IN!lines!from!the!ViperONE!unit!or!the!pressure!container.!!Once!the!air!is!disconnected!and!the!Air!Release!Valve!is!opened!on!the!
pressure!container,!the!container!can!easily!be!opened!and/or!lines!disconnected.!!
!
Use!a!1/4”!quick!connect!for!the!air!in!source.!The!output!pressure!on!the!air!compressor!should!be!set!to!a!maximum!of!75!psi!
output.!The!pressure!gauge!on!the!2!quart!container!should!read!40!psi.!Adjust!as!necessary.!!!
!
At!this!point!there!should!be!no!air!leaking!from!the!pressure!container!or!inside!the!ViperONE.!If!there!is!an!air!leak!check!that!all!
supply!tubes!are!firmly!seated!and!that!the!lid!of!the!pressure!container!is!securely!tightened.!
!
!
!
WHAT*IS*ON*THE*CONTROL*PANEL?*
*
•Start*Button:!Pressing!the!button!will!initiate!the!ViperONE!to!spray!the!shirt.!Quickly!press!and!release!the!Start!button.!DO!
NOT!HOLD!IN.!
•E$Stop*Button:!Depressing!this!will!exhaust!all!the!pressure!in!the!ViperONE!
causing!all!functionality!to!stop.!
•Spray*Adjustment*Knob:!The!knob!is!a!multi>turn!knob.!Rotating!fully!
clockwise!will!completely!shut!air!off!to!the!system!and!the!unit!will!not!run!
or!spray.!Turning!the!knob!counter!clockwise!will!increase!the!speed!of!the!
spray!head,!resulting!in!less!fluid!applied!to!the!shirt.!!See!the!GRAMS!OF!
LAYDOWN!PER!NUMBER!OF!TURNS!chart!in!Figure!3!to!select!the!desired!
amount.!
!
*
Adjusting*the*Spray*Length*
There!is!a!slot!on!the!right!side!of!the!ViperONE!with!an!adjusting!knob.!!This!knob!can!be!loosened!and!moved,!then!re>tightened.!DO!
NOT!COMPLETELY!REMOVE.!Use!the!ruler!on!the!side!of!the!unit!to!set!spray!length.!
!
Loading*the*Shirt*
The!shirt!collar!needs!to!be!located!closest!to!the!operator!on!the!platen.!!It!is!easiest!if!you!
hold!the!shirt!up!so!that!the!bottom!hem!of!the!shirt!drops!into!the!gap!between!the!back!of!
the!platen!and!the!front!of!the!ViperONE.!You!can!then!pull!the!garment!out!and!position!the!
collar!to!a!desired!location.!
!
Make!sure!that!the!shirt!is!completely!smooth!and!the!edges!are!tucked!under!the!platen!
before!closing!the!slide!drawer.!The!shirt!will!help!create!a!seal!that!keeps!the!airborne!mist!
and!over!spray!inside!the!spray!chamber.!
!
TIP:!For!loading!thicker!garments!such!as!sweatshirts,!remove!the!black!half>round!bar!on!the!
front!of!the!platen!to!allow!for!more!room!for!the!garment!to!go!into!the!ViperONE!spray!
chamber!without!catching.!!
!
Spraying*the*Shirt*
Firmly!close!the!drawer!once!the!shirt!is!in!position.!Press!the!green!START!button.!DO*NOT*HOLD*IN*START*BUTTON.*After!spraying,!
carefully*remove!the!garment!and!cure!the!pre>treatment!according!to!manufacturer’s!specifications.!
! !
