Viking DTWN3048SS User manual

VENTILATION
Desi ner Built-In Wall Hoods
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
All models include
Standard Features & Accessories
*Shown throughout with a justable uct cover, inclu e .
**Shown throughout with uct cover, sol separately.
See Installat on Notes & Accessor es for uct cover mo el numbers an ship weights.
ORDERING INSTRUCTIONS
First specify mo el number, followe by color co e (DTWS3049SS). Specify ecorative rail co e at en (DTWS3049SSCR).
• Must also purchase interior or exterior
ventilator kit, sol separately (see
Installat on Notes & Accessor es for
recommen e Viking ventilator
pro ucts
• 24”D.(tests show 24”D. hoo s
perform properly over 27”D. ranges)
• Heat sensor turns the ventilator on full
power when cooking temperatures
reach uncomfortable levels
• Variable spee controls for custom
venting—separate on/off switch allows
you to leave ventilator at
favorite/most-use setting
• 12-hour timer built into ventilator
controls
• Delay feature allows you to set the
ventilator to shut off on its own from
10 – 30 minutes later
• Heavy- uty construction; elegant
esign, an styling
o Virtually seamless stainless steel
esign with no visible screws
• Easy cleanup
o Dishwasher-safe, stainless steel
mesh filters efficiently remove
grease an heate vapors from the
air, an are easily remove for quick
cleaning (frame an mesh are
stainless steel for urability an long
life)
•See D mens ons & Spec f cat ons
table for number of filters (an
spacers) per mo el
o Design of low-profile filter system
means less interior hoo space to
be cleane
o Canopy interior is completely line
in stainless steel for increase
rigi ity, seamless appearance, an
easy cleaning
• 50-watt halogen lights with immer
control
o Power switch an immer control
are separate, allowing you to leave
immer at favorite position
o See D mens ons & Spec f cat ons
table for number of lights per mo el
DTWS models include
• 9"H.
• A justable uct cover (for 8 – 9’
ceilings) shippe stan ar (see
D mens ons & Spec f cat ons table)
o Finish matches canopy exterior
DTWN models include
• 18"H.
• Duct covers must be or ere
separately (see Installat on Notes &
Accessor es)
Model numbers
SLIM TRADITIONAL WALL HOODS
• DTWS3049—30"W.
• DTWS3649—36"W.
• DTWS4249—42"W.
• DTWS4849—48"W.
TALL TRADITIONAL LEGDELESS WALL
HOODS
• DTWN3048—30"W.
• DTWN3648—36"W.
• DTWN4248—42"W.
• DTWN4848—48"W.
Slim Tra itional Wall Hoo s shoul not
be installe over Professional cooking
pro ucts with the gas Char-Grill feature.
A 1,200 or 1,500 CFM (if applicable)
ventilator kit shoul be use when
installe over ranges/rangetops with gas
grill.
EXTRA FINISH DETAILS FOR DTWS
MODELS ONLY
• Accessory Rail—along front of canopy
(must be or ere an factory installe )
• Stainless Steel/Chrome (CR)—Stainless
steel rail with chrome supports/brackets
an hooks (inclu e )
• Brass Trim Option (BR)—nameplate, rail,
supports/brackets, an hooks (inclu e ).
Brass components have a urable
protective coating for maintenance-free
normal use.
FINISH DETAILS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass (SE),
Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
• Finish esignates exterior of canopy
• Stainless Steel (SS) canopy interior
DTWS Sl m Trad t onal
Wall Hood*
Model Options
DTWN Tall Trad t onal
Ledgeless Wall Hood**
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

24”
(61.0cm)
A
9”
(22.9cm)
C
B
12”
(30.5cm)
2”
(5.1cm)
13”
(33.0cm)
VENTILATION
Desi ner Built-In Wall Hoods
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
✪
Please see
Installat on Notes &
Accessor es for
important information,
including ventilator
kits, duct covers,
backsplashes, and
warming shelf
panels.
Dimensions & Specifications
PRODUCT DIMENSIONS
DTWS Sl m Trad t onal
Wall Hood
SLIM TRADITIONAL
WALL HOOD
DTWN Tall
Trad t onal Ledgeless
Wall Hood
24”
(61.0cm)
A
B
18”
(45.7 cm)
12”
(30.5cm)
12”
(30.5cm)
TALL TRADITIONAL
LEDGELESS WALL HOOD
Model Hood Duct Cover Li hts Filters Heat Approx.
Width (A) Hei ht Width (B) Depth Hei ht (C) Lamps Ship. wt.
DTWS3049 29-7/8” (75.9 cm) 9” (22.9 cm) 12” (30.5 cm) 12” (30.5 cm) 21” (53.3cm)— 22N/A 50 lbs.
33” (83.8 cm) (22.5 kg)
DTWS3649 35-7/8” (91.1 cm) 9” (22.9 cm) 12” (30.5 cm) 12” (30.5 cm) 21” (53.3cm)— 22N/A 60 lbs.
33” (83.8 cm) (27.0 kg)
DTWS4249 41-7/8” (106.4 cm) 9” (22.9 cm) 12” (30.5 cm) 12” (30.5 cm) 21” (53.3cm)— 23N/A 70 lbs.
33” (83.8 cm) (31.5 kg)
DTWS4849 47-7/8” (121.6 cm) 9” (22.9 cm) 20” (50.8 cm) 12” (30.5 cm) 21” (53.3cm)— 33N/A 81 lbs.
33” (83.8 cm) (36.5 kg)
DTWN3048 29-7/8” (75.9 cm) 18” (45.7 cm) 29-7/8 12” (30.5 cm) 12” (30.5 cm) 22N/A 59 lbs.
(75.9 cm) (26.6 kg)
DTWN3648 35-7/8” (91.1 cm) 18” (45.7 cm) 35-7/8” 12” (30.5 cm) 12” (30.5 cm) 22N/A 69 lbs.
(91.1 cm) (31.1 kg
DTWN4248 41-7/8” (106.4 cm) 18” (45.7 cm) 41-7/8” 12” (30.5 cm) 12” (30.5 cm) 23N/A 79 lbs.
(106.4 cm) (35.6 kg)
DTWN4848 47-7/8” (121.6 cm) 18” (45.7 cm) 47-7/8” 12” (30.5 cm) 12” (30.5 cm) 33N/A 90 lbs.
(121.6cm) (40.5 kg)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

66”min.
(167.6cm)
to
72”max.
(182.9cm)
30”min.
(76.2cm)
to
36”max.
(91.4cm)
36”
(91.4cm)
VENTILATION
Desi ner Built-In Wall Hoods
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Dimensions & Specifications
CLEARANCE DIMENSIONS
30”min.
(76.2 cm)
to
36”max.
(91.4 cm)
66”min.
(167.6cm)
to
72”max.
(182.9cm)
36”
(91.4 cm)
TALL TRADITIONAL
LEDGELESS WALL HOOD
SLIM TRADITIONAL
WALL HOOD
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

Proper installation/ductin is extremely
important to ensure maximum
performance. Use a qualified and
trained installer.
DUCTING
• Check with a qualifie an
traine installer or local co es
for makeup air requirements, if
any.
• Max. uct run length
o For 300 – 1,200 CFM—50’
(152.4 m)
o For 1,500 CFM—75’ (22.9 m)
o For general reference only;
for longer uct runs, increase
uct size an contact a
qualifie an traine installer.
o Straight runs an gra ual
turns are best; for example,
each 90° elbow is equivalent
to 5’ – 10’ (1.52 – 3.05 cm) of
straight run.
• 7” (17.8 cm) roun uct for
300 – 600 CFM; 10” for 900 –
1500 CFM
o Never use flexible uct; it
creates back pressure/air
turbulence an greatly
re uces performance.
GAS
Not applicable
ELECTRICAL
• Har wire irect with two-wire
groun
• 120 VAC/60 Hz
• Max. amp usage (rating
inclu es recommen e
ventilator kit rating)—see
Dimensions & Specifications
table
PLUMBING
Not applicable
DTWS Sl m Trad t onal
Wall Hood
DTWN Tall
Trad t onal Ledgeless
Wall Hood
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
VENTILATION
Desi ner Built-In Wall Hoods
Installation Requirements
* A 1,200 CFM interior- or exterior-power ventilator shoul be use when installe over range/rangetop with gas char-grill.
** It is recommen e that the 1,500 CFM ventilator be use with longer uct runs.
Note: Maximum amp ating fo hoods includes ecommended ventilato kit ating. All p oducts must be ha d wi ed with two-wi e g ound. An inte io - o
exte io -powe ventilato kit must be pu chased fo installation with all 18”H. hoods.
Model Ventilator Kits Duct Size Max. Amps
Interior Exterior Interior Exterior Interior Exterior
DTWS3049 DIV300/440 DEV900/DIL900 7” (17.8 cm) 10” (25.4 cm) 1.7/3.2 6.6
DTWS3649 DIV300/440 DEV900/1200/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 1.7/3.2 6.6
DTWS4249 DIV440 DEV900/1200/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 3.2 6.6
DTWS4849 DIV880 DEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 5.6 4.3/5.1
DTWN3048 VIV300/600/1200* VEV900/1200*/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 2.4/4.6/6.6 6.6/3.9
DTWN3648 VIV300/600/1200* VEV900/1200*/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 2.4/4.6/6.6 6.6/3.9
DTWN4248 VIV600/1200* VEV900/1200*/DIL900/1200 7” (17.8 cm) 10” (25.4 cm) 4.6/6.6 6.6/3.9
DTWN4848 VIV1200* VEV1200/1500**/DIL1200 10” (25.4 cm) 10” (25.4 cm) 7.0 4.3/5.1
Note: All CFMs a e based on tests with 0.1 static p essu e. Without applying static p essu e (some b ands do not), CFM could be g eatly
ove stated.
UTILITY REQUIREMENTS
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

VENTILATION
Desi ner Built-In Wall Hoods
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Ventilator Kits
• See Installat on Requ rements table for recommen ations for each hoo mo el
• A 1,200 CFM interior or 1,500 CFM exterior (if applicable) ventilator shoul be use over ranges/rangetops with gas grill
•Must use Viking ventilator kits with Viking hoo s; use of non-Viking kits voi s pro uct warranty
Duct Covers
• DCW for DTWN mo els
o 12”H./12”D.
o Exten height of hoo by 12”; conceal uct
• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray (OG), Gol en Mist (GM), Lemona e (LE), Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Re (RR), Apple Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
o When or ering, specify finish co e following accessory mo el number (for example, DCSB3008-SS)
Duct Cover Extensions
• For use with DTWS Slim Tra itional Wall Hoo s
• Exten s height of hoo by up to 12” (for 10’ ceilings)
• Replaces a justable uct cover supplie with hoo
• Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray (OG), Gol en Mist (GM), Lemona e (LE), Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Re (RR), Apple Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
o When or ering, specify finish co e following accessory mo el number (for example, DCCE1010-SS)
✪Installation Notes & Accessories
Kit model Description Hood models Approx. ship wt. lbs. (k )
DIV300 300 CFM interior power DTWS3049/3649 15 (6.8)
DIV440 440 CFM interior power DTWS3049/3649/4249 25 (11.3)
DIV880 880 CFM interior power DTWS4849 36 (16.2)
DEV900 900 CFM exterior power DTWS3049/3649/4249 39 (17.6)
DEV1200 1,200 CFM exterior power DTWS3649/4249/4849 53 (23.9)
DEV1500 1,500 CFM exterior power DTWS4849 47 (21.3)
VIV300 300 CFM interior power DTWN3048/3648 27 (12.2)
VIV600 600 CFM interior power DTWN3048/3648/4248 27 (12.2)
VIV1200 1,200 CFM interior power DTWN3048/3648/4248/4848 43 (19.4)
VEV900 900 CFM exterior power DTWN3048/3648/4248 39 (17.6)
VEV1200 1,200 CFM exterior power DTWN3048/3648/4248/4848 53 (23.9)
VEV1500 1,500 CFM exterior power DTWN4848 47 (21.3)
DIL900 900 CFM in-line power DTWS3049/3649/4249 20 (9.1)
DIL1200 1,200 CFM in-line power DTWS3649/4249/4849 25 (11.3)
VIL900 900 CFM in-line power DTWN3048/3648/4248 20 (9.1)
VIL1200 1,200 in-line power DTWN3048/3648/4248/4848 25 (11.3)
Model Description Approx. ship wt. lbs. (k )
DCW30 Duct cover for 30”W. DTWN 10 (4.5)
DCW36 Duct cover for 36”W. DTWN 11 (5.0)
DCW42 Duct cover for 42”W. DTWN 13 (5.9)
DCW48 Duct cover for 48”W. DTWN 14 (6.3)
Model Description Approx. ship wt. lbs. (k )
DCCE1010 Duct cover extension (for 30”W. DTWS ood) 4 (1.8)
DCCE1210 Duct cover extension (for 36” & 42”W. DTWS oods) 6 (2.7)
DCCE2010 Duct cover extension (for 48”W. DTWS ood) 9 (4.1)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE

VENTILATION
Desi ner Built-In Wall Hoods
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
Backsplashes
• Stainless Steel (SS)
• 30”H.
•Backsplashes protect the wall space below hoo
• Create a continuous finish between cooking surface an hoo
• Low maintenance, easy to clean
• Hemme e ges with screw holes
• Kit inclu es backsplash an fastening screws
Warmin Shelf Panels
• Stainless Steel (SS)
• 12”D./12”H.
• Shelf panels hol cookware an con iments
• Fol up/ own, heavy- uty warming shelves (non-removable), factory installe on stainless steel backsplash
• 15-7/8”W. X 10-1/8”D.
• Kit inclu es shelf (or shelves) an fastening screws
Compliance Information
WARRANTY SUMMARY*
• Three-year full warranty—complete pro uct (Professional an Designer)
• Five-year limite warranty—all ventilator motors (Professional an Designer)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items (Professional an Designer)
*Must use V k ng vent lator k ts w th V k ng hoods; use of non-V k ng k ts vo ds product warranty. For complete warranty see Use & Ca e Guide.
Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (k )
BKS30 30”W. backsplas 7 (3.2)
BKS36 36”W. backsplas 9 (4.1)
BKS42 42”W. backsplas 12 (5.4)
BKS48 48”W. backsplas 14 (6.3)
Model Description Approx. ship wt. lbs. (k )
WGP30 30”W. warming s elf panels (one s elf) 9 (4.1)
WGP36 36”W. warming s elf panels (two s elves) 12 (5.4)
WGP42 42”W. warming s elf panels (two s elves) 14 (6.3)
WGP48 48”W. warming s elf panels (two s elves) 16 (7.2)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
