Viking Professional VIBB536R User manual

REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
All models include
• Total capacity—20.3 cu. ft. (574.5 L)
oRefrigerator - 15.2 cu. ft.
oFreezer - 5.1 cu. ft.
o84”H./24”D.
• ProChill™ Temperature
Management System
oVariable-speed DC Overdrive™
Compressor is one of the quietest,
most technologically advanced com-
pressors available
oElectronic controls maintain the tem-
perature selection within 1ºF
oMulti-channel airflow system and
Odor Eliminator™ Evaporator
removes odors and excess humidity
•Exclusive Plasmacluster™* Ion Air
Purifier
oEliminates airborne bacteria and
mold spores
oRemoves odors
oEnhances food preservation
oNever needs replacing
• Refrigerator Compartment
oFive adjustable tempered glass spill-
proof shelves
• Adjustable Cold Zone™ drawer with
precision ball-bearing glides
oSeparate temperature control can be
set for produce or fresh meat storage
oQuick chill option chills foods and
beverages in minutes
• Adjustable Humidity Zone™ drawers
with precision ball-bearing glides
oHumidity can be set high for leafy
greens or low for fruits and vegeta-
bles with skins
• Two conveniently located deli drawers
with full-extension precision ball-bear-
ing glides
• Two in-the-door sealed dairy
compartments with covers
• Four patented adjustable aluminum
door bins with tempered glass fronts
• Top-shelf provides quick chill-down
area
• Full extension freezer drawer on preci-
sion ball-bearing glides
oPositive self-closing feature ensures a
good seal
oAdaptive defrost
oTwo slide-out wire baskets
• Super Clog-Resistant™ Condenser is
maintenance-free under normal use
• Tru-Flush™ design
oAllows Professional Integrated and
Custom Panel models to fit flush into
24” deep installation cutout
• Open door alarm sounds and glows to
warn that door has been ajar for three
minutes
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
• Must be ordered right or left hinge.
(As you face unit, RIGHT has hinge on
right side and handle on left side;
LEFT has hinge on left side and han-
dle on right side.)
*Plasmacluster is a registered trademark
of Sharp Corporation.
VCBB536/VIBB536
Professional/Professional
Integrated
FINISH DETAILS FOR DFBB MODEL
• Handles not included—opt for custom
handles, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for
more information and additional
specifications.
FINISH DETAILS FOR VCBB/VIBB MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles (with chrome-plated
brackets); black lower kickplate.
• Brass Trim Option (BR)—nameplate,
handle/brackets, and side trim. Brass
components have a durable protective
coating for maintenance-free normal
use.
DFBB536
Custom Front
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify model number, followed by hinge preference (“R” for right or “L” for left), and then color code (VCBB536RSS).
If ordering optional brass trim, specify code at end (VCBB536RSSBR).

VCBB536/VIBB536
Professional/Professional
Integrated
REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
!
Please see
Installation Notes &
Accessories
for important
information,
including panel,
grille, and handle
kits.
36”
(91.4cm)
22-3/16”
(56.4cm)
24-11/16”
(62.7cm)
27-1/4”
(69.2cm)
35”
(88.9cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
79-17/32”
(202cm)
52”
(132.1cm)
3-19/32”
(9.1cm)
23-1/16”
(58.5cm)
36”
(91.4cm)
23-3/8”
(59.4cm)
24”
(61.0cm)
26-1/2”
(67.3cm)
35”
(88.9cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
79-17/32”
(202cm)
52”
(132.1cm)
3-19/32”
(9.1cm)
23-1/16”
(58.5cm)
VCBB536 VIBB536
Overall width 36” (91.4 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm)
To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm)
To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)
Approx. ship weight 565 lbs. (254.3 kg)
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Specifications
PRODUCT DIMENSIONS
PROFESSIONAL PROFESSIONAL
INTEGRATED
ALL MODELS

35”
(88.9cm)
82-7/8”
(210.5cm)
min.
to
84-1/16”
(213.5cm)
max.
23-13/16”
(60.5cm)
24-3/4”
(62.9cm)
79-17/32”
(202cm)
52”
(132.1cm)
3-1/2”
(8.9cm)
23-1/16”
(58.5cm)
36”
(91.4cm)
Varies
CUSTOM FRONT
REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
DFBB536
Custom Front
!
Please see
Installation Notes &
Accessories
for important
information,
including panel,
grille, and handle
kits.
DFBB536
Overall width 36” (91.4 cm)
Overall height (from bottom) 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 23-13/16” (60.5 cm)
To front of top grille 24-3/4” (62.9 cm)
To front of handle Varies
Approx. ship weight 500 lbs. (227.3 kg)
See Custom Panels section for
more information and additional
specifications.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Specifications
PRODUCT DIMENSIONS
ALL MODELS

REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
VCBB536/VIBB536
Professional/Professional
Integrated
DFBB536
Custom Front
22--11//22””
((66..44ccmm))
5588--1111//3322””
((114488..22ccmm))
2244--1111//1166””
((6622..77ccmm))
5566--55//88””
((114433..88ccmm))
5544--77//3322””
((113377..77ccmm)
1
144””
((3355..66ccmm))
3366””
((9911..44ccmm))
3355””
((8888..99ccmm))
1188--2299//3322””
((4488..00ccmm))
33--11//3322””
((77..77ccmm))
112200..0000
111100..0000
9900..0000
2244””
((6611..00ccmm))
3366””
((9911..44ccmm))
3355””
((8888..99ccmm))
2-1/2” (6.4 cm)
Professional Integrated
5588--33//88””
((114488..33ccmm))
5566--1111//1166””
((114444..00ccmm))
5544--99//3322””
((113377..99ccmm)
1133--11//88””
((3333..33ccmm))
1188--33//1166””
((4466..22ccmm))
11--2277//3322””
((44..77ccmm))
112200..0000
111100..0000
9900..0000
PROFESSIONAL
PROFESSIONAL INTEGRATED
Dimensions & Specifications
See Custom Panels section for
more information and additional
specifications.
DOOR SWING
• Adjustable door stops standard—90°, 110°, or 120° swing

REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Door
Wall
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(61.0 cm)
standard
cabinet
depth
2-1/2”
(6.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Countertop
overhang
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Partial overlay
cabinet door
TOP VIEW
TOP VIEW
TOP VIEW

REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED
Door
24”
(61.0 cm)
standard
cabinet depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Door
24”
(61.0 cm)
standard
cabinet
depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
3/4”
(1.9 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Cabinet
door
TOP VIEW
TOP VIEW
TOP VIEW
Overlapping cabinet doors

Anti-tipboard
6”
(15.2cm)
9”
(22.9cm)
9”
(22.9cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
35-1/2”
(90.2cm)min.
to
35-3/4”
(90.8cm)min.
Professional
24”*
(61.0cm)min.
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
1”
(2.5cm)
3-5/8”
(9.2cm)
Optionalfloor
waterlineentry
36”
(91.4 cm)
ProfessionalIntegrated/
CustomFront
VCBB536/VIBB536
Professional/Professional
Integrated
DFBB536
Custom Front
See Custom Panels section for
more information and additional
specifications.
REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cord
with grounded
three-prong plug
attached to
product
• 115 VAC/60 Hz;
15 amp dedicated
circuit
• Maximum amp
usage—9.9
• Estimated
energy usage—
567 kWh/year
PLUMBING
• Inlet waterline
requirements—
1/4”copper
tubing
• 20 psi min.;
120 psi max.
Installation Requirements
ACCESS REQUIREMENTS
VCBB536 VIBB536 DFBB536
Cutout width 35-1/2” (90.2 cm) min. to 36” (91.4 cm) 36” (91.4 cm)
35-3/4” (90.8 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
*Custom front models fit flush in 25”-deep (63.5 cm)
cabinet openings. They can be installed in standard
24”-deep openings. The door faces and top grille
will protrude 3/4” (1.9 cm) into the room.

REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
9”
(22.9cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
71-1/2”
(181.6cm)
Professional
72”
(182.9cm)
ProfessionalIntegrated/
CustomFront
24”*
(61.0cm)
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
3-5/8”
(9.2cm)
Optionalfloor
water lineentry
1”
(2.5cm)
Seeanti-tipboardinstallation
6”
(15.2cm)
9”
(22.9cm)
Installation Requirements
VCBB536/VCBB536 VIBB536/VIBB536 DFBB536/DFBB536
Cutout width 71-1/2” (181.6 cm) 72” (182.9 cm) 72” (182.9 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
36”W./36”W. REFRIGERATOR/
FREEZER BOTTOM MOUNT
COMBINATION
ACCESS REQUIREMENTS – Dual Installation
ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
*Custom front models fit flush in 25”-deep (63.5 cm) cabinet openings. They can be installed in standard 24”-deep openings. The
door faces and top grille will protrude 3/4” (1.9 cm) into the room.

R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Side Panel Kits
• Stainless Steel (SS)
• Panels provide finished, freestanding look; unit must still be secured to the wall
•Kit includes one panel and installation hardware
Side Panel Hardware Kit
• For use with Designer built-in refrigerator/freezers
• Hardware allows installation of custom side panels
• Kit includes brackets, screws, and installation instructions to mount panels on left and right side
Top Panel Kit
• Stainless Steel (SS)
• Panel provides finished, freestanding look; unit must still be secured to the wall
• Kit includes one panel and installation hardware
Top Grille Kits
• Stainless Steel (SS)
• For use with installation of two 36”W. bottom-mount refrigerator/freezers
• Grille creates a single unit look
• Kit includes one full-length grille, center cabinet trim connector, and grill installation hardware
Handle Kits
• For use with custom front refrigerator/freezers
• For use on locally supplied custom front panels
• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products
• Kit includes two handles and installation hardware
Compliance Information
WARRANTY SUMMARY*
• Two-year full warranty—complete unit
• Six-year full warranty—sealed refrigeration system and automatic ice maker
• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,
dryer/strainer, evaporator, and connecting tubing)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items
* For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
Model Description Approx. ship wt. lbs. (kg)
PHK-DFBB-SS Professional handles (Stainless Steel) 10 (4.5)
PHK-DFBB-BR Professional handles (Brass) 10 (4.5)
HKFDS-SS Designer handles (Stainless Steel) 10 (4.5)
HKFDS-BR Designer handles (Brass) 10 (4.5)
REFRIGERATION
Quiet Cool™ Built-In 36”W. Bottom-Mount
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
!Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PSSPL3 Professional side panel left (VCBB) 45 (20.2)
PSSPR3 Professional side panel right (VCBB) 45 (20.2)
DSSPL3 Designer side panel left (VIBB/DFBB) 45 (20.2)
DSSPR3 Designer side panel right (VIBB/DFBB) 45 (20.2)
Model Description Approx. ship wt. lbs. (kg)
PBRTGK72-SS Professional 72”W. grille (for two VCBB units) 25 (11.3)
DBRTGK72-SS Designer 72”W. grille (for two DFBB units) 25 (11.3)
Model Description Approx. ship wt. lbs. (kg)
TOP-36 36”W. top panel 22 (10.0)
Model Description Approx. ship wt. lbs. (kg)
SPHKDS Side panel hardware kit 3 (1.4)

FINISH DETAILS FOR VCSB/VISB MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles (with chrome-plated
brackets); black lower kickplate.
• Brass Trim Option (BR)—nameplate,
handle/brackets, side trim. Brass com-
ponents have a durable protective
coating for maintenance-free normal
use.
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Model Options
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
All models include
• Total capacity—24.0 cu. ft. (679.7 L)
oRefrigerator - 15.0 cu. ft.
oFreezer - 9.0 cu. ft.
o84”H./24”D.
• ProChill™ Temperature Management
System
oVariable-speed DC Overdrive™
Compressor is one of the quietest,
most technologically advanced com-
pressors available
oElectronic controls maintain the tem-
perature selection within 1ºF
oMulti-channel airflow system and
Odor Eliminator™ Evaporator
removes odors and excess humidity
•Exclusive Plasmacluster™* Ion Air
Purifier
oEliminates airborne bacteria and
mold spores
oRemoves odors
oEnhances food preservation
oNever needs replacing
• Refrigerator Compartment
oFour adjustable tempered glass spill-
proof shelves
• Adjustable Cold Zone™ drawer with
precision ball-bearing glides
oSeparate temperature control can be
set for produce or fresh meat storage
oQuick chill option chills foods and
beverages in minutes
• Adjustable Humidity Zone™ drawers
with precision ball-bearing glides
oHumidity can be set high for leafy
greens or low for fruits and vegeta-
bles with skins
• Two in-the-door sealed dairy
compartments with covers
• Four patented adjustable aluminum
door bins with tempered glass fronts
• Top-shelf provides quick chill-down
area
• Freezer Compartment
oAdaptive defrost
oThree wire shelves and two slide-out
baskets
oThree patented adjustable alu-
minum door bins with tempered
glass fronts
• Super Clog-Resistant™ Condenser is
maintenance-free under normal use
• Tru-Flush™ design
oAllows Professional Integrated and
Custom Panel models to fit flush into
24” deep installation cutout
• Open door alarm sounds and glows
to warn that door has been ajar for
three minutes
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
*Plasmacluster is a registered trademark
of Sharp Corporation.
VCSB542/VISB542
Professional/Professional
Integrated
FINISH DETAILS FOR DFSB MODEL
• Handles not included—opt for custom
handles, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for
more information and additional
specifications.
DFSB542
Custom Front
Standard Features & Accessories
ORDERING INSTRUCTIONS
First specify model number, and then color code (VCSB542SS). If ordering optional brass trim, specify code at end (VCSB542SSBR).

!
Please see
Installation Notes &
Accessories
for important
information,
including panel and
handle kits.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
22-3/16”
(56.4cm)
24-11/16”
(62.7cm)
3-19/32”
(9.1cm)
42”
(106.7cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
27-1/4”
(69.2cm)
23-3/8”
(59.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
3-19/32”
(9.1cm)
42”
(106.7cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
26-1/2”
(67.3cm)
PROFESSIONAL
INTEGRATED
VCSB542 VISB542
Overall width 42” (106.7 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm)
To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm)
To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)
Approx. ship weight 652 lbs. (293.4 kg)
VCSB542/VISB542
Professional/Professional
Integrated
Dimensions & Specifications
PRODUCT DIMENSIONS
PROFESSIONAL

24-3/4”
(62.9cm)
75-15/16”
(192.9cm)
3-1/2”
(8.9cm)
42”
(106.7cm)
41”
(104.1cm)
Varies
23-13/16”
(60.5cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
CUSTOM FRONT
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
!
Please see
Installation Notes &
Accessories
for important
information,
including panel and
handle kits.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
DFSB542
Overall width 42” (106.7 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 23-13/16” (60.5 cm)
To front of top grille 24-3/4” (62.9 cm)
To front of handle Varies
Approx. ship weight 525 lbs. (236.2 kg)
DFSB542
Custom Front
See Custom Panels section for
more information and additional
specifications.
Dimensions & Specifications
PRODUCT DIMENSIONS

VCSB542/VISB542
Professional/Professional
Integrated
DFSB542
Custom Front
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
42”
(106.7 cm)
41-5/16”
(104.9 cm)
24-23/32”
(62.8 cm)
2-1/2”
(6.4 cm)
40-19/32”
(103.1 cm)
39-15/32”
(100.3 cm)
43-1/2”
(110.5 cm)
45”
(114.3 cm)
45-31/32”
(116.8 cm)
10-19/32”
(26.3 cm)
12-21/32”
(32.1 cm)
9-1/16”
(24.6 cm)
8-1/8”
(20.6 cm)
41” (104.1 cm)
3”
(7.6 cm)
41”
(104.1 cm)
3”
(7.6 cm)
90° 90°
110° 110°
120° 120°
PROFESSIONAL
See Custom Panels section for
more information and additional
specifications.
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
41-5/16”
(105.0 cm)
24”
(61.0 cm)
39-15/32”
(100.3 cm)
40-19/32”
(103.1 cm)
43-1/2”
(110.5 cm)
44-31/32”
(114.3 cm)
45-31/32”
(116.8 cm)
9-1/2”
(24.1 cm)
7-5/32”
(18.2 cm)
1-27/32”
(4.7 cm)
11-27/32”
(30.1 cm)
8-3/4”
(22.2 cm)
1-27/32”
(4.7 cm)
90° 90°
110° 110°
120° 120°
42”
(106.7 cm)
41”
(104.1 cm)
2-1/2” (6.4 cm)
Professional Integrated
PROFESSIONAL INTEGRATED
Dimensions & Specifications
DOOR SWING
• Adjustable door stops standard—90°, 110°, or 120° swing

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL
Door
Wall
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(61.0 cm)
standard
cabinet
depth
2-1/2”
(6.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Countertop
overhang
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Partial overlay
cabinet door
TOP VIEW
TOP VIEW
TOP VIEW

REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
Door
24”
(61.0 cm)
standard
cabinet depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Door
24”
(61.0 cm)
standard
cabinet
depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
3/4”
(1.9 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Cabinet
door
TOP VIEW
TOP VIEW
TOP VIEW
Overlapping cabinet doors

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Anti-tipboard
6”
(15.2cm)
9”
(22.9cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
24”*
(61.0cm)min.
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7 cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
1”
(2.5cm)
3-5/8”
(9.2cm)
Optionalfloor
water lineentry
9”
(22.9cm)
41-1/2”
(105.4cm)min.
to
41-3/4”
(106.0cm)min.
Professional
42”
(106.7cm)
ProfessionalIntegrated/
CustomFront
VCSB542/VISB542
Professional/Professional
Integrated
DFSB542
Custom Front
See Custom Panels section for
more information and additional
specifications.
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cord
with
grounded
three-prong plug
attached to
product
• 115 VAC/60 Hz;
15 amp dedicat-
ed circuit
• Maximum amp
usage—9.9
• Estimated
energy usage—
653 kWh/year
PLUMBING
• Inlet waterline
requirements—
1/4”copper
tubing
• 20 psi min.;
120 psi max.
Installation Requirements
ACCESS REQUIREMENTS
VCSB542 VISB542 DFSB542
Cutout width 41-1/2” (105.4 cm) min. to 42” (106.7 cm) 42” (106.7 cm)
41-3/4” (106.0 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
*Custom front models fit flush in 25”-deep (63.5 cm)
cabinet openings. They can be installed in standard
24”-deep openings. The door faces and top grille
will protrude 3/4” (1.9 cm) into the room.

Side Panel Kits
• Stainless Steel (SS)
• Panels provide finished, freestanding look; unit must still be secured to the wall
•Kit includes one panel and installation hardware
Side Panel Hardware Kit
• For use with Designer built-in refrigerator/freezers
• Hardware allows installation of custom side panels
• Kit includes brackets, screws, and installation instructions to mount panels on left and right side
Top Panel Kit
• Stainless Steel (SS)
• Panel provides finished, freestanding look; unit must still be secured to the wall
• Kit includes one panel and installation hardware
Handle Kits
• For use with custom front refrigerator/freezers
• For use on locally supplied custom front panels
• Handles allow refrigerator/freezers with custom front panel to coordinate with other Professional and Designer products
• Kit includes two handles and installation hardware
Compliance Information
WARRANTY SUMMARY*
• Two-year full warranty—complete unit
• Six-year full warranty—sealed refrigeration system and automatic ice maker
• Twelve-year limited warranty—sealed refrigeration system (includes compressor, condenser,
dryer/strainer, evaporator, and connecting tubing)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer
!Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5)
PHK-DFSB5-BR Professional handles (Brass) 10 (4.5)
HKFDS-SS Designer handles (Stainless Steel) 10 (4.5)
HKFDS-BR Designer handles (Brass) 10 (4.5)
Model Description Approx. ship wt. lbs. (kg)
PSSPL2 Professional side panel left (VCSB) 45 (20.2)
PSSPR2 Professional side panel right (VCSB) 45 (20.2)
DSSPL2 Designer side panel left (VISB/DFSB) 45 (20.2)
DSSPR2 Designer side panel right (VISB/DFSB) 45 (20.2)
Model Description Approx. ship wt. lbs. (kg)
TOP-42 42”W. top panel 23 (10.4)
Model Description Approx. ship wt. lbs. (kg)
SPHKDS Side panel hardware 3 (1.4)

FINISH DETAILS FOR VCSB/VISB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
• Finish codes designate door fronts.
Stainless steel upper grille, side trim,
and handles (with chrome-plated
brackets); black lower kickplate.
• Brass Trim Option (BR)—nameplate,
handle/brackets, and side trim. Brass
components have a durable protective
coating for maintenance-free normal
use.
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
Model Options
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
All models include
• Total capacity—23.6 cu. ft. (667.9 L)
oRefrigerator - 15.0 cu. ft.
oFreezer - 8.6 cu. ft.
o 84”H./24”D.
• ProChill™ Temperature Management
System
oVariable-speed DC Overdrive™
Compressor is one of the quietest,
most technologically advanced com-
pressors available
oElectronic controls maintain the tem-
perature selection within 1ºF
oMulti-channel airflow system and
Odor Eliminator™ Evaporator
removes odors and excess humidity
•Exclusive Plasmacluster™* Ion Air
Purifier
oEliminates airborne bacteria and
mold spores
oRemoves odors
oEnhances food preservation
oNever needs replacing
• Refrigerator Compartment
oFour adjustable tempered glass
spillproof shelves
• Adjustable Cold Zone™ drawer with
precision ball-bearing glides
oSeparate temperature control can be
set for produce or fresh meat storage
oQuick chill option chills foods and
beverages in minutes
• Adjustable Humidity Zone™ drawers
with precision ball-bearing glides
oHumidity can be set high for leafy
greens or low for fruits and vegeta-
bles with skins
• Two in-the-door sealed dairy
compartments with covers
• Four patented adjustable aluminum
door bins with tempered glass fronts
• Top-shelf provides quick chill-down
area
• Freezer Compartment
oAdaptive defrost
oThree wire shelves and two slide-out
baskets
oThree patented adjustable alu-
minum door bins with tempered
glass fronts
• Ice/Water Dispenser
oThrough-the-door dispenser
provides cubed ice, crushed ice and
water in easy on-hand operation
oPremium water filter provides clean-
er water and ice supply by filtering
bad tastes, odors, sediment and
harmful contaminants.
• Super Clog-Resistant™ Condenser is
maintenance-free under normal use
• Tru-Flush™ design
oAllows Professional Integrated and
Custom Panel models to fit flush into
24” deep installation cutout
• Open door alarm sounds and glows to
warn that door has been ajar for three
minutes
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
*Plasmacluster is a registered trademark
of Sharp Corporation.
FINISH DETAILS FOR DFSB MODEL
• Handles not included—opt for custom
handles, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for
more information and additional
specifications.
Standard Features & Accessories
ORDERING INSTRUCTIONS
First specify model number, and then color code (VCSB542DSS). If ordering optional brass trim, specify code at end (VCSB542DSSBR).
VCSB542D/VISB542D
Professional/Professional
Integrated
DFSB542D
Custom Front

!
Please see
Installation Notes &
Accessories
for important
information,
including panel and
handle kits, and
water filters.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
22-3/16”
(56.4cm)
24-11/16”
(62.7cm)
75-15/16”
(192.9cm)
3-19/32”
(9.1cm)
42”
(106.7cm)
27-1/4”
(69.2cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
23-3/8”
(59.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
42”
(106.7cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
26-1/2”
(67.3cm)
3-19/32”
(9.1cm)
PROFESSIONAL PROFESSIONAL
INTEGRATED
VCSB542D VISB542D
Overall width 42” (106.7 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 22-3/16” (56.4 cm) 23-3/8” (59.4 cm)
To front of top grille 24-11/16” (62.7 cm) 24” (61.0 cm)
To front of handle 27-1/4” (69.2 cm) 26-1/2” (67.3 cm)
Approx. ship weight 676 lbs. (304.2 kg)
VCSB542D/VISB542D
Professional/Professional
Integrated
Dimensions & Specifications
PRODUCT DIMENSIONS

23-13/16”
(60.5cm)
24-3/4”
(62.9cm)
75-15/16”
(192.9cm)
42”
(106.7cm)
41”
(104.1cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
Varies
3-1/2”
(8.9cm)
CUSTOM FRONT
REFRIGERATION
Quiet Cool™ Built-In 42”W. Side-By-Side
Refrigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E L E A S E D 3 / 1 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
!
Please see
Installation Notes &
Accessories
for important
information,
including panel and
handle kits, and
water filters.
Star-K Kosher
Certification for
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
DFSB542D
Overall width 42” (106.7 cm)
Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (from rear)
To front edge of side trim 23-13/16” (60.5 cm)
To front of top grille 24-3/4” (62.9 cm)
To front of handle Varies
Approx. ship weight 525 lbs. (236.2 kg)
DFSB542D
Custom Front
See Custom Panels section for
more information and additional
specifications.
Dimensions & Specifications
PRODUCT DIMENSIONS
