VisualGate SVP-1000 Installation instructions

Network Video Decoder SVP-1000 Full Manual
1
NETWORK VIDEO DECODER
MODEL: SVP-1000
Full Manual (English)
Version 1.0

Network Video Decoder SVP-1000 Full Manual
2
Warning
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.

Network Video Decoder SVP-1000 Full Manual
3
Warning
This equipment has been tested and found to comply with the limits for a Class B Digital Device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment can radiate radio frequency
energy therefore, if it is not installed and used in accordance with the instruction, it may cause
harmful interference to radio communication. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment causes harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution
Any changes or modifications in construction of this device which are not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.

Network Video Decoder SVP-1000 Full Manual
4
Precautions
1. HEED WARNINGS
Adhere to all warnings on the appliance and in the operating instructions.
2. POWER SOURCES
Operate this equipment only from the type of power source indicated on the label. If you are not
sure of the type of power being used, consult your dealer or local power company.
3. OVERLOADING
Do not overload wall units and extension cords, as this can result in a risk of fire or electric shock.
Frayed power cords, damaged or cracked wire insulation, and broken plugs are dangerous.
Periodically examine the cord and replace it if appearance indicates damage or deteriorated
insulation.
4. POWER PLUG PROTECTION
Route the power supply cords so they cannot be walked on or pinched by items placed upon or
against them.
5. VENTILATION
Do not block the slots or openings of the video server and do not place the equipment on a bed,
soft rug, or other similar surface.
6. ATTACHMENTS
Do not use attachments other than those specifically recommended by the equipment
manufacturer as they may cause hazards.
7. TO PREVENT SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE
If you spill liquid on the unit, consult authorized service personnel. Moisture can damage internal
parts. Do not use this equipment near sources of water.
8. ACCESSORIES
Use only with a manufacturer recommended card, stand, tripod, bracket or table. The equipment
may fall, causing serious injury to a child or adult and serious damage to the appliance.
9. CLEANING THE OUTSIDE SURFACES
Unplug this equipment from the wall outlet before cleaning. Use a damp cloth for cleaning.
10. REQUIRING SERVICE
Unplug the equipment from the wall outlet and request qualified service personnel.
11. SAFETY CHECK
Upon completion of any service or repairs to this equipment, ask the service technician to
perform safety checks to determine that the equipment is in safe operating condition.

Network Video Decoder SVP-1000 Full Manual
5
12. IMPORTANT NOTE TO THE INSTALLER
This installation should be made by a qualified service person and should conform to all local
codes. In order to provide this product with protection against risk of unintentional operation by
employees, customers, janitors and cleaners working on the premises, and from falling objects,
building vibrations and similar causes, it is recommended this product be enclosed in the tamper-
resistant lock box. Make sure that the lock box is well ventilated or maintained with an air cooling
system.

Network Video Decoder SVP-1000 Full Manual
6
Table of Contents
1. Introduction of SVP-1000................................................................................................7
1.1. Product Overview................................................................................................7
1.2. Features....................................................................................................................7
1.3. Packing Contents .................................................................................................8
1.4. System Requirements ..........................................................................................8
1.5. System Configuration..........................................................................................9
1.6. Physical Description...........................................................................................10
1.6.1. Front View ...................................................................................................10
2. Basic Setup of SVP-1000................................................................................................12
2.1. Installation.............................................................................................................12
2.2. Network Setting of a PC.......................................................................................13
2.2.1. Verifying the network setup status of a user PC......................................13
2.2.2. Operation of the Web Viewer (URL192.168.1.10)...................................16
3. Configuration of Network Environment......................................................................19
3.1. Check up Network Environment and Installation Type ...................................19
3.2. Installation.............................................................................................................20
3.2.1. IPAddress Setup..........................................................................................20
4. Display Mode ..................................................................................................................23
4.1. Initial Login Screen...............................................................................................23
4.1.1. Installation of the Web Viewer ..................................................................23
4.1.2. Initial Log-in Screen of SVP-1000 .............................................................24
4.2. SVP-1000 Setting Page .........................................................................................25
5. Admin Setting Mode.......................................................................................................26
5.1. General Setting......................................................................................................26
5.2. Registration Setting ..............................................................................................27
5.3. Language Setting...................................................................................................28
5.4. Information Setting...............................................................................................29
5.5. Network Setting.....................................................................................................31
APPENDIX A. Video Server Connection Diagram.........................................................33
APPENDIX B. Troubleshooting........................................................................................35
APPENDIX C. Technical Specification of SVP-1000......................................................36

Network Video Decoder SVP-1000 Full Manual
7
1. Introduction of SVP-1000
1.1. Product Overview
• About the Video DECODER
SVP-1000, the NETWORK VIDEO DECODER is equipped with an embedded system for displaying
MPEG-4 video streams arriving from the Internet. Without requiring a PC, NETWORK VIDEO
DECODER (SVP-1000) can log in to the remote Video Server / camera located anywhere in the
world.In some applications the footprint and expense of a PC is impractical to decode the network
video streams. In these cases, the embedded NETWORK VIDEO DECODER (SVP-1000) is a
much more efficient and cost effective solution. Video output of SVP-1000 is connected to a TV or a
monitor directly.
1.2. Features
Compact Size
Embedded Linux
Receive Live& Real time Video streams
MPEG-4 Decompression
Low Latency
Built-in Watch-Dog Timer
Built-in WEB Decoder
Support Full Duplex Audio
No need Personal Computer
Support Composite Video
Support all VisualGate Products

Network Video Decoder SVP-1000 Full Manual
8
1.3. Packing Contents
NETWORK VIDEO DECODER Cross LAN Cable CD-ROM with manual and
software
DC Adapter(12V/1A)
* Separate Sale
Power Cable
+Terminal Block 2p
Terminal Block 5p
1.4. System Requirements
Operating System : Microsoft Windows® 2000 or Windows® XP
CPU : Intel® Pentium®Ⅳ1.6Ghz or faster
RAM : 512MB or higher
VGA : AGP, Video RAM 64MB or higher
Web Browser : Internet Explorer version 6.0 or higher
Direct-X : 8.x or higher
INPUT Voltage : DC 12V / 1A
Operating Temperature: : 0℃~ 50℃(32~122℉)
Humidity: 20~80% RHG, Non-Condensing

Network Video Decoder SVP-1000 Full Manual
9
1.5. System Configuration

Network Video Decoder SVP-1000 Full Manual
10
1.6. Physical Description
1.6.1. Front View
1) POWER : Power Supply status displays (Red LED on)
2) LAN: When data is transmitted and received through the LAN port, the LED blinks.
3) OPER: 1Channel Video Server is in operation (Orange LED blinks)
1.6.2. Rear View

Network Video Decoder SVP-1000 Full Manual
11
1) VIDEO OUT : 1Vp-p Composite, 1Channel
2) AUDIO IN : MONO Audio Input, 1Channel
3) AUDIO OUT : MONO Audio Output, 1Channel
4) POWER : DC12V /1A
5) ALARM IN/OUT : Port for alarm input, output
6) RS-485 : Port for P/T/Z control.
7) LAN : RJ-45 Ethernet Connector
8) RESET : Initial state which is factory default
9) RS-485 ON/OFF : RS-485 On/Off switch
10) ALARM IN/OUT : TTL LEVEL input/output

Network Video Decoder SVP-1000 Full Manual
12
2. Basic Setup of SVP-1000
2.1. Installation
•If you use Network LAN Card in your PC, you can connect the decoder directly to a PC with a
Cross LAN Cable provided in the package.
• On the assumption that both the user PC and SVP-1000 are used under static IP, and SVP-1000
is directly connected with the user PC or Local Network, the installation procedure is to be:
ectly connected with the user PC or Local Network, the installation procedure is to be: directly connected with the user PC or Local Network,
the installation procedure is to be:
1) Connect TV Monitor and SVP-1000 with a Video Cable. (①)
2) In case of using the controller (ex. Joystick), connect it with RS-485 Port (②).
3) Connect SVP-1000 to a PC with a Cross LAN Cable (③)
②
③
④
①

Network Video Decoder SVP-1000 Full Manual
13
4) Supply power on SVP-1000 ( Be sure to use Exclusive Power Adapter) (④)
5) Wait about 2 minutes after power is on the SVP-1000 decoder. The light on LINK LED shows
that the system is booted successfully.
2.2. Network Setting of a PC
2.2.1. Verifying the network setup status of a user PC
• To connect the SVP-1000 decoder to the user PC, the network setting of the user PC must
be verified as in the following:
1) Go to ‘Start’ -> ’Settings’ -> ‘Control Panel’, then select ‘Network and Internet Connection’

Network Video Decoder SVP-1000 Full Manual
14
2) Click Local Area Connection
3) Check the properties of Internet Protocol [TCP/IP]

Network Video Decoder SVP-1000 Full Manual
15
Network Setting of User PC
4) Setup IP Address, Subnet Mask and Gateway in the user PC with 192.168.1.50,
255.255.255.0 and 192.168.1.1 as it is shown in the picture above.
• Caution
- To activate SVP-1000, the user PC must have the same network setup status as it is preset in the
SVP-1000 decoder. But when you assign the IP address, please be careful not to use the default
IP written on the back side of the video server (192.168.1.10), since the same default IP address
is allotted to all products.
- Basic network setting values of SVP-1000 are:
▶IP Address : 192.168.1.10
▶ Subnet Mask : 255.255.255.0
▶ Gateway : 192.168.1.1

Network Video Decoder SVP-1000 Full Manual
16
• After network setting of a PC, you can verify the network status as following:
1) Go to ’ Start’ -> ‘Run’ ->input ‘cmd’
2) When a DOS window appears as above, input 'ipconfig'.
3) The display shows the current network setting of a PC.
2.2.2. Operation of the Web Viewer (URL 192.168.1.10)
Start a Web Browser
1) Start a Web Browser and input 192.168.1.10 in URL and click ‘Enter’. Then, a user log-in
page appears. In case, it does not open, reset the video server (click the ‘Reset hole’) to
bring it to the default value, and reboot it.
2) When the ActiveX Code for ‘'vg3xview_viewer' pops up, click ‘yes’, then a message window
shows as below.

Network Video Decoder SVP-1000 Full Manual
17
3) Click ‘Install’.
4) When installation of vg3xview_viewer' is completed, the User Log-in (Auth) Page appears.
User Log-in (Auth) Page
5) When the Log-in Page appears, input User name and Password and click ‘OK’.
- User name: admin
- Password: admin

Network Video Decoder SVP-1000 Full Manual
18
5) The Web Viewer appears .

Network Video Decoder SVP-1000 Full Manual
19
3. Configuration of Network Environment
3.1. Check up Network Environment and Installation Type
▶To install SVP-1000 properly, basic understanding of Network Environment is required.
• Private line Environment
In a huge complex such as Company, University, Research center, public IP addresses are
generally used. Under this environment, the user must set a Static IPAddress for the SVP-1000
decoder. If DHCP server is available on the network, select ‘Dynamic IP Address’. You can get the
required information (IP address, subnet mask, gateway, DHCP server) from the network
administrator.
• Broadband (ADSL, Cable, Fiber Optic) Modem Environment
At Home, in the stores and small offices a Broadband modem (DSL, Cable Modem) or a public IP
address is usually in use. In order to use several PCs sharing one Public IP address, the user need
a specific device called Router.

Network Video Decoder SVP-1000 Full Manual
20
3.2. Installation
3.2.1. IP Address Setup
1) After checking Video, connect SVP-1000 to a PC with a Cross LAN Cable
2) Cable connection and Network Setup should be done as it is instructed in ‘ 2.1.
Installation and 2.2 network setting ’.
3) Run a Web Browser and input 192.168.1.10 in URL and click ‘Enter’.
The Decoder Auth Page appears.
Auth Page of SVP-1000
4) Put ‘admin’ in User Name and Password line, click ‘OK’,
5) Click ‘Settings’, then ‘Setting Page’ appears.
6) Go to ‘Network Setting’ on the right side of the screen.
7) Input default IPAddress, Gateway, Netmask of SVP-1000 on the Network Setting Page.
8) 2 different DNSAddresses should be given.
9) Click ‘Apply’ to save setting values.
