Viking Technology VRFEM2008GZIQSTH User manual

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 1 of 34
www.vikingtechnology.com
SATA 6Gb/s
Industrial
mSATA
Manual
mSATA (mini-SATA, MO-300) is a non-volatile, solid-state storage device
delivering Serial ATA performance, reliability and ruggedness for
industrial and environmentally challenging applications.

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 2 of 34
www.vikingtechnology.com
Revision History
Date
Revision
Description
Checked By
3/28/17
Initial Release based on
PSFEM2xxxxZxxx_B
Add VRFEM2016GZIRSTH
(40to+85'c, SLC)

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 3 of 34
www.vikingtechnology.com
Legal Information
Legal Information
Copyright© 2017 Sanmina Corporation. All rights reserved. The information in
this document is proprietary and confidential to Sanmina Corporation. No part of
this document may be reproduced in any form or by any means or used to make
any derivative work (such as translation, transformation, or adaptation) without
written permission from Sanmina. Sanmina reserves the right to revise this
documentation and to make changes in content from time to time without
obligation on the part of Sanmina to provide notification of such revision or
change.
Sanmina provides this documentation without warranty, term or condition of any
kind, either expressed or implied, including, but not limited to, expressed and
implied warranties of merchantability, fitness for a particular purpose, and non-
infringement. While the information contained herein is believed to be accurate,
such information is preliminary, and should not be relied upon for accuracy or
completeness, and no representations or warranties of accuracy or
completeness are made. In no event will Sanmina be liable for damages arising
directly or indirectly from any use of or reliance upon the information contained in
this document. Sanmina may make improvements or changes in the product(s)
and/or the program(s) described in this documentation at any time.
Sanmina, Viking Technology, Viking Modular Solutions, and Element logo are
trademarks of Sanmina Corporation. Other company, product or service names
mentioned herein may be trademarks or service marks of their respective
owners.

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 4 of 34
www.vikingtechnology.com
Ordering Information: mSATA SSD Solid-State Drive
Viking P/N
Interface
Temp
User
GB
Client/Ent
NAND
VRFEM2008GZIQSTH
MO-300
(-40to+85'c)
8
Client
TSB 24nm “H-die”SLC
VRFEM2016GZIRSTH
MO-300
(-40to+85'c)
16
Client
TSB 24nm “H-die”SLC
Notes:
1. Higher capacity points may be available based on customer application. Consult your local Viking Field Application
Engineer.
2. SSD’s ship unformatted from the factory unless otherwise requested.

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 5 of 34
www.vikingtechnology.com
Product Picture(s)

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 6 of 34
www.vikingtechnology.com
Industrial SSD’s –Viking’s Industrial SSD contains sophisticated provisions to
protect firmware and data from corruption due to unexpected power loss.
However, an Industrial SSD by industry definition does not contain on-board
capacitance. Should power fail unexpectedly, “in-flight” write data may be lost.
Industrial SSD’s are best used in designs that manage power fail events at the
system level.

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 7 of 34
www.vikingtechnology.com
Table of Contents
1INTRODUCTION 10
1.1 Features 10
1.2 Block Diagram 11
1.3 SATA Interface 12
2PRODUCT SPECIFICATIONS 13
2.1 Capacity and LBA count 13
2.2 Performance 13
2.3 Timing 15
2.3.1 STANDBY IMMEDIATE Command 15
2.4 Electrical Characteristics 15
2.4.1 Absolute Maximum Ratings 15
2.4.2 Supply Voltage 16
2.4.3 Power Consumption 16
2.5 Environmental Conditions 16
2.5.1 Temperature and Altitude 16
2.5.2 Shock and Vibration 16
2.5.3 Electromagnetic Immunity 17
2.6 Reliability 17
3MECHANICAL INFORMATION 17
3.1 mSATA SSD Weight 20
4PIN AND SIGNAL DESCRIPTIONS 20
4.1 Signal and Power Description Tables 20
4.2 Hot Plug Support 21
5COMMAND SETS 21
5.1 ATA Commands 22
5.1.1 48-Bit Address Command Set 23

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 8 of 34
www.vikingtechnology.com
5.1.2 ATA General Feature Command Set 23
5.1.3 Device Configuration Overlay Command Set 23
5.1.4 General Purpose Log Command Set 23
5.1.5 Host Protected Area Command Set 24
5.1.6 Power Management Command Set 24
5.1.7 Security Mode Feature Set 24
5.1.8 Identify Device Data 25
5.1.1 S.M.A.R.T. Support 28
5.1.2 SATA 3.0 S.M.A.R.T. Command Set 29
5.2 SATA Commands 33
5.2.1 Native Command Queuing (NCQ) 33
6REFERENCES 33
7GLOSSARY 34

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 9 of 34
www.vikingtechnology.com
Table of Tables
Table 2-1: Maximum Sustained Read and Write Bandwidth ____________________________ 13
Table 2-2: Random Read and Write Input/Output Operations per Second (IOPS) ___________ 14
Table 2-3: STANDBY IMMEDIATE Timing _________________________________________ 15
Table 2-4: Absolute Maximum Ratings ____________________________________________ 15
Table 2-5: Operating Voltage ____________________________________________________ 16
Table 2-6: Typical Power Consumption ____________________________________________ 16
Table 2-7: Temperature and Altitude Related Specifications____________________________ 16
Table 2-8: Shock and Vibration Specifications_______________________________________ 17
Table 2-9: Reliability Specifications _______________________________________________ 17
Table 4-1: Mini PCIe Connector Pin Signal Definitions ________________________________ 20
Table 5-1: Supported ATA Commands ____________________________________________ 22
Table 5-2: List of Device Identification _____________________________________________ 25
Table 5-3: S.M.A.R.T. Command Set______________________________________________ 29
Table 5-4: Extended SMART Attribute Table________________________________________ 29
Table 5-5: Extended SMART Attribute Actual Data ___________________________________ 30
Table 5-6: Supported S.M.A.R.T. EXECUTE OFF-LINE IMMEDIATE Subcommands ________ 32
Table of Figures
Figure 1-1: High-Level Block Diagram _____________________________________________ 11
Figure 3-1: Dimensions ________________________________________________________ 18

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 10 of 34
www.vikingtechnology.com
1 Introduction
Viking’s rugged industrial designed SSD’s offer the highest flash storage
reliability and performance in harsh environments such as shock, vibration,
humidity, altitude, ESD, and extreme temperatures.
1.1 Features
The SSD delivers the following features:
Offers seamless SATA Revision 3.0 interface support for SATA up to
6Gb/s
Low overall SSD power consumption
Supports Native Command Queuing (NCQ) to 32 commands
Compatible with all major SLC and MLC flash technologies
S.M.A.R.T.
Superior wear-leveling algorithm
Efficient error recovery
TRIM

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 11 of 34
www.vikingtechnology.com
1.2 Block Diagram
Figure 1-1: High-Level Block Diagram
Notes:
1.Support for up to 2-channels and 2 CE in the NAND Flash interface
2
2

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 12 of 34
www.vikingtechnology.com
1.3 SATA Interface
The Serial ATA (SATA) interface is compliant with the SATA IO Serial
ATA specification, revision 3.0 that supports SATA up to 6Gb/s.
The SATA interface connects the host computer to the SSD subsystem.
The SATA interface runs at a maximum speed of 6 Gbps (Giga-bits per
second). If the host computer is unable to negotiate a speed of 6 Gbps,
the SATA interface automatically renegotiates to a speed of 3 Gbps or 1.5
Gbps.
For a list of supported commands and other specifics, please see Chapter 5.

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 13 of 34
www.vikingtechnology.com
2 Product Specifications
2.1 Capacity and LBA count
Raw Capacity
(GB)
User Capacity
(GB)
LBA Count
16
14
27,370,224
16
16
31,277,232
32
30
58,626,288
32
32
62,533,296
64
60
117,231,408
64
64
125,045,424
128
120
234,441,648
128
128
250,069,680
256
240
468,862,128
256
256
500,118,192
Notes:
1. Per LBA1-03 spec, LBA counts = (97,696,368) + (1,953,504 * (Advertised Capacity in GBytes –50))
2. User addressable 512byte sectors
2.2 Performance
Table 2-1: Maximum Sustained Read and Write Bandwidth
Capacity
Flash Structure
Performance1
CrystalDiskMark
ATTO
Read
Write
Read
Write
(MB/s)
(MB/s)
(MB/s)
(MB/s)
14/16GB
16GBx1, BGA, TSB H die SLC
TBD
TBD
TBD
TBD
30/32GB
32GBx1, BGA, TSB H die SLC
TBD
TBD
TBD
TBD
60/64GB
32GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
TBD
120/128GB
64GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
TBD
240/256GB
128GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
TBD
480/512GB
256GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
TBD
Notes:
1. Performance Estimate based on MLC 32GB: R/W using CrystalDiskMark
(~560/165) and R/W using ATTO (~560/540 MB/s Actual data is pending from DVT lab testing
2. Performance may vary from flash configuration, SDR configuration, and platform.
3. Refer to Application Note AN0006 for Viking SSD Benchmarking Methodology.
4. Data is based on SSD’s using Toshiba A15nm Toggle NAND devices

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 14 of 34
www.vikingtechnology.com
1.
Table 2-2: Random Read and Write Input/Output Operations per Second
(IOPS)
Capacity
Flash Type
Random Read
IOPS
Random Write
IOPS
32GB
15nm
TBD
TBD
64GB
15nm
TBD
TBD
128GB
15nm
TBD
TBD
256GB
15nm
TBD
TBD
512GB
15nm
TBD
TBD
Notes:
1.Performance measured using Iometer 08 with queue depth set to 32.
2.Write Cache enabled with DDR cache.
3.Random IOPS cover the entire range of legal logical block addresses (LBA’s).
4.Measurements are performed on a full drive (all LBA’s have valid content).
5.Performance may vary by NAND type and host.
6.Refer to Application Note AN0006 for Viking SSD Benchmarking Methodology.
7.Data is based on SSD’s using Toshiba A15nm NAND devices
8.L95A data not currently available

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 15 of 34
www.vikingtechnology.com
2.3 Timing
2.3.1 STANDBY IMMEDIATE Command
The Power-On-to-Ready time assumes a proper shutdown (power removal
preceded by STANDBY IMMEDIATE command. A STANDBY IMMEDIATE
before power down always performs a graceful shutdown and does not require
the use of the hold-up circuit. Note that SMART attribute 174 "Unexpected Power
Loss" records the number of non-graceful power cycle events.
Table 2-3: STANDBY IMMEDIATE Timing
Power Cycle Endurance
Min
Max
Unit
STANDBY IMMEDIATE to WE completed
-
72.9
ms
Notes: From Standby Immediate command to NAND Write Protect enable.
2.4 Electrical Characteristics
2.4.1 Absolute Maximum Ratings
Values shown are stress ratings only. Functional operation outside normal
operating values is not implied. Extended exposure to absolute maximum ratings
may affect reliability.
Table 2-4: Absolute Maximum Ratings
Description
Min
Max
Unit
Maximum Voltage Range for Vin
-0.2
6
V
Maximum Temperature Range
-40
85
c

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 16 of 34
www.vikingtechnology.com
2.4.2 Supply Voltage
The operating voltage is 3.3V
Table 2-5: Operating Voltage
Description
Min
Max
Unit
Operating Voltage for 3.3 V
- 5%
+5%
V
2.4.3 Power Consumption
All onboard power requirements of the SSD are derived from the SATA 3.3V
Table 2-6: Typical Power Consumption
Capacity
Flash Structure
Power Consumption1
Read
Write
Devslp
(mW)
(mW)
(mW)
14/16GB
16GBx1, BGA, TSB H die SLC
TBD
TBD
TBD
30/32GB
32GBx1, BGA, TSB H die SLC
TBD
TBD
TBD
60/64GB
32GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
120/128GB
64GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
240/256GB
128GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
480/512GB
256GBx2, BGA, TSB H die SLC
TBD
TBD
TBD
Notes:
1. Estimate based on MLC : R/WDevslp 1030,1210, 4.9 mW
5.Measured using Toshiba Toggle SLC NAND
2.5 Environmental Conditions
2.5.1 Temperature and Altitude
Table 2-7: Temperature and Altitude Related Specifications
Conditions
Operating
Shipping
Storage
Industrial
Temperature- Ambient
-40 to 85°C
-40 to 85°C
-40 to 85°C
Humidity (non-
condensing)
90% under 40C
93% under 40C
93% under 40C
Notes:
2.5.2 Shock and Vibration
SSD products are tested in accordance with environmental specification for
shock and vibration

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 17 of 34
www.vikingtechnology.com
Table 2-8: Shock and Vibration Specifications
Stimulus
Description
Shock
Acceleration Force: 1500G
Half Sin Pulse Duration: 0.5ms
Vibration
Frequency/Displacement: 20Hz~80Hz/1.52mm
Frequency/Acceleration: 80Hz~2000Hz/20G
X, Y, Z axis/60 min for each
2.5.3 Electromagnetic Immunity
mSATA is an embedded product for host systems and is designed not to impair
with system functionality or hinder system EMI/FCC compliance.
2.6 Reliability
Table 2-9: Reliability Specifications
Parameter
Description
MTBF
Over 2,000,000 hours
ECC
72-bit per 1KByte
Read Endurance
Unlimited
Write Endurance SLC (TBW)
16GB
32GB
64GB
128GB
256GB
512GB
TBD
TBD
TBD
TBD
TBD
TBD
Data retention
> 90 days at NAND expiration
NOTES:
1. Samples were built using Toshiba Toggle SLC NAND.
2. TBW may differ according to flash configuration and platform.
3. The endurance of SSD could be estimated based on user behavior, NAND endurance cycles,
and write amplification factor. It is not guaranteed by flash vendor
3 Mechanical Information
mSATA (MO-300)
Form Factor
Height (mm)
Width (mm)
Length (mm)
Min
-
29.70
50.65
Max
4.85
30.00
50.95

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 18 of 34
www.vikingtechnology.com
Figure 3-1: Dimensions

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 19 of 34
www.vikingtechnology.com
Notes: All dimensions are in millimeters

Manual
3/28/2017
PSFEM2xxxxZIxx
Viking Technology
Revision A
Page 20 of 34
www.vikingtechnology.com
3.1 mSATA SSD Weight
The weight of the mSATA (mini-SATA, MO-300) SSD is approximately 8
grams.
4 Pin and Signal Descriptions
4.1 Signal and Power Description Tables
Table 4-1: Mini PCIe Connector Pin Signal Definitions
Pin #
Type
Description
P1
Reserved
No Connect
P2
+3.3V
3.3V
P3
Reserved
No Connect
P4
GND
Return Current Path
P5
Reserved
No Connect
P6
Reserved
No Connect
P7
Reserved
No Connect
P8
Reserved
No Connect
P9
GND
Return Current Path
P10
Reserved
No Connect
P11
Reserved
No Connect
P12
Reserved
No Connect
P13
Reserved
No Connect
P14
Reserved
No Connect
P15
GND
Return Current Path
P16
Reserved
No Connect
P17
Reserved
No Connect
P18
GND
Return Current Path
P19
Reserved
No Connect
P20
Reserved
No Connect
P21
GND
Return Current Path
P22
Reserved
No Connect
P23
+B
Host Receiver Differential Signal Pair
P24
+3.3V
3.3V Source
P25
-B
Host Receiver Differential Signal Pair
P26
GND
Return Current Path
P27
GND
Return Current Path
