PILOT PARC SLAVE UNIT
Unit for indoor parking facilities for use with a PILOT PARC
MASTER

2/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
CONTENTS
1. GENERAL INFORMATION ................................................................................................................ 3
1.1 Warnings ................................................................................................................................. 3
1.2 Reception - Storage ................................................................................................................. 4
1.3 Warranty ................................................................................................................................. 4
2. PRODUCT PRESENTATION.............................................................................................................. 5
2.1 Dimensions (in mm).................................................................................................................. 5
2.2 Range....................................................................................................................................... 5
2.3 Characteristics.......................................................................................................................... 5
3. ELECTRICAL CONNECTIONS.......................................................................................................... 5
3.1 Instructions before connecting.................................................................................................. 5
3.2 Selection of cables and their protection, according to NF C 15-100 ....................................... 6
3.3 Maximum connection capacity and tightening torque .............................................................. 6
3.4 Cable gland ............................................................................................................................. 7
3.5 Wiring diagrams: see § "7. ANNEXES", page 8....................................................................... 7
4. COMMISSIONING.............................................................................................................................. 7
5. MAINTENANCE.................................................................................................................................. 7
6. WASTE MANAGEMENT.................................................................................................................... 7
6.1 Treatment of packaging and General Industrial Waste (GIW).................................................. 7
6.2 Treatment of Professional WEEE............................................................................................. 7
7. ANNEXES........................................................................................................................................... 8
7.1 Connection and power wiring diagrams ................................................................................... 8
7.2 Control connection wiring diagrams ........................................................................................ 9

3/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
1. GENERAL INFORMATION
VIM cannot be held liable for any injury or material damage caused by failure to comply with the safety
instructions or due to any modication to product.
The CE markings and declarations of conformity certify conformity with the applicable European stand-
ards.
EC declaration of conformity available on www.vim.fr.
1.1 Warnings
Preliminary remarks
This product has been manufactured in compliance with strict technical safety rules in accordance with EC
standards.
Check that the product is in accordance with your order and that the characteristics shown on the name
plate are compatible with those of the installation.
Before installing and using this product, read these instructions carefully as they contain important infor-
mation for your safety and that of users during installation, operation and maintenance.
This manual contains information intended for all personnel exposed to the risks associated with use of
the product in order to prevent any injury to persons and/or material damage consequent upon operation
or maintenance.
The standards and recommendations indicated below reect the applicable standards, especially with
regard to safety. We recommend that all those exposed to risks must comply with the accident prevention
standards.
VIM can in no case be held liable for any injury or material damage due to failure to comply with the safety
instructions or due to any modication to product.
Regularly check the labels and markings on the product. These are required to be replaced if they become
illegible.
Once installation is complete, ensure this manual is available to the nal user for any later consultation.
Precautions to be taken for the correct operation of the system.
Connecting cables must be installed so that inductive and capacitive noise do not interfere with the auto-
mation functions (in particular, do not run the control cables alongside power cables).
Fluctuations in mains voltage or deviations from its rating must not exceed the tolerance limits indicated in
the present instructions as these can cause faulty operation.
Reminder: the installation must comply with the provisions relating to the EMC Directive and the LVD.
The installation of this product and its accessories, their settings and any other work on them must be
carried out by a professional electrician in accordance with best practice, the EMC and Low Voltage Direc-
tives, applicable installation standards (NF C 15-100, etc.) and applicable safety rules.
Do not modify the factory wiring. Comply with the installation and connection plans supplied. Contact our
service department before making any installation or wiring modications.
Before switching on, check that the supply corresponds fully with the indications in these instructions and
those on the product: connection to a di󰀨erent voltage can result in destruction of the equipment.
Since this equipment is to be incorporated in an installation, the whole installation must be made compliant
and approved by the nal installer (compliance must be established with coordination type 1 of the appli-
cable standards EN 60204-1 and IEC 60947-4-1).

4/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
Certain box references include a device to protect the supply against short-circuits. Ensure that the
short-circuit current between this unit and the motor(s) connected is lower than the breaking capacity of
this protection device (aM type fuses).
The motor(s) and other accessories that require it must be earthed via this unit.
The electrical signals delivered must not be used for any purpose other than those described in these
instructions; failure to comply with this instruction can have serious consequences for the operator and/or
the equipment.
Emergency shuto󰀨s must be installed on any machine requiring this function.
Isolate and secure the supply before any work on the equipment (installation or maintenance operation),
which must be carried out by qualied and authorised personnel.
Even when this product is disconnected from power, it may contain hazardous voltage levels from external
control circuits:
Risk of electric shock and electrical arc
1.2 Reception - Storage
Every product is carefully inspected before shipping. On reception, you must check that it has not been
damaged during transport. If this should be the case, make it known to the transporter within 72hrs, by
recorded letter with notice of receipt, summarising all the reservations established at the time of delivery. If
the equipment is received without express reservation, the purchaser has no recourse against VIM.
The product must be stored protected from weather, shocks and soiling due to splashing of any kind during
its transport from the supplier to the nal customer and on the site before installation.
Temperature: -20°C to +60°C
Relative humidity: 30 to 95% without condensation.
1.3 Warranty
Any removal or addition of material in the unit and any work on the original wiring is not permitted without
our authorisation and could result in the withdrawal of approvals and the warranty.
An electrical connection not consistent with the diagram described in this notice and/or installation regula-
tions in force invalidates our warranty contract.
The unit must be used according to manufacturer’s specications, otherwise the function it fulls could be
compromised.
The equipment supplied is normally covered by a 12-month warranty from the date of invoice.
The following are excluded from our warranty: faults connected with abnormal use or use not in accord-
ance with the recommendations in our manuals and instructions, defects found following normal wear and
tear, incidents caused by negligence, failure to monitor or maintain correctly, defects due to poor installa-
tion of the equipment or to poor storage conditions before installation.
In any event, VIM is not responsible for equipment that has been modied, repaired or disassembled even
if only partially.

5/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
2. PRODUCT PRESENTATION
2.1 Dimensions (in mm)
Use the mounting kit provided.
A
C
B
D
E
Unit A B C D* E*
9 to 25A
362 254 200 371 239
32 to 80A
600 300 235 550 216
95A
600 500 300 640 456
115 and 150A
700 500 300 740 456
185A
800 600 350 840 556
225A
1000 600 350 1040 556
*mountings
2.2 Range
Unit H
PILOT PARC E 1 DA
1 three-phase 400V 2-speed motor with Dahlander windings
PILOT PARC E 1 BI
1 three-phase 400V 1-speed or 2-speed motor with separate windings
2.3 Characteristics
Unit A B C
Ratings 9 to 80A Polycarbonate
Colour RAL7035 IP55
Use: -20°C to +40°C.
30 to 95% without condensation.
Conform IEC 695-2-1 (test to 960°C).
Built-in switch-disconnector: 3 points padlockable in OFF
position
Rated 95 to 225A Steel
Colour RAL7035
3. ELECTRICAL CONNECTIONS
3.1 Instructions before connecting
3.1.1 Power supply
Three-phase 400V 50/60Hz + Earth, according to current standards.
Connect the power cable phases directly to the switch-disconnector and the earth conductor on one of
the specic terminals provided for this purpose.
The connection wire cross-section must be identical from the motor to the rst magnetic protection de-
vice encountered upstream (PILOT PARC cabinet or Low Voltage Main Panel depending on model).

6/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
3.1.2 Motor output
Connect the motor phases directly to the corresponding thermal relay and the earth conductor on one of
the specic terminals provided for this purpose.
For versions controlling a Dahlander motor, check the securing of conductors connecting the KME to the
thermal relay output Rtpv once the motor is connected.
Set each thermal relay LS and HS to the corresponding value on the connected motor’s plate.
3.2 Selection of cables and their protection, according to NF C 15-100
Application of coordination type 1: for an installation in accordance with the regulations, it is imperative to
install magnetic electrical protection on the power supply to units of the following type:
Rated current of HS
motor (max in A) Fuse protection Only magnetic circuit breaker protection
Type Rating (A) Type Rating (A)
2.6
aM 10x38
4
ABB-MO325
4
3.5 6 4
5.5 10 6.3
11.5 16 12.5
18.5 25 25
25 32 ABB-MO450 32
32
aM 22x58
40
50 63
65 100
80 125
95 125
115 aM 22x58 125
150 aM T0 160
185 aM T0 200
225 aM T1 250
Shaded cells = fuses built into PILOT PARC.
Otherwise, protection is installed by the installer.
When changing a component, replace existing hardware only with components with identical features.
3.3 Maximum connection capacity and tightening torque
Data for rigid, solid conductors.
Rated current
of HS motor
(max. in A)
Power supply Power output Control terminal block
Max section
(mm²) Tightening
torque
(Nm) Max section
(mm²) Tightening
torque
(Nm) Max section
(mm²) Tightening
torque
(Nm)
9 10 0.8 4 1.7 1.5
Automatic
(spring-loaded
terminal blocks)
18 10 0.8 4 2.5 1.5
25 10 0.8 6 2.5 1.5
32 25 3.5 6 2.5 1.5
50 25 3.5 35 5 1.5
65 35 23 35 5 1.5
80 50 23 35 9 1.5
95 50 23 35 9 1.5
115 50 22 50 9 1.5
150 70 22 70 18 1.5
185 95 22 95 35 1.5
225 120 44 120 35 1.5
Auxiliary contact on switch-disconnector: Max section = 2.5mm2; Tightening torque = 1.7Nm.

7/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
3.4 Cable gland
Cable diameter tolerance range (mm):
ISO M16 ISO M25 ISO M32 ISO M40 ISO M50 ISO M63
4.5-10 10-17 17-25 22-33 28-38 32-44 or 36-52*
* For PILOT PARC ratings 185 and 225A.
Rated current
of HS motor
(max. in A)
Power supply Power output Control
Type Number Type Number Type Number
9 ISO M25 1 ISO M25 2
M16 2
18 ISO M25 1 ISO M25 2
25 ISO M32 1 ISO M32 2
32 ISO M32 1 ISO M32 2
50 ISO M40 1 ISO M40 2
65 ISO M50 1 ISO M50 2
80 ISO M50 1 ISO M50 2
95 ISO M63 1 ISO M63 2
115 ISO M63 1 ISO M63 2
150 ISO M63 1 ISO M63 2
185 ISO M63 1 ISO M63 2
225 ISO M63 1 ISO M63 2
3.5 Wiring diagrams: see § "7. ANNEXES", page 8
4. COMMISSIONING
Product operation = refer to the instructions of PILOT PARC MASTER.
5. MAINTENANCE
Annual maintenance or more often if it is necessary.
6. WASTE MANAGEMENT
6.1 Treatment of packaging and General Industrial Waste (GIW)
The packaging (pallets not on deposit, cartons, lms, wooden boxes) and other GIW must be made reus-
able by an approved service provider.
It is strictly prohibited to burn, bury or dump them in the natural environment.
6.2 Treatment of Professional WEEE
This product must not be dumped or treated with household refuse, but must be dropped o󰀨 at an appro-
priate collection point for waste electrical and electronic equipment (WEEE).

8/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
7. ANNEXES
7.1 Connection and power wiring diagrams
7.1.1 Version with 1 Dahlander motor (PILOT PARC E 1 DA)
= required power wiring; connect power supply directly to the switch disconnector.
5 6
Rtgv1
Rtpv1
KMgv1
KME1 KMpv1
2
1
KMpv1
KME1
KME1KMpv1
KMpv1 KME1 KMgv1
3
4
POWER SUPPLY
3 x 400V 50/60Hz + PE
Compliant with French regulations
1
24
3
6
5
21
22
13
14
A2 A2 A2
(fuse according to model)
95
96
95
96
Rtpv1Rtgv1
A1 A1 A1
22
21 21
22
13
14
PE
PE L3 L2L1
ISOLATOR
SWITCH : INTZ
1L1 3L2 5L3
2T1 4T2 6T3
1L1 3L2 5L3 1L1 3L2 5L3 1L1 3L2 5L3
2T1 4T2 6T3
2T1 4T2 6T3 2T1 4T2 6T3
M
3~
7.1.2 Version with 1 motor with separate windings (PILOT PARC E 1 BI)
= required power wiring; connect power supply directly to the switch disconnector.
56
Rtgv1
Rtpv1
KMgv1
KMpv1
2
1
KMpv1
KMgv1
KMpv1KMgv1
3
4
POWER SUPPLY
3 x 400V 50/60Hz + PE
Compliant with French regulations
1
24
3
6
5
21
22
A2 A2
(fuse according to model)
95
96
95
96
Rtpv1Rtgv1
A1 A1
21
22
13
14
PE
PE L3 L2L1
ISOLATOR
SWITCH : INTZ
1L1 3L2 5L3
2T1 4T2 6T3
1L1 3L2 5L3 1L1 3L2 5L3
2T1 4T2 6T3 2T1 4T2 6T3
M
3~

9/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
7.2 Control connection wiring diagrams
7.2.1 Connection of PILOT PARC MASTER 1 motor
Case of connection incorporating the maximum controllable PILOT PARC SLAVE units
AUXILIARY CONTACT CONTACTORS
TERMINAL
N°
(onto
terminals)
TERMINAL
N°
(onto
terminals)
73
74
64
63
64
63
53
54 4
3
74
73
24V
24V
PILOT PARC SLAVE
N°1
TERMINAL N°
PILOT PARC MASTER
1 MOTOR
TERMINAL N°
PILOT PARC SLAVE
N°3
TERMINAL N°
PILOT PARC SLAVE
N°2
TERMINAL N°
1 2
54
53
5 6 6
56
5
1
KMgv1 KMgv1 KMgv1KMpv1KMpv1 KMpv1
4
34
214
21
3
13 14
6
PILOT PARC MASTER
1 MOTOR
TERMINAL N° PILOT PARC SLAVE
N° 1
PILOT PARC SLAVE
N° 2
PILOT PARC SLAVE
N° 3
Auxiliary contact
isolator switch INTZ
Auxiliary contact
isolator switch INTZ
Auxiliary contact
isolator switch INTZ
(Note : possibility of other INTZ auxiliary contact serial connection, tted on the fan power supply)
1
2
2
1
2
3
HS command1
LS command
2
Thermal relay info report
3
13 14 13 14

10/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
7.2.2 Connection to 2-motor PILOT PARC MASTER
Case of connecting incorporating the maximum controllable PILOT PARC SLAVE units
565665
3
1
21
2
12
3 4
4
43
5 6 6556
43
1 2
5
4
4
21
3
34
21
PILOT PARC SLAVE
N°1
TERMINAL N°
PILOT PARC MASTER
2 MOTORS
TERMINAL N°
PILOT PARC SLAVE
N°3
TERMINAL N°
PILOT PARC SLAVE
N°2
TERMINAL N°
64
64
64
64
63
63
63
63
74
74
74
74
73
73
73
73
24V
54
54
54
54
53
53
53
53
1
2
3
1
1
1
1
1
2
2
2
2
2
3
AUXILIARY CONTACT CONTACTORS
AUXILIARY CONTACT CONTACTORS TERMINAL N°
(onto terminal)
KMgv1 KMgv1KMgv1
KMpv1KMpv1KMpv1
KMgv2KMgv2KMgv2 KMpv2KMpv2KMpv2
PILOT PARC SLAVE
N°4
TERMINAL N°
PILOT PARC SLAVE
N°6
TERMINAL N°
PILOT PARC SLAVE
N°5
TERMINAL N°
HS command1
LS command
2
Thermal relay info report
3

11/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
PILOT PARC MASTER
2 MOTORS
TERMINAL N°
PILOT PARC SLAVE
N° 1
PILOT PARC SLAVE
N° 4
PILOT PARC SLAVE
N° 2
PILOT PARC SLAVE
N° 5
PILOT PARC SLAVE
N° 3
PILOT PARC SLAVE
N° 6
TERMINAL
N°
(onto
terminal)
24V
13
13
14
14
6
Auxiliary contact
isolator switch INTZ
Auxiliary contact
isolator switch INTZ
Auxiliary contact
isolator switch INTZ
Auxiliary contact
isolator switch INTZ
Auxiliary contact
isolator switch INTZ
Auxiliary contact
isolator switch INTZ
(Note : possibility of other INTZ auxiliary contact serial connection, tted on the fan power supply)
13
13
14
14
13
13
14
14

12/12 NT00000584-PILOT-PARC-ESCLAVE-AN-200723
Non-binding document. With a view to continuously improving equipment, the manufacturer reserves the
right to make any technical modications without giving prior notice.
VIM
Les prés de Mégy Sud – SOUDAN
CS 60120 - 79401 ST MAIXENT L’ECOLE CEDEX
Tel.: [phone] or 05 49 06 60 25 – Fax: [phone]
[email protected] - www.vim.fr
