Vishay TSOP61 Series User manual

IR Receiver Modules for Remote Control Systems
www.vishay.com Document Number: 82176
178 Rev. 1.7, 10-Jun-08
TSOP61..
Vishay Semiconductors
MECHANICAL DATA
Pinning
1 = GND, 2 = GND, 3 = VS, 4 = OUT
DESCRIPTION
The TSOP61.. series are miniaturized SMD-IR receiver
modules for infrared remote control systems. PIN diode and
preamplifier are assembled on lead frame, the epoxy
package is designed as IR filter.
The demodulated output signal can directly be decoded by a
microprocessor. The main benefit is the operation with short
burst transmission codes and high data rates.
This component has not been qualified according to
automotive specifications.
FEATURES
• Photo detector and preamplifier in one package
• Internal filter for PCM frequency
• Continuous data transmission possible
• TTL and CMOS compatibility
• Output active low
• Low power consumption
• Lead (Pb)-free component
• Component in accordance to RoHS 2002/95/EC and
WEEE 2002/96/EC
SPECIAL FEATURES
• Enhanced data rate up to 4000 bit/s
• Operation with short burst possible (≥6 cycles/burst)
• Taping available for topview and sideview assembly
BLOCK DIAGRAM APPLICATION CIRCUIT
16797
1234
e3
PARTS TABLE
CARRIER FREQUENCY SHORT BURSTS AND HIGH DATA RATES (AGC1)
30 kHz TSOP6130
33 kHz TSOP6133
36 kHz TSOP6136
36.7 kHz TSOP6137
38 kHz TSOP6138
40 kHz TSOP6140
56 kHz TSOP6156
3
1;2
4
16838
Input AGC Band
pass
Demo-
dulator
Control circuit
PIN
25 kΩ
V
S
OUT
GND
C1 =
4.7 µF
TSOPxxxx
GND
Circuit
µC
R1 = 100 Ω
+ VS
GND
Transmitter
with
TSALxxxx
VS
R1and C1recommended to suppress power supply
disturbances. The output voltage should not be
hold continuously at a voltage belowVO= 2.0 V
by the external circuit.
VO
17170
OUT

Document Number: 82176 www.vishay.com
Rev. 1.7, 10-Jun-08 179
TSOP61..
IR Receiver Modules for
Remote Control Systems Vishay Semiconductors
Note
(1) Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating only
and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this specification
is not implied. Exposure to absolute maximum rating condtions for extended periods may affect the device reliability.
Note
(1) Tamb = 25 °C, unless otherwise specified
TYPICAL CHARACTERISTICS
Tamb = 25 °C, unless otherwise specified
Fig. 1 - Output Function Fig. 2 - Pulse Length and Sensitivity in Dark Ambient
ABSOLUTE MAXIMUM RATINGS (1)
PARAMETER TEST CONDITION SYMBOL VALUE UNIT
Supply voltage (pin 3) VS- 0.3 to + 6.0 V
Supply current (pin 3) IS3mA
Output voltage (pin 1) VO- 0.3 to (VS+ 0.3) V
Output current (pin 1) IO10 mA
Junction temperature Tj100 °C
Storage temperature range Tstg - 40 to + 100 °C
Operating temperature range Tamb - 25 to + 85 °C
Power consumption Tamb ≤85 °C Ptot 30 mW
ELECTRICAL AND OPTICAL CHARACTERISTICS (1)
PARAMETER TEST CONDITION SYMBOL MIN. TYP. MAX. UNIT
Supply current Ev= 0 ISD 0.7 1.2 1.5 mA
Ev= 40 klx, sunlight ISH 1.3 mA
Supply voltage VS2.7 5.5 V
Transmission distance Ev= 0, test signal see fig. 1, IR diode TSAL6200,
IF= 250 mA d35m
Output voltage low IOSL = 0.5 mA, Ee= 0.7 mW/m2,
test signal see fig. 1 VOSL 250 mV
Minimum irradiance
(30 to 40 kHz)
VS= 3 V, pulse width tolerance:
tpi - 5/fo< tpo < tpi + 6/fo, test signal see fig. 1 Ee min. 0.35 0.5 W/m2
Minimum irradiance
(56 kHz)
VS= 3 V, pulse width tolerance:
tpi - 5/fo< tpo < tpi + 6/fo, test signal see fig. 1 Ee min. 0.4 0.6 W/m2
Minimum irradiance
(30 to 40 kHz)
VS= 5 V, pulse width tolerance:
tpi - 5/fo< tpo < tpi + 6/fo, test signal see fig. 1 Ee min. 0.45 0.6 W/m2
Minimum irradiance
(56 kHz)
VS= 5 V, pulse width tolerance:
tpi - 5/fo< tpo < tpi + 6/fo, test signal see fig. 1 Ee min. 0.5 0.7 W/m2
Maximum irradiance tpi - 5/fo< tpo < tpi + 6/fo, test signal see fig. 3 Ee max. 30 W/m2
Directivity Angle of half transmission distance ϕ1/2 ± 45 deg
E
e
T
t
pi
*
t
* t
pi
10/f
0
is recommended for optimal function
V
O
V
OH
V
OL
t
16110
Optical Test Signal
(IR diode TSAL6200, IF= 0.4 A, 30 pulses, f = f0, t = 10 ms)
Output Signal
t
d1)
t
po2)
1)
7/f
0
<t
d
<15/f
0
2)
t
pi
- 5/f
0
<t
po
< t
pi
+ 6/f
0
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
0.1 1 10 100 1000 10 000
Ee- Irradiance (mW/m²)
16908
Input Burst Duration
= 950 nm,
optical test signal, fig. 1
Output Pulse
t - Output Pulse Width (ms)
po

www.vishay.com Document Number: 82176
180 Rev. 1.7, 10-Jun-08
TSOP61..
Vishay Semiconductors IR Receiver Modules for
Remote Control Systems
Fig. 3 - Output Function
Fig. 4 - Output Pulse Diagram
Fig. 5 - Frequency Dependence of Responsivity
Fig. 6 - Sensitivity in Bright Ambient
Fig. 7 - Sensitivity vs. Supply Voltage Disturbances
Fig. 8 - Sensitivity vs. Electric Field Disturbances
Ee
t
VO
VOH
VOL t
600 µs 600 µs
t = 60 ms
ton toff
94 8134
Optical Test Signal
Output Signal, (see fig. 4)
T ,T - Output Pulse Width (ms)
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
0.1 1 10 100 1000 10 000
Ee- Irradiance (mW/m²)
16909
Toff
= 950 nm,
optical test signal, fig. 3
Ton
on off
0.0
0.2
0.4
0.6
0.8
1.0
1.2
0.7 0.9 1.1 1.3
f/f0- Relative Frequency16925
f = f0± 5 %
Δf(3 dB) = f0/10
E /E - Rel. Responsivity
e min. e
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
0.01 0.1 1 10 100
E - Ambient DC Irradiance (W/m2)16911
Correlation with ambient light sources:
10 W/m21.4 klx (Std.illum.A, T= 2855 K)
10 W/m28.2 klx (Daylight, T= 5900 K)
Ambient, = 950 nm
Ee min. - Threshold Irradiance (mW/m2)
0.0
0.5
1.0
1.5
2.0
0.1 1 10 100 1000
V
sRMS
- AC Voltage on DC Supply Voltage (mV)
16912
f = fo
f = 10 kHz
Ee min. - Threshold Irradiance (mW/m²)
f = 1 kHz
f = 100 Hz
Ee min. - Threshold Irradiance (mW/m²)
0.0 0.4 0.81.2 1.6
0.0
0.4
0.8
1.2
2.0
E - Field Strength of Disturbance (kV/m)
2.0
94 8147
1.6
f(E) = f0

Document Number: 82176 www.vishay.com
Rev. 1.7, 10-Jun-08 181
TSOP61..
IR Receiver Modules for
Remote Control Systems Vishay Semiconductors
Fig. 9 - Max. Envelope Duty Cycle vs. Burstlength
Fig. 10 - Sensitivity vs. Ambient Temperature
Fig. 11 - Relative Spectral Sensitivity vs. Wavelength
Fig. 12 - Directivity
Fig. 13 - Sensitivity vs. Supply Voltage
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
020406080 100 120
Burst Length (number of cycles/burst)
16914
f = 38kHz, Ee= 2 mW/m2
Max. Envelope Duty Cycle
0.0
0.1
0.2
0.3
0.4
0.5
0.6
- 30 - 15 0 15 30 45 60 75 90
T
amb
- Ambient Temperature (°C)
16918
Sensitivity in dark ambient
E - Threshold Irradiance (mW/m²)
e min.
0.0
0.2
0.4
0.6
0.8
1.0
1.2
750 850 950 1050 1150
λ-Wavelength (nm)
16919
S ( ) - Relative Spectral Sensitivityλ
rel
16801
0.4 0.2 0 0.2 0.4 0.6 0.6
0.9
0°
30°
10° 20°
40°
50°
60°
70°
80°
1.0
0.8
0.7
drel - Relative Transmission Distance
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0
VS- Supply Voltage (V)
17185
E - Sensitivity (mW/m )
2
e min.

www.vishay.com Document Number: 82176
182 Rev. 1.7, 10-Jun-08
TSOP61..
Vishay Semiconductors IR Receiver Modules for
Remote Control Systems
SUITABLE DATA FORMAT
The circuit of the TSOP362.. is designed so that unexpected
output pulses due to noise or disturbance signals are
avoided. A bandpass filter, an integrator stage and an
automatic gain control are used to suppress such
disturbances.
The distinguishing mark between data signal and
disturbance signal are carrier frequency, burst length and
duty cycle.
The data signal should fulfill the following conditions:
• Carrier frequency should be close to center frequency of
the bandpass (e.g. 38 kHz).
• Burst length should be 10 cycles/burst or longer.
• After each burst which is between 10 cycles and 70 cycles
a gap time of at least 14 cycles is necessary.
• For each burst which is longer than 1.8 ms a corresponding
gap time is necessary at some time in the data stream.
This gap time should be at least 6 times longer than the
burst
• Up to 800 short bursts per second can be received
continuously
Some examples for suitable data format are: NEC code
(repetitive pulse), NEC code (repetitive data), Toshiba
Micom Format, Sharp code, RC5 code, RC6 code, R-2000
code, Sony code.
When a disturbance signal is applied to the TSOP362.. it can
still receive the data signal. However the sensitivity is
reduced to that level that no unexpected pulses will occur.
Some examples for such disturbance signals which are
suppressed by the TSOP362.. are:
• DC light (e.g. from tungsten bulb or sunlight)
• Continuous signal at 38 kHz or at any other frequency
• Signals from fluorescent lamps with electronic ballast with
high or low modulation (see figure 14 or 15)
Fig. 14 - IR Signal from Fluorescent Lamp with Low Modulation
Fig. 15 - IR Signal from Fluorescent Lamp with High Modulation
0101520
Time (ms)
16920
IR Signal
IR Signal from Fluorescent
Lamp with LowModulation
5
0101520
Time (ms)
16921
IR Signal
IR Signal from Fluorescent
Lamp with High Modulation
10

Document Number: 82176 www.vishay.com
Rev. 1.7, 10-Jun-08 183
TSOP61..
IR Receiver Modules for
Remote Control Systems Vishay Semiconductors
PACKAGE DIMENSIONS
ASSEMBLY INSTRUCTIONS
Reflow Soldering
• Reflow soldering must be done within 72 h while stored
under a max. temperature of 30 °C, 60 %RH after opening
the dry pack envelope
• Set the furnace temperatures for pre-heating and heating
in accordance with the reflow temperature profile as shown
in the diagram. Excercise extreme care to keep the
maximum temperature below 260 °C. The temperature
shown in the profile means the temperature at the device
surface. Since there is a temperature difference between
the component and the circuit board, it should be verified
that the temperature of the device is accurately being
measured
• Handling after reflow should be done only after the work
surface has been cooled off
Manual Soldering
• Use a soldering iron of 25 W or less. Adjust the
temperature of the soldering iron below 300 °C
• Finish soldering within 3 s
• Handle products only after the temperature has cooled off
16629

www.vishay.com Document Number: 82176
184 Rev. 1.7, 10-Jun-08
TSOP61..
Vishay Semiconductors IR Receiver Modules for
Remote Control Systems
VISHAY LEAD (Pb)-FREE REFLOW SOLDER PROFILE
TAPING VERSION TSOP..TT dimensions in millimeters
0
50
100
150
200
250
300
0 50 100 150 200 250 300
t (s)
T (°C)
255 °C
240 °C 245 °
C
max. 260 °C
max. 120 s max. 100 s
217 °C
max. 20 s
max. Ramp Up 3 °C/s max. Ramp Down 6 °C/s
max. 2 cycles allowed
19800
16584

Document Number: 82176 www.vishay.com
Rev. 1.7, 10-Jun-08 185
TSOP61..
IR Receiver Modules for
Remote Control Systems Vishay Semiconductors
TAPING VERSION TSOP..TR dimensions in millimeters
16585

www.vishay.com Document Number: 82176
186 Rev. 1.7, 10-Jun-08
TSOP61..
Vishay Semiconductors IR Receiver Modules for
Remote Control Systems
REEL DIMENSIONS in millimeters
LEADER AND TRAILER dimensions in millimeters
COVER TAPE PEEL STRENGTH
According to DIN EN 60286-3
0.1 to 1.3 N
300 ± 10 mm/min.
165° to 180° peel angle
LABEL
Standard bar code labels for finished goods
The standard bar code labels are product labels and used for
identification of goods. The finished goods are packed in final
packing area. The standard packing units are labeled with
standard bar code labels before transported as finished
goods to warehouses. The labels are on each packing unit
and contain Vishay Semiconductor GmbH specific data.
16734
Trailer Leader
no devices
min.
200 min. 400
StartEnd
devices
96 11818
no devices

Document Number: 82176 www.vishay.com
Rev. 1.7, 10-Jun-08 187
TSOP61..
IR Receiver Modules for
Remote Control Systems Vishay Semiconductors
DRY PACKING
The reel is packed in an anti-humidity bag to protect the
devices from absorbing moisture during transportation and
storage.
FINAL PACKING
The sealed reel is packed into a cardboard box. A secondary
cardboard box is used for shipping purposes.
RECOMMENDED METHOD OF STORAGE
Dry box storage is recommended as soon as the aluminum
bag has been opened to prevent moisture absorption. The
following conditions should be observed, if dry boxes are not
available:
• Storage temperature 10 °C to 30 °C
• Storage humidity ≤60 %RH max.
After more than 72 h under these conditions moisture
content will be too high for reflow soldering.
In case of moisture absorption, the devices will recover to the
former condition by drying under the following condition:
192 h at 40 °C + 5 °C/ - 0 °C and < 5 %RH (dry air/nitrogen)
or
96 h at 60 °C + 5 °C and < 5 %RH for all device containers or
24 h at 125 °C + 5 °C not suitable for reel or tubes.
An EIA JEDEC standard JESD22-A112 level 4 label is
included on all dry bags.
Example of JESD22-A112 level 4 label
VISHAY SEMICONDUCTOR GMBH STANDARD BAR CODE PRODUCT LABEL (Finished Goods)
PLAIN WRITING ABBREVIATION LENGTH
Item-description - 18
Item-number INO 8
Selection-code SEL 3
LOT-/serial-number BATCH 10
Data-code COD 3 (YWW)
Plant-code PTC 2
Quantity QTY 8
Accepted by ACC -
Packed by PCK -
Mixed code indicator MIXED CODE -
Origin xxxxxxx+ Company logo
LONG BAR CODE TOP TYPE LENGTH
Item-number N 8
Plant-code N 2
Sequence-number X 3
Quantity N 8
Total length - 21
SHORT BAR CODE BOTTOM TYPE LENGTH
Selection-code X 3
Data-code N 3
Batch-number X 10
Filter - 1
Total length - 17
Aluminum bag
Label
Reel
15973
16943

www.vishay.com Document Number: 82176
188 Rev. 1.7, 10-Jun-08
TSOP61..
Vishay Semiconductors IR Receiver Modules for
Remote Control Systems
ESD PRECAUTION
Proper storage and handling procedures should be followed
to prevent ESD damage to the devices especially when they
are removed from the antistatic shielding bag. Electro-static
sensitive devices warning labels are on the packaging.
VISHAY SEMICONDUCTORS STANDARD
BAR CODE LABELS
The Vishay Semiconductors standard bar code labels are
printed at final packing areas. The labels are on each
packing unit and contain Vishay Semiconductors specific
data.
16962

Document Number: 82176 www.vishay.com
Rev. 1.7, 10-Jun-08 189
TSOP61..
IR Receiver Modules for
Remote Control Systems Vishay Semiconductors
OZONE DEPLETING SUBSTANCES POLICY STATEMENT
It is the policy of Vishay Semiconductor GmbH to
1. Meet all present and future national and international statutory requirements.
2. Regularly and continuously improve the performance of our products, processes, distribution and operating systems with
respect to their impact on the health and safety of our employees and the public, as well as their impact on the environment.
It is particular concern to control or eliminate releases of those substances into the atmosphere which are known as ozone
depleting substances (ODSs).
The Montreal Protocol (1987) and its London Amendments (1990) intend to severely restrict the use of ODSs and forbid their use
within the next ten years. Various national and international initiatives are pressing for an earlier ban on these substances.
Vishay Semiconductor GmbH has been able to use its policy of continuous improvements to eliminate the use of ODSs listed in
the following documents.
1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments respectively.
2. Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental Protection Agency
(EPA) in the USA.
3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C (transitional substances) respectively.
Vishay Semiconductor GmbH can certify that our semiconductors are not manufactured with ozone depleting substances and do
not contain such substances.
We reserve the right to make changes to improve technical design
and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each customer application by the
customer. Should the buyer use Vishay Semiconductors products for any unintended or unauthorized application, the buyer shall
indemnify Vishay Semiconductors against all claims, costs, damages, and expenses, arising out of, directly or indirectly, any
claim of personal damage, injury or death associated with such unintended or unauthorized use.
Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany

Document Number: 91000 www.vishay.com
Revision: 18-Jul-08 1
Disclaimer
Legal Disclaimer Notice
Vishay
All product specifications and data are subject to change without notice.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf
(collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein
or in any other disclosure relating to any product.
Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any
information provided herein to the maximum extent permitted by law. The product specifications do not expand or
otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed
therein, which apply to these products.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any conduct of Vishay.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless
otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such
applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting
from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding
products designed for such applications.
Product names and markings noted herein may be trademarks of their respective owners.
