Vitek Transcendent VT-TPTZ25HRAN-4PNL User manual

VITEK
VITEK
VT-TPTZ25HRAN-4PNL
Transcendent Gen. IV
4 MegaPixel 25× IP PTZ with A.I.
QUICK START GUIDE
FEATURES
• 1/2.7” BSI and NIS (Backside-Illuminated and Near-Infrared Sensing)
4 MegaPixel Progressive Scan CMOS STARLIGHT Sensor
•Up to 4 MegaPixel (2560 × 1440) Max Resolution @ 30fps
•Ultra High-Speed Pan / Tilt / Zoom with 25× Optical Zoom Lens
•3.6s Zoom Speed (Optical, Wide-Tele), F1.65~F3.8 Aperture Range
•Smart IR with up to 525’ (160m) IR Range
•Smart H.265+/H.265/H.264+/H.264/MJPEG Compression
•Real-Time Auto Zoom Tracking: Transcendent Gen. IV IP PTZ Cameras Feature the Most
Advanced PTZ Auto-Tracking Available, Powered by A.I.
•Gen. IV Advanced Analytics: Intrusion Detection, Line Crossing, Region Entrance / Exit,
Target Counting [All by Human / Vehicle Classification] Scene Change, Face Detection
•Backlight / Highlight Compensation, Auto-White Balance, Gain Control, Day / Night
•True 120dB WDR (Wide Dynamic Range)
•360 Presets, 8 Cruises, up to 16 Presets / Cruise + 4 Tracks (3+ Min. Recording / Track)
•1 Ch. Audio In + Out*, 1 Ch. Alarm In + Out
• Advanced Starlight Technology
•True Day/Night with ICR Cut Filter with Auto/Manual Gain Control
•360° Endless Pan Range, Configurable Speed: .1~200°/s + 240°/s Preset
•Built-in MicroSD Card Slot, Supporting Local Recording up to 256GB
•IP66 Ingress Protection + IK10 [Excluding Glass] Impact Rating
•12VDC Power or PoE+ (802.3.at, class 3)
*12VDC 3Amps Power Supply Included, **PoE Injector Required for PoE Power: VT-POE60 / VT-POE95 [see pg. 13]
•Reset Button, Heater, Fan, Water Removal with Quick Spinning
•1 RJ45 10M/100M Adaptive Ethernet (Supports PoE 802.3.at)
•Wall Mount, Pendant Mount, Semi-Flush Mount, Corner Mount Adapter and
Pole Mount Adapter Sold Separately [see pg. 13]
•3-Year Warranty
*Please research local, state and federal laws regarding the implementation of audio surveillance
PLEASE NOTE:
Complete User Guide, Software, Tools, and Updates are
available online. Scan the QR Code or visit:
http://www.vitekcctv.com/Downloads
*Shown with wall mount
VT-TPT23HR-WM
[SOLD SEPARATELY]

2 3
Cable Connections
Overview
First connect the Weather Resistant Cap to an Ethernet patch cable, then connect
cameras’ ethernet adaptor. If not powering the camera with PoE+, also connect the
power cable to an approved 12VDC Power Supply.
Weather Resistant Network Coupler
1. Loosen the nut from the Weather Resistant Network Coupler.
2. Run ethernet cable through coupler, then attach a RJ-45 connector.
3. Tighten the nut and coupler for a weather resistant seal.
1. LAN
2. HP Audio Out
3. MIC In
4. Alarm In / Alarm Out
5. Power
6. Grounding Wire
7. Safety Cable

3
Cable Connections
Overview
First connect the Weather Resistant Cap to an Ethernet patch cable, then connect
cameras’ ethernet adaptor. If not powering the camera with PoE+, also connect the
power cable to an approved 12VDC Power Supply.
Weather Resistant Network Coupler
1. Loosen the nut from the Weather Resistant Network Coupler.
2. Run ethernet cable through coupler, then attach a RJ-45 connector.
3. Tighten the nut and coupler for a weather resistant seal.
1. LAN
2. HP Audio Out
3. MIC In
4. Alarm In / Alarm Out
5. Power
6. Grounding Wire
7. Safety Cable
Installation
Alarm Connections
Before beginning, make sure that the wall or ceiling is strong enough to
1. Alarm Input
a) There is one independent alarm input
port (ALM-IN1), and one grounding port (ALM-GND).
b) Alarm input (NO type): Connect DC5V~DC12V voltage between
the alarm input port (ALM-IN1) and the grounding port (ALM-GND).
c) Alarm input (NC type): DIsconnect the voltage between the alarm input port
(ALM-IN1) and the grounding port (ALM-GND)
2. Alarm Output
a) Supports 1CH alarm output including OPEN, COM connections.
b) Alarm output: One passive switch for a user to connect alarm devices:
the alarm output state will be on / off according to your users’ setting.
withstand the weight of the camera, and that the power is off.*Wall mounting
instructions are below, followed by ceiling mounting and semi-ush mounting.
MicroSD Card
Installation
1. Loosen the cover’s 4 screws
and remove it.
2. Insert a microSD card as
indicated (right) and re-install
the cover.
Insert a
MicroSD

4 5
1. Install the ceiling mount according to the following diagram:
3. Attach the bracket
to the wall with four
screws.
4.Hook the safety wire to the bracket.
Then connect the cables. After that,
attach the speed dome to the bracket
with the screws.
Installation Using Wall Mount VT-TPT23HR-WM
*see page 10 for mount dimensions
(mount sold separately)
1. Fasten the adapter to
the bracket.
2. Drill the screw holes in the
wall according to the template.
Then insert the plastic plugs
into the holes.
.32”
3.10”
3.94”

5
1. Install the ceiling mount according to the following diagram:
3. Attach the bracket
to the wall with four
screws.
4.Hook the safety wire to the bracket.
Then connect the cables. After that,
attach the speed dome to the bracket
with the screws.
Installation Using Wall Mount VT-TPT23HR-WM
*see page 10 for mount dimensions
(mount sold separately)
1. Fasten the adapter to
the bracket.
2. Drill the screw holes in the
wall according to the template.
Then insert the plastic plugs
into the holes.
.32”
3.10”
3.94”
Installation Using Semi-Flush Ceiling Mount VT-TPT20HR-FM
*see page 10 for mount dimensions (mount sold separately)
*The following illustrations are for
demonstration purposes only, and depictions
of the PTZ camera used as an example
will dier from the actual camera.
4. Connect cables, then hook the
safety wire to the adapter stem.
5. Securely attach the camera
to the adapter stem with screws.
Adapter tube
2. Mount the adapter tube to the
bracket and secure it with a screw.
3. Secure the pendent mounting
bracket to the ceiling.

6 7
Attach
8.35”
s Thr
8.35
LAN Configuration
The camera can be accessed on the local network either using the
IP-Tool or directly in a web browser.
Accessing the Camera Using the IP-Tool
1. Make sure the camera and PC are connected to the LAN.
2. Locate the IP-Tool installer at www.
vitekcctv.com/Downloads/Soft-
ware/Transcendent-IPTool_v2.0.2.zip
, then install on the PC. Open
the installed application.
3. Modify the IP address. The default IP address is 192.168.226.201.
Click the information of the camera listed in the above table to show
the network information on the right side. Modify the IP address and
gateway of the camera and make sure its network address is in the
same local network segment as the computer’s. Please modify the
IP address of your device according to the practical situation.
For example, the IP address of your computer
is 192.168.13.4. So the IP address of the
camera shall be changed to 192.168.13.X.
After modification, please input the password
of the administrator and click “Modify” button
to modify the setting.
** Default admin password: “123456".
MENU
N etwor k C a bl e N etwor k C a bl e
Switch
R outer C omputer
P T Z C amer a

7
LAN Configuration
The camera can be accessed on the local network either using the
IP-Tool or directly in a web browser.
Accessing the Camera Using the IP-Tool
1. Make sure the camera and PC are connected to the LAN.
2. Locate the IP-Tool installer at www.
vitekcctv.com/Downloads/Soft-
ware/Transcendent-IPTool_v2.0.2.zip
, then install on the PC. Open
the installed application.
3. Modify the IP address. The default IP address is 192.168.226.201.
Click the information of the camera listed in the above table to show
the network information on the right side. Modify the IP address and
gateway of the camera and make sure its network address is in the
same local network segment as the computer’s. Please modify the
IP address of your device according to the practical situation.
For example, the IP address of your computer
is 192.168.13.4. So the IP address of the
camera shall be changed to 192.168.13.X.
After modification, please input the password
of the administrator and click “Modify” button
to modify the setting.
** Default admin password: “123456".
MENU
N etwor k C a bl e N etwor k C a bl e
Switch
R outer C omputer
P T Z C amer a

8 9
4. Double-click the IP address and then the system will pop up the
web browser to connect IP-CAM. Edge in IE mode / IE browser
will download the Active X. control. After downloading, a login
window will pop up as shown below:
Input the user name and password to log in.
Default user name: admin / Default password: 123456.
Directly Access Through a Web Browser
The default network settings are as shown below:
IP address: 192.168.226.201 HTTP: 80
Subnet Mask: 255.255.255.0 Data Port: 9008
Gateway: 192.168.226.1
You may use the above default settings when you log in the camera for
the first time.
1. Manually set the IP address of the PC. The network segment should
be the same as the default settings of IP-CAM. Open the network
and share center. Click “Local Area Connection” to pop up the
following window.
Select “Properties” and then select Internet protocol according to the
actual situation (for example: IPV4). Next, click “Properties” button to
set the network of the PC.
2. Open Edge in IE mode / IE browser and input the default address
of IP-CAM and confirm. Edge in IE mode / IE browser will
download Active X control.
3. After downloading Active X control, the login dialog box will pop up.
4. Input the default username and password and then enter to view.
WAN Configuration
Access the camera by the router or virtual server for example.
1. Make sure the camera is connected to the LAN; Then log into the
menu to set up the port number.
the IP address.
4. Open the web browser and input its WAN IP and HTTP port to
access the IP-CAM.
3. Go to the router’s management interface through IE browser to
forward the IP address and port of IP-CAM in the “Virtual Server”.

9
2. Open Edge in IE mode / IE browser and input the default address
of IP-CAM and confirm. Edge in IE mode / IE browser will
download Active X control.
3. After downloading Active X control, the login dialog box will pop up.
4. Input the default username and password and then enter to view.
WAN Configuration
Access the camera by the router or virtual server for example.
1. Make sure the camera is connected to the LAN; Then log into the
menu to set up the port number.
the IP address.
4. Open the web browser and input its WAN IP and HTTP port to
access the IP-CAM.
3. Go to the router’s management interface through IE browser to
forward the IP address and port of IP-CAM in the “Virtual Server”.

10 11
Installation Mount Dimensions
VT-TPT20HR-FM
VT-TPT20HR-PM
VT-TPT23HR-WM
10.07”
5.32”
3.94”
7.22”
2.48”
3.51”
2.48”
2.54”
9.17”
9.17”
5.10”
4.27”

11
DETAILED SPECIFICATIONS
Image Sensor 1/2.7” BSI (Backside-Illuminated) and NRI (Near-Infrared Sensing) Progressive Scan STARLIGHT CMOS Sensor
Pixel Size 2.0um
Effective Pixels 2884(H) × 1624(V)
Resolution 4.0 MegaPixel (2560 ) Resolution @ 30fps
Min. Illumination Color: 0.01 Lux @ (F1.65 AGC On) B/W: 0.002 Lux @ (F1.65 AGC On), 0 Lux w/IR
Image setting Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, (Adjusted by Client)
Shutter Speed 60Hz (NTSC): 1/30s ~ 1/30,000s, 50Hz (PAL): 1/25s ~1/25,000s
White Balance Auto / Manual / Indoor / Outdoor
Day / Night True Day/Night via ICR Cut Filter + Schedule [Auto/Manual Gain Control]
Iris Control Auto / Manual
SNR ≥52dB
DNR XD-DNR (3D-DNR / 2D-DNR) - Auto/Manual
WDR True WDR (120dB)
IR Type / Distance Smart IR - Up to 525’ IR Range (160M)
Smart IR Yes
Image Enhancement Backlight Compensation (BLC), Highlight Compensation (HLC)
Privacy Mask 4 Areas, up to 4 Masks in a Single Frame
Overlay Features Picture: Custom Logo on video [128x128px], 24bit BMP, OSD: Max 15 Character / Line, 8 Lines, White or Red Font
Lens / Focal Length 4.8~120mm Lens (25x Optical Zoom) w/3.6s Zoom Speed, and Digital Zoom
Zoom Speed Approx. 3.6s (Optical Zoom, Wide Tele)
Field of View (FOV) Horizontal: 55°~2.4° / Vertical: 33°~1.4° / Diagonal: 61.5°~2.8° (Wide-tele) **All listed speeds + / - 5%
Working Distance Wide: 1.0m ~ INF, Tele: 1.5m ~ INF
Aperture Range F1.65 ~ F3.8 (wide-tele)
Iris Type Auto DC-IRIS, 16 Stops
IR Cut type Removable IR Cut filter
D.O.R.I. (US)
D.O.R.I. (Metric)
Detect (8px/ft): 7874’, Observe (19px/ft): 3124’, Recognize (38px/ft): 1575’, Identify (76px/ft): 787’
Detect (25px/M): 2400M, Observe (63px/M): 952M, Recognize (125px/M): 480M, Identify (250px/M): 240M
Pan Range / Speed 360° Endless, Configurable from .1°/s ~ 200°/s; Preset speed: 240°/s
Tilt Range / Speed -10°~90° [Auto-Flip] / Configurable, from 0.1/s~200°/s, Preset speed: 240°/s
PTZ Features Proportional Zoom, Pwr-Off Memory, 3D Position, PTZ Position Display
Preset / Cruise 360 / 8 Cruises, Up to 16 Presets for Each Cruise
Tracks 4 Tracks, Record Time Over 3 Minutes for Each Track
Scheduled Tasks Preset / Cruise / Track / Random Scan / Boundary Scanning / Dome Reboot
Max Resolution 2560x1440 (16:9 Aspect Ratio)

12 13
DETAILED SPECIFICATIONS CONT’D.
Main Stream 30fps: 2560×1440,1920×1080,1280×960,1280×720
Sub Stream / Third Stream Sub: 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) / Third: 30fps @ 1920×1080 (1080p) and Lower
Video Compression (Standards) H.265+/H.265/H.264+/H.264/MJPEG (H.265: H.265 / HEVC Codec MP, Level 5.0, H.264: H.264/AVC codec BP/MP/HP, Level 5.1)
Video Bit Rate 64Kbps to 8Mbps
Audio Compression / Bit Rate G.711A/U / 64Kbps
Deep Learning Engine Supports Face Recognition (FR) up to 15 Human Faces / Sec (max), Human/Vehicle Detection
Smart Auto Tracking Auto Tracking (supports tracking specified target types such as human and vehicle), Manual Tracking
Basic Event Detection Motion detection, Video Tampering, Exception (Network Disconnected, IP Address Conflict, SD Card Full / Error)
Smart Event Detection Trip Wire (+ Bi-Directional), Intrusion / Line Crossing / Region Entering + Exiting, Support Alarm Triggering by
Specified Target Types (Human / Vehicle), Un-attended Baggage, Object Removal, Auto / Manual Smart Tracking
Gen. IV Advanced Analytics Face Detection (15 faces simultaneously), Detect, Track, Capture + Vehicle / Non Vehicle Detection & Tracking
Protocols HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/
IP, UDP, DHCP, PPPoE
Audio Interface 1 Audio Input (MIC in), 1 Audio Output,* Line Level, Impedance, 600Ω
Alarm Interface 1 Alarm Input (Dry Contact); 1 Alarm Output
Alarm Linkage Alarm Actions, Including Preset, Cruise, Track, Memory Card Video Record, Trigger Recording,
Upload to FTP/Memory, Card, Send Email
Live View Connections Up to 6 Simultaneous Live View Connections
User/Host Up to 16 users, 3 levels: Administrator, Advanced and Normal Users
Security Measures User Authentication (ID and PW), Host authentication (MAC address); HTTPS encryption., IEEE802.1x port-based
net account control; IP address filtering
Web Browser Internet Explorer (IE) - Plug-in Required, Edge in IE Mode
API ONVIF, Third-Party Integration
CVBS (BNC), RS485 NA
On-Board Storage Built-in microSD/SDHC/SDXC card slot, up to 256GB
Network Interface 1 RJ45 10M/100M Adaptive Ethernet (Support PoE+ 802.3.at)
Thermal / Weather Management Internal Heater and Fan + Quick Spin Water Removal
Reset Button YES
Working Environment -40°F~140°F (-40°C~60°C), 90% RH [STORAGE CONDITIONS: -40°F~158°F (-40°C~70°C), 95% RH]
Cold Start -22F / - 30°C (30 Minutes Waiting Time), 90% RH
Weather / Impact / Protection IP66 + IK10 (Excl. Glass Window), 6000V (Lightning, Surge, and Voltage Transient Protection)
Power 12VDC @ 3amps, PoE+ (23W with IR on, PTZ on)
*Power Supply Included ,**PoE Injector Req’d for PoE Power - see following page
Dimensions and Weight 6.81” × 10.51” (173mm × 268mm), NET: 4.85lb (2.2kg) / SHIPPING: 7.50lb (3.4kg)
*Please research local, state and federal laws regarding the implementation of audio surveillance
*INCLUDED* POWER SUPPLY
12VDC 3amp Power Supply

13
ACCESSORIES AVAILABLE
FOR VT-TPTZ25HRAN-4PNL
VT-TWM36
Optional 3’ (1M) Extended
Wall Mount - White
MOUNTS [SOLD SEPARATELY]
POE INJECTORS [SOLD SEPARATELY]
VT-TPLM36
Optional 3’ (1M) Extended
Pole Mount Bracket - White
VT-TCNM36
Optional 3’ (1M) Extended
Corner Mount Bracket -
White
VT-POE60
60 Watt POE Mid-Span Injector, 4-Pair Compliant
VT-POE95
95 Watt POE Mid-Span Injector, 4-Pair Compliant
VT-TPT20HR-FM
Semi-flush Mount
VT-TPT20HR-PM
Optional Ceiling/
Pedestal Mount for
Transcendent
IP PTZs
VT-TC N MT-W
Transcendent
Universal Corner
Mount Adapter -
White (reqs.
VT-TPT23HR-WM)
VT-TPT23HR-WM
Optional Universal
Wall Mount for
Transcendent
IP PTZs
VT-TPLMT-W
Transcendent
Universal Pole
Mount Adapter -
White (reqs.
VT-TPT23HR-WM)

14 15
Pair with VITEK Transcendent Series NDAA Compliant
Network Recorders: VT-TNR818PFN, VT-TNR1646PFN,
and VT-TNR3216PFN with Built-in PoE and Gen IV.
Advanced A.I. including Face Detection, Target
Counting, and Other Fully Programmable Analytics.
ALSO CONSIDER THESE
OTHER GREAT TRANSCENDENT
IP PRODUCTS!
VITEK Network Video Recorders Supporting up to
12MP Resolution & Real Time Video!

15
Vitek Wireless Access Points to Reduce Costly
Cable Installation!
VT-WAP1150 and VT-WAP2150 High Speed 5.8GHz DIP AP /
CPE Wireless Bridge w/ 8MB Storage, 64MB RAM, 150MBps
transmission, and Point-to-Multi-Point (P2MP) Topology
With high speed transmission of 150Mbps and a wireless range
of 3000ft. (VT-WAP1150) and 1.25 miles (VT-WAP2150) these
products eliminate the need for expensive and troublesome long-
distance cables in areas where CCTV monitoring and rigorous
surveillance take place. These small, lightweight and durable units are
easy to install and easy to use with an innovative and straightforward
10-button plug-and-play dip switch that facilitates the creation of a
robust wireless network without a computer. Set-up can be simply
configured for point-to-point or point-to-multipoint topology depending
on the application, with up to 128 IP group configurations!
VT-WAP1150 VT-WAP2150

16 PB
LIMITED PRODUCT
WARRANTY
VITEK products carry a three (3) year limited warranty. VITEK warrants to the
purchaser that products manufactured by VITEK are free of any rightful claim
of infringement or the like, and when used in the manner intended, will be
free of defects in materials and workmanship for a period of three (3) years,
or as otherwise stated above, from the date of purchase by the end user.
This warranty is nontransferable and extends only to the original buyer or end
user customer of a VITEK Authorized Reseller.
The product must have been used only for its intended purpose, and not
been subjected to damage by misuse, willful or accidental damage, caused
by excessive voltage or lightning.
The product must not have been tampered with in any way or the guarantee
will be considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become necessary.
28492 CONSTELLATION ROAD VALENCIA, CA 91355
WWW.VITEKCCTV.COM
Version 1.0
Nov 2022
CLASS A DIGITAL DEVICE (INDUSTRIAL & COMMERCIAL ENVIRONMENT)
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to CE and FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause harm-
ful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be required to correct
