Vision PR001 User manual

PR001
iPhone 4/4S/5 underwater housing
USER GUIDE

PRECAUTIONS
NOTE : Not following these instructions or ignoring these precautions may
cause a flood or malfunction and may damage the device used in this
housing.
-When storing and transporting the housing, protect it with a soft
pouch or something that won’t scratch or damage the housing.
-When used, the o-ring must be absolutely clean and free of sand,
hairs or any other particule.
-Sealing surface must also be cleaned before being used.
-Rinse the housing in fresh water after each use. Clean the buttons
area and then wipe the whole system before removing the cap.
-Replacing the o-rings should be done once a year to assure best
sealing and waterproofness.
-Avoid scratching the main window and the camera lenses acrylic
parts.
-To remove an o-ring, use a non-sharp plastic tool that won’t break it.
-Only use replacement parts provided by OVISION or by one of its
authorized dealer.

PR001 – iPhone underwater housing
1. Locking security latches
2. Main window
3. Push button
4. Push button
5. Push button
6. Push button
7. Camera window
8. Cap

INSTRUCTIONS
PREPARING THE IPHONE
Before placing your iPhone into the OVISION housing, follow these
instructions.
1. Press and hold pressure with your finger on the
iPhone’s camera application. After doing that, the
multiple applications will become shaky and with
and xon the top left corner.
2. Place your finger on the iPhone’s camera
application and slide it to the bottom left or right
corner of the iPhone’s screen by holding pressure.
Figure 1
Figure 2

3. Go to the iPhone’s settings and set Airplane mode
to ON. It will prevent the iPhone from running out of
battery quickly.
4. In Settings –General, set the Auto-Lock function
to Never.
Figure 3
Figure 4

INSTALLING THE IPHONE INTO THE HOUSING
Before installing your iPhone into the OVISION housing, make sure to read
and understand these instructions.
1. Open both latches①.
2. Pull cap⑦to open the housing.
3. Slide the iPhone into the housing and make sure the back is in
contact with rubber bumpers into the housing.
4. Push back the cap⑦to close the housing.
5. Close both latches①.
6. Wash main window②and camera window⑦to have the best quality
of filming possible

WARRANTY
1. OVISION products are covered by a 1 year warranty from the purchase
date of the consumer. This warranty covers any material or manufacturing
defects.
2. The warranty does not cover the products housed in OVISION’s housings.
Any problem or failure of the device while using OVISION products is not
the responsibility of OVISION.
3. Parts that require maintenance or special care(ORINGS, windows) are not
covered by the warranty.
4. OVISION doesn’t hold responsibility for any damage caused by an
unauthorized (by OVISION) modification or improper use.
5. The warranty is only valuable if the product is bought by an authorized
dealer of OVISION.
6. Unauthorized modifications or repairs (by OVISION) will automatically
void the warranty.
