Viking EDFUD141 User manual

Professional Performance for the Home™
®

No matter what the photo spreads in home fashion
magazines would have you believe, the delight of cooking always begets the chore of
cleaning up. The most spectacular meal leaves a stack of dirty dishes in its wake.
But the Viking dishwasher tackles these mundane tasks with style and ease.
The heavy-duty dishwasher silently scours until the last stubborn morsel is gone.
And now this high-powered performance is available in both the bold, commercial look
of the Professional Series and the striking curves of the Designer Series. It may be
a dirty job. But it doesn’t have to look that way.
®

Design flexibility
■ Accepts two design options
• Locally customised panels completely integrate
unit with cabinetry
• Optional Viking door panel in any Professional or
Designer colour finish (see optional accessories)
Quiet, efficient operation
■ Sound-absorbing, heat-retaining insulation
• Heavy asphalt insulation on top, sides, rear, and
bottom of tank
• Top and both sides of tank and inside of door are
quieted by an additional layer of felt
■ Two motor/pump assemblies for more efficient
circulation and drainage than single-motor systems
• Anti-jam, auto-reversing pump
Dishwashers
The triple filtration system leaves
dishes spot-free with its removable
large-objects strainer and
self-cleaning small-objects filter.
Interior design
■ Super-extendible, graphite nylon racks are fully
useable for no lost space
• Taller upper rack with super-stable rack guides
glides out to nearly full extension
• Two dual-level cup racks in upper rack
• Lower rack extends an extra ten centimetres from
tank for easier loading
• Fold-down tines provide space for large items
• Large silverware/cutlery basket includes
special compartment with lid to hold smaller
items in place during washing
■ Accommodates 14 international place settings of
china in a single load
■ Special basket located above upper rack
accommodates knives and long utensils
■ Interior light comes on when door is opened,
allowing better visibility
Washing and drying
■ Superior automatic water-heating system
• 1,800 watt water-heating element guarantees
ample supply of hot water
■ Heating accuracy assured by two separate thermostats
Fully useable graphite nylon racks
offer convenient random loading
without any lost space.

EDFUD141 – shown with optional
Professional door in Burgundy finish
and Brass Trim Option
Integrated controls inside dishwasher provide a smooth outside appearance.

The stainless steel tank and inner
door are completely rustproof and
offer unsurpassed durability.
EDFUD142 – shown with
optional Designer door
in stainless steel finish
The Sani Cycle setting heats the water
to a germ-incinerating 75º C, ensuring
even your dirtiest dishes come
out spotless and sterilised.

■ Multi-level wash system
• Stainless steel lower and upper wash arms turn in
opposite directions for complete water coverage
• Automatic detergent dispenser
• Automatic rinse agent dispenser with fill indicator
■ Triple filtration and waste-removal system
• Separate motor/pump quietly drains dishwasher
• Removable, self-cleaning fine filter captures
smaller particles
• Removable strainer captures large objects,
protecting pump from damage
■ Electronic controls offer several wash cycles as well as
other options designed to reduce energy costs
• Cycles include Pots/Pans, Heavy, Normal,
Light/China, Quick, and Rinse/Hold
• Cycle options include Temp Selection, Extra Dry,
and 5-Hour Delay
• Top/Bottom Rack Only and Express option
■ Temperature options range from 30˚C to 75˚C
depending on cycle
■ All cycles are extremely efficient, with Normal wash
using only 9,9 litres of water and China using only
8 litres of water
■ Convect-Air™ Drying
• Motorised fan extracts moisture from dishes,
utensils, and tank
• Switch-activated vent door opens only during
drying for quieter operation
• Safely vents between door and lower panel –
away from controls and cabinets
Commercial construction and design
■ Extra tall tank and inner door made from rustproof
surgical stainless steel
■ Counterbalanced, heavy-duty door springs for
effortless opening and closing
■ Tough, zinc-coated steel frame and one-piece
galvanised steel base pan
■ Twin fill valve and overflow protection switch
prevents mechanical malfunction overflows
Optional accessories
■ Professional door (PSD24) in any Professional colour
finish; must be ordered separately from dishwasher
■ Designer door (DSD24) in any Designer colour finish;
must be ordered separately from dishwasher
■ Professional (PHK23) and Designer (DHK20) handle
kits in Stainless Steel (SS) or Brass (BR) for use with
custom door panel
Custom door panel
with Professional handle
(may use custom handle)
Designer door panel
in Stainless Steel
Custom door panel
with Designer handle
(may use custom handle)
Professional door panel
in Stainless Steel

Exclusive finishes
■ Professional door panels (PSD24) available in
Stainless Steel (SS), Black (BK), White (WH), Almond (AL),
Biscuit (BT), Stone Gray (SG), Graphite Gray (GG),
Burgundy (BU), Lemonade (LE), Mint Julep (MJ),
Forest Green (FG), Viking Blue (VB), Cobalt Blue (CB),
and Eggplant (EP)
• May be ordered with Brass Trim Option (BR) for
nameplate and door handle/brackets
■ Designer door panels (DSD24) available in
Stainless Steel (SS), Black (BK), White (WH), Biscuit (BT),
Stone Gray (SG), and Graphite Gray (GG)
• May be ordered with Brass Trim Option (BR) for
door handle
■ All brass components have a durable, protective
coating for maintenance-free normal use
■ Viking Range Corporation uses the most up-to-date
processes and best materials available to produce all
colour finishes. However, slight colour variation may be
noticed because of the inherent differences in painted
parts and porcelain parts, as well as differences in room
lighting, product locations, and other factors.
white almond
biscuit
stone gray
graphite gray burgundy
lemonade mint julep
forest green
black
white
viking blue
cobalt eggplant
PROFESSIONAL DESIGNER
biscuit
stone gray
graphite gray
blackstainless steel stainless steel

Basic specifications
EDFUD141
Description 60CM WIDE DISHWASHERS
Overall Width
Overall Height from Floor
Overall Depth from Rear
Cutout Width
Cutout Height
Cutout Depth
Electrical Requirements
Water-Heating Element Rating
Maximum Amp Usage
59,6 cm
82 cm minimum
89,5 cm maximum
57 cm to edge of side (includes drain
hose and door panel)
115,2 cm with door open
60,0 cm
82 cm minimum
87 cm maximum
57 cm
230V/50Hz
10 amps
Performance Class A: Energy A: Cleaning A: Drying
Sound Level 47dB (A)
1,800 watts
Basic water supply data
■ Inlet water temperature – 60°C maximum at the
dishwasher recommended; however, dishwasher will
perform properly with cold water (see 15°C columns
on cycle data chart)
■ Inlet water pressure operating range – 0,3 - 10 bar
■ Unit supplied with 1,65 m PEX water supply line that
has a 3/4 inch NPT female connection
■ Water softener
Basic drain data
■ 2,0 m, 1,9 cm ID “crimp-proof” rubber drain hose with
clamp attached to dishwasher; can be extended up
to a maximum of 3 m with 1,9 cm ID copper tubing
■ High loop of drain hose required
■ Minimum height from floor – 35 cm
■ Maximum height from floor – 95 cm
■ Connect drain hose to drain motor/pump (right front
of dishwasher under lower panel)
■ Check local codes for air gap requirement in drain line
Must be 5,1 cm clearance to side wall if installed in
a corner.
All electrical and plumbing connections must conform
to local codes.
Approximate Shipping Weight 54 kg
EDFUD142
86 cm minimum
93,5 cm maximum
57 cm to edge of side (includes drain
hose and door panel)
119,2 cm with door open
86 cm minimum
87 cm maximum
55 kg

NOTE: Includes time for dry
■ Express option available for Pots/Pans, Heavy, Normal, and Light/China cycles.
■ Reduces washing time and lowers temperature (not available on Quick wash or Rinse/Hold).
Water
Temperature
Description 60CM WIDE DISHWASHER
Pots/Pans
Heavy
Normal
Light/China
Quick
Rinse/Hold
60˚C or 75˚C
Pre-Wash Main Wash Rinse
55˚C or 70˚C
55˚C or 65˚C
40˚C or 50˚C
30˚C or 50˚C
2
2
–
–
–
–
1
1
1
1
1
–
3
3
2
2
2
1
Extra Dry Option
Description
Pots/Pans
Heavy
Normal
Light/China
Quick
Rinse/Hold
Total Water Litre Input Water*
15˚C
Input Water*
60˚C
yes
Total Wash Time – Minutes
yes
yes
yes
no
no
18
18
9,9
9,9
8
3
200
195
165
140
30
4
180
175
150
105
25
4
–
Cycle data
*Using the higher water temperature setting

Notes
©2005, Viking Range Corporation
Specifications subject to change without notice.
