ViM KSDR ECOWATT 48 User manual

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-190905
INST R U C T IO N M A NU A L
INST A LLA T IO N | W IR ING | C O M M ISSIO NING | M A INT ENA NC E |
AFNOR CERTIFICATION
ISO 14001
Environnement
AFNOR CERTIFICATION
ISO 9001
Qualité
K SD R EC O W A T T ®
4 8 / 8 8 / 1 2 0 / 1 6 0 / 2 0 0
Compact controlled single ow air handling unit (AHU)

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909052/88
ENGLISH
SOMMAIRE
1 . GENER A LINF O R M A T IO N................................................................................................................ 3
1.1 Warnings .................................................................................................................................. 3
1.2 Safety Guidelines ..................................................................................................................... 4
1.3 Receipt - Storage...................................................................................................................... 4
1.4 Warranty................................................................................................................................... 4
2 . P R ESENT A T IO NO F R A NGE- P R O D U C T ....................................................................................... 5
2.1 Range....................................................................................................................................... 5
2.2 Functional diagrams ................................................................................................................ 6
2.3 Products - Main Components................................................................................................... 9
3 . INST A LLA T IO N................................................................................................................................ 1 2
3.1 Unit identication / Symbols ................................................................................................... 12
3.2 Dimensions and weights......................................................................................................... 12
3.3 Handling ................................................................................................................................. 14
3.4 Location and attachment ........................................................................................................ 15
4 . HY D R A U LIC A ND F LU ID C O NNEC T IO N....................................................................................... 1 8
4.1 Connection of the water coils ................................................................................................. 18
4.2 Connection of the DX coils ..................................................................................................... 19
4.3 Condensate drainage (ER, EF, EX, EIX, ECF, and ERC versions only)................................. 20
5 . A ER A U LIC C O NNEC T IO N.............................................................................................................. 2 0
5.1 Connection of the ducts.......................................................................................................... 20
5.2 Connection of the accessories ............................................................................................... 20
6 . ELEC T R IC A LC O NNEC T IO N.......................................................................................................... 2 2
6.1 Electrical characteristics......................................................................................................... 22
6.2 AHU power connection with electrical heater......................................................................... 24
6.3 AHU power connection for the water coil ............................................................................... 26
6.4 Connecting an external unit.................................................................................................... 27
6.5 Control panel and connection................................................................................................. 28
6.6 Connection of components to control the ventilation mode.................................................... 29
6.7 Connecting temperature control accessories with an internal battery.................................... 32
6.8 Connecting the remote control with ETD display.................................................................... 35
6.9 Connection panel.................................................................................................................... 36
7 . C O M M ISSIO NING............................................................................................................................ 3 8
8 . ST A ND A R D C O NF IGU R A T IO N....................................................................................................... 3 9
8.1 Simplied Menus / Access...................................................................................................... 40
8.2 Constant ow operation (CAV) ............................................................................................... 43
8.3 Variable ow operation (VAV) ................................................................................................. 44
8.4 Constant pressure operation (COP)....................................................................................... 45
8.5 Antifreeze protection of the heating coil (EC, ECF and ER versions) .................................... 46
8.6 Temperature control................................................................................................................ 46
8.7 Temperature control with DX coil, EX and EIX versions......................................................... 47
9 . A D V A NC ED C O NF IGU R A T IO N....................................................................................................... 5 0
9.1 Hourly programming............................................................................................................... 50
9.2 Override.................................................................................................................................. 52
9.3 Control of the inputs/outputs................................................................................................... 52
9.4 Measurement of the air ow and pressure - Check the K coe󰀩cient ..................................... 53
9.5 Resetting the CORRIGO ........................................................................................................ 55
1 0 . C O M M U NIC A T IO N........................................................................................................................... 5 7
10.1 Connection to BMS in modbus language .............................................................................. 57
10.2 Bacnet communication protocole for BMS communication .................................................... 61
10.3 Integrated web server application........................................................................................... 71

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909053/88
ENGLISH
1 1 . M A INT ENA NC E................................................................................................................................ 8 0
11.1 Prior precautions .................................................................................................................... 80
11.2 Frequency of maintenance..................................................................................................... 80
11.3 List of faults ............................................................................................................................ 81
11.4 Maintenance/replacement of the fresh air lter ..................................................................... 82
11.5 Casing maintenance............................................................................................................... 83
11.6 Maintenance/replacement of the fan ...................................................................................... 83
11.7 Maintenance/replacement of the electrical heater.................................................................. 84
11.8 Maintenance/replacement of the water coil............................................................................ 84
11.9 Replacement of the CORRIGO automaton battery ................................................................ 85
11.10 Replacement parts ................................................................................................................. 85
1 2 . W A ST EM A NA GEM ENT .................................................................................................................. 8 6
12.1 Treatment of packaging and non-hazardous waste ............................................................... 86
12.2 Professional treatment of EEEW............................................................................................ 86
1 . GENER A L INF O R M A T IO N
1 . 1 W a r n i n g s
This product has been manufactured in accordance with rigorous technical rules of security in accordance
with the standards of the EC. The EC declaration, as well as the instructions, can be downloaded from the
Internet site www.vim.fr.
Before installing and using this product, carefully read these instructions which contain important indi-
cations for your safety and that of users during the installation, commissioning, and maintenance of this
product.
Once the installation is complete, leave this manual in the machine for any later consultation.
The installation of this product (installation, connections, commissioning, maintenance) and all other inter-
ventions must be carried out by a professional applying the rules of the art, safety standards, and regula-
tions in force.
It must comply with the requirements relating to the Electromagnetic Compatibility (EMC) and the Low
Voltage Directive.
VIM will not be responsible for any possible bodily injury and/or material damage caused when the safety
instructions have not been followed or following a modication of the product.
The KSDR ECOWATT® single ow units are intended for single ow ventilation and air handling applica-
tions in kitchens or tertiary buildings.
Indoor (recommended) or outdoor installation:
• Max. permanent environment temperature: -30°C / +40 °C.
• To avoid damage to electronic components (very low temperature, condensation) the safety switch
located on the front panel must be maintained in the "ON" position except for maintenance periods.
• Relative humidity: 95% max. without condensation.
• Atmosphere not potentially explosive.
• Atmosphere of low salinity without any corrosive chemical agents.

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909054/88
ENGLISH
1 . 2 Sa f e t y Gu i d e l i n e s
• Use the appropriate PPE (Personal Protective Equipment) for any handling operation.
• Before installing the air handling unit (AHU), make sure that the support and location are su󰀩ciently
resistant to bear the weight of the unit and accessories.
• Respect the danger labels present on the various access doors or panels:
• Live electrical equipment / Rotating machinery / Potentially ammable dust-laden lters:
FIRE DANGER
DIRTY FILTERS ARE
INFLAMMABLE
• Do not open the access doors without having cut the electrical power from the lockable safety iso-
lator switch located on the unit
• If there is work to be performed on the device, cut the electrical power at the main circuit breaker and
make sure that nobody is able to reconnect it accidentally.
• Make sure that any mobile parts have stopped.
• Check that the fan motor is not accessible from the connection sheath.
Before start-up, check the following points:
• Ensure that the device does not contain any foreign body.
• Check that all the components are fastened in their original locations.
• Manually check that the fan is not rubbing and is not blocked.
• Check the connection of the earth electrode.
• Check that the access cover is securely closed.
1 . 3 R e c e i p t - St o r a g e
In the event of any lack, non-conformity, or total or partial damage of the delivered products, the Buyer
must note its written reservations on the carrier's receipt in accordance with Article 133-3 of the Commer-
cial Code and conrm them within 72 hours by registered letter with a copy sent to VIM.
The receipt of the material without reservation deprives the Buyer of any subsequent recourse against us.
The product must be stored out of bad weather and protected from any impacts and stains caused by
projections of any kind during its transport from the supplier to the end client, and on the work site prior to
installation.
1 . 4 W a r r a n t y
The material provided by VIM is guaranteed for 12 months - Parts only - from the invoice date. VIM un-
dertakes to replace any parts or equipment which are recognised by our services as being faulty, with the
exception of any damages, interests, or penalties such as operating losses, commercial prejudice, or other
immaterial or indirect damages.
Our warranty excludes any faults related to improper use or any use that is non-compliant with the rec-
ommendations of our instructions, any faults observed following normal usage, any incidents caused by
negligence, lack of monitoring or maintenance, or any defects due to poor installation of the equipment or
unsuitable storage conditions prior to assembly.
In no case may VIM be held responsible for any transformed or repaired equipment, even partially.

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909055/88
ENGLISH
2 . P R ESENT A T IO N O F R A NGE - P R O D U C T
2 . 1 R a n g e
Use: Supply of fresh air into buildings with heating or cooling. Installation on feet, inside or outside.
5 Si ze s : 48 (4,800 m³/h), 88 (8,800 m³/h), 120 (12,000 m³/h), 160 (16,000 m³/h), and 200 (20,000 m³/h).
• M o d e l s w i t h i n t e g r a t e d c o i l s :
-EC : heating coil.
-EF : cooling coil.
-ER : reversible heating coil/cooling coil, 3, 4, 6 or 8 rows.
-EC F : heating coil + cooling coil.
-ERC: reversible coil + heating coil
-EI: electric heater.
-EIX : electric heaters for preheating + DX coil.
-EX : DX coil
• Congurations:
-D: Indoor version, right-hand access in the direction of the air.
-G: Indoor version, left-hand access in the direction of the air
-EX D : Outdoor version, right-hand access in the direction of the air.
-EX G: Outdoor version, left-hand access in the direction of the air.
• C o n s t r u c t i o n s :
-Monoblock sizes 48 to 120,
-Bi-block sizes 160 and 200: 1 casing with filtration, control and ventilation, and 1 casing with the thermal
coils.
• D a m p e r s
-Si z e s 4 8 t o 8 8 : d e l i v e r e d w i t h o u t t h e d a m p e r
-Motorised dampers are available as accessories (following table)
-Suction setting for antifreeze protection of water coils
-Blowing setting to comply with CH 38 article of Public Access Buildings (ERP) French regulation.
K SD R s i z e s C o d e A c c e s s o r y d e s i g n a t i o n D e s c r i p t i o n
48 170286
C D R 1 0 0 F 8 0 0 x 6 1 0
Motorisable antifreeze or re damper
88 170349
C D R 1 0 0 F 1 1 0 0 x 9 1 0
Motorisable antifreeze or re damper
-Si z e s 1 2 0 t o 2 0 0 : d e l i v e r e d w i t h d a m p e r ( o p t i o n a l o n M o d e l 1 2 0 EI w i t h e l e c t r i c a l h e a t e r )
-Motorised damper fitted as standard inside the AHU
-Dual function: antifreeze protection of the water coils and compliant with article CH 38 of the ERP, Public
Access Buildings French regulation.
K SD R s i z e s w i t h i n t e r n a l d a m p e r EC EF ER EC F ER C EI
120
160
200
Included, Option
R e m i n d e r o f a r t i c l e C H 3 8 , P u b l i c A c c e s s B u i l d i n g s F r e n c h r e g u l a t i o n : Obligation to provide a metal
damper downstream of the lters, controlled by a DAD (Autonomous Detector Trigger) for the AHU (whatev-
er the ow) serving sleeping areas and the AHUs handling more than 10,000 m³/h.
• C o m m u n i c a t i n g c o n t r o l l e r a s s e m b l e d / w i r e d r e a d y t o b e c o n n e c t e d :
-Variable airflow (VAV), constant airflow (CAV), constant pressure (COP).
-The ASR ECOWATT system for interlocked association with a KUBAIR F400 ECOWATT or a TED F400
ECOWATT - Consult the manual "NT00000438-SYSTEME-ASR-ECOWATT" available on www.vim.fr.
-Temperature control by the included CORRIGO controller specific to VIM.
-Modbus communicating on RS485 port and Bacnet IP on TCP/IP port.
-ETD remote touch display included (10 m cable).

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909056/88
ENGLISH
2 . 2 F u n c t i o n a l d i a g r a m s
For any specic conguration contact the VIM After-Sales service.
K SD R EC O W A T T ®w i t h D X c o i l ( EX )
S1
S4
M1
R
DP1 DP3
Fl1
ETDGTCou
DX
Groupe
DX
Kit DX
Souage air neuf
Aspiration air neuf
Outdoor air Supply air
S1 T° supply sensor
S4 T° fresh air sensor
RCORRlGO Controller
M 1 Motor-fan
M 5 Fresh air damper (accessory)
F l 1 Fresh air filter
D P 1 Fresh air prefilter pressure
switch
D P 3 Airflow measurement
D X DX coil
D P 5 Differential pressure sensor
(accessory COP mode)
ET D Touch display for control of the
KSDR
See § "8.7 Temperature control with DX coil, EX and EIX versions", page 47.
K SD R EC O W A T T ®w i t h e l e c t r i c a l h e a t e r a n d D X c o i l ( EIX )
S1
S4
M1
R
DP1
DP3
Fl
1
ETD
GT
C
ou
Pr
1
Ba
t1
Tr
iac
DX
S5
Gr
oupe
DX
Kit
DX
Pr
2
Souage air neuf
Aspiration air neuf
Outdoor air
DX group
Supply air
S1 T° supply sensor
S4 T° fresh air sensor
RCORRlGO Controller
P R 1
P R 2
Safety thermostat (manual/
auto)
M 1 Motor-fan
F l 1 Fresh air lter
D P 1 Fresh air lter pressure switch
D P 3 Airow measurement
S5 Unit pre-heat sensor
D X DX coil
B a t 1 Electric pre-heater
SSR
( s o l i d
s t a t e
r e l a y )
Power control
ET D Touch display for control of the
KSDR
D X k i t Interface with the DX group
(customer supplied)
See § "8.7 Temperature control with DX coil, EX and EIX versions", page 47.

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909057/88
ENGLISH
K SD R EC O W A T T ®w i t h e l e c t r i c a l h e a t e r ( EI)
S1
S4
M1
R
DP1 DP3
Fl1
ETD GTC
ou
Pr1
Bat1
Triac
Pr2
Souage air neufAspiration air neuf Supply air
Outdoor air
S1 T° supply sensor
S4 T° fresh air sensor
RCORRlGO Controller
P R 1
P R 2
Safety thermostats
M 1 Motor-fan
M 5 Fresh air damper (accessory)
F l 1 Fresh air lter
F I2 Fresh air lter (option)
D P 1 Fresh air lter pressure switch
D P 3 Airow measurement
B a t 1 Electrical heater
ET D Touch display for control of the
KSDR
K SD R EC O W A T T ®w i t h w a t e r c o i l ( ER / EC / EF )
S1
S4
M1
R
DP1 DP3
Fl1
ETD GTCou
Pr10
Bat1
M6
S20
Souage air neuf
Aspiration air neuf
Supply air
Outdoor air
S1 T° supply sensor
S4 T° fresh air sensor
RCORRlGO Controller
P r 1 0 Antifreeze sensor
S2 0 Change-over thermostat
M 1 Motor-fan
M 5 Fresh air damper (accessory)
M 6 Motorised valve
F l 1 Fresh air lter
D P 1 Fresh air lter pressure switch
D P 3 Airow measurement
B a t 1 Reversible water coil / heating
coil / cooling coil
ET D Touch display for control of the
KSDR

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909058/88
ENGLISH
K SD R EC O W A T T ®w i t h w a t e r c o i l ( EC F / ER C )
S1
S4
M1
R
DP1 DP3
Fl1
ETDGTC
ou
Bat1 Bat2
M6
M7
Pr10
Souage air neuf
Aspiration air neuf
Outdoor air Supply air
S1 T° supply sensor
S4 T° fresh air sensor
RCORRlGO Controller
P r 1 0 Antifreeze sensor
M 1 Motor-fan
M 5 Fresh air damper (accessory)
M 6 Motorised valve
M 7 Motorised valve
F l 1 Fresh air lter
D P 1 Fresh air lter pressure switch
D P 3 Airow measurement
B a t 1 Heating coil / reversible coil
B a t 2 Cooling coil / heating coil
ET D Touch display for control of the
KSDR

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-1909059/88
ENGLISH
2 . 3 P r o d u c t s - M a i n C o m p o n e n t s
Electrical heater version (EI), electrical pre-heater + DX coil (EIX), heating coil (EC), cooling coil (EF),
heating + cooling coils (ECF), reversible (ER), reversible + heating coils (ERC):
K SD R EC O W A T T
®
4 8 - 8 8
Sens du ux d’air
103
5
81 2
6
4
7
Air direction
1Prelter
2Filter
3Motor-fan
4Control panel
5Fresh air T° sensor
6Supply T° sensor
7Roof insulation
8Bottom insulation
1 0 Motor assembly sensor - Pressure switch
M o d e l s EC - EF - ER - EC F M o d e l EI
21
20 22
2 0 Water coil(s)
2 1 Droplet separators (EF,
ER, ECF)
2 2 Drain trays (EF, ER,
ECF)
3132 30
3 0 Static power relays
3 1 Safety Thermostat
3 2 Quick connectors
M o d e l EIX M o d e l EX
46 43
44
40
41
42
45
47
4 0 DX coil
4 1 Drain tray
4 2 Droplet separator
4 3 Preheating coil
4 4 Anti-radiation screen
4 5 Safety thermostat
4 6 Static relays
4 7 Quick connectors
50
5 0 DX coil

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090510/88
ENGLISH
K SD R EC O W A T T
®
1 2 0
10
3
5
81 2
6
4
7
9
Sens du ux d’air
Air direction
1Prelter
2Filter
3Motor-fan
4Control panel
5Fresh air T° sensor
6Supply T° sensor
7Roof insulation
8Bottom insulation
9Internal damper for coil freeze protection and/or
application compliant with CH 38 article ERP French
Regulation. 24 V On/O󰀨 actuator, with return spring,
mounted and wired at the factory.
1 0 Motor assembly sensor - Pressure switch
M o d e l s EC - EF - ER - EC F M o d e l EI
2120 22
2 0 Water coil(s)
2 1 Droplet separators (EF,
ER, ECF)
2 2 Drain trays (EF, ER,
ECF)
3132 30
3 0 Static power relays
3 1 Safety Thermostat
3 2 Quick connectors
M o d e l EX
50
5 0 DX coil

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090511/88
ENGLISH
K SD R EC O W A T T
®
1 6 0 - 2 0 0
10
3
5
81 2
6
4
7
9
Sens du ux d’air
Air direction
1Prelter
2Filter
3Motor-fan
4Control panel
5Fresh air T° sensor
6Supply T° sensor
7Roof insulation
8Bottom insulation
9
Internal damper located behin the control for coil
freeze protection and/or application compliant with
CH 38 article ERP French Regulation. 24 V On/O󰀨
actuator, with return spring, mounted and wired at
the factory.
1 0 Motor assembly sensor - Pressure switch
M o d e l s EC - EF - ER - EC F
23
22
21
20
2 0 Water coil(s)
2 1 Droplet separators (EF, ER, ECF)
2 2 Drain trays (EF, ER, ECF)
2 3 Connecting terminal for valves
M o d e l EI
30
32
31
33
3 0 Static power relays
3 1 Safety Thermostat
3 2 Quick connectors
3 3 Disconnnect switch

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090512/88
ENGLISH
3 . INST A LLA T IO N
3 . 1 Unit identication / Symbols
Identication label - stuck on the machine above the control cabinet
16278
KSDR ECOWATT ECF48 D
CODE : 685347
Made in France
U = 3~ 400V - 50/60 Hz
I Nom / RC = 2.3 A
P = 1.5kW
Q Nom = 4800m
3
/h
:258kg
www.vim.fr
CORRIGO Bat Eau chaude+froide CTA
General data
Motor data U = 3~ 400V - 50/60 Hz I Nom / RC = 1,7A 2140 RPM
Filter data
M5 DP initial / final = 60/200 Pa
F7 DP initial / final = 65/200 Pa
Bat/Coil data
ECF Eau chaude/Hot water + Eau froide/Cold water
3 . 2 D i m e n s i o n s a n d w e i g h t s
K SD R EC O W A T T
®
4 8 M O NO B LO C K
In d o o r m o d e l O u t d o o r m o d e l
E
A
M
F
J
C
K
D
I
M8(*)
GB
H
E
A
M
F
J
C
K
D
I
M8(*
)
GB
H
P
N
O
P
N
O
W e i g h t s ( K g ) EC / EF / ER 4 * EC F ER 6 * EC 6 C * EI m a x . EIX EX
K SD R EC O W A T T
®
4 8
233 258 255 275 278 260 237
For outdoor version, add 30 kg.
(*) ER4: reversible coil, 4 rows, ER6: reversible coil, 6 rows, EC6C: 6 rows heating coil + 2 rows heating coil.
Si z e A B C D E F G ( e x c e p t
EI) G ( EI)
K SD R EC O W A T T
®
4 8 1,715 1,000 800 620 925 100 100 65
Si z e H I J K M N O P
K SD R EC O W A T T
®
4 8 840 650 150 869 1,415 1,975 1,175 1,020

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090513/88
ENGLISH
K SD R EC O W A T T
®
8 8 a n d 1 2 0 M O NO B LO C K
In d o o r m o d e l O u t d o o r m o d e l
E
A
J
ML
F
C
K
D
I
M8(*)
GB
H
E
A
J
ML
F
C
K
D
I
M8(*)
GB
H
O
N
P
O
N
P
Si z e A B C D E F G ( e x c e p t
EI) G ( EI) H
K SD R EC O W A T T
®
8 8 1,950 1,315 1,100 810 1,165 100 100 65 1,140
K SD R EC O W A T T
®
1 2 0 2,400 1,315 1,100 1,100 1,465 100 100 65 1,140
Si z e I J K L M N O P
K SD R EC O W A T T
®
8 8 850 135 1,284 161 611 2,210 1,485 1,270
K SD R EC O W A T T
®
1 2 0 1,188 135 1,284 197 802 2,400 1,485 1,580
W e i g h t s ( K g ) EC / EF / ER * EC F ER 6 * * EC 6 C * * * EI m a x . EIX EX
K SD R EC O W A T T
®
8 8
350 387 383 413 417 364 356
K SD R EC O W A T T
®
1 2 0
583 646 638 688 696 - 593
For outdoor version, add:
- KSDR 88: 40 kg.
- KSDR 120: 45 kg.
(*) ER: reversible coil, 4 rows in Size 88, 3 rows in size 120,
(**) ER6: reversible coil, 6 rows,
(***) EC6C: 6 rows heating coil + 2 rows heating coil.

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090514/88
ENGLISH
K SD R EC O W A T T
®
1 6 0 a n d 2 0 0 B I- B LO C K
In d o o r m o d e l O u t d o o r m o d e l
M8(*)
B
H
G
ID
C
KJ
F
A
E
Q
M8(*)
B
H
G
ID
C
K
J
F
A
E
Q
Block 1 Block 2
Block 2Block 1
O
N
P
Q
O
N
P
Q
M o d e l s W e i g h t s v e n t i l a t i o n
m o d u l e ( K g )
W e i g h t s c o i l m o d u l e ( s ) ( K g )
EC EF - ER 4 * ER 8 * EC 8 C * EC F EI m a x .
K SD R EC O W A T T
®
1 6 0 Indoors 583 175 232 316 331 356 240
Outdoors 622 193 250 334 349 374 260
K SD R EC O W A T T
®
2 0 0 Indoors 788 207 274 384 400 330 290
Outdoors 834 227 294 404 420 350 310
(*) ER4: reversible coil, 4 rows, ER8: reversible coil, 8 rows, EC8C: 8 rows heating coil + 2 rows heating coil.
Si z e A B C D E F G
( e x c e p t EI) G ( EI)
K SD R EC O W A T T
®
1 6 0 2,800 1,610 1,210 1,160 1,485 140 100 65
K SD R EC O W A T T
®
2 0 0 2,800 1,950 1,515 1,160 1,485 140 100 65
Si z e H I J K N O P Q
K SD R EC O W A T T
®
1 6 0 1,240 1,216 160 1,380 2,800 1,820 1,615 750
K SD R EC O W A T T
®
2 0 0 1,545 1,216 160 1,688 2,800 2,120 1,625 750
3 . 3 Ha n d l i n g
The units are delivered screwed onto pallets.
The handling of KSDR ECOWATT® air handling unit casings can be managed by pallet truck, forklift truck,
or crane. Handling machines will be appropriate for the load and lifting conditions. The fan modules of
sizes 160 and 200 cannot be loaded on a conventional tailgate.
The device must be handled with care and only in a horizontal position. Holes of 50 mm Ø are provided
in the frame allowing the insertion of a tube to attach the slings. To avoid damage to the unit casing, it is
necessary to use long slings and compensator type spacers .
When using a forklift or pallet truck, use forks that are long enough to not depress the bottom panel and to
avoid tipping over. Position the forks low enough to not damage the doors.

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090515/88
ENGLISH
I mini
I
Lifting with a forklift truck
P a l l e t D i m e n s i o n s
Si z e M o d u l e Le n g t h
( m m ) W i d t h
l
( m m )
K SD R 4 8
Unit 2,100 1,460
K SD R 8 8 - 1 2 0
2,400 1,580
K SD R 1 6 0 - 2 0 0 Fan 2,300 2,200
Coil 2,250 1,300
3 . 4 Lo c a t i o n a n d a t t a c h m e n t
3 . 4 . 1 Lo c a t i o n
The KSDR ECOWATT® AHU must be placed on a horizontal and smooth surface that is able to support the
load. The KSDR ECOWATT® AHU versions D and G are intended for indoor installation at the premises.
Only the versions EXD and EXG are delivered with a roof that can be used outdoors.
In all cases, provide any ducts, connection accessories, anti-vibration and anti-freezing protection needed
for the unit.
It is important to provide enough space (Z at the minimum) to allow panels opening, commissioning, and
maintenance (lters, fans, heat exchanger). Do not place the unit against a wall to avoid the transmission
of solid-state noise.
Z
200 mm
Coil
Si z e Z ( m m )
K SD R 4 8
2,000
K SD R 8 8
2,630
K SD R 1 2 0
2,630
K SD R 1 6 0
3,220
K SD R 2 0 0
3,900
O p e n i n g t h e d o o r s
The doors are opened by quarter-turn locks using an 8 mm Allen key.
For sizes 48, 88 and 120, the doors rest in a lower groove before being retained by their locks.
Crane lifting
Spacer

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090516/88
ENGLISH
3 . 4 . 2 Su p p o r t s
The units are supplied with feet or crosspieces according to the models. The support feet must rest on
the whole contact surface.
K SD R EC O W A T T
®
4 8
1415 mm
570 mm
Ø11
Ø50
19
154
19
154
50
10077
Détail Y
K SD R EC O W A T T
®
8 8 / 1 2 0
AA
50
67,5
135
Ø11
1254
50
35
AA
50
67,5
135
Ø11
1254
50
35
Si z e D i m e n s i o n A
( m m )
K SD R 8 8
746
K SD R 1 2 0
936
K SD R EC O W A T T
®
1 6 0 / 2 0 0
A
1934 637
112
35
162
93
18
A
1934 637
112
35
162
93
18
Si z e D i m e n s i o n A
( m m )
K SD R 1 6 0
1,223
K SD R 2 0 0
1,528
For sizes 88 - 120 - 160 - 200, the units are delivered with galvanized steel crosspieces, 3 mm thick,
100 mm high, with an assembly system between the two modules, drilling for anti-vibration pads location
or feet for levelling. The chassis can allow lifting one unit after assembly on the ground.

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090517/88
ENGLISH
3 . 4 . 3 M o d u l e A s s e m b l y
A s s e m b l y o f t h e f a n m o d u l e s a n d K SD R EC O W A T T
®
1 6 0 a n d 2 0 0 u n i t s
1
Alignment of the casings and connection of the four
M12 screws from inside the fan module. Attach the
rst retaining bracket.
2
Position the side member against the attached
bracket.
3
Attach the second bracket and bring the modules
together.
4
Position the retaining plates and screw them in po-
sition. Connect the 2 modules by their quick electri-
cal connectors.

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090518/88
ENGLISH
4 . HY D R A U LIC A ND F LU ID C O NNEC T IO N
4 . 1 C o n n e c t i o n o f t h e w a t e r c o i l s
W a t e r c o i l t o t h e l e f t W a t e r c o i l t o t h e r i g h t La b e l s
Batterie Eau à droite
Batterie Eau à Gauche
Water inlet
Air direction
Air direction
Water outlet
Water inlet
Water outlet
Batterie Eau à droite
Batterie Eau à Gauche
Water inlet
Air direction
Air direction
Water outlet
Water inlet
Water outlet
504423-OUT 504423-IN
504423-Etiquette-Marquage-batteries-eau-190114
2 modèles - Format 50 x 50 mm
Pantone 108
Noir 100%
W a t e r o u t l e t W a t e r e n t r a n c e
The hydraulic features of the unit are particular to your requirement and
are determined by computer selection: loss of pressure on the water/
water ow. Refer to the selection for sizing the valve, accessories, and
pump.
The connection of the piping to the unit must not impose any mechanical,
vibration or thermal (dilation) constraints.
The units are delivered already threaded at the ends.
During the tightening of the unit thread, hold the tubing with the aid of a
wrench to prevent the tubes being damaged by twisting.
Respect the water entry and exit direction indicated on the labels glued
to the coil panel(s)
C o n n e c t i o n o f t h e h y d r a u l i c a c c e s s o r i e s :
C h a n g e - o v e r t h e r m o s t a t ( ER v e r s i o n s o n l y ) , v a l v e s , a n d a n t i f r e e ze s e n s o r
A change-over thermostat (THCO) is to be installed on the hydraulic network and connected to the elec-
trical cabinet of the unit. It allows inversion of the mixing valve control in installations with only one unit,
according to the uid temperature detected at valve inlet.
R e v e r s i b l e c o i l w i t h c h a n g e - o v e r t h e r m o s t a t a n d a n t i f r e e z e s e n s o r
W a t e r c o i l t o t h e l e f t W a t e r c o i l t o t h e r i g h t
Antifrost sensor:
to be set on coil water outlet
Change-over sensor (THCO):
to be set on coil water inlet
Sizes / Congurations U n i t h e a d e r d i a m e t e r s
48 88 120 160 200
EC 1” 1 1/4” 2” 1 1/4” 1 1/4”
EF 1” 1 1/2” 2” 2” 2”
ER 3 o r 4 r o w s 1” 2” 2” 2” 2”
ER 6 o r 8 r o w s 3/4” 1” 2” 2” 2”

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090519/88
ENGLISH
C o n n e c t i o n o f t h e c h a n g e - o v e r t h e r m o s t a t
BROWN (not used)
BLACK (term. 27)
RED (+24VDC)
Technical characteristics:
• Inverter contact output 240 V~, 3 A
• Contact changes below 15°C ± 4°C (cooling mode) and above
30°C ± 4°C (heating mode)
• Spring fastening on the piping
• Electrical connection of 3 wires 1,5 mm
• IP 65 protection
Ensure the good condition and the connection of the antifreeze sensor installed on the hot water return
of the unit (heating coil or reversible).
The coil headers have a male pipe thread at the end.
The motorised 3-way valves are not delivered already assembled.
Respect the positioning of the mixing valve on the network and the direction of the inlet and outlet of the
water as indicated on the label stuck to the unit panel(s).
4 . 2 C o n n e c t i o n o f t h e D X c o i l s
U n i t 2 EX c i r c u i t s
Refrigerant
connection (liquid)
Refrigerant
connection (gas)
Gauche
C1
C2
D2
D1
The DX coil has 2 interlaced
circuits :
• 1st circuit :
External gas header C1
and liquid header D1,
• 2nd circuit :
Central gas header C2
and liquid header D2.
Each circuit header has a dif-
ferent marking.
The cooling connection must be made by a qualied refrigeration mechanic, experienced in the rules of
the art.
Si z e M o d e l D X c o i l i n n e r v o l u m e ( d m
3
) Nu m b e r o f c i r c u i t s C o n n e c t i o n l i q u i d / g a s Ø
4 8 EX 5.0 1 22/35 (mm)
8 8 EX 7.0 1 28/35 (mm)
120 EX 2 x 4,28 22x3/8"/3/4" (mm)
4 8 EIX 3.1 1 3/8"/3/4"
8 8 EIX 2x3/ 2 2 2x3/8"/3/4"

NT00000535-KSDR-ECOWATT-48-88-120-160-200-AN-19090520/88
ENGLISH
4 . 3 C o n d e n s a t e d r a i n a g e ( ER , EF , EX , EIX , EC F , a n d ER C v e r s i o n s o n l y )
Coil header
The drain tray outlet
Ø14 mm
The unit is equipped with a droplet separator and a
condensate drain tray of stainless steel welded at
the corners.
The condensate drain is 35 mm long and 14 mm in
diameter. The unit casings are all in overpressure
during the operation of the KSDR so that a water
siphon is not required.
Install a ball siphon to avoid the return of odours
from the network when the machine is stopped.
Insulate the condensate drain pipe to prevent the
formation of condensation, and to prevent the risk of
freezing of the drainage in relation to the conditions
of use.
5 . A ER A U LIC C O NNEC T IO N
5 . 1 C o n n e c t i o n o f t h e d u c t s
The ducts should not impose any mechanical constraints on the unit.
Check that the fan-motor is not accessible from the connection line (protection by the connection duct or
an air inlet grill).
Depending on the conguration of the installation and the sound level required, the addition of a silencer
may be necessary at the air discharge.
Take great care to waterproof the networks along all their lengths, from the entrances to the exits.
The fresh air duct must always be insulated, to avoid losses and the risk of condensation. The insulation
level, particularly in cold rooms and regions, must be reinforced.
C i r c u l a r F l a n g e Smooth rectangular ange
The connection of the casings to the aeraulic network is made on their suction or supply frames.
Smooth anges for rectangular or circular connections, to attach with crimping nuts to the suction or supply
frames of the casings, are available.
5 . 2 C o n n e c t i o n o f t h e a c c e s s o r i e s
5 . 2 . 1 C H r a i n h o o d - C HR r a i n h o o d w i t h d a m p e r
To prevent the entrance of water due to precipitation, a rain protection hood is mounted at the suction and
is fastened by crimping nuts on the suction framework of the KSDR after dismantling the grills. The version
CHR includes an on/o󰀨 24 V servomotor power supplied by the main power supply of the KSDR control. It
is managed by the KSDR controller.
