1 Overview
1.1 Range of application
This Manual introduces VISION REVO series product, its installation, operation and as well as its
maintenance. All the technical features that distinguish the VISION REVO series products are also
described. VISION REVO system developed by SHENZHEN CENTER POWER TECH.CO.,
LTD. is suitable for high-voltage lithium battery system, and widely used in UPS backup power,
large energy storage and other applications.
1.2 For the reader
This Manual of installation, operation and maintenance is suitable for every kind of user - commons
users, skilled users & expert users who may need to view technical information. The manual will
then define the operations that experienced, instructed and other personnel can perform. This
Manual is suitable for the installation & Operation & Maintenance of all lithium batteries cabinet for
the TP, TPH and TPL series of REVO.
1.3 Manual
This manual must be consulted carefully before using, installing and maintaining the product. Please
properly store and put the Manual at an accessible place. All the information in the Manual, including
the Figures and symbols, is owned by SHENZHEN CENTER POWER TECH.CO., LTD. Such
information must not be used by personnel not authorized by SHENZHEN CENTER POWER
TECH.CO., LTD.
The Manual will be constantly updated and revised, and the users shall refer to the purchased
products for the latest updates. For more details, please get the latest Manual through the sales
channel.

SHENZHEN CENTER POWER TECH CO., LTD
Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and
Ecological Park, Nanshan District, Shenzhen, China
Tel: [phone] Fax: [phone] Email: [e-mail]
Green Our Earth Power Your Vision
8
2 Product description
2.1 Brief introduction
REVO series lithium battery system is developed by SHENZHEN CENTER POWER TECH.CO.,
LTD. It is suitable for high-voltage lithium battery system and is mainly used in UPS backup power
or energy storage, high-precision multi-string (16S) cell voltage and temperature acquisition. The
module adopts passive equalization, and the maximum equalization current reaches 300mA. The
external communication interface adopts isolated CAN bus to realize the cascade communication of
up to 15 BMU. This Manual describes the type and size, performance, technical characteristics,
warnings and precautions of REVO series lithium battery system. This specification applies only to
backup battery products provided by SHENZHEN CENTER POWER TECH.CO., LTD.
2.2 Solution introduction
REVO series uses VISION high-rate LFP batteries and self-developed BMS system,
integrated remote cloud management system and intelligent fire protection module, with
high reliability, good stability, long service life and excellent safety performance.
2.3 Product functions and advantages
REVO series has four levels of safety protection to ensure the safety and reliability of the
system throughout the life cycle; it adopts a three-level management architecture design to
accurately monitor the status of each component in the system, which ensures stable
system performance and ensure the safety of user load power supply.

SHENZHEN CENTER POWER TECH CO., LTD
Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and
Ecological Park, Nanshan District, Shenzhen, China
Tel: [phone] Fax: [phone] Email: [e-mail]
Green Our Earth Power Your Vision
9
2.4 Product list
VISION REVO systems consist of:
Cabinet
LIBVISRAC50AH
Suitable for 8 or 10 modules LIBVISMOD50
LIBVISRAC100AH
Suitable for 8 or 10 modules LIBVISMOD100
LIBVISRAC40AH
Suitable for 8 or 10 modules LIBVISMOD40
LIBVISRAC200AH
Suitable for 8 or 10 modules LIBVISMOD200
Different models of battery modules or cabinets cannot be installed in parallel
CBMS
LIBVISSG250TP0
Suitable for LIBVISMOD50
LIBVISSG630TP0
Suitable for LIBVISMOD100
LIBVISSG630TPH
Suitable for LIBVISMOD40
LIBVISSG250TPL
Suitable for LIBVISMOD200
Battery Modules
LIBVISMOD50
V-LFP51.2V50AH TP10
LIBVISMOD100
V-LFP51.2V100AH TP20
LIBVISMOD40
V-LFP51.2V40AH TPH20
LIBVISMOD200
V-LFP51.2V200AH TPL10
It is not possible to install different models of battery modules in the same system
GBMS
LIBVISGBMS
Group Battery Management System
There must be at least one GBMS per lithium battery system

SHENZHEN CENTER POWER TECH CO., LTD
Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and
Ecological Park, Nanshan District, Shenzhen, China
Tel: [phone] Fax: [phone] Email: [e-mail]
Green Our Earth Power Your Vision
10
3 Safety instruction
3.1 Label description
In order to ensure the users safety while using this product, the Manual provides pertinent
identification information and corresponding symbols.
Please read carefully the following list of symbols used in this Manual.
Table 3.1-1 Safety Symbols
Low potential danger: it may result in mild or moderate injury
High risk of serious injury or death
High voltage inside the cabinet: a touch may lead to electric shock danger
Wear safety goggles all the time during installation or maintenance
Service by properly expert users only
Disconnect charger and verify no-voltage before maintenance
Turn off the battery system and Lock-out/Tag-out before maintenance. (If necessary, signal
maintenance operations appropriately).
Recycle lithium-ion batteries
Firmly ground to ensure the safety of operators and protect the grounding terminal (PE)
Emphasis and supplement: a quick way to master this step
