QUICK START GUIDE - REFURBISHED SOUND BAR
Model: R-
SB3621n-E8
VIZIO Sound Bar
Please read this guide before using the product.
English - ii
Your Unit is designed and manufactured to operate within dened design limits, and misuse may result in electric shock or re. To prevent your Unit
from being damaged, the following rules should be observed for its installation, use, and maintenance. Please read the following safety instructions
before operating your Unit. Keep these instructions in a safe place for future reference.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the
apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power
supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• To reduce the risk of electric shock or component damage, switch o the power before connecting other components to your Unit.
• Unplug the power cord before cleaning your Unit. A damp cloth is sucient for cleaning. Do not use a liquid or a spray cleaner on your Unit. Do not
use abrasive cleaners.
• Always use the accessories recommended by the manufacturer to insure compatibility.
• When moving your Unit from an area of low temperature to an area of high temperature, condensation may form in the housing. Wait before
turning on your Unit to avoid causing re, electric shock, or component damage.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of your Unit and to protect it
from overheating, be sure these openings are not blocked or covered. Do not place your Unit in a bookcase or cabinet unless proper ventilation is
provided.
• Never push any object into the slots and openings on your Unit enclosure. Do not place any objects on the top of your Unit. Doing so could short
circuit parts causing a re or electric shock. Never spill liquids on your Unit.
• Never use the subwoofer in the upright, vertical position without installing the legs
• Do not block the subwoofer ports. Allow for 1-2 inches of space around all sides for ventilation.
• WARNING: Exposure to loud sounds can damage your hearing causing hearing loss and tinnitus (ringing or buzzing in the ears). With continued
IMPORTANT SAFETY INSTRUCTIONS
English - iii
exposure to loud noises, ears may become accustomed to the sound level, which may result in permanent damage to hearing without any noticeable
discomfort.
• When connected to a power outlet, power is always owing into your Unit. To totally disconnect power, unplug the power cord.
• Do not overload power strips and extension cords. Overloading can result in re or
electric shock.
• The wall socket should be located near your Unit and be easily accessible
• Keep your Unit away from moisture. Do not expose your Unit to rain or moisture. If water penetrates into your Unit, unplug the power cord and
contact your dealer. Continuous use in this case may result in re or electric shock.
• Do not use your Unit if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact your dealer
immediately. Do not try to repair your
unit yourself.
• Avoid using dropped or damaged appliances. If your Unit is dropped and the housing is damaged, the internal components may function abnormally.
Unplug the power cord immediately and contact your dealer for repair. Continued use of your Unit may cause re or electric shock.
• Do not install your Unit in an area with heavy dust or high humidity. Operating your Unit in environments with heavy dust or high humidity may
cause re or electric shock.
• Ensure that the power cord and any other cables are unplugged before moving your Unit.
• When unplugging your Unit, hold the power plug, not the cord. Pulling on the power cord may damage the wires inside the cord and cause re or
electric shock. When your Unit will not be used for an extended period of time, unplug the power cord.
• To reduce risk of electric shock, do not touch the connector with wet hands.
• Insert the remote control batteries in accordance with instructions. Incorrect polarity may cause the battery to leak which can damage the remote
control or injure the operator.
• See the important note and rating located on the back of the unit.
• WARNING - This equipment is not waterproof. To prevent a re or shock hazard, do not place any container lled with liquid near the equipment
(such as a vase or ower pot) or expose it to dripping, splashing, rain, or moisture.
• CAUTION - Danger of explosion or re if batteries are mistreated. Replace only with the same or specied type.
• Do not leave the batteries exposed to direct sunlight for a long period of time with doors and windows closed. Do not disassemble the batteries or
dispose of it in re.
• Where the MAINS plug or appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
• No naked ame sources, such as lighted candles, should be placed on the apparatus.
• The unit is intended for use in moderate and tropic climates.
WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
The lighting ash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the presence of not isolated dangerous voltage
within the product that may be sucient magnitude
to constitute a risk of shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and servicing instructions in
the literature accompanying the appliance.
Warning: This equipment is a Class II or double
insulated electrical appliance. It has been designed
in such a way that it does not require a safety
connection to electrical earth.
English - iv
TABLE OF CONTENTS
Package contents .........................................................................................................................5
Controls & Connections...............................................................................................................6
First-Time Setup............................................................................................................................9
Using the Remote.........................................................................................................................14
LED Indicators...............................................................................................................................15
Bluetooth Audio Pairing...............................................................................................................17
Using Bluetooth mode............................................................................................................18
Advanced Setup............................................................................................................................19
Connecting a Subwoofer ........................................................................................................20
Using Button Combinations ........................................................................................................21
Wall-Mounting the Sound Bar.....................................................................................................22
Help & Troubleshooting...............................................................................................................24
Limited Warranty..........................................................................................................................27
Legal & Compliance......................................................................................................................29
English - 5
PACKAGE CONTENTS
2 x Wall
Mount Screws 2 x Power Cables
Quick Start Guide
QUICK START GUIDE
Model: SB3621n-E8
VIZIO Sound Bar
Please read this guide before using the product.
VIZIO Sound Bar Remote Control
requires 2x AAA
Batteries
2 x Wall
Mount Brackets
(Sound Bar)
Wireless Subwoofer
MARKHERE
APPOSEZUNEMARQUE ICI
MARQUEAQUÍ
MARKHERE
APPOSEZUNEMARQUE ICI
MARQUEAQUÍ
English - 6
CONTROLS & CONNECTIONS
* Supports .WAV le format playback only.
Power Port
71-S3621N-TYPB3
116.5mm
38mm
Part No.: 10612000248
Serial No.: SHCOWGAS0100001
条码、内容均为示例，须按实际打印！
Model/UPC/Material#...
序列号编码规则：
AUX
Analog Audio In (Stereo 3.5mm)
USB*
USB In
Back of Sound Bar
71-S3621N-TYPB3
116.5mm
38mm
Part No.: 10612000248
Serial No.: SHCOWGAS0100001
条码、内容均为示例，须按实际打印！
Model/UPC/Material#...
序列号编码规则：
English - 7
71-S3621N-TYPB4
116.5mm
38mm
OPTICAL
Digital Optical Audio In
DIGITAL
Coaxial In
71-S3621N-TYPB4
116.5mm
38mm
English - 8
Input Press to change
the audio source.
Volume Increase or decrease the
loudness of the audio.
Power Press to turn
soundbar on or o.
Bluetooth Input Hold to pair.
(See ‘Bluetooth Audio Pairing’ for
more information.)
Power Button
Power Port
LED Indicator
Pairing Button
Top of
Sound Barr
Back of Subwoofer
English - 9
71-S3621N-TYPB4
116.5mm
38mm
FIRST-TIME SETUP
* Not all TVs have the audio outputs shown above. To con-
nect the Sound Bar directly to your other devices (Blu-Ray
player, game system, etc.) see your device’s user manual.
† When using either of the Digital Inputs, if there is no
audio: (A) try setting the TV output to PCM or (B) Connect
directly to your Blu-ray/other source, some TVs do not
pass through digital audio.
Back of Sound Bar
AND CONNECT
IT TO YOUR TV
1CHOOSE ONE CABLE
BETTER
DIGITAL OPTICAL
CABLE†
DIGITAL COAXIAL
CABLE†
BETTER
English - 10
71-S3621N-TYPB3
116.5mm
38mm
Part No.: 10612000248
Serial No.: SHCOWGAS0100001
条码、内容均为示例，须按实际打印！
Model/UPC/Material#...
序列号编码规则：
2Connect the power cable to the sound bar AC
IN as shown.
Plug the power cable into an electrical outlet.
English - 11
Back of Subwoofer Connect the power cable to the Subwoofer
AC IN as shown.
Plug the power cable into an electrical outlet
and press the power button.
The subwoofer should automatically power
on when plugged in.
3
English - 12
Sound Bar is
centered below
the TV.
For the best surround sound experience, position the Sound Bar as shown.
The Sound Bar should be close to ear level. The Subwoofer should be placed in a
corner of the room.
4
Wireless
Subwoofer
English - 12
English - 13
5
Remove the battery cover by gently
sliding it away from the remote.
6
Insert batteries and gently slide the
battery cover back into place.
7Turn your TV and sound bar. The sound bar will automatically
turn on and begin searching for an active input.*
The LED indicators on the front of the sound bar will begin cycling
in pairs through inputs until an audio source is detected.**
You can press the INPUT button to switch between audio
sources. For example, if you connected your TV to AUX , set the
sound bar to AUX .
Input
Power
Top Top
Tip: Pressing the INPUT button will stop
the auto detect function.
*Occurs only during rst-time set up.
**Auto detect function only occurs once when the sound bar is rst powered on. To enable this feature again, you must
do a Factory Reset (see the Using Button Combinations section for more information) or press and hold the INPUT
button for 3 seconds.
When needed, VIZIO recommends Duracell ‘AAA’ alkaline batteries.
English - 14
USING THE REMOTE
Volume +/-
Press to increase and decrease
volume.
Previous
Press to return to previous track.
Bluetooth
Switches to bluetooth mode. Long
press puts sound bar in bluetooth
pairing mode.
Mute
Press to mute/unmute.
Power
Press to turn on or o.
Play/Pause
Press to play or pause.
Next
Press to skip to the next track.
Input
Press to change the input source
TruVolume
Turns TruVolume On and O. Movie
Toggle to Movie mode
Music
Toggle to Music mode.
TruSurround
Turns TruSurround On and O.
Subwoofer
Press the Previous/Next button to
increase/decrease the level of the
subwoofer
Bass
Press the Previous/Next
button to increase/decrease
the level of the bass.
Treble
Press the Previous/Next
button to increase/decrease
the level of the Treble.
English - 15
LED Indicators are located here.
The LED Indicators will behave dierently with each button on the remote control.
Function LED Behavior Description
Input
Press the INPUT button on the remote to cycle through the available inputs:
•Analog Audio In - AUX Stereo 3.5mm
•Coaxial In - Digital
•Digital Optical Audio In - Optical
•Bluetooth
•USB In - USB
Press and hold the INPUT button on the remote control for 3 seconds to
enable the auto input detect function.
Bluetooth
Pairing
Press and hold the button on the remote. The Sound Bar will be
discoverable for 15 minutes. You can now search for the Sound Bar (VIZIO
SB3621n) using your Bluetooth Device. The sound bar will power down if
no device is found.
Note: Set your Bluetooth device into pairing mode prior to the Sound Bar.
DTS
TruVolume
On/O
Press the TVOL button to enable/disable TruVolume.
When enabled (On), TruVolume provides a consistent and comfortable
volume level for a more enjoyable listening experience.
(When searching for device)
Flash from the bottom to the
top and back continuously.
TruVolume On
TruVolume O
LED INDICATORS
Analog Audio In - AUX
Coaxial In - Digital
Digital Optical Audio In
Optical
Bluetooth
USB In - USB
English - 16
Function LED Behavior Description
DTS
TruSurround
On/O
Press the TSHD button to enable/disable DTS TruSurround. When
enabled (On), all inputs will produce virtual surround sound. When
disabled (O), all sources will playback in stereo.
Equalizer Mode
Press the EQ button to toggle between two preset equalizer
settings, Music and Movie.
Note: Movie mode is on by default.
Treble
Levels
Press the TREBLE button then press the Next/Previous button to
increase/decrease the treble level. The LED indicators will move to the
top with increasing levels and to the bottom with decreasing levels.
Bass
Levels
Press the BASS button then press the Next/Previous button to
increase/decrease the bass level. The LED indicators will move to the
top with increasing levels and to the bottom with decreasing levels.
Subwoofer
Levels
Press the SUB button then press the Next/Previous button to increase/
decrease the level of the subwoofer. The LED indicators will move to the
top with increasing levels and to the bottom with decreasing levels.
Note: Decreasing the level to the minimum turns o the subwoofer.
When a Dolby
Digital signal is
detected.
Dolby Digital is only available on either the Coaxial In or Digital Optical
Audio In inputs. When a Dolby Digital signal is detected, the Dolby Digi-
tal indicator LED will light up for 3 seconds before fading away.
Two center LEDs indicate
Treble level 0.
Two center LEDs indicate
Bass level 0.
TruSurround On
TruSurround O
Dolby Digital
Indicator LED
Movie
Music
Two center LEDs indicate
sub level 0.
English - 17
To pair the sound bar with a Bluetooth device:
1. Press and hold the Bluetooth button on the sound bar or on
the remote for ve (5) seconds. When the sound bar is in Bluetooth
Pairing Mode, the LED Indicators on the Display Panel on the front
of the Sound Bar will light sequentially from bottom to top and
back again.
Once the device is paired, the LED Indicators will stop ashing.
2. You can now search for the sound bar (VIZIO SB3621n) using
your Bluetooth device. For more information, refer to the user
documentation that came with the device.
3. Play audio from your Bluetooth device. Volume can be controlled
on your source device and the sound bar.
Bluetooth
Device
BLUETOOTH AUDIO PAIRING
Top of Sound Bar
English - 18
Your sound bar supports music streaming from smartphones, tablets, and computers with Bluetooth
capability. Device compatibility will vary, see your device’s documentation for more information. Once you
have paired your source device to the sound bar, as long as you stay within range of the sound bar, your
device should remain paired. If the input is changed, the Bluetooth device will disconnect. If the source is
changed back to Bluetooth, the last paired bluetooth device will reconnect automatically.
Maximizing Signal
A Bluetooth signal has a range of up to 30 feet. Keep in mind that Bluetooth is a compressed audio format, so
streamed music may lose some integrity when compared to a wired connection.
Try the following if your sound quality is less than optimal:
•If you hear any break-up or disconnect while streaming music from your device, move the source
device closer to the sound bar.
•Be sure that there are no solid obstructions in the line-of-sight between the sound bar and the
source device.
•Other wireless devices can aect Bluetooth range, including wireless security cameras, wireless video
baby monitors, cordless phones, and microwave ovens. Turning o or moving these devices may
improve Bluetooth range.
Your sound bar is not equipped with a microphone,
so it cannot operate as a hands-free device for a
smartphone.
Reduce the volume levels on your device and on the
sound bar before pressing Play. High volume levels
can damage your hearing.
USING BLUETOOTH MODE
English - 19
71-S3621N-TYPB3
116.5mm
38mm
Part No.: 10612000248
Serial No.: SHCOWGAS0100001
条码、内容均为示例，须按实际打印！
Model/UPC/Material#...
序列号编码规则：
71-S3621N-TYPB4
116.5mm
38mm
ADVANCED SETUP
* Supports .WAV le format
playback only.
DIGITAL OPTICAL
CABLE
DIGITAL COAXIAL
CABLE
Back of Sound Bar
Game Console
Network Media Player Tablet/MP3 Player/Laptop
USB Thumb Drive*
3.5MM TO
RCA CABLE
English - 20
The Subwoofer has already been paired with the
Sound Bar by VIZIO. However, the Subwoofer may
need to be re-linked to the Sound Bar if there is no
sound coming from the Subwoofer.
1
First conrm that the power LED is illuminated.
Press and hold the Pairing button on the back of
the Subwoofer for 5 seconds. The LED on the back
of the Subwoofer will begin to blink.
2
Press and hold the Power button on the top of
the Sound Bar for 5 Seconds. The LED indicators
on the front will
ash 3 times. The Subwoofer is
now linked with the Sound Bar.
What does pairing mean?
Pairing means to wirelessly
connect.
Buttons are located on
top of the Sound Bar
Back of Subwoofer
Power Button
CONNECTING A SUBWOOFER
Table of contents
Other VISIO Speakers System manuals
