VISIONARY DESIGNS SEGUE DESIGNS VK-1350 Manual

© 2024
Order #XXXXX
Locked layer contains
placeholder marks.
Plan View
10’
10’
VK-1350 - 10’ x 10’ Lightbox Display
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2024
Order #XXXXX
Locked layer contains
placeholder marks.
= 1 sq foot
Plan View

© 2024
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information

© 2024
Order #XXXXX
Straight Connection
All knobs must be tightened securely to ensure a proper connection.
All knobs must be tightened securely to ensure a proper connection.
Adjust connectors if necessary to
prevent gaps in connection.
Upper Horizontal Extrusion
Lower Horizontal Extrusion
Straight Connector
Straight Connector
Corner
Connectors Corner
Connectors
Corner
Connectors Corner
Connectors
COMPLETED ASSEMBLY
3) Tighten all knobs to secure connection.
Slide verticals over
lower connectors.
Then slide upper
connectors into
groove of verticals.
Tighten all knobs.
When assembling frame, first attach all straight
connectors, then attach corner connectors.
1) Place extrusions end-to-end.
2) Loosen all knobs, then slide straight
connectors across the seam of extrusions.
Disassembly
1) Loosen all knobs.
2) Slide connectors off of one extrusion.
3) Tighten knobs to prevent loss during
packing & shipping.
CEI110 Profile
Slide both connectors across seam of extrusions.
Tighten all knobs.
Corner Connection
3) Tighten all knobs to secure connection.
Disassembly
1) Loosen knobs on vertical extrusions.
2) Slide the vertical extrusions off of
corner connectors on lower and upper
horizontal extrusions.
1) Loosen knobs, then slide vertical extrusions onto
corner connectors of lower horizontal extrusion.
2) Slide corner connectors of upper horizontal
extrusion into grooves of vertical extrusions.
Keep straight connectors in groove of
extrusion. Do not remove connectors
during disassembly.
CEI110 Frame Assembly

© 2024
Order #XXXXX
Graphic Removal
To remove the graphic
the frame, locate the fabric
pull tab.Gently pull up on the
tab to remove the fabric.
Step 1
Insert corner A. Turn edge of
graphic so silicon welt is
perpendicular to face of
graphic. Insert narrow side
of welt with fabric to outside
into the channel. Repeat for
other side of this corner.
Step 2
Repeat Step 1 for opposite
corner C, then insert corner
B, followed by corner D, to
complete the installation of
the corners.
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
It is important to first insert
graphic into each alternate
corner then to the sides of
the frame. If this is not done,
graphic will not fit into the
frame correctly.
Corner A
Corner D
Corner B
Corner C
from
SEG Installation

© 2024
Crate 1 of 1
Order #XXXXX
Locked layer contains
placeholder marks.
CRATE PACKING
Crate Packing

© 2024
Step 1 of 6
Order #XXXXX
Locked layer contains
placeholder marks.
Attach CEI110
extrusions to
back hole of
baseplates
When assembled
Item
1
2
3
4
5
6
7
8
9
10
Qty.
1
1
1
1
1
1
1
1
1
1
Description
86”h CEI110 Vertical Extrusion
86”h CEI110 Vertical Extrusion
57.5”w CEI110 Horizontal Extrusion
57.5”w CEI110 Horizontal Extrusion
57.5”w CEI110 Horizontal Extrusion
57.5”w CEI110 Horizontal Extrusion
82.353”h Z45 Vertical Extrusion
82.353”h Z45 Vertical Extrusion
6” x 22” Base Plate w/ 2 holes
6” x 22” Base Plate w/ 2 holes
FRONT VIEW
Assemble frame flat on ground.
Steps:
Refer to the CEI110 Frame Assembly general information page.
1) Assemble horizontals [3-4], [5-6] together using straight connectors.
See CEI-110 Straight Connection detail.
2) Connect verticals [1,2] between horizontal assemblies [3/4], [5/6]
using corner connectors. See CEI-110 Corner Connection detail.
3) Attach verticals [7,8] between horizontal assemblies [3/4], [5/6].
4) Connect Base Plates [9] & [10] to lower horizontals using
bolts & wing nuts.
1
2
3
5
6
78
9
10
4
CEI-110 Straight Connection
1. Place extrusions end-to-end.
2. Slide connectors
across seam of
extrusions.
*
3. Tighten all knobs to
secure connection.
CEI-110 Corner Connection
*1. Slide extrusion onto
corner connectors.
2. Tighten all knobs to
secure connection.
*
*
*
*
*
*
Backwall Lightbox Assembly

© 2024
Step 2 of 6
Order #XXXXX
Locked layer contains
placeholder marks.
FRONT ELEVATION VIEW
Transformer Transformer
Steps:
1) Connect power cords to Supernova lights in lightbox, as shown.
+
-
Power
Female
Transformer
144W / 6 Amp / 24V
++
--
Lights Male
Light to Light Attachment
Maximum of 7 lights per chain / 12 lights per Transformer
Light to Transformer Attachment
Power
Break
Power
Break
Lightbox Wiring

© 2024
Step 3 of 6
Order #XXXXX
Locked layer contains
placeholder marks.
Custom
74°
Tool-less
corner
connector
FRONT VIEW
11
12
13
14
15
16 17
Item
11
12
13
14
15
16
17
Qty.
1
1
1
1
1
1
1
Description
95.916”h TSP49 Vertical Extrusion
55.715” curved TSP49 Extrusion
55.715” curved TSP49 Extrusion
91.129”w TSP49 Horizontal Extrusion
49.916”w TSP49 Horizontal Extrusion
92.333”h Z45 Vertical Extrusion
92.333”h Z45 Vertical Extrusion
Steps:
1) Attach vertical [11] between horizontals [14,15]. See TSP49 Corner Connection detail.
2) Assemble curved extrusions [12-13] together. See TSP49 Straight Connection detail.
3) Attach curved extrusion [12] to horizontal [14]. See TSP49 Corner Connection detail.
4) Connect curved extrusion [13] to horizontal [15] using Custom Corner Connector detail.
5) Attach verticals [16,17] between horizontals [14,15] as shown.
PR53
TSP49
TSP49
Insert PR53 Spline into
extrusion; secure with set screws
TSP49 Straight Connection
*
TSP49
Lock
Slide end of extrusion
over corner lock as shown.
Tighten setscrew
to secure extrusions
TSP49 Corner Connection
*
Custom Corner Connector
1. Slide extrusion onto
Corner Connector.
2. Tighten all knobs to
secure connection.
*
Keep corner connectors attached to extrusions.
*
*
*
**
When assembled
Assemble frame flat on ground.
Front Frame Assembly

© 2024
Step 4 of 6
Order #XXXXX
Locked layer contains
placeholder marks.
Slide V4 connector into top
groove of CEI110 extrusion.
Tighten set screw to secure
V4 in place.
Attach L-Bracket
to V4 using bolt.
Connect L-Bracket to back
of Z45 verticals using bolts.
L-Brackets
L-Brackets
Lightbox Frame Front Frame
L-Bracket Attachment
BACK VIEW
BACK VIEW
*
When assembled
Monitor
Mount
L-Brackets
Item
--
Qty.
2
Description
5” x 2.5” Custom L-Bracket
S
E
G
Gra
p
h
i
c
Note: Monitor mount installs over SEG graphic.
Bolts
Monitor Mount
Z45
Z45
Monitor Mount Attachment
*
Attach Standoff Barrels to verticals using
wing nuts. Then attach Monitor Mount to
Standoff Barrels, using bolts.
Stand-Off
Barrels
Wing
nuts
Steps:
Refer to the SEG Installation general information page.
1) Apply SEG graphic to front of lightbox frame.
2) Connect front frame horizontal [14][ to base plates [9,10]
using bolts & wing nuts.
3) Attach L-Brackets to top of lightbox horizontal [5] & connect
to back of verticals [16,17]. See L-Bracket Attachment detail.
4) Apply SEG graphic to front of front frame.
5) Install Monitor Mount to verticals [16,17] of front frame.
See Monitor Mount Attachment detail.
6) Apply SEG blocker to back of lightbox frame.
Attach TSP49
extrusions to
front hole of
baseplates
S
E
G
Gr
ap
h
ic
SE
G
Blo
c
k
e
r
S
E
G
Gr
ap
h
ic
9
10
5
16
17
14
**
**
set
screw
V4 Connector
Bolt Connection
Frames Connection

© 2024
Step 5 of 6
Order #XXXXX
Locked layer contains
placeholder marks.
*
*
1A
1
2
2A
Shelf
Support
Door
Door
Infill
Infill
Item
1,1A
2,2A
3,3A
4
5
6
7,7A
8,8A
Qty.
1,1
1,1
1,1
1
1
1
2,2
2,2
Description
46.25” CEI110 Horizontal Extrusion
37.5” CEI110 Vertical Extrusion
37.5” S44 Vertical Extrusion
37.5” S44 Vertical Extrusion w/ Door Hinges
37.5” S44 Vertical Extrusion w/ Door Stops
37.5” S44 Vertical Extrusion w/ Door Hinges
14.153” Z45 Horizontal Extrusion
20.408” Z45 Horizontal Extrusion
8
8A
8A
7
7A
3
3A
4
5
6
7A
7
8
*
*
Transformer
to power
++
+
-
-
-
to power
Lights
Male
Male
Female
Female
Transformer
96W / 4A / 24V
Light to Light Connection
Light to Transformer Connection
Maximum of 7 light bars per transformer.
Steps:
1) Assemble CEI110 extrusions [1,1A,2,2A], inserting
2-piece Sintra light blocker. See CEI110 Frame Assembly sheet for instruction.
2) Connect lights and transformer. See Light Connection details.
3) Attach horizontals [7] and [8] between verticals [3,4,5,6,3A].
4) Slide infills between verticals [3,4] and [3A,6], making sure Velcro
is facing inward.
5) Connect doors to verticals [4] and [6]. See Door Connection detail.
6) Attach horizontals [7A] and [8A] between verticals [3,4,5,6,3A].
7) Connect shelf supports to Velcro on infills.
Keep counter sides assembled, when packing.
Sint
r
a
Ligh
t
B
l
o
c
ker
Sint
r
a
Ligh
t
B
l
o
c
ker
Door
Hinge
Hinge
Slide pin into
hinge attached
to vertical.
Slide door
hinge over pin.
Door Connection
*
Pin
MOD-1700C Assembly

© 2024
Step 6 of 6
Order #XXXXX
Locked layer contains
placeholder marks.
*
Counter Top
Shelf
Align hole with pin Rotate pin. Spring
will push pin into hole.
Counter Top Attachment
12
*
Pin
Hole
*
Steps:
1) Attach assembled frame to verticals [3] and [3A].
See Frame Attachment detail.
2) Install SEG graphic to front of assembled frame.
See SEG Graphic Installation detail.
3) Place shelf inside assembled base on top of pins and supports.
4) Place counter top on assembled base, then secure with pins.
See Counter Top Attachment detail.
5) Connect power cords to wireless chargers
in counter top. Completed Assembly
3
3A
Attach frame to
connector on
vertical extrusion,
using bolt.
Frame Attachment
Bolt
Connector
*
*
*
Graphic Removal
To remove the graphic from
the frame, locate the fabric
pull tab.Gently pull up on the
tab to remove the fabric.
Step 1
Insert corner A. Turn edge of
graphic so silicon welt is
perpendicular to face of
graphic. Insert narrow side
of welt with fabric to outside
into the channel. Repeat for
other side of this corner.
Step 2
Repeat Step 1 for opposite
corner C, then insert corner
B, followed by corner D, to
complete the installation of
the corners.
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
SEG Graphic Installation
It is important to first insert
graphic into each alternate
corner then to the sides of
the frame. If this is not done,
graphic will not fit into the
frame correctly.
Corner A
Corner D
Corner B
Corner C
SEG Graphic
*
Wireless / USB
Chargers
Wireless / USB
Chargers
MOD-1700C Assembly (cont’d)
