Vink Spreader User manual

1
Vink Spreader
Vink-elst b.v.
Nijverheidstraat 59
6681 LN Bemmel
Nederland
www.vink-elst.nl
[email protected]
Tel [phone]
Fax [phone]

2
Preface
The Vink spreader is a useful hand tool for spreading all kinds of bedding materials in the boxes like
sawdust and different kinds of chopped dry products. These bedding materials can be mixed with
lime or other powdery substances. Mix equal parts by weight, lime with sawdust, one part of lime with
one part of sawdust. The spreading mechanism is powered by a cordless drill. Most common drills
will fit. The spreader conforms to the European Machine Directives, if applicable.
Technical Information:
Volume: 43 liter
Volume: filled: 8-10 kg
Volume: empty: 4 kg
Material container: LDPE
Minimum chuck capacity: 600 tpm
Minimum action drill chuck: 10 mm
Safety instructions:
Be aware for dust
The apparatus is only to be used by professionals.
Prevent injury caused by moving parts
Do not spread moist bedding materials
Do not spread towards other persons
First remove the drill before you remove the items that has got stuck in the spreading
mechanism.
Use of the spreader
Fill the spreader with bedding materials, if necessary in layer (powdery materials) Please note
other items like rocks and twigs will come in the spreader.
Place the connecting tool on the drill and connect to the drive shaft of the spreading
mechanism
Adjust the length of the supplied belt so that you can handle the drill with an almost straight
arm
The spreader is ready for use!
Attention:
This spreader is not suitable for spreading lime only.
We have a special designed spreader for lime or powdery substances only.
Maintenance and repair
The spreader must be cleaned if necessary but requires no further maintenance. The spreader
mechanism can be replaced in case of damage or wear. Disassemble the bolts on the inside of the
container. The mechanism can be removed and replaced

3
Spare parts
1 Spreader mechanism zs01
2 Container zs02
3 Connecting tool zs03
4 Belt zs04
1 2 3 4
If in doubt, take up contact with your dealer or the manufacturer
EC - Declaration of conformity
Manufacturer: Vink-Elst B.V.
Nijverheidstraat 59, 6681 LN Bemmel, Holland, Tel.[phone],
Fax: [phone],
E-mail: [email protected],
Website: www.vink-elst.nl
We declare that, the Vink spreader
conforms to the Machine Directives 2006/42/EG as recently amended.
G.J. Vink –Managing director May 2013
Vink Warranty
Vink warrants, the spreader will, with normal use and service, be free from faulty parts, manufacture
or workmanship for a period of one (1) year from invoice date.
The warranty does not apply where damage is caused by other factors, including without limitation
Normal wear and tear
Abuse, mishandling, accident or failure to follow operating instructions
Repair by unauthorized person
Damage caused by external influences as floods, fire etc. environmental and atmospheric
disturbances and mechanical damage caused by dropping
This warranty is limited to the exchange of the defective part during its warranty period, Disassembly
and assembly of parts are for the Client’s account
The part/product must be returned to Vink carriage paid.
Replaced parts are warranted for the remainder of the original products warranty period.
