Vision WGC-Q User manual

Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try and correct the interferene by
one of the following measures:
Reorient or relocate the receiving antenna,
Increase the separation between the equipment and receiver,
Connect the equipment into and outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undersired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Limited Warranty
Vision Guarantees that every wireless garage contact is free from physical defects in material
and workmanship under normal usage for one year from the date of purchase. If the product
proves defective during this one-year warranty period, Vision will replace it free of charge.
Vision does not issue any refunds. This warranty is extended to the original end user
purchase only and is not transferable. This warranty does not apply to : (1) damage to units
caused by accident, dropping or abuse in handling, or any negligent usage; (2) units which
have been repaired, taken apart, or modified by an unauthorized personnel; (3) units not
used in accordance with instruction; (4) damages exceeding the cost of the product; (5)
transit damage, initial installation costs, removal cost, or reinstallation cost.
Installation & Operation Manual
WGC-Q
Wireless Garage Contact

Introduction
Thanks for choosing the wireless garage contact of the home security device.
This sensor monitors garage when garage is opened and closed.
Product Description and Specification
*** For indoor use only***
Specification: Package Content:
Protocol: 319.5MHz 1pc WGC-Q senso
r
Operating Range: Up to 200 feet line of sight 1pc CR123A Lithium Battery
Operating Temp.: -15°C~ 60°C (5°F ~140°F)
1pc Installation & Operation manual
Battery: Panasonic CR123A * 1PC
Installation
1. Unscrew the screw fastening the rear cover.
2. Slide the rear cover down.
3. Using the screws or adhesive tape to affix the rear cover on the frame along the
opening edge of garage.
4. Before insert the battery, put home security controller into learning mode. Once put on
CR123A battery into the battery compartment and LED will flash 5 times, and WGC-Q
garage contact will automotive included into system.
5. Slide back the rear cover and screw fastening with the front cove.
6. External Switch: You could use an external switch to connect with the WGC-Q for
extending detection. The WGC-Q has 2 normally closed contact terminals. These can be
used for external switch wired contacts. The external switch will send an alarm report by
opening the garage.
Operation
1. Opening the garage to separate the magnet from the sensor will send signal to the
controller, and the LED will flash 5 times
2. Normal operation, the LED will not light.
3. The WGC-Q sensor equipped with tamper switch. If the cover of sensor is removed, the
garage contact will report a zone tamper to the controller, and the LED will flash 5 times.
4. If garage contact is in low battery status, it will report a message to controller, and LED
will flash slow. Please change the battery.
