listed in 1, 2 and 3,
be aware that you will have to pay a restocking charge.
Warranty
TWO YEAR LIMITED WARRANTY
Viking warrants its products to be free from defects in the workmanship or materials, under normal use and service, for a period of two years from the date of
purchase from any authorized Viking distributor. If at any time during the warranty period, the product is deemed defective or malfunctions, return the product to
Viking Electronics, Inc., 1531 Industrial Street, Hudson, WI., 54016. Customer must contact Viking's Technical Support Department at 715-386-8666 to obtain a
Return Authorization (R.A.) number.
This warranty does not cover any damage to the product due to lightning, over voltage, under voltage, accident, misuse, abuse, negligence or any damage
caused by use of the product by the purchaser or others. This warranty does not cover non-EWP products that have been exposed to wet or corrosive environments.
This warranty does not cover stainless steel surfaces that have not been properly maintained.
NO OTHER WARRANTIES. VIKING MAKES NO WARRANTIES RELATING TO ITS PRODUCTS OTHER THAN AS DESCRIBED ABOVE AND DISCLAIMS
ANY EXPRESS OR IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
EXCLUSION OF CONSEQUENTIAL DAMAGES. VIKING SHALL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE TO PURCHASER, OR ANY OTHER
PARTY, FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL OR EXEMPLARY DAMAGES ARISING OUT OF OR RELATED TO THE SALE OR USE OF THE
PRODUCT SOLD HEREUNDER.
EXCLUSIVE REMEDY AND LIMITATION OF LIABILITY. WHETHER IN AN ACTION BASED ON CONTRACT, TORT (INCLUDING NEGLIGENCE OR STRICT
LIABILITY) OR ANY OTHER LEGAL THEORY, ANY LIABILITY OF VIKING SHALL BE LIMITED TO REPAIR OR REPLACEMENT OF THE PRODUCT, OR AT
VIKING'S OPTION, REFUND OF THE PURCHASE PRICE AS THE EXCLUSIVE REMEDY AND ANY LIABILITY OF VIKING SHALL BE SO LIMITED.
IT IS EXPRESSLY UNDERSTOOD AND AGREED THAT EACH AND EVERY PROVISION OF THIS AGREEMENT WHICH PROVIDES FOR DISCLAIMER OF
WARRANTIES, EXCLUSION OF CONSEQUENTIAL DAMAGES, AND EXCLUSIVE REMEDY AND LIMITATION OF LIABILITY, ARE SEVERABLE FROM ANY
OTHER PROVISION AND EACH PROVISION IS A SEPARABLE AND INDEPENDENT ELEMENT OF RISK ALLOCATIONAND IS INTENDED TO BE ENFORCED
AS SUCH.
