Vitek VTD-B72 User manual

Industrial Video Products, Inc. "Quality Products At An Affordable Price"
Specifications
PERFORMANCE YOU NEED
QUALITY YOU TRUST
9970 GLENOAKS BLVD. UNIT B SUN VALLEY, CA 91352
PHONE: 888-VITEK-70 818-771-0300 FAX: [phone]
WWW.VITEKCCTV.COM
VTD-C14
VTD-C14
VTD-C75
VTD-C75
VTD-B72
VTD-B72
Image Device
Effective Pixels
Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Gamma Correction
White Balance
AGC
BLC Function
Lens Angle
Video Output
Power Source
Power Consumption
Standard Lens
Dimensions (W x H)
Weight
1/4" Color Panasonic CCD image sensor
512 x 492
380 TV Lines
1 Lux / F2.0
More Than 48dB (AGC Off)
1/60 to 1/100,000 sec.
0.45
Auto White Balance
Yes
N/A
70°
Composite: 1.0 Vp-p / 75Ω
12VDC (+/-10%)
80mA
f3.6mm / F2.0 (2.9/6/8/12mm Optional)
3.43" x 3.18"
280 g. / 9.87 oz. / 0.611 lbs.
1/3” Color Sony CCD Image Sensor
510 x 492
420 TV Lines
0.5 Lux / F2.0
More Than 48 db
1/60 to 1/100,000 sec.
N/A
Auto White Balance
N/A
Auto Detect
92°
Composite: 1.0 Vp-p / 75Ω
12VDC (+/-10%)
120mA
f3.6mm / F2.0 (2.9/6/8/12mm Optional)
3.43" x 3.18"
280 g. / 9.87 oz. / 0.611 lbs.
1/3" B/W Sony CCD image Sensor
512 x 492
400 TV Lines
0.1 Lux / F2.0
More Than 48dB
1/60 to 1/100,000 sec.
N/A
N/A
N/A
N/A
92°
Composite: 1.0 Vp-p / 75Ω
12VDC (+/-10%)
120mA
f3.6mm / F2.0 (2.9/6/8/12mm Optional)
3.43" x 3.18"
280 g. / 9.87 oz. / 0.611 lbs.
