Vision Mantis compact User manual

User Guide

Compact & Elite with Universal Stand

Table of Contents

English Mantis Compact 6 - 8

Mantis Elite 9 - 11

Français Mantis Compact 14 - 16

Mantis Elite 17 - 19

Deutsch Mantis Compact 22 - 24

Mantis Elite 25 - 27

Italiano Mantis Compact 30 - 32

Mantis Elite 33 - 35

Español Mantis Compact 38 - 40

Mantis Elite 41 - 43

日本語 Mantis Compact 46 - 48

Mantis Elite 49 - 51

中文 Mantis Compact 54 - 56

Mantis Elite 57 - 59

한국어 Mantis Compact 62 - 64

Mantis Elite 65 - 67

Русский Mantis Compact 70 - 72

Mantis Elite 73 - 75

Health & Safety

Vision Engineering and its products conforms to the requirements of the EC Directives on Waste Electrical and Electronic

Equipment (WEEE) and Restriction of Hazardous Substances (RoHS).

Electrical Supply

Stand Input Voltage: 9VDC 1.7A

Power Supply Voltage (via plug top power supply) : 100-240VAC 50-60HZ 1.0A Max

Environmental Conditions

Indoor use

Altitude up to 2000m

Operating Temperature: 0°C - +40°C

Storage Temperature: 0°C to + 50°C for 3 months without any adverse effects

Maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50% relative humidity at 40°C.

Mains voltage supply fluctuations not to exceed 10% of the nominal voltage

If equipment is not used in a manner as specified, protection provided by the equipment may be impaired.

The product should be located such that the Power Supply can be unplugged in the event of an emergency.

Mantis Compact with Universal Stand - User Guide www.visioneng.com/support

English

MANTIS COMPACT

Packing Contents

Assembly

1Secure the universal mount to the work

surface using the G-clamp provided or by

using appropriate screws located in the

holes of the mount.

2Place the universal arm on top of the

universal mount and lower it on to the

spigot until it is fully mounted.

3Loosen the upper retaining bolt in the

universal arm. Remove the lower retaining

bolt . Carefully place the locating hook

of the Mantis viewing head over the

upper retaining bolt of the universal arm.

Replace the lower retaining bolt , ensuring

that the bolt passes through the lower locating mount

of the Mantis viewing head.

Tighten the upper and lower retaining bolts then re-seat the universal arm rubber

gaiter .

4Remove the red transit plug from the underneath of the viewing head.

5Fit and lock the chosen objective lens into the objective seat.

6Ensuring the power adapter is suitable for your supply voltage, connect the power adapter

plug to a suitable power outlet and its output connector to the base of the universal arm.

7Connect the output lead at the top of the universal arm to the rear of the viewing head.

Do not attempt to connect the power adapter directly to the viewing head.

Universal mount

G-clamp

Counter balanced boom stand

Viewing head

Power adapter

Objective lens

Desiccant Replacement

The desiccant removes excess moisture from the optical

head.

 Disconnect the power supply from the bottom of the

head.

 Remove the screw securing the desiccant cover and lift

the cover off.

 Insert the new desiccant and replace the desiccant cover.

LED Arrays

 Remove the desiccant cover .

 Remove the two crosshead screws that secure the LED

array and remove the array complete with filters .

 Reassembly is the reverse of this procedure.

Routine Maintenance

www.visioneng.com/support Mantis Compact with Universal Stand - User Guide

English

MANTIS COMPACT

Overview

Turn on the power switch and place the subject be-

neath the Mantis viewing head.

Focus

The aim of the universal stand products is that the height of

the instrument is set to a comfortable viewing position and the

subject is then lifted (normally by hand) into focus. Thus maintaining

optimum ergonomics.

To set the height of the instrument, ensure the friction clamp is

loosened then move the viewing head up or down until the required

viewing position is obtained and tighten the friction clamp.

Eye Spacing

Adjust the eye spacing control to obtain a comfortable stereo view.

Note: Adjusting the eye spacing is very important for viewing

comfort and must be adjusted for each Mantis user.

Changing Lenses

To change the objective lens, twist and remove lens . Store the lens in the supplied container.

Fit and lock the chosen objective lens into the objective seat.

Head Counterbalance

When a lens has been changed, it may be necessary to adjust the head counterbalance. Adjust the

counterbalance screw (clockwise for lighter lenses or counter-clockwise for heavier ones) until the viewing head does

not drift up or down when unsupported.

Ergonomic Viewing

An ergonomic posture will ensure that users fully benefit from the advantages provided by the Mantis optical technology.

In setting up your Mantis, firstly arrange your workspace, paying attention to the heights of the chair and table.

When seated with a straight back, your eyes should be comfortably lined up with the Mantis viewing head. Forearms

should be supported by the work surface.

Operation

General Care

 When not in use, cover your Mantis with the dust cover provided.

 Remove dust with a soft brush or cleaning cloth.

 The Mantis lenses should be cleaned with a lens cleaning cloth.

 Keep accessories in a dust-free environment when not in use.

Service

Service and repair work must only be carried out by service engineers authorised by Vision Engineering.

This product is warranted to be free from defects in material and workmanship for a period of one year from the date of invoice to the original purchaser.

If during the warranty period the product is found to be defective, it will be repaired or replaced at facilities of Vision Engineering or elsewhere, all at the

option of Vision Engineering. However, Vision Engineering reserves the right to refund the purchase price if it is unable to provide replacement, and repair is

not commercially practicable or cannot be timely made. Parts not of Vision Engineering manufacture carry only the warranty of their manufacturer. Expendable

components such as fuses carry no warranty.

This warranty does not cover damage in transit, damage caused by misuse, neglect, or carelessness, or damage resulting from either improper servicing or

modification by other than Vision Engineering approved service personnel. Further, this warranty does not cover any routine maintenance work on the product

described in the user guide or any minor maintenance work which is reasonably expected to be performed by the purchaser.

No responsibility is assumed for unsatisfactory operating performance due to environmental conditions such as humidity, dust, corrosive chemicals, deposition

of oil or other foreign matter, spillage, or other conditions beyond the control of Vision Engineering.

Except as stated herein, Vision Engineering makes no other warranties, express or implied by law, whether for resale, fitness for a particular purpose or
