Dell™ PowerVault™ 750N and 755N NAS Appliances
SYSTEM ADMINISTRATOR’S GUIDE

___________________
Information in this document is subject to change without notice.
© 2001 Dell Computer Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Computer
Corporation is strictly forbidden.
Trademarks used in this text:
Dell , the DELL logo, PowerVault , Dell OpenManage ,
PowerEdge
, and Dell ActiveArchive are trademarks of Dell Computer Corporation;
Microsoft , MS-DOS , Windows, and Windows NT are registered trademarks of Microsoft
Corporation;
Novell and NetWare are registered trademarks of Novell, Inc.; VERITAS and
Backup Exec are registered trademarks of VERITAS Software; UNIX isaregistered trademark
of The Open Group of the United States;
Intel is a registered trademark of Intel Corporation;
Computer Associates is a registered trademark and ARCserveIT is a trademark of Computer
Associates International.
Other trademarks and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. Dell Computer Corporation disclaims any
proprietary interest in trademarks and trade names other than its own.
June 2001 P/N 7E309 Rev. A00

Contents 3
Contents
1Introduction
The Boot Process . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
System Configuration . . . . . . . . . . . . . . . . . . . . . . 1-3
Administrator User Name and Password . . . . . . . . . . . . . 1-3
Basic Configuration. . . . . . . . . . . . . . . . . . . . . . . . 1-3
Configuring Your System With DHCP . . . . . . . . . . . . . 1-4
Configuring Your System Using a Serial Connection . . . . . . 1-4
Configuring Your System Using the Kick-Start Utility . . . . . 1-6
Disabling the Kick-Start Utility . . . . . . . . . . . . . . . . 1-14
2NAS Manager
Basic Navigation . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Status Area . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Menu Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
How To Find Online Help . . . . . . . . . . . . . . . . . . . . . 2-3
Using Shares . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Managing Shares . . . . . . . . . . . . . . . . . . . . . . . 2-4
Adding a Share . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Modifying Share Properties . . . . . . . . . . . . . . . . . . 2-6
Removing a Share . . . . . . . . . . . . . . . . . . . . . . . 2-6
Removing a Protocol From the Share . . . . . . . . . . . . . 2-6
Using the PowerVault Advanced Administration Menu . . . . . 2-7
Retrieving Your Service Tag . . . . . . . . . . . . . . . . . . 2-8

Contents 4
Disk Quotas . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Enabling Disk Quota Management. . . . . . . . . . . . . . . 2-8
Adding Disk Quota Entries . . . . . . . . . . . . . . . . . . 2-9
Modifying Quota Properties . . . . . . . . . . . . . . . . . . 2-10
Removing Disk Quota Entries . . . . . . . . . . . . . . . . . 2-10
Using Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Managing Logs . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Using Other Languages . . . . . . . . . . . . . . . . . . . . . . 2-13
Shutting Down the NAS Appliance . . . . . . . . . . . . . . . . 2-14
Managing Volumes . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Creating a Volume . . . . . . . . . . . . . . . . . . . . . . 2-14
Preparing a Volume for Expansion . . . . . . . . . . . . . . 2-15
Expanding a Volume . . . . . . . . . . . . . . . . . . . . . 2-15
Deleting a Volume. . . . . . . . . . . . . . . . . . . . . . . 2-16
Viewing Volume Properties . . . . . . . . . . . . . . . . . . 2-16
Managing Disks . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Listing Available Disks . . . . . . . . . . . . . . . . . . . . 2-17
Rescanning for Disks . . . . . . . . . . . . . . . . . . . . . 2-17
Creating a Hotspare . . . . . . . . . . . . . . . . . . . . . . 2-17
Freeing a Hotspare . . . . . . . . . . . . . . . . . . . . . . 2-18
Forcing a Disk Online . . . . . . . . . . . . . . . . . . . . . 2-18
Viewing Disk Properties . . . . . . . . . . . . . . . . . . . . 2-18
3Advanced Disk and Volume Management
Using Array Manager
Array Manager Common Tasks . . . . . . . . . . . . . . . . . . 3-2
Creating a New Volume . . . . . . . . . . . . . . . . . . . . 3-2
Deleting an Existing Volume . . . . . . . . . . . . . . . . . 3-2
Expanding an Existing Volume . . . . . . . . . . . . . . . . 3-3

Contents 5
Array Manager Console . . . . . . . . . . . . . . . . . . . . . . 3-3
Left Pane . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Right Pane . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Launching Array Manager From the NAS Manager . . . . . . . 3-4
Managing Disk Arrays . . . . . . . . . . . . . . . . . . . . . . 3-5
Recommended Virtual Disk Configuration . . . . . . . . . . . 3-5
Creating Virtual Disks . . . . . . . . . . . . . . . . . . . . 3-5
Deleting Virtual Disks . . . . . . . . . . . . . . . . . . . . . 3-6
Reconfiguring and Managing Virtual Disks . . . . . . . . . . 3-7
Array Disk Commands . . . . . . . . . . . . . . . . . . . . . . 3-10
Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Rebuild . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Assign Global Hot Spare . . . . . . . . . . . . . . . . . . . 3-11
Unassign Global Hot Spare . . . . . . . . . . . . . . . . . . 3-11
Online Array Disk . . . . . . . . . . . . . . . . . . . . . . . 3-11
Offline Array Disk . . . . . . . . . . . . . . . . . . . . . . . 3-12
Prepare to Remove . . . . . . . . . . . . . . . . . . . . . . 3-12
Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
General Controller Commands . . . . . . . . . . . . . . . . . . 3-12
Rescan Controller . . . . . . . . . . . . . . . . . . . . . . . 3-13
Flush Cache . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Enable Sound . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Disable Sound . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Rebuild Rate . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Disk Management . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Writing a Disk Signature . . . . . . . . . . . . . . . . . . . 3-14
Upgrading a Basic Disk to a Dynamic Disk . . . . . . . . . . 3-15
Reactivating Dynamic Disks . . . . . . . . . . . . . . . . . . 3-16
Merging Foreign Disks . . . . . . . . . . . . . . . . . . . . 3-16
Volume Management . . . . . . . . . . . . . . . . . . . . . . . 3-16
Volume Overview . . . . . . . . . . . . . . . . . . . . . . . 3-17

Contents 6
Checking Partition or Volume Properties . . . . . . . . . . . 3-17
Formatting a Partition or Volume . . . . . . . . . . . . . . . 3-17
Delete a Partition or Volume . . . . . . . . . . . . . . . . . 3-18
Working With Dynamic Volumes . . . . . . . . . . . . . . . . . 3-18
Creating a Dynamic Volume . . . . . . . . . . . . . . . . . . 3-18
Extending a Dynamic Simple or Spanned Volume . . . . . . . 3-20
4System Management
Dell OpenManage Remote Assistant Card . . . . . . . . . . . . 4-2
Alert Log Messages From Dell OpenManage
Server Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Configuring SNMP Community Properties . . . . . . . . . . 4-4
Configuring SNMP Agent Properties . . . . . . . . . . . . . . 4-5
5System Recovery, Backup, and Restore
Recovery From System Failure . . . . . . . . . . . . . . . . . . 5-2
Reinstalling the Operating System . . . . . . . . . . . . . . . 5-2
Initial System Setup . . . . . . . . . . . . . . . . . . . . . 5-3
System State Backup and Restore . . . . . . . . . . . . . . . . 5-3
Backing Up System State Data . . . . . . . . . . . . . . . . 5-4
Restoring System State Data . . . . . . . . . . . . . . . . . 5-4
Windows 2000 Backup and Recovery Tools . . . . . . . . . . . 5-6
Supported Third-Party Backup Software . . . . . . . . . . . . 5-6
Third-Party Backup Software for Network Backups . . . . . . . 5-7
Installing Network Accelerator Agents . . . . . . . . . . . . 5-7
Third-Party Backup Software for Local Backups . . . . . . . . 5-7
Installing VERITAS Backup Exec . . . . . . . . . . . . . . . 5-7
Installing ARCserve 2000 . . . . . . . . . . . . . . . . . . . 5-9

Contents 7
Backing Up Persistent Images . . . . . . . . . . . . . . . . . . 5-10
Limitations on Backing Up Persistent Images . . . . . . . . . 5-11
Restoring Persistent Images From Tape Backup . . . . . . . . 5-11
Installing Tape Device Drivers for Windows 2000 Backup
and Recovery Tools . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Installing Drivers for PowerVault Tape Drives . . . . . . . . . 5-12
Installing Drivers for PowerVault Tape Drive
Media Changers . . . . . . . . . . . . . . . . . . . . . . . . 5-13
6Dell ActiveArchive™
Introduction to Persistent Images . . . . . . . . . . . . . . . . 6-2
Cache File . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Cache Thresholds . . . . . . . . . . . . . . . . . . . . . . . 6-3
Persistent Image Retention Weights . . . . . . . . . . . . . . 6-3
Persistent Image Considerations . . . . . . . . . . . . . . . . 6-3
Storing Persistent Images . . . . . . . . . . . . . . . . . . . 6-4
Accessing Directories, Folders, and Files . . . . . . . . . . . 6-4
Allowing User’s Access to Persistent Images . . . . . . . . . 6-4
Preparing Your Volumes for Persistent Images . . . . . . . . . 6-5
Scheduling Persistent Images . . . . . . . . . . . . . . . . . . 6-6
Displaying the List of Persistent Images . . . . . . . . . . . . 6-6
Adding Persistent Images to the Schedule . . . . . . . . . . . 6-6
Deleting a Persistent Image Schedule . . . . . . . . . . . . . 6-7
Editing the Properties of a Persistent Image’s Schedule . . . . 6-7
Using Persistent Images . . . . . . . . . . . . . . . . . . . . . 6-8
Taking a New Persistent Image on Demand . . . . . . . . . . 6-8
Deleting a Persistent Image . . . . . . . . . . . . . . . . . . 6-9
Setting Persistent Image Retention Weights . . . . . . . . . . 6-9
Configuring the Persistent Image Global Settings . . . . . . . 6-10
Configuring Persistent Image Volume Settings . . . . . . . . 6-10

8Contents
Accessing Stored Persistent Images in ActiveArchive . . . . . 6-11
Restoring Volumes From an Existing Persistent Image . . . . . 6-12
7Advanced Features
Installing Multilanguage User Interface
(MUI) Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Installing and Configuring Support for Other Languages . . . . 7-4
Network Adapter Teaming . . . . . . . . . . . . . . . . . . . . . 7-5
Creating Network Teams Using the Broadcom Advanced
Server Control Suite . . . . . . . . . . . . . . . . . . . . . . 7-6
Removing an Adapter From a Network Team . . . . . . . . . . 7-7
Changing the Network Team Mode Using the
Broadcom Advanced Server Control Suite . . . . . . . . . . . 7-8
Creating Network Teams Using the Intel PROSet Utility . . . . 7-8
Removing Network Teams Using the Intel PROSet Utility . . . 7-9
Removing an Adapter From a Network Team Using the
Intel PROSet Utility . . . . . . . . . . . . . . . . . . . . . . 7-9
Changing the Network Team Mode Using the Intel PROSet
Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Services for UNIX . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Server for Network File System (NFS) . . . . . . . . . . . . 7-11
UNIX Utilities . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Telnet Server . . . . . . . . . . . . . . . . . . . . . . . . . 7-12
Services For UNIX MMC Console . . . . . . . . . . . . . . 7-13
ActiveState ActivePerl 5.6 . . . . . . . . . . . . . . . . . . 7-13
User Name Mapping . . . . . . . . . . . . . . . . . . . . . 7-13
Basic Scenarios . . . . . . . . . . . . . . . . . . . . . . . 7-15
File Server for Macintosh . . . . . . . . . . . . . . . . . . . . 7-16
Services for NetWare . . . . . . . . . . . . . . . . . . . . . . 7-18
Configuring the NWLink IPX/SPX Compatible Protocol . . . 7-18

Contents 9
Microsoft Directory Synchronization Services . . . . . . . . . 7-19
Windows 2000 MSDSS Domain Controller . . . . . . . . . . 7-19
Outline of the Deployment Procedure . . . . . . . . . . . . . 7-20
Uninterruptible Power Supply (UPS). . . . . . . . . . . . . . . 7-25
Upgrading to a Multiprocessor System . . . . . . . . . . . . . 7-26
Using Secured Socket Layers . . . . . . . . . . . . . . . . . . 7-27
Introduction to SSL Certificates . . . . . . . . . . . . . . . . 7-27
Server Certificates . . . . . . . . . . . . . . . . . . . . . . 7-27
PowerVault 750N/755N Certificate . . . . . . . . . . . . . . 7-28
Using a Custom Certificate . . . . . . . . . . . . . . . . . . 7-28
Obtaining a Server Certificate From a
Certification Authority . . . . . . . . . . . . . . . . . . . . 7-28
Console Redirection . . . . . . . . . . . . . . . . . . . . . . . 7-29
Minimum Hardware and Connection Requirements . . . . . . 7-30
Software Requirements . . . . . . . . . . . . . . . . . . . . 7-30
Configuring Console Redirection on the System . . . . . . . . 7-30
Configuring Console Redirection on the Client System . . . . . 7-31
Rebooting the System . . . . . . . . . . . . . . . . . . . . . 7-32
Configuring Special Keys . . . . . . . . . . . . . . . . . . . 7-32
Defragmenting a Volume Containing Persistent Images . . . . . 7-36
8Online Server Diagnostics
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Installing the Online Server Diagnostics . . . . . . . . . . . . . 8-3
Installing the JAVA Runtime Environment . . . . . . . . . . 8-4
Using the Online Server Diagnostics . . . . . . . . . . . . . . . 8-4
Starting the Online Server Diagnostics . . . . . . . . . . . . 8-4
Specifying a Target Appliance . . . . . . . . . . . . . . . . . 8-4
Configuring Online Server Diagnostics . . . . . . . . . . . . . 8-5
Running Online Server Diagnostics . . . . . . . . . . . . . . 8-5

10 Contents
Exiting Diagnostics . . . . . . . . . . . . . . . . . . . . . . 8-6
Learning About Diagnostic Tests . . . . . . . . . . . . . . . . 8-6
9Troubleshooting
Tables
Table 1-1. Kick-Start Configuration Overview . . . . . . . 1-7
Table 7-1. Categories of UNIX Utilities . . . . . . . . . 7-11
Table 7-2. Terminal Emulation Types . . . . . . . . . . . 7-30
Table 7-3. VT100/220 Supported Escape
Sequences . . . . . . . . . . . . . . . . . . . 7-33
Table 7-4. ANSI Supported Escape Sequences . . . . . . 7-34
Table 7-5. Additional Escape Sequences . . . . . . . . . 7-35
Table 9-1. Troubleshooting Issues . . . . . . . . . . . . . 9-2

Preface 11
Preface
This guide provides system administrators, IT professionals, and those responsible for the
installation of network attached storage (NAS) devices, with the information necessary to
install, configure, and operate the Dell™ PowerVault™ 750N and 755N NAS appliances.
Chapters include the following information:
• Chapter 1 — “Introduction” provides an overview of the system features, as well as the
information necessary to perform the initial configuration of the system.
• Chapter 2 — “NAS Manager” provides a high-level introduction to the NAS Manager
and how to find help.
• Chapter 3 — “Advanced Disk and Volume Management Using Array Manager”
provides a comprehensive solution to storage management in an integrated graphical
view.
• Chapter 4 — “System Management” provides directions for installing and configuring
a Dell OpenManage™ Remote Assistant Card (DRAC) and information about Dell
OpenManage Server Assistant.
• Chapter 5 — “System Recovery, Backup, and Restore” provides information on
recovering from system failure, and how to back up and restore the system state.
• Chapter 6 — “Dell ActiveArchive™” provides information on the creation and
preservation of persistent images of the PowerVault NAS appliance system data
volumes using Dell ActiveArchive.
• Chapter 7 — “Advanced Features” provides information on network adapter teaming,
network services for UNIX®, Macintosh, and Novell®NetWare®, language support,
and other advanced features.
• Chapter 8 — “Online Server Diagnostics” describes how to install and run the Online
Server Diagnostics on your NAS appliance.
• Chapter 9 — “Troubleshooting” lists potential issues with probable causes and
possible solutions.
Warranty and Return Policy Information
Dell Computer Corporation (“Dell”) manufactures its hardware products from parts and
components that are new or equivalent to new in accordance with industry-standard
practices. For information about the Dell warranty for your system, see your System
Information document.

12 Preface
www.dell.com | support.dell.com
Safety, Regulatory, and Warranty Information
For safety, regulatory, and warranty information for your system, see the System Information
document included with your system.
Other Documents You May Need
In addition to this System Administrator’s Guide, the following documentation is included
with your system:
• The NAS appliance User's Guide, which describes system features, technical
specifications, and device drivers.
• The NAS appliance Installation and Troubleshooting Guide provides instructions for
installing system hardware and includes troubleshooting and diagnostic procedures for
testing your system.
• Supporting system documentation on the NAS appliance Resource CD, that includes
information about all the option cards and software installed.
• The NAS appliance Localization CD that contains the Microsoft®Windows®
Multilanguage User Interface (MUI) and language locales.
•YourSystem Information document, which provides basic information about your
system.
•TheDell OpenManage Array Manager User’s Guide provides instructions for using the
Dell OpenManage™ Array Manager common interface for configuring and managing
local and remote storage.
•TheDell OpenManage Remote Assistant Card (DRAC) User's Guide provides
instructions for using the DRAC to manage and use a server through a modem or
network connection, even when the server itself is down.
•TheDell OpenManage Server Agent Messages Reference Guide describes the event
messages logged by the Dell OpenManage Server Agent 4.0 or later.
You may also have one or more of the following documents:
• Documentation that is included with options you purchase separately from the
system. This documentation includes information that you need to configure and
install these options in your system.

Preface 13
• Technical information files—sometimes called “readme” files—that might be
installed on the hard-disk drive to provide last-minute updates about technical
changes to the system or advanced technical reference material intended for
experienced users or technicians.
• Documentation updates that are sometimes included with the system to describe
changes to the system or software. Always read these updates before consulting any
other documentation. These updates often contain information that supersedes the
information in the other documents.
Notational Conventions
The following subsections describe notational conventions used in this document.
Notes, Notices, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your
computer.
NOTICE: A NOTICE indicates either potential damage to hardware orloss of data and tells you
how to avoid the problem.
CAUTION: A CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
WARNING: A WARNING indicates a potentially hazardous situation which, if not
avoided, may result in severe injury.
Some warnings may appear in alternate formats and may be unaccompanied by an icon. In
such cases, the specific presentation of the warning is mandated by regulatory authority.
Typographical Conventions
The following list defines (where appropriate) and illustrates typographical conventions
used as visual cues for specific elements of text throughout this document:
•Keycaps, the labeling that appears on the keys on a keyboard, are enclosed in angle
brackets.
Example: <Enter>
•Key combinations are series of keys to be pressed simultaneously (unless otherwise
indicated) to perform a single function.
• Example: <Ctrl><Alt><Enter>

14 Preface
www.dell.com | support.dell.com
•Commands presented in lowercase bold are for reference purposes only and are not
intended to be typed when referenced.
Example: “Use the format command to...”
In contrast, commands presented in the Courier New font are part of an instruction
and intended to be typed.
Example: “Type format a: to format the diskette in drive A.”
•Filenames and directory names are presented in lowercase bold.
Examples: autoexec.bat and c:\windows
•Syntax lines consist of a command and all its possible parameters. Commands are
displayed in lowercase bold; variable parameters (those for which you substitute a
value) are displayed in lowercaseitalics; constant parametersare displayed in lowercase
bold. The brackets indicate items that are optional.
Example: del [drive:][path]filename [/p]
•Command lines consist of a command and may include one or more of the command’s
possible parameters. Command lines are presented in the Courier New font.
Example: del c:\myfile.doc
•Screen text is text that appears on the screen of your monitor or display. It can be a
system message, for example, or it can be text that you are instructed to type as part of
a command (referred to as a command line). Screen text is presented in the Courier
New font.
Example: The following message appears on your screen:
No boot device available
Example: “Type md c:\programs and press<Enter>.”
•Variables are placeholders for which you substitute a value. They are presented in
italics.
Example: DIMMx(where xrepresents the DIMM socket designation).

www.dell.com | support.dell.com
SECTION 1
Introduction

1-2 Introduction
www.dell.com | support.dell.com
This chapter provides an overview of the Dell™ PowerVault™ 750N and 755N network
attached storage (NAS) appliances features, as well as the information necessary to perform
the initial configuration of the system.
These systems are “headless” systems that are managed through the onboard Ethernet
connection; they operate without a keyboard, monitor, or mouse. While it is possible to
connect these peripherals to a system, it is generally not necessary unless you are
troubleshooting the system. These systems are managed and monitored via a Web-based
user interface, the NAS Manager. You can also manage these systems remotely from a client
computer attached to the network.
The Boot Process
The internal drives in your NAS appliance are logical small computer system interface
(SCSI) drives that are controlled by a hardware redundant array of independent disks
(RAID) controller. The Microsoft®Windows®Powered operating system and boot sectors
are installed on two RAID 1 (mirrored) hard-disk drives.
The PowerVault 755N NAS appliance, which is a rack mounted system, uses a split bus and
has five drives. One drive is in the drive media bay and four drives are in the standard bay.
The operating system is installed on two mirrored RAID 1 drives. Data is stored on the
remaining three drives that are configured as RAID 5 drives.
The PowerVault 750N NAS appliance, which can be a tower or rack mounted system, uses a
split bus and has eight drives. Two drives are in the drive media bay and six drives are in the
drive internal bay. The operating system is installed on the two drives in the media bay,
which are configured as mirrored RAID 1 drives. Data is stored on the remaining six drives
that are configured as RAID 5 drives.
The boot sequence is as follows:
•CD-ROMdrive
• Diskette drive
• Operating system hard-disk drive

Introduction 1-3
System Configuration
You can perform most configuration tasks through the NAS Manager, which is a web
browser interface to the NAS appliance. The NAS Manager menus consist of common
management tasks grouped under tabs on a menu bar. Each tab on the main menu bar has
an associated secondary menu bar associated with it. The secondary menu bar lists the tasks
you can perform from that page. The NAS Manager allows you to perform routine
administrative tasks such as shutdown, restart, new share creation, and set user
configuration. The NAS Manager home page displays a status indicator and provides a link
to the Messages page, which contains details about logged events.
You can access the Terminal Services Advanced Client from the NAS Manager to perform
tasks not available directly through the NAS Manager. See “Advanced Features” for more
information.
Administrator User Name and Password
To log on to the NAS Manager, you must enter the administrator user name and password.
The default administrator user name is administrator and the default password is
powervault. To change the user name and password, click Set Administrator Password in
the Welcome window.
Basic Configuration
This section includes information to enable you get your system up and running. You will
set the basic configuration from another system that has a keyboard, monitor, and mouse.
After you set the basic configuration, you can use the NAS Manager to set passwords, local
users, shares, and so on.
NOTICE: If you do not use Kick-Start to configure your system, you must disable Kick-Start
immediately. If Kick-Start is enabled, the system logs in automatically as administrator, which
creates a security risk. Kick-Start also takes up system resources by constantly checking for
configuration information. For additional information, see “Disabling the Kick-Start Utility.”
There are several ways to configure your system, depending on whether or not you are using
Dynamic Host Configuration Protocol (DHCP):
• If DHCP is installed on your network, your system automatically configures the
network settings.
• If DHCP is not installed on your network, you can configure your system using a serial
connection or the Dell OpenManage™ Kick-Start utility.

1-4 Introduction
www.dell.com | support.dell.com
Configuring Your System With DHCP
NOTICE: If you do not use Kick-Start to configure your system, you must disable Kick-Start
immediately. If Kick-Start is enabled, the system logs in automatically as administrator, which
creates a security risk. Kick-Start also takes up system resources by constantly checking for
configuration information. For additional information, see "Disabling the Kick-Start Utility."
When the system is powered on for the first time, it invokes the DHCP client to get
parameters (the Internet protocol (IP) address, gateway subnet mask, and domain naming
system (DNS) server address) from a DHCP system. The default system name
(“Dellxxxxxxx”, where xxxxxxx is the system’s service tag number) is entered as the DNS
server name. Connect to the system using Microsoft Internet Explorer 5.0 or later (or for
Red Hat Linux only, use Netscape Navigator 6.0 or later) by entering the system name in
the Web browser.
NOTE: Microsoft Internet Explorer 4.0 may be used only with Windows NT®4.0 with Service
Pack 4 or later. All other browsers are not supported.
If DHCP fails, you need to set the IP address, gateway subnet mask, and DNS server using
either a serial connection or the Kick-Start utility.
You can configure the system using the NAS Manager. The NAS Manager is served on port
1279 and is accessed by the URL,https://<systemname | system_ipaddress>:1279, where
systemname is the DELL<service_tag>. Port 1279 uses secured socket layers (SSL) to
encrypt data going to and coming from the NAS appliance to provide some data security.
NOTICE: Although port 1278 can be used, it uses plain text authentication, which can be a
significant security risk. Therefore, using port 1278 is not recommended.
In a system without a DNS server, you can use Internet Explorer (or for Linux only, use
Netscape 6.0 or later) to search for the default hostname of the system (“Dellxxxxxxx”,
where xxxxxxx is the system’s service tag number).
NOTE: The NAS Manager default administrator user name is administrator and the
default password is powervault.
Configuring Your System Using a Serial Connection
NOTICE: If you do not use Kick-Start to configure your system, you must disable Kick-Start
immediately. If Kick-Start is enabled, the system logs in automatically as administrator, which
creates a security risk. Kick-Start also takes up system resources by constantly checking for
configuration information. For additional information, see “Disabling the Kick-Start Utility.”
NOTE: You must be logged in as Administrator to perform these steps.

Introduction 1-5
On a system running Windows 2000, perform the following steps to connect to the NAS
Manager through the Administration port:
1Connect the serial cable included with your system from the system you are using for
configuration to the administration port (serial port 1) on your system.
2Click the Start button, point to Settings, and then click Control Panel.
3In the Control Panel, click Phone and Modem Options.
4On the Modems tab, click Add for the Add/Remove Hardware Wizard.
5Click the Don't detect my modem; I will select it from a list checkbox and then click
Next.
6In the drop-down menu for Manufacturers, click (Standard Modem Types).
7In the drop-down menu for Models, click Communications cable between two
computers, and then click Next.
8Click the Selected ports radio button, select the appropriate communication port
from the list, and then click Next.
9Click Finish to close the Add/Remove Hardware Wizard, and then click OK to close
the Phone and Modem Options dialog box.
10 On the desktop, right-click My Network Places and click Properties.
11 In the Properties window, double-click Make New Connection.
The Network Connection Wizard displays.
12 Click Next.
13 Select the radio button for Connect Directly To Another Computer and click Next.
14 Select the radio button for Guest and click Next.
15 In the drop-down menu, click the COM port that you are using and then click Next.
16 Click Only for myself and then click Next.
17 Enter the name of the connection and then click Finish.
After you configure your direct serial connection, the Connect Direct Connection
window displays.
18 Click Properties.
19 Click the General tab.
20 Under Select a Device, click Communication cable between two computers.

1-6 Introduction
www.dell.com | support.dell.com
21 Click Configure.
This selection opens the Modem Configuration window.
22 In the Maximum Speed (bps) drop-down menu, click 115200.
23 Click OK to close the Modem Configuration window.
24 Click OK to close the Direct Connection window.
The Connect Direct Connection box prompts you for a user name and password.
25 Enter the user name and password for your system.
26 Click Connect.
This action connects the system you are using for configuration.
27 Start the Web browser on the system you are using to configure the NAS appliance.
28 Type in the name of the PowerVault 750N or 755N system.
The PowerVault NAS Manager displays.
Configuring Your System Using the Kick-Start Utility
The Kick-Start utility is software shipped with your system. This utility is used to define the
initial network configuration of a system, which makes the system available on the network
for complete configuration using the NAS Manager. This utility is intended for customers
who have one or more systems to configure but do not want to use the default DHCP
assigned address and system name.
A NAS appliance requiresconfiguration information before it can function on the web. You
can specify this information locally using the Kick-Start utility installed on the NAS
appliance.
You can also supply configuration information using the Remote Kick-Start utility (a
browser-based Java applet) to save the configuration information on a diskette or send it to
one or more systems across an IP network from another system on the same IP subnet.
NOTE: The system you use to create configuration files must be running Windows 2000 and
have one of the following browsers installed: Microsoft Internet Explorer 5.0 or higher or
Netscape 6.0 or higher. If you use a Netscape browser, you must install the Java plug-in, which
is available at http://java.sun.com/.
NOTE: The Remote Kick-Start utility provides an integrated DHCP service that can supply a
temporary IP address to discovered NAS appliances that you add to your network before
configuring them. If your network already provides DHCP services, the Remote Kick-Start
utility detects this and does not turn on the integrated DHCP service.
