Vintage Vibe Wurly 200A User manual

200 & 200A
Wurlitzer Power Transformers

TABLE OF CONTENTS
PRIMARY WIRING SCHEMATICS.........................PAGE 2
MODEL 200 VINTAGE AMPLIFIER......................PAGE 3
MODEL 200A VINTAGE AMPLIFIER.....................PAGE 4
VINTAGE VIBE CLASSIC 200 AMP.......................PAGE 5
VINTAGE VIBE 200A AMP ................................PAGE 6
1

PRIMARY WIRING SCHEMATIC
120VAC LINE VOLTAGE 240VAC LINE VOLTAGE
2

Model 200 Vintage Amplier:
Solder the transformer’s secondary wires to the corresponding locations on the amplier PCB as indexed in the table below.
BOARD DIAGRAM
TRANSFORMER WIRE AMPLIFIER PCB
RED PIN #10
RED PIN#11
BLUE PIN #9
RED/YELLOW PIN #1
3

Model 200A Vintage Amplier:
Solder the transformer’s secondary wires to the corresponding locations on the amplier PCB as indexed in the table below.
BOARD DIAGRAM
4
TRANSFORMER WIRE AMPLIFIER PCB
RED PIN X1
RED PIN X2
BLUE PIN X3
RED/YELLOW PIN X4

Vintage Vibe Classic 200 Amplier:
Solder the transformer’s secondary wires to the corresponding locations on the amplier PCB as indexed in the table below.
5
Transformer Wire Amplier PCB
Red “RED”
Red “RED”
Blue “BLUE”
Red/Yellow “YEL”
BOARD DIAGRAM

Vintage Vibe 200A Wurly-Vibe Amplier:
Solder the transformer’s secondary wires to the corresponding locations on the amplier PCB as indexed in the table below.
6
Transformer Wire Amplier PCB
Red “R”
Red “R”
Blue “B”
Red/Yellow “R/Y”
BOARD DIAGRAM
