VIRDI AC-2200 User manual

Copyright 2000 By Union Community Co., Ltd.
AC-2200 .USER GUIDE
Version kor-1.08

AC-2200 User Guide
2
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
<Revison History>
Version
Date
Description
Firmware Version
1.00
2015-09-01
-Initial Release
10.61.00-000.00
1.01
2015-10-18
-Form Change
10.61.00-000.02
1.02
2015-12-28
-Modify Display
10.61.00-000.09
1.03
2015-01-18
-Error Correction
-Add Default Setting
-Add LFD Setting
-Add UDL Setting
1x.61.00-000.12
(Version Change)
1.04
2016-01-26
-Modify SN-related Information
1x.61.00-000.14
1.05
2016-01-29
-Modify Misspelling
1x.61.00-000.15
1.06
2016-02-05
-Modify Misspelling
1x.61.00-000.16
1.07
2016-03-07
-Add a reboot phrase after setting
1x.61.00-000.20
1.08
2016-03-18
-Complete a Korean version of manual
1x.61.00-000.22

AC-2200 User Guide
3
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
<Glossaries>
Administrator (Admin)
-The administrator can access to the terminal menu mode. He/she has the authority to
add/modify/delete terminal users and to change the operating environment by changing
settings.
-If there is no registered administrator in the terminal, anybody can access to the terminal menu
and change settings. It is recommended that more than one administrator will be
necessarily registered in the terminal.
-The administrator has the authority to change critical environmental settings of the fingerprint
reader. So, special attention is required to its registration and operation.
1:1 Authentication
-The user fingerprint is verified after entering User ID or Card.
-Only User ID or the user fingerprint registered to the card is compared. This is called One-to-
One Authentication.
1:N Authentication
-The user is identified only by the fingerprint.
-The same fingerprint as the input fingerprint is identified among the registered fingerprints
without User ID or Card entered. This is called One-to-N Identification.
Authentication Level
-As a level used for fingerprint authentication, it is displayed in Step 1 to 9. Authentication
cannot be allowed before the degree of match between two fingerprints is higher than the set
authorization level.
-The higher authentication level may ensure the higher security. But it requires the relatively
high concordance rate. When authenticating User ID, it high likely to deny authentication.
-1:1 Level: Authentication level used for one-to-one authentication
-1:N Level: Authentication level used for one-to-n authentication
Authentication Method
-This refers to various types of authentication methods composed of each combination of
FP(Footprint) and RF(Card) and so forth.
Ex) Card or FP: Authenticated by either card or fingerprint
Function Key
-This refers to [F1], [F2], [F3], and [F4] keys, which enable users to access the menu or change
the mode such asAttend or Leave.

AC-2200 User Guide
4
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
Table of Contents
<Revison History>....................................................................................................................2
<Glossaries> .............................................................................................................................3
Table of Contents .....................................................................................................................4
1. Before Getting Started.........................................................................................................6
1.1. Safety Notes.................................................................................................................6
1.2. Product Details ...........................................................................................................7
1.3. Buttons displayed during operation.........................................................................8
1.4. ViRDI logo LED signals displayed during operation..............................................8
1.5. Screens displayed during operation..........................................................................8
1.5.1. Icon Information..............................................................................................9
1.5.2. Message Information.......................................................................................9
1.6. Voice guide announced during operation...............................................................13
1.7. Buzzer guide announced during operation............................................................13
1.8. How to register and enter correct fingerprint.......................................................13
2. Product Description...........................................................................................................15
2.1. Product Features ......................................................................................................15
2.2. Configuration Diagram ...........................................................................................17
2.2.1. Standalone Use (Access)...............................................................................17
2.2.2. Connecting the PC server (access, T&A, food service control)....................17
2.3. Product Specification...............................................................................................18
3. Environment Setting..........................................................................................................19
3.1. Checkpoints before environment setting................................................................19
3.1.1. Enter the menu ..............................................................................................19
3.1.2. Modify settings..............................................................................................20
3.1.3. Save after completion of environment setting...............................................20
3.2. Menu Configuration.................................................................................................21
3.3. User Management ....................................................................................................24
3.3.1. Add User........................................................................................................24
3.3.2. Delete User....................................................................................................27
3.3.3. Modify User ..................................................................................................28
3.3.4. Add Administrator.........................................................................................31
3.3.5. Delete All Users ............................................................................................31
3.4. Network Setting........................................................................................................32
3.4.1. Terminal ID ...................................................................................................32
3.4.2. IP Setting.......................................................................................................34
3.4.3. Server IP Setting............................................................................................35
3.5. Option Setting...........................................................................................................39
3.5.1. Application Setting........................................................................................39

AC-2200 User Guide
5
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
3.5.2. Authentication Method Setting......................................................................43
3.5.3. Door Setting ..................................................................................................47
3.5.4. Volume Setting..............................................................................................48
3.5.5. Camera Setting..............................................................................................49
3.5.6. Current Time Setting.....................................................................................50
3.5.7. RS485 Set......................................................................................................51
3.5.8. Mobile Key Setting .......................................................................................52
3.6. Terminal Information Inquiry ................................................................................53
3.7. Additional Function .................................................................................................54
3.7.1. Terminal Lock Setting...................................................................................54
3.7.2. Card Number Inquiry....................................................................................55
3.7.3. Monitor Input Port Setting ............................................................................55
3.7.4. Duress FP Setting..........................................................................................57
3.8. Device Setting............................................................................................................58
3.8.1. System Configuration....................................................................................58
3.8.2. Card Reader Format Setting..........................................................................59
3.8.3. Fingerprint Sensor Setting.............................................................................59
3.8.4. Wiegand Speaker Output...............................................................................61
3.8.5. Terminal Initialization...................................................................................63
3.8.6. External Device Setting.................................................................................65
4. How to Use Terminal .........................................................................................................68
4.1. When operating to [1.Access]..................................................................................68
4.1.1. Authentication Mode.....................................................................................68
4.1.2. Authentication Using Fingerprint..................................................................68
4.1.3. Authentication Using Card............................................................................69
4.2. When operating to [2.T&A] ....................................................................................71
4.2.1. Authentication Mode.....................................................................................71
4.2.2. Fingerprint Authentication ............................................................................71
4.2.3. Authentication Using Card............................................................................71
4.3. When operating to [2.Cafeteria] .............................................................................71

AC-2200 User Guide
6
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
1. Before Getting Started
1.1. Safety Notes
Warning
Do not operate the terminal
with wet hands, and pay
attention not to let any liquid
such as water enter inside the
terminal.
→Otherwise, malfunction or
electric shock may be caused.
Keep the terminal away from
inflammables.
→ Otherwise, it may cause a
fire.
Do not disassemble, repair or
remodel the terminal at your
disposal.
→ Otherwise, it may cause
malfunction, electric shock, or
a fire.
Do not allow children to
touch the terminal carelessly.
→ Otherwise, it may cause
safety accidents of children
or malfunction.
- Non-compliance of safety notes may cause death or serious injury for users.
Cautions
Do not install the terminal in a
place exposed to direct
sunlight.
→ Otherwise, it may cause
malfunction, deformation and
discoloration.
Do not install the terminal in
humid or dusty places.
→ Otherwise, it may cause
malfunction.
Do not clean this terminal by
sprinkling water, nor wipe it
with benzene, thinner, and
alcohol.
→ Otherwise, it may cause
electric shock or a fire.
Keep the terminal away from
magnets.
→ Otherwise, it may cause
failure and malfunction.
Keep the fingerprint input
section clean.
→ Otherwise, the fingerprint
cannot be recognized correctly.
Do not spray insecticides or
inflammables on the
terminal.
→ Otherwise, it may cause
deformation and
discoloration.
Keep the terminal away from
shock or sharp objects.
→ Otherwise, it may damage
the terminal and result in
malfunction.
Do not install the terminal in
a place where there is a
severe change in
temperature.
→ Otherwise, it may cause
malfunction.
- Non-compliance of safety notes may cause personal injury or property damage for users.
※We are not responsible for any accidents and damage that may arise from non-compliance of
the information in this manual.

AC-2200 User Guide
7
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
1.2. Product Details

AC-2200 User Guide
8
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
1.3. Buttons displayed during operation
F1
-Switch to ‘Attend’ mode from the default screen.
-Used to move up or increase [↑] in the menu mode
F2
-Switch to ‘Leave’ mode from the default screen.
-Used to move down or decrease [↓] in the menu mode.
F3
-Switch to ‘Outdoor’ mode from the default screen.
-When pressing for more than 2 seconds, you enter the menu mode:
[F3~]
-Used to escape [ESC] or move left [] in the menu mode.
When pressing for more than two seconds, this is used to [ESC] button:
[ESC~]
F4
-Switch to ‘Return’ mode from the default screen.
Pressing it again in the ‘Return’ mode is changed to ‘Access’ mode.
-Used to enter [ENT] or move right [] in the menu mode.
When pressing for more than two seconds, this is used to [ENT] button:
[F4~]
1.4. ViRDI logo LED signals displayed during operation
ViRDI
Power
Blue
On: Normal
Flickering: Under Bluetooth communication
ViRDI
Door
Green
On: Door Open
Off: Door Close
ViRDI
Alarm
Red
Off: Normal
Flickering: Case Open or Lock Controller Communication
Error
※The LED may light on simultaneously in some cases. (Ex. Red and Blue flicker)
1.5. Screens displayed during operation
Displays the current time
- When access control: Displays access mode (F1, F2, F3, F4,
Access)
- When T&A control: Displays Attend/Leave mode (Attend,
Leave, Outdoor, Return)
- When food service control: Displays the menu and current
meal time countdown
Displays Status icon and Access mode

AC-2200 User Guide
9
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
1.5.1. Icon Information
①Fire Detection
A fire is detected by the fire detection sensor.
②Door Status
The door is open.
③Server
Connection
Status
The LAN cable is not connected.
Only Link is connected.
④USB
Connection
The USB is connected. (USB port is service port.)
1.5.2. Message Information
-The default screen of AC2200
-The fingerprint is being input or on standby.
-When authentication is successful

AC-2200 User Guide
10
Union Community / (138-050) 5th Fl., Hyundai Topics Building, 44-3, Bangi-dong, Songpa-
gu, Seoul, Korea // Tel : [phone] , Fax : [phone]
E-mail: [email protected]; http://www.unioncomm.co.kr
-When authentication fails
-When fingerprint input fails
-If your finger is released too early before your fingerprint is
entered
-When an unregistered card is entered
-When 1:N Authentication is attempted under the condition that
authentication priority is SN and there is no user who has been
allowed for 1:N Authentication
-When anti-passback is in error
-When the server cannot handle too many authentication requests
from the terminal
