Viking FDSB5481 Series Guide

• Total capacity—27.5 cu. ft. (779 L)
oRefrigerator - 18.5 cu. ft.
oFreezer - 9.0 cu. ft.
o 84”H./24”D.
• ProChill™ Temperature Management
System
oVariable-spee DC Over rive™
Compressor is one of the quietest,
most technologically a vance com-
pressors available
oElectronic controls with igital tem-
perature rea outs
oMulti-channel airflow system an
O or Eliminator™ Evaporator
removes o ors an excess humi ity
•Exclusive Plasmacluster™* Ion Air
Purifier
oEliminates airborne bacteria an
mol spores
oRemoves o ors
oEnhances foo preservation
oNever nee s replacing
• Refrigerator Compartment
oFour a justable tempere glass
spillproof shelves
• A justable Col Zone™ rawer with
precision ball-bearing gli es
oSeparate temperature control can be
set for pro uce or fresh meat storage
oQuick chill option chills foo s an
beverages in minutes
• A justable Humi ity Zone™ rawers
with precision ball-bearing gli es
oHumi ity can be set high for leafy
greens or low for fruits an vegeta-
bles with skins
oTwo in-the- oor seale airy com-
partments with covers
oFour patente a justable aluminum
oor bins with tempere glass fronts
oTop shelf provi es quick chill- own
area
• Freezer Compartment
oA aptive efrost
oThree wire shelves an two sli e-out
baskets
oThree patente a justable alu-
minum oor bins with tempere
glass fronts
• Super Clog-Resistant™ Con enser is
maintenance-free un er normal use
• Tru-Flush™ esign allows all mo els to
fit flush into 24” eep installation
cutout
• Open oor alarm soun s an glows to
warn that oor has been ajar for three
minutes
• A justable oor stops stan ar —90°,
110°, or 120° swing
• Sabbath Mo e
*Plasmacluster is a registere tra emark
of Sharp Corporation.
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
All models include
FINISH DETAILS FOR VCSB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Apple Re (AR), Biscuit (BT),
Burgun y (BU), Chocolate (CH),
Cinnamon (CN), Cobalt Blue (CB),
Cotton White (CW), Dijon (DJ),
Graphite Gray (GG), Iri escent Blue
(IB), Kettle Black (KB), Lemona e (LE),
Mint Julep (MJ), Plum (PL), Racing Re
(RR), Sage (SA), Sea Glass (SE), Stone
Gray (SG), Taupe (TP), Viking Blue (VB),
Wasabi (WS).
• Finish co es esignate oor fronts.
Stainless steel upper grille, si e trim,
an han les (with chrome-plate brack-
ets); black lower kickplate.
• Brass Accent Option (BR)—nameplate
an han le en caps. Brass components
have a urable protective coating for
maintenance-free normal use.
Standard Features & Accessories
Model Options
VCSB 481
Professional
ORDERING INSTRUCTIONS
First specify mo el number, an then color co e (VCSB5481SS). If or ering optional brass accent, specify co e at en (VCSB5481SSBR).
FINISH DETAILS FOR FDSB MODEL
• Han les not inclu e —opt for custom
han les, or purchase a Viking
Professional Series han le kit (see
Installation Notes & Accessories).
• See Custom Panels section for
more information an a itional
specifications.
FDSB 481
Custom Panel

✪
Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel an
han le kits.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
22-3/16”
(56.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
3-19/32”
(9.1cm)
48”
(121.9cm)
26-1/2”
(67.3 cm)
47”
(119.4cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
23-3/8”
(59.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
48”
(121.9cm)
26-1/2”
(67.3cm)
47”
(119.4cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
3-19/32”
(9.1cm)
VCSB5481 VCSB5481/Flush Mount
Overall width 48” (121.9 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To fro t edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm)
To fro t of top grille 24” (61.0 cm) 24” (61.0 cm)
To fro t of ha dle 26-1/2” (67.3 cm) 26-1/2” (67.3 cm)
Approx. ship weight 715 lbs. (321.8 kg)
VCSB 481
Professional
Dimensions & Speci ications
PRODUCT DIMENSIONS
PROFESSIONAL
WITH FLUSH
MOUNT TRIM
PROFESSIONAL

23-13/16”
(60.5cm)
24-3/4”
(62.9cm)
75-15/16”
(192.9cm)
48”
(121.9cm)
48”
(121.9cm)
47”
(119.4cm)
82-3/4”
(210.2cm)
Min.
to
84-1/16”
(213.5cm)
max.
Varies
3-1/2”
(8.9cm)
CUSTOM PANEL
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
✪
Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel an
han le kits.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
FDSB5481
Overall width 48” (121.9 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To fro t edge of side trim 23-3/16” (60.5 cm)
To fro t of top grille 24-3/4” (62.9 cm)
To fro t of ha dle Varies
Approx. ship weight 650 lbs. (292.5 kg)
FDSB 481
Custom Panel
See Custom Panels section for
more information an a itional
specifications.
Dimensions & Speci ications
PRODUCT DIMENSIONS

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
7-3/8”
(18.7 cm)
1-27/32”
(4.7 cm)
9-13/16”
(25.0 cm)
24-3/32”
(61.2 cm)
39-15/16”
(101.4cm)
41-27/32”
(106.3cm)
47”
(119.4cm)
48-11/32”
(122.8cm)
10-21/32”
(27.1cm)
1-27/32”
(4.7cm)
14-5/8”
(37.2cm)
51-7/16”
(130.7cm)
50-3/16”
(127.5cm)
48”
(121.9cm)
41-3/32”
(104.4cm)
90°
110°
120°
90°
110°
120°
2-1/2” (6.4 cm)
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
See Custom Panels section for
more information an a itional
specifications.
PROFESSIONAL
Dimensions & Speci ications
DOOR SWING
• A justable oor stops stan ar —90°, 110°, or 120° swing
VCSB 481
Professional
FDSB 481
Custom Panel

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
Door
Wall
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(61.0 cm)
standard
cabinet
depth
1-3/4”
(4.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
1-3/4”
(4.4 cm) offset
Countertop
overhang
Dimensions & Speci ications
CLEARANCE DIMENSIONS—PROFESSIONAL
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
1-3/4”
(4.4 cm) offset
Partial overlay
cabinet door
TOP VIEW
TOP VIEW
TOP VIEW

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
Door
24”
(61.0 cm)
standard
cabinet
depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Dimensions & Speci ications
CLEARANCE DIMENSIONS—PROFESSIONAL WITH FLUSH MOUNT TRIM
Door
24”
(61.0cm)
standard
cabinet
depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
3/4”
(1.9 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Cabinet
door
TOP VIEW
TOP VIEW
TOP VIEW
Overlappi g cabi et doors

Anti-tipboard
6”
(15.2cm)
9”
(22.9cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
47-5/8”min.
(121.0cm)
to
47-3/4”max.
(121.3cm)
Professional
48”
(121.9cm)
FlushMountOnly
24”*
(61.0cm)min.
ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
1”
(2.5cm)
3-5/8”
(9.2cm)
Optionalfloor
waterlineentry
9”
(22.9cm)
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cor
with groun e
three-prong plug
attache to
pro uct
• 115 VAC/60 Hz;
15 amp e icat-
e circuit
• Maximum amp
usage—9.9
• Estimate
energy usage—
670 kWh/year
PLUMBING
• Inlet waterline
requirements—
1/4”copper
tubing
• 20 psi min.;
120 psi max.
Installation Requirements
ACCESS REQUIREMENTS
VCSB5481 VCSB5481/Flush Mount FDSB5481
Cutout width 47-5/8” (121.0 cm) mi . to 48” (121.9 cm) 48” (121.9 cm)
47-3/4” (121.3 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
*Custom pa el models fit flush i 25”-deep (63.5 cm)
cabi et ope i gs. They ca be i stalled i sta dard
24”-deep ope i gs. The door faces a d top grille
will protrude 3/4” (1.9 cm) i to the room.
See Custom Panels section for
more information an a itional
specifications.
VCSB 481
Professional
FDSB 481
Custom Panel

REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Side Panel Kits
• Stainless Steel (SS)
• Panels provi e finishe , freestan ing look; unit must still be secure to the wall
•Kit inclu es one panel an installation har ware
Side Panel Hardware Kit
• For use with custom panel built-in refrigerator/freezers
• Har ware allows installation of custom si e panels
• Kit inclu es brackets, screws, an installation instructions to mount panels on left an right si e
Top Panel Kit
• Stainless Steel (SS)
• Panel provi es finishe , freestan ing look; unit must still be secure to the wall
• Kit inclu es one panel an installation har ware
Handle Kits
• For use with custom panel refrigerator/freezers
• For use on locally supplie custom panels
• Han les allow refrigerator/freezers with custom panels to coor inate with other Professional pro ucts
• Kit inclu es two han les an installation har ware
Compliance In ormation
WARRANTY SUMMARY*
• Three-year full warranty—complete unit
• Six-year full warranty—seale refrigeration system
• Twelve-year limite warranty—seale refrigeration system (inclu es compressor, con enser,
ryer/strainer, evaporator, an connecting tubing)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items
*For complete warranty see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PSSPL2 Professio al side pa el left - Sta dard Mou t 45 (20.2)
PSSPR2 Professio al side pa el right - Sta dard Mou t 45 (20.2)
DSSPL2 Desig er side pa el left - Flush Mou t 45 (20.2)
DSSPR2 Desig er side pa el right - Flush Mou t 45 (20.2)
Model Description Approx. ship wt. lbs. (kg)
PHK-DFSB5-SS Professio al ha dles (Stai less Steel) 10 (4.5)
Model Description Approx. ship wt. lbs. (kg)
TOP-48 48”W. top pa el 24 (10.8)
Model Description Approx. ship wt. lbs. (kg)
SPHKDS Side pa el hardware 3 (1.4)
