VISIO VD-T User manual

5-
VD-T
User Manual
Please read the instructions carefully before use

4-
Notion: For the Manual Setting you can operate the unit in two ways：
1. Choose all fixtures, to set up the functions step by step.
2. Choose one operation step, to set up fixture by fixture.
1-
Features
VD-T is a specially designed handy setup tool for all Visio integral fixtures and
Controllers. By connecting VD-T to any fixture via XLR, user can easily setup
DMX address, Channel modes, White Balance, Manual Colors, Fade Speed
and other functions on the Visio LED fixtures.
Technical specifications
Power input: 6F22 9V battery
Dimension: 128 x 23 x 70mm
Weight: 0.158 kg

2-
Main Function
Press MENU button to enter menu mode, press Function button until the
required one is shown on the display. Select the function by ENTER button.
Use Function button to change the mode. Once the required mode has
been selected, press ENTER button to setup. Back to the functions without any
change press MENU button. The main functions are shown below:
DMX 512 Address Setting
Press the MENU button, press ENTER button to enter, use the
Function select the Address setting, the unit you selected will
lighting in green. Press ENTER button use DATE button to
change the DMX 512 address, once the address has been selected,
press ENTER button to setup.
3-
Channel Mode
Press the MENU button, press ENTER button to enter, use the
Function select the channel mode, the unit you select will
lighting in green. Press ENTER button use DATE button to
select channel modes,once selected, press ENTER button to setup.
White Balance
Press the MENU button, press ENTER button to enter, use the
Function select the white balance, the unit you select will
lighting in green. Press ENTER button to enter use DATE to
select ON or OFF, once ON has been selected, press ENTER
button to setup. Use Function to select the red, green, blue,
cool, warm and amber. Then use DATE button to adjust the
white balance (125-255),once selected, press ENTER button to
setup.
Manual Color
Press the MENU button, press ENTER button to enter, use the
Function select the manual color, the unit you selected will
lighting in green. Press ENTER button to enter use DATE to
select ON or OFF, once ON has been selected, press ENTER
button to setup. Use Function to select the red, green, blue,
cool, warm, amber and strobe. Then use DATE button to adjust
the manual color (0-255),once selected, press ENTER button to
setup.
.
Fade Speed
Press the MENU button, press ENTER button to enter, use the
Function select the fade speed, the unit you selected will
lighting in green. Press ENTER button to enter use DATE to
select ON or OFF, once ON has been selected, press ENTER
button to setup. Use DATE button to adjust the fade speed
(0-255),once selected, press ENTER button to setup.
