vissonic M5 Series User manual

M5 Series Modular Matrix Switcher
User
User Manual Manual
Version1.8

The indications of symbols
■ Safety instructions
Some symbols pointing out the potential risk of injury and property loss are used in the instructions and
devices, to help you use the devices safely and properly. Symbols and their indications are as follows. Please
make sure that you have known these instructions before reading the manual.
Remind users to operate and maintenance
according to the instructions attached to the
devices. If ignoring this information, it may
cause death or injury due to wrong operations.
Remind users that uninsulated dangerous
voltage in devices may lead to electric shock.
CE certification means that the product has
reached the safety requirements specified by
EU regulations, users can be assured.
SGS certification means that the product has
reached the quality standards of the world's
largest Societe Generale de Surveillance.
This product has passed ISO9001
international quality certification
(certification bodies: Rheinland TUV).
WARNING: To avoid electric shock, do not open
the cover, and do not place unnecessary portion
in the chassis. Please contact qualified service
personnel.
■General information indications
Information that may lead to an unsuccessful
operation or setting and other relevant
information needed to be noticed is listed.

Important notes
Warning
To ensure reliable use of devices and safety of personnel, please observe the following items in
the installation, use and maintenance.
Notes in installation
◆Do not use this product in the following places: Where exists dust, smoke, conductive dust,
corrosive gases or flammable gases; where exposes to high temperature, condensation or wind and
rain; where exists vibration and shock. Electric shock, fire, incorrect operation will also lead to product
damage and deterioration;
◆During screw hole processing and wiring, metal chips and wire heads shall not be dropped into
ventilation holes of controllers, which may cause a fire, malfunction or incorrect operation;
◆When the installation work is done, make sure that no foreign body is left on the surface of
ventilation, including contact paper and other packaging materials, otherwise it may lead to poor
run-time heat, causing a fire, malfunction or incorrect operation;
◆Avoid wiring or inserting/pulling plugs in charged state, otherwise it may easily lead to electric shock
or cause damage to the circuit;
◆Installation and wiring must be solid and reliable, poor contact may result in incorrect operation;
◆For application in occasions with severe interference, shielded cables should be used to input and
output high-frequency signal so that anti-interference performance of the system could be improved.
Notes in wiring
◆All of the external power supply must be cut off before carrying out installation, wiring and other
operations, or it may cause electric shock or equipment damage;
◆This product is grounded through the grounding conductor of the power cord. In order to avoid
electric shock, the grounding conductor must be connected to earth. Before connecting the input or
output terminals of the product, make sure that the product is properly grounded;
◆Once wiring is completed, foreign matters should be immediately removed. Please cover the
terminal covers of product before power connection to avoid electric shock;
Notes in operation and maintenance
◆Do not touch the terminal when power is on, or it may cause electric shock or incorrect operation;
◆Perform cleaning and terminal tightening when power is off, for these operations may cause
electric shock when power is on;
◆Perform connection, removal or other operations of the communication signal cables and the cables
of expansion board or control unit after power is off, or it may cause equipment damage or incorrect
operation;
◆Do not disassemble the equipment, so as not to damage the internal electrical components;
◆Always read the manual, after security fully recognized, changing the program, commissioning,
starting and stopping operations after security is fully recognized;
◆Button batteries must be replaced when the power is off. When you indeed need to replace the
button batteries with the power on, the operation should be performed by a qualified electrical

technician wearing insulated gloves.
Notes in product obsolescence
◆Explosive electrolytic capacitors: It may cause explosion when electrolytic capacitor on the circuit
board burns;
◆Please collect and process separately, it cannot be put in the life garbage.
◆Please process it as industrial waste, or process it in accordance with local environmental
regulations.

Contents
Chapter One Overview ........................................................................................................................................... 1
1.1 Product Equipment .......................................................................................................................................1
1.2 function features ...........................................................................................................................................2
1.3 cabinet installation ....................................................................................................................................... 2
Chapter Two Hardware Introductions .................................................................................................................. 3
2.1 VW-VL0808 panel diagram .........................................................................................................................3
2.2 VW-VL1616 panel diagram .........................................................................................................................3
2.3 VW-VL3636 panel diagram .........................................................................................................................3
2.4 VW-VL7272 panel diagram .........................................................................................................................6
2.5 Link of matrix and peripherals .....................................................................................................................8
2.5.1 Input interface description ............................................................................................................8
2.5.2 Output interface description .........................................................................................................8
2.5.3 Control board communication port and link method ............................................................... 8
2.5.4 Matrix RS-232 control interface .................................................................................................. 8
2.5.5 Link of matrix and control computer ...........................................................................................8
2.5.6 Matrix KEYBOARD interface .......................................................................................................8
2.5.7 Link of matrix and extended keyboard .......................................................................................9
2.5.8 Matrix Ethernet Interface ..............................................................................................................9
2.5.8.1 Hardware linking method ...................................................................................................... 9
2.5.8.2 Connection Method Description of RJ45 Ethernet Port straight-through Line and
Cross-line ........................................................................................................................................... 9
2.5.9 HDMI port description .................................................................................................................10
2.5.10 DVI port description .................................................................................................................. 10
2.5.11 DB15 interface description .......................................................................................................11
2.5.12 DB15 male socket transfer cable(S terminal, RCA head) ..................................................11
2.5.13 DB15 male socket transfer cable definition .......................................................................... 12
Chapter Three Control Panel Operating Instructions ......................................................................................13
3.1 panel description ........................................................................................................................................ 13
3.1.1 VW-VL0808 panel ....................................................................................................................... 14
3.1.2 VW-VL1616 panel ....................................................................................................................... 14
3.1.3 VW-VL3636 panel ....................................................................................................................... 15
3.2 input boards ................................................................................................................................................ 18
3.2.1 MX-HM4I input board function features ...................................................................................18
3.2.2 MX-DVI4I input board function features .................................................................................. 18
3.2.3 MX-HD4I twisted pair input board function features ............................................................. 18
3.2.4 MX-VA4I input board function features ....................................................................................18
3.2.5 MX-SDI4I input board function features .................................................................................. 19
3.2.6 MX-SF4I optical fiber input board function features ..............................................................19
3.2.7 MX-IP2I input card Functions and Features ...........................................................................19
3.2.8 MX-HM2I 4K HDMI input board function features ................................................................. 19
3.3 output boards .............................................................................................................................................. 19
3.3.1 MX-HM4O seamless output board function features ............................................................19

3.3.2 MX-DVI4O seamless output board function features ........................................................... 19
3.3.3 MX-HD4O twisted pair seamless output board function features .......................................20
3.3.4 MX-VA4O seamless output board function features ............................................................. 20
3.3.5 MX-SDI4O seamless output board function features ........................................................... 20
3.3.6 MX-SF4O optical fiber seamless output board function features ....................................... 20
3.3.7 MX-HM2O 4K HDMI OUT seamless output board function features .................................20
3.4 preview boards ........................................................................................................................................... 21
3.4.1 MX-PMX preview board function features .............................................................................. 21
3.5 control boards .............................................................................................................................................21
3.5.1 VIS-CON ENT4 control board function features ....................................................................21
3.5.2 VIS-CON ENT5 advanced control board function features ................................................. 21
3.6 specifications and technical parameters .....................................................................................................22
Chapter Four Instructions .........................................................................................................................................29
4.1 M5 series Matrix Switcher instructions ..................................................................................................... 29
4.2 Splicer instructions .....................................................................................................................................38
Chapter Five Software .......................................................................................................................................... 39
5.1 Connection ................................................................................................................................................. 39
5.2 Matrix switching control(Seamless output card is needed) .......................................................................41
Chapter Six Web Control Based on VIS-CON ENT4 ............................................................................................. 41
6.1 Connection ................................................................................................................................................. 41

M5 Series Modular matrix switcher User Manual
1
Chapter One Overview
M5 series Modular matrix switcher can realize
graphics processing and seamless switching
flexibly. The matrix adopts high-performance
hardware design, perfectly supports a variety of
high-definition digital / analog signal switching
and processing, and supports two-way RS-232,
two-way IR signal assigned switching function. It
can also divide a completed image signal into
several signals assigned to several different
display unites, forming a large display screen to
display dynamic images. It provides a one-stop
solution for various industries to assign, switch
and process a variety of video and control signals,
which can be widely used in radio and television
engineering, multimedia conference room,
large-screen display engineering, television
teaching, intelligent traffic management centers,
command and control centers and other places.
X series Modular matrix switcher contains
VW-VL0808,VW-VL1616,VW-VL3636,VW-VL727
2 and other models, its signal input/output
interface contains HDMI, DVI, VGA, HDBaseT,
SDI, optical fiber and other video interfaces.
Leading all-digital signal processing technology
ensures undistorted processing, sending top
quality screen to the display terminal. With
customized configuration of various types of the
same or different input/output boards, single
interface type or multi-interface type of matrix can
be formed, such as optical fiber matrix, HDMI
matrix, DVI matrix, CAT5 matrix, VGA matrix,
YUV matrix, Video matrix and so on.
X series Modular matrix switcher provides a
variety of control modes, with remote control
operation, RS-485 extended keyboard, but also
provides two standard RS-232 communication
interfaces and network ports, convenient for
users to coordinate it with various remote control
devices.
1.1Product Equipment
VW-VL0808
VW-VL1616
VW-VL3636
VW-VL7272
Modular matrix switcher can be composed of
any of the following input and output boards:
Input boards:
MX-HM4I input board (HDMI signal input)
MX-DV4I input board (DVI signal input)
MX-HD4I twisted pair input board (HDBas
eT signal input)
MX-VA4I input board (CV, YPbPr, VGAI si
gnal input)
MX-SDI4I input board (SDI signal input)
MX-SF4I optical fiber input board (OPTIC
AL FIBER signal input)
Seamless output boards:
MX-HM4O seamless output board (HDMI
signal output)
MX-DVI4O seamless output board (DVI, R
GB signal output)
MX-HD4O twisted pair seamless output b
oard (HDBaseT signal output)
MX-VA4O seamless output board (CV, YP
bPr, VGAI signal output)
MX-SDI4O seamless output board (SDI si
gnal output)
MX-SF4O optical fiber seamless output bo
ard (OPTICAL FIBER signal output)
Preview board:
MX-PMX preview board (video signal outp
ut)
Control board:
VIS-CON ENT4 control board

M5 Series Modular matrix switcher User Manual
2
VIS-CON ENT5 advanced control board
1.2 function features
◆All digital switching, each seamless output
board can realize real-time seamless switching;
◆Each stitching output board can realize video
stitching; picture windows in full screen can zoom,
overlay and roam arbitrarily;
◆Preview board can realize previewing videos
by group and switching function;
◆Support DVI 1.0 protocol, in line with HDCP1.3,
compatible with HDMI 1.3a;
◆Support hot plug, support audio and video
signal switching together;
◆Digital audio and analog audio in HDMI input
board can be input selectively, digital audio and
analog audio in HDMI output board can be output
simultaneously;
◆Support PC software control switching and
EDID management;
◆HDBaseT input/output signals support
embedded (or local) two-way RS-232 and
two-way IR signals, and can switch optionally with
video signal or switch separately. They also
support POC providing external power supply
(VW-VL3636 and its upgrades support POC);
◆Flexible control with infrared remote control,
RS485, RS232 communication interface and
network ports, and can be controlled by distant
HDBaseT / optical fiber serial ports, convenient
for users to coordinate it with various remote
control devices;
◆Support firmware upgrade online;
◆support intelligent control matrix fan operation;
◆SDI input board has looping out function;
◆VW-VL3636 and its upgrades have redundant
power supply design;
◆Plug-in board structure design, flexibly
allocate input/output signal type and signal
channel number.
1.3 cabinet installation

M5 Series Modular matrix switcher User Manual
3
Chapter Two Hardware Introductions
2.1 VW-VL0808 panel diagram
VW-VL0808 front panel:
VW-VL0808 back panel:
2.2 VW-VL1616 panel diagram
VW-VL1616 front panel:
VW-VL1616 back panel:
2.3 VW-VL3636 panel diagram
VW-VL3636 front panel:

M5 Series Modular matrix switcher User Manual
4
VW-VL3636 back panel:

M5 Series Modular matrix switcher User Manual
5

M5 Series Modular matrix switcher User Manual
6
2.4 VW-VL7272 panel diagram
VW-VL7272 front panel

M5 Series Modular matrix switcher User Manual
7
VW-VL7272 Rear Panel：

M5 Series Modular matrix switcher User Manual
8
2.5 Link of matrix and peripherals
2.5.1 Input interface description
The input interface is composed of MX-DV4
I, MX-HM4I, MX-HD4I, MX-VA4I, MX-SDI4I an
d MX-SF4I input board, enable to combine va
rious input signal formats arbitrarily.
2.5.2 Output interface description
The output interface is composed of MX-DV
I4O, MX-HM4O, MX-HD4O, MX-VA4O, MX-SD
I4O, MX-SF4O seamless output board enable
to combine various input signal formats arbitra
rily.
2.5.3 Control board communication port
and link method
M5 modular matrix provides standard RS-232
serial communication ports, in addition to realize
switching operations with infrared remote control,
it can also control by using a variety of control
systems (such as PC, VISSONIC control systems,
control systems of other manufacturers, etc.).
2.5.4 Matrix RS-232 control interface
Modular matrix provides two-way RS-232 serial
interfaces (a DB9 female connector, a male DB9
connector), you can use this interface to control
the matrix. Pin description of RS-232 port DB9
female connector is as follows:
pin
signal
description
1
-
-
2
TXD
RS-232 protocol, sending data
3
RXD
RS-232 protocol, receiving
data
4
-
-
5
GND
Signal ground
6
-
-
7
-
-
8
-
-
9
-
-
Pin description of RS-232 port DB9 male
connector is as follows:
pin
signal
description
1
-
-
2
RXD
RS-232 protocol, sending data
3
TXD
RS-232 protocol, receiving
data
4
-
-
5
GND
Signal ground
6
-
-
7
-
-
8
-
-
9
-
-
2.5.5 Link of matrix and control
computer
With RS232 cable to link the computer's serial
communication port (COM1 or COM2) and the
matrix cabinet’s RS-232 communication port, and
use control command to control. For more details,
refer to Chapter five, Instructions.
2.5.6 Matrix KEYBOARD interface
The matrix provides one-way KEYBOARD
interface, it is used to link with extended keyboard

M5 Series Modular matrix switcher User Manual
9
VIS-MKB100 so that you can switch the channels
of the matrix. KEYBOARD is a four-foot 3.8mm
phoenix interface, its pin description is as follows:
pin
signal
description
1
+5V
Output DC5V/1A, enable to
provide power for MKB100
2
+
RS-485 protocol, DATA+
3
-
RS-485 protocol, DATA-
4
GND
Signal ground
2.5.7 Link of matrix and extended
keyboard
Based on screen printing, correspondingly
connect matrix cabinet KEYBOARD interface with
extended keyboard MATRIX interface, then you
can control the matrix. For more details, refer to
User's Manual of VIS-MKB100 Matrix
Keyboard.
2.5.8 Matrix Ethernet Interface
2.5.8.1 Hardware linking method
There are two ways to link matrix with
Ethernet adapter hardware
1) cross-connect method
Matrix and control computer is directly
connected via CAT5 crossover
cable.
2) through-connect method
Matrix and Ethernet switchboard or
concentrator is connected via CAT-5
straight-through cable.
2.5.8.2 Connection Method Description
of RJ45 Ethernet Port straight-through
Line and Cross-line
The system adopts CAT-5 (super 5-type line)
as wires, using RJ-45 connector (commonly
known as crystal head) of CAT-5 to connect
network devices. Standard twisted-pair
connection method is specifically regulated,
aiming to ensure the symmetry of cable connector
layout so that the interference between the cables
within the connector can be offset. Super 5-type
line in general has four pairs of wires twisted
together, with different colors.
There are two ways to connect twisted pair:
EIA / TIA 568B standard and EIA / TIA 568A
standard.

M5 Series Modular matrix switcher User Manual
10
T568A line order
1
2
3
4
5
6
7
8
Wh
ite
Gre
en
Gre
en
Wh
ite
Ora
nge
Blu
e
Wh
ite
Blu
e
Ora
nge
Wh
ite
Bro
wn
Bro
wn
T568B line order
1
2
3
4
5
6
7
8
Wh
ite
ora
nge
Ora
nge
whi
te
Gre
en
Blu
e
White
Blue
G
r
e
e
n
White
Brow
n
B
r
o
w
n
Straight-through line: both ends are connected in
T568B line order.
Crossover line: one end is connected in T568A
line order, the other end is connected in T568B
line order.
2.5.9 HDMI port description
HDMI-A Type Line description:
Users can connect a variety of computer
signals, audio and video signal equipment, such
as DVD players, desktop computers, graphics
workstations, and number displays in different
occasions, output terminals can be connected to
the projector, VCRs, computer monitors,
amplifiers and so on.
PIN
Function
1
TMDS Data2+
2
TMDS Data2 Shield
3
TMDS Data2–
4
TMDS Data1+
5
TMDS Data1 Shield
6
TMDS Data1–
7
TMDS Data0+
8
TMDS Data0 Shield
9
TMDS Data0–
10
TMDS Clock+
11
TMDS Clock Shield
12
TMDS Clock–
13
CEC
14
Reserved (in cable but N.C. on device)
15
SCL
16
SDA
17
DDC/CEC Ground
18
+5V Power
19
Hot Plug Detect
2.5.10 DVI port description
DVI-D Dual Link interface description
1
9
8
17 24
PIN
Function
1
T.M.D.S.Data2-
2
T.M.D.S.Data2+
3
T.M.D.S. Data 2/4 Shield
4
T.M.D.S. Data 4-
5
T.M.D.S. Data 4+
6
DDC Clock
7
DDC Data
8
No Connect
9
T.M.D.S.Data1-
10
T.M.D.S.Data1+
11
T.M.D.S.Data1/3 Shield
12
T.M.D.S.Data3-
13
T.M.D.S.Data3+
14
+5V Power
15
Ground (for +5V)
16
Hot Plug Detect
17
T.M.D.S. Data 0-
18
T.M.D.S. Data 0+

M5 Series Modular matrix switcher User Manual
11
19
T.M.D.S. Data 0/5 Shield
20
T.M.D.S.Data5-
21
T.M.D.S.Data5+
22
T.M.D.S. Clock Shield
23
T.M.D. S. Clock +
24
T.M.D.S .Clock-
2.5.11 DB15 interface description
Pin description of component video DB15 port is
as follows:
PI
N
VGA
Compone
nt
S-Vide
o
Composi
te
1
RED
Pr
N/C
N/C
2
GREEN
Y
N/C
N/C
3
BLUE
Pb
N/C
N/C
4
ID2
N/C
N/C
CVBS
5
GND
GND
N/C
GND
6
GND
GND
GND
N/C
7
GND
GND
GND
N/C
8
GND
N/C
N/C
N/C
9
N/C
N/C
Y
N/C
10
GND
N/C
N/C
N/C
11
N/C
N/C
C
N/C
12
SDA
N/C
N/C
N/C
13
HSYNC
N/C
N/C
N/C
14
VSYNC
N/C
N/C
N/C
15
SCL
N/C
N/C
N/C
Pin description of VGA video output board is as
follows:
pin
signal
description
1
RED
red primary
2
GREEN
green primary
3
BLUE
blue primary
4
ID2
address code 2
5
GND
ground
6
RGND
red ground
7
GGND
green ground
8
BGND
blue ground
9
KEY
reserved
10
SGND
digital ground
11
ID0
address code 0
12
SDA
data pin
13
HSYNC
horizontal
synchronization
14
VSYNC
vertical synchronization
15
SCL
clock signal
2.5.12 DB15 male socket transfer cable
(S terminal, RCA head)

M5 Series Modular matrix switcher User Manual
12
2.5.13 DB15 male socket transfer cable
definition
VGA input board of matrix supports the input of
analog, composite video and component video; VGA
output board supports the output of analog, composite
video and component video. If users need input or
output component video signal, they need connect
DB15 male socket transfer cable (S terminal, RCA
head). The two kinds of connection are different, two
things should be noticed:
1. the connection of VGA input board: support VGA,
CVBS and YPbPr signal; when CVBS and YPbPr
signal are needed, only three lines of DB15 male
socket transfer cable terminal is useful. As shown
above, the connection of YPbPr signal is Y attached to
green line, Pb attached to blue line, Pr attached to red
line; For CVBS signal, green line is the right one,
signals can be recognized automatically, no setting is
needed (VGA input port can access three signals, but
one port can only attach to one signal a time).
2, the connection of VGA output board: support VGA,
CVBS and YPbPr signal; when CVBS and YPbPr
signal are needed, four lines of DB15 male socket
transfer cable terminal are useful. As shown above,
the connection of YPbPr signal is Y attached to green
line, Pb attached to blue line, Pr attached to red line;
For CVBS signal, only yellow line is the right one.
VGA or YPbPr signal output requires instruction
setting; CVBS output has always been on, no setting
is needed.

M5 Series Modular matrix switcher User Manual
13
Chapter Three Control Panel Operating
Instructions
3.1 panel description
Front Panel Operation
Seamless switching operation (need seamless output card VW-HM4O；VW-DV4O；VW-HD4O；
VW-VA4O；VW-SF4O or VW-SD4O)
1.
Sample 1. Switch input 1 to the output 2
Sequencing
Pressing button
LCD display
Note
1
1
Select the input 1
V/M
1V
press 1 times and
display “V” for matrix
switching action
2
1V2
Select output 2
ENTER
Switch OK！
Confirm. If there are no
input board, the LCD
display ”Not online!”
Sample 2. Switch input 1 to the output 2 and output 3
Sequencing
Pressing button
LCD display
Note
1
1
Select the input 1
V/M
1V
press 1 times and display “V” for
matrix switching action
2
1V2
Select output 2
/
1V2/
Press”/” button
3
1V2/3
Select output 3
ENTER
Switch OK！
Confirm. If there are no
input board, the LCD
display ”Not online!”

M5 Series Modular matrix switcher User Manual
14
Sample 3. Switch the input 1 to all output
Sequencing
Pressing button
LCD display
Note
1
1
Select the input 1
ALL
1All.
Switch finish.
3.1.1 VW-VL0808 panel
VW-VL0808 front panel:
VW-VL0808 back panel:
3.1.2 VW-VL1616 panel
VW-VL1616 front panel:
