VT-TPTZ32HRAN-8PNS
Transcendent Gen IV 8 MegaPixel [4K]
32× IP PTZ with A.I. Powered Facial
Detection and Auto-Tracking
PLEASE NOTE:
Complete User Guide, Software, Tools, and Updates are
available online. Scan the QR Code or visit:
http://www.vitekcctv.com/Downloads
*Shown with
optional wall mount
VT-TPT23HR-WM
KEY FEATURES
• 1/2.8” 8 MegaPixel [4K] SONY STARVIS® Progressive Scan StarlightCMOS Sensor
• NDAA Compliant
• Up to 8.0 MegaPixel [4K] (3840 × 2160) Resolution @ 30fps
• Ultra High-Speed Pan / Tilt / Zoom with 32× Optical Zoom Lens (4.8- 154mm Focal Length)
• Smart IR with 650’ (200m) IR Range
• Real-Time Auto Zoom Tracking: Transcendent GEN IV IP PTZ Cameras
feature the most advanced PTZ Auto-Tracking available, powered by A.I.!
• AI Facial Detection: Transcendent GEN IV Advanced Analytics deliver
improved Facial Detection, with up to 95% accuracy!
• Intelligent Tracking: Intelligent tracking is capable of tracking people, cars,
and bicycles entering and exiting the camera’s view
• True 120dB WDR (Wide Dynamic Range)
• Smart H.265+/H.265/H.264+/H.264/MJPEG Compression
• True Day/Night with ICR Cut Filter with Auto/Manual Gain Control
• 1 Alarm Input + 1 Alarm Output
• 1 Audio Input (MIC in) + 1 Audio Output
• Built-in MicroSD Card Slot, Supporting Local Recording up to 256GB
• Scalable Video Coding (SVC)
• Stealth Gimbal Driving Technology
• ONVIF Compliant with Zero Configuration + API and SDK
• IP66 Ingress Protection + IK10 Impact (Excludes Glass Window)
• DC24V, 24VAC or PoE++ Power Supply Included, PoE Injector Required for PoE Power
• 1 RJ45 10M/100M Adaptive Ethernet
• Optional Pendant, Semi-Flush, Corner, Pole, and Wall Mounts Available [See pg. 11]
• 3-Year Warranty
* Please research local, state and federal laws regarding the implementation of audio surveillance
** SONY™ is an independent and wholly owned corporation and has not tested or verified this
product’s compatibility with this sensor.
QUICK START GUIDE

2 3
DISCLAIMER:

3

4 5
anchors
1/2”

5
Install IP Tool onto the PC and then run IP Tool.
Edge in IE mode / IE browser.
Edge in IE mode / IE Network Connections
Alarm Connections
1. Alarm Input
a) There is one independent alarm input
port (ALM-IN1), and one grounding port (ALM-GND).
b) Alarm input (NO type): Connect DC5V~DC12V voltage between
the alarm input port (ALM-IN1) and the grounding port (ALM-GND).
c) Alarm input (NC type): DIsconnect the voltage between the alarm input port
(ALM-IN1) and the grounding port (ALM-GND)
2. Alarm Output
a) Supports 1CH alarm output including OPEN, COM connecitons.
b) Alarm output: One passive switch for a user to connect alarm devices:
the alarm output state will be on / off according to your users’ setting.

6 7

7
Edge in IE mode / IE browser to connect IP-CAM. Edge in IE
mode / IE browser will auto-download the Active X control. After
downloading, a login window will pop up:
Direct Access Through Edge in IE mode / IE

8 9
Open the Edge in IE Mode / IE browser and input the default
address of the IP-CAM and confirm. The Edge in IE Mode / IE
browser will download the Active X control automatically.
7.7” (196mm)
12.5”
(307mm)

9
Image Sensor 1/2.8” Sony STARVIS® Progressive Scan Starlight CMOS Sensor
Resolution 8.0 MegaPixel (3840 × 2160) Resolution @ 30fps
Min. Illumination Color: 0.01 Lux @ (F1.2 AGC On) B/W: 0.002 Lux @ (F1.2 AGC On), 0 Lux w/IR
Image setting Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, (Adjusted by Client)
Shutter Speed 60Hz: 1/30s - 1/30,000s, 50Hz: 1/25s - 1/25,000s
White Balance Auto / Manual / Indoor / Outdoor
Day / Night Auto / Manual + Schedule
Gain Control Auto / Manual
Iris Control Auto / Manual
SNR ≥52dB
DNR XD-DNR (3D-DNR / 2D-DNR) - Auto/Manual
WDR True WDR (120dB)
IR Range Up to 656’ IR Range (200M), Dual Stack 850nm IR Array
Smart IR Yes
Image Enhancement Backlight Compensation (BLC), Highlight Compensation (HLC)
Privacy Mask 4 Programmable Areas, Up to 8 Masks In the Same Frame
Overlay Features Picture: Custom Logo on video [128×128px], 24bit BMP
On-Screen Display Max 15 Character / Line, 8 Lines, White or Red Font
Lens / Focal Length 4.8~154mm Lens (32× Optical Zoom)
Zoom Speed Approx. 4.6s (Optical Zoom, Wide Tele)
Field of View (FOV) Horizontal: 61.3°~2.18° / Vertical: 36°.9~1.22° / Diagonal: 68.4°~2.5° (Wide-tele) **All listed speeds + / - 5%
Working Distance Wide: 1.0m ~ INF, Tele: 1.5m ~ INF
Iris F1.2 ~ F4.4 (wide-tele)
IR Cut type Removable IR Cut filter
D.O.R.I. f=154mm (US)
D.O.R.I. f=154mm (Metric)
Detect (8px/ft): 11575’, Observe (19px/ft): 4593’, Recognize (38px/ft): 2296’, Identify (76px/ft): 1148’
Detect (25px/M): 3528M, Observe (63px/M): 1400M, Recognize (125px/M): 700M, Identify (250px/M): 350M
D.O.R.I. f=4.8mm (US)
D.O.R.I. f=4.8mm (Metric)
Detect (8px/ft): 453.5’, Observe (19px/ft): 179.7’, Recognize (38px/ft): 90.8’, Identify (76px/ft): 45.4’
Detect (25px/M): 138M, Observe (63px/M): 54.8M, Recognize (125px/M): 27.8M, Identify (250px/M): 13.8M
Pan Range / Speed 360° Endless, Configurable from .5°/s ~ 120°/s; Preset speed: 150°/s
Tilt Range / Speed -5°~90° [Auto-Flip] / Configurable, from .5°/s ~ 120°/s; Preset speed: 150°/s
PTZ Features Proportional Zoom, Pwr-Off Memory, 3D Position, PTZ Position Display
Preset / Cruise 360 / 8 Cruises, Up to 16 Presets for Each Cruise
Tracks 4 Tracks, Record Time Over 3 Minutes for Each Track
Scheduled Tasks Preset / Cruise / Track / Random Scan / Boundary Scanning / Dome Reboot
Max Resolution 3840 × 2160
DETAILED SPECIFICATIONS

10 11
Main Stream 60Hz: 30fps:3840 × 2160,2560 × 1440,1920 × 1080,1280 × 960,1280 × 720
50Hz: 25fps: 3840 × 2160,2560 × 1440,1920 × 1080,1280 × 960,1280 × 720
Sub Stream 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
50Hz: 25fps: (704 × 576, 640 × 480, 352 × 288)
Third Stream 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
Video Compression H.265+/H.265/H.264+/H.264/MJPEG
Compression Standards H.265: HEVC Codec MP, Level 5.0, H.264: AVC codec BP/MP/HP, Level 5.1
Video Bit Rate 64Kbps to 16Mbps
Audio Compression / Bit Rate G.711A/U / 64Kbps
Deep Learning Engine Supports Face Recognition (FR) up to 15 Human Faces / Sec (max), Human/Vehicle Detection
Smart Auto Tracking Auto Tracking (supports tracking specified target types such as human and vehicle), Manual Tracking
Basic Event Detection Motion detection, Video Tampering, Exception (Network Disconnected, IP Address Conflict, SD Card Full / Error)
Smart Event Detection Trip Wire (+ Bi-Directional), Intrusion / Line Crossing / Region Entering + Exiting, Support Alarm Triggering by
Specified Target Types (Human / Vehicle), Un-attended Baggage, Object Removal, Auto / Manual Smart Tracking
Gen. IV Advanced Analytics Face Detection (15 Faces Simultaneously), Detect, Track, Capture + Vehicle / Non Vehicle Detection & Tracking
Protocols HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/
IP, UDP, DHCP, PPPoE
Audio Interface 1 Audio Input (MIC in), 1 Audio Output, Line Level, Impedance, 600Ω*
Alarm Interface 1 Alarm Input (Dry Contact); 1 Alarm Output
Alarm Linkage Alarm Actions, Including Preset, Cruise, Track, Memory Card Video Record, Trigger Recording,
Upload to FTP/Memory, Card, Send Email
Reset Button Yes
Live View Connections Up to 6 Simultaneous Live View Connections
User/Host Up to 16 users, 3 levels: Administrator, Advanced and Normal Users
Security Measures User Authentication (ID and PW), Host authentication (MAC address); HTTPS encryption., IEEE802.1x port-based
net account control; IP address filtering
Web Browser Internet Explorer (IE) - Plug-in Required, Edge in IE Mode
Network Interface 1 RJ45 10M/100M Adaptive Ethernet, Support PoE++( 802.3.bt)
API ONVIF, Third-Party Integration
CVBS (BNC), RS485 NA
On-Board Storage Built-in microSD/SDHC/SDXC card slot, up to 256GB
Thermal Management Internal Heater and Fan, Hot Air Blows on Glass to Remove Frost, Ice, Remove Water-Droplets w/ Quick Spinning
Lens Wiper NA
Working Environment 40°F ~ 149°F (-40°C ~ 65°C), Cold start at -22°F (30°C) (0.5 Hour Warm-up Time), ≤90%RH Non-condensing
Weather Rating / Protection IP66, 6000V (Lightning, Surge, and Voltage Transient Protection)
Impact Protection IK10 (Excluding Glass Window)
Power DC24V/24VAC** @ 2.5amps, PoE++ (34W with IR on and PTZ Working)
Dimensions and Weight 7.7” × 12.5” (196mm × 307mm), 8.31lb (3.7kg)
Please research local, state and federal laws regarding the implementation of audio surveillance
SONY™ is an independent and wholly owned corporation and has not tested or verified this product’s
compatibility with this sensor.
DETAILED SPECIFICATIONS CONT’D...
*Power Supply Included, PoE Injector Required for PoE Power - see next page

11
Pendent/Ceiling Mount
VT-TP20HR-PM
Universal
Pole Mount Adapter
VT-TPLMT
Universal
Corner Mount Adapter
VT-TC N MT
VT-TPT20HR-PM VT-TPLMT VT-TCNMT
OPTIONAL ACCESSORIES
FOR VT-TPTZ32HRAN-8PNS
VT-POE60 / VT-POE95
MidSpan PoE Injectors
(sold separately)
VT-TPT23HR-WM
Univeral Wall Mount for
Transcendent IP PTZ
Cameras including
VT-TPTZ232RAN-8PNS
*Both VT-TPLMT and VT-TCNMT Req.
VT-TPT23HR-WM

12 PB
LIMITED PRODUCT
WARRANTY
VITEK products carry a three (3) year limited warranty. VITEK warrants to the
purchaser that products manufactured by VITEK are free of any rightful claim
of infringement or the like, and when used in the manner intended, will be
free of defects in materials and workmanship for a period of three (3) years,
or as otherwise stated above, from the date of purchase by the end user.
This warranty is nontransferable and extends only to the original buyer or end
user customer of a VITEK Authorized Reseller.
The product must have been used only for its intended purpose, and not
been subjected to damage by misuse, willful or accidental damage, caused
by excessive voltage or lightning.
The product must not have been tampered with in any way or the guarantee
will be considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become necessary.
28492 CONSTELLATION ROAD VALENCIA, CA 91355
WWW.VITEKCCTV.COM
Version 1.0
Oct. 2022
