Viking DFSB542 Series User manual

CUSTOM PANEL–REFRIGERATION
Built-In 42”W. Side-By-Side Refri erator/Freezer &
Refri erator/Freezer with Dispenser—DFSB542/542D
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 5 / 1
© 2 1 V R C — INFORMATION SUBJECT TO CHANGE
22-13/16”
(57.9cm)
75-1/2”
(191.8cm)
3/4”
(1.9 cm)
3/4”
(1.9 cm)
18-3/16”
(46.2cm)
22-13/16”
(57.9cm)
75-1/2”
(191.8cm)
3/4”
(1.9cm)
18-3/16”
(46.2cm)
31-5/8”
(80.3cm)
10-11/16”
(27.1cm)
12-3/8”
(31.4cm)
3-5/32”
(8.0cm)
3/4”
(1.9cm)
DFSB542 DFSB542D
DFSB542
Note: Panel overlays must be dry, solid, straight one piece panels. The use of multiple panel pieces to achieve the dimensions is not
recommended.
Dimensions & Specifications
DFSB542/542D
Overall panel width
Refrigerator front 22-13/16” (57.9 cm)
Freezer front 18-3/16” (46.2 cm)
Overall panel height 75-1/2” (191.8 cm)
Overall panel depth 3/4” (1.9 cm)*
Maximum panel weight
Refrigerator front 40 lbs. (18.1 k )
Freezer front 35 lbs. (15.9 k )
*Panel thickne mu t not exceed 1” (2.5 cm) on hinge ide. Thicker panel will interfere with door wing and clearance.
CUSTOM PANEL DIMENSIONS
DFSB542D

CUSTOM PANEL–REFRIGERATION
Built-In 42”W. Side-By-Side Refri erator/Freezer &
Refri erator/Freezer with Dispenser—DFSB542/542D
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 5 / 1
© 2 1 V R C — INFORMATION SUBJECT TO CHANGE
Dimensions & Specifications
DFSB542 DFSB542D
CUSTOM SIDE PANEL DIMENSIONS
Note: Adding a 3/4” (1.9 cm) side panel adds an additional 3/4” (1.9 cm) to the overall width of the product for each side panel.
Re uires side panel hardware kit (Kit model number – SPHKDS)
DFSB542/DFSB542D
Overall panel width 3/4” (1.9 cm)
Overall panel height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.*
Overall panel depth 24” (61.0 cm)
*Depending on how high leveling feet are rai ed and cabinet enclo ure height.
3/4”
(1.9 cm)
End panel
1”
(2.5 cm) 1/4”
(0.6 cm)
Z-Bracket
21-3/4”
(55.2 cm)
21-3/4”
(55.2cm)
24”
(61.0cm)
Optional kickplate notch
Dimensions determined by cabinets
24”
(61.0 cm)
82-7/8”
(210.5cm)min.
to
84-1/16”
(213.5cm)max.*
82-7/8”
(210.5cm) min.
to
84-1/16”
(213.5cm)max.*

CUSTOM PANEL–REFRIGERATION
Built-In 42”W. Side-By-Side Refri erator/Freezer &
Refri erator/Freezer with Dispenser—DFSB542/542D
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 5 / 1
© 2 1 V R C — INFORMATION SUBJECT TO CHANGE
Dimensions & Specifications
DFSB542/542D
Overall grille width 41-1/2” (108.0 cm)
Overall grille height 3” (7.6 cm)
Overall grille depth 3-3/4” (9.5 cm)
1/2”
(1.27cm)
1-1/2”
(3.81cm)
1/4” Radius
(.64 cm)
2-3/4”
(6.98cm)
1/2”
(1.27cm)
3/4”
(1.90cm)
1/2”
(1.27cm)
1/8”
(.31cm)
1/2”
(1.27 cm)
1/4” Radius
1/4” Radius
(1.2cm) (1.2 cm)
1/4” Radius
(.64cm)
Reverse dimensions
for other end.
7/8”
(2.22cm)
1/2”
(1.27 cm)
2-1/8”
(5.39 cm)
3-1/8”
(7.94 cm)
3-5/8”
(9.20cm)
1-3/8”
(3.49cm)
3/8”
(.95cm)
3/8” Radius
3/8” Radius
(.95cm) (.95 cm)
3/8” Radius
(.95cm)
41-1/2”
(105.41cm)
1/2”
(1.27 cm)
3-1/8”
(7.93 cm)
Optional hinge cover
40”
(101.60cm)
40”
(101.60 cm)
3/4”
(1.90 cm)
3/4”
(1.90 cm)
3-1/4”
(9.52cm)
3-3/4”
(9.52 cm)
1/2”
(1.27 cm)
3-5/8”
(9.20cm)
39-15/16”
(101.44cm)
3”
(7.62 cm)
3”
(7.62cm)
3/4”
(1.90cm)
24-27/32”
(63.10 cm)
26-3/16”
(66.51 cm)
5-17/32”
(14.04cm)
4-11/64”
(10.60cm)
2-1/8”
(5.4cm)
DFSB542 DFSB542D
CUSTOM GRILLE DIMENSIONS
