Viotek CanyonBreeze 3 User manual

User Manual
CANYONBREEZE-3
V R H E A D S E T

PRODUCT DESCRIPTION
PRODUCT FEATURES
Optical Axis Slider
"AR"Window Capacitive Touch Button
Headphone/Data line/Chager socket
The CB3 Plus is a newly-developed headset which works with most
smart phones and VR and AR applications. With it, you can play VR
games, AR games, watch 3D movies, or enjoy 360� videos.
Specially-designed lenses system that allows you to adjust spacing
to ensure clear and stable images.
Specific gaps in the padding allow you to keep your glasses on and
still enjoy VR tech.
Altogether a lightweight 290G (0.6lbs), 30% lighter than other
similar products.
Low weight and adjustable headband work together to decrease
pressure against different facial areas.
Unique button compatible with Google Cardboard applications.
Transparent AR window, which can fit for AR function without
removing it.
Airflow vents help release heat generated by phones after long
periods of use.
Peripheral windows allow for the use of your phone’ s AUX, OTG, or
charger ports while you watch.
Slim, ergonomic body style
Fits phone with displays up to 4.7 inches and up to 6 inch displays

INSTRUCTIONS
Assembly:
Insert the headband straps into the corresponding notches. Fold the
strap ends over to secure them using the Velcro sections. Next, put on
the headset to test the fit and adjust the straps if needed.
Size Range:
The CB3 fits phones with displays up to
4.7 in. (119mm) and accommodated a
display up to a total length of
approximately 6in. (152mm).
Configuration:
Download the Google Cardboard app and use it to scan the QR code
below. This will optimize the app for the CB3.
It is recommended to use apps which rely on and/or are
found through the Google Cardboard app as these have
been tested and formatted for high quality.

Insert the headband straps into the corresponding notches. Fold the
strap ends over to secure them using the Velcro sections. Next, put on
the headset to test the fit and adjust the straps if needed.
Activate a VR app and use it to open a video or image. Close the lid
securely and put on the CB3. If the image is unclear, this may be due
to your pupillary distances (PD). Adjust the optical axis sliders until the
image is clear.
The CB3’s lenses can accommodate pupillary distances (PD) of
53-72mm. Any eye care professional can measure your PD if desired.
Assuming any necessary adjustments have been made, you may now
enjoy your CB3.
**Note, some apps may be interactive. For these types, use the
Capacitive Touch Button.
Using the CB3:
Open the lid of the CB3. Center your phone with the screen facing
towards the lens on the inside of the lid and press gently close the lid to
secure the phone in place.

CAPACITIVE TOUCH BUTTON
This button is located on the bottom of the CB3 and simulates touches
against the screen of your phone. The button works with Google
Cardboard, which means all games and apps available through Google
Cardboard are fully compatible with the CB3.
WHERE TO FIND VR CONTENT:
For 3D movies or videos, search "side by side 3D" in YouTube or
other video websites on your phone, and use full screen to watch.
For VR apps, search with the keywords such as "VR" or "card-
board" in the Google Play Store or iOS App Store. Check to make
sure any apps you download are in side by side format.
Copy 3D side by side videos from your computer or cloud storage
to your phone and use a video player in your phone to watch.
Copy 3D side by side videos into a USB and connect it to your
phone via an OTG data line. Open the video player on your phone
to watch. Typically, this method can only be used with Android
phones as modern models are likely to have an OTG function.
Any other side by side 3D content may also be used with the CB3.
The capacitive parameters of phones differ. If the button sensitivity
seems low or does not work, try pressing harder. It’ s possible you
may need to fully press the button so that its surface reaches your
phone.

WARNING:
When cleaning, please note the front lid and the lenses are all
make of acrylic material. Please use purified or distilled water and
soft cloth to clean them. If the mess cannot be removed with water,
apply a gentle cleaner or detergent to the cloth and clean. Do not
apply any cleaner or detergent directly to the CB3. After cleaning
with any cleaner or detergent, rinse with purified or distilled water
and dry so as not to leave cleaner residue on the CB3.
After using the CB3, place it in a stable location or container where
it will be come in contact with or be scratched by abrasive materi-
als.
NEVER put CanyonBreeze-3 under the direct sunlight. As the
lenses are some type of convex lenses, direct sunlight might be
focused by the lenses and will generate very high power and might
cause fire.
