Vitek VT-IR1C/24 User manual

FEATURES
VT-IR1C/24
COLOR INFRARED CCD CAMERA
INDUSTRIAL VIDEO PRODUCTS, INC.
"QUALITY PRODUCTS AT AN AFFORDABLE PRICE"
PERFORMANCE YOU NEED
QUALITY YOU TRUST
BLK PMS 356
S
WWANN
G
R AP HIC S
17185 McKeever St.
Granada Hills, CA 91344
Tel [phone]
Fax [phone]
1/3” COLOR CCD CAMERA WITH 6MM LENS STD.
400 LINES RESOLUTION
AUTOMATICALLY SWITCHES TO B/W IN LOW LIGHT
CONDITIONS
I.R. RANGE BEYOND 45 FEET
56˚BEAM SPREAD
SEMI-COVERT 840NM WAVELENGTH
PHOTOCELL AUTOMATICALLY DETECTS DARKNESS
TO PRESERVE ENERGY
OPTIONALLENSCONFIGURATIONS(8 + 12MM)
24 VAC POWER INPUT
12 VDC VERSION ALSO AVAILABLE
The VT-IR1C/24 is a highly versatile color camera
capable of delivering detailed color images by day as
well as crisp, clear black & white images in total
darkness. Low voltage 24vac and 12vdc versions are
available for ease of installation. A durable aluminum
construction and built-in fan with photocell make the
VT-IR1C/24 and VT-IR1C/12 ideal for any indoor or
outdoor surveillance application.
The
everything
cam

QUALITY YOU TRUST
SPECIFICATIONS
PERFORMANCE YOU NEED
INDUSTRIAL VIDEO PRODUCTS, INC.
9970 GLENOAKS BLVD. UNIT B
SUN VALLEY, CALIFORNIA 91 52
PHONE: 888-VITEK-70 818-771-0 00
FAX: [phone]
www.vitekcctv.com
VT-IR1C/24
Pick Up Device 1/3” CCD Image Sensor
Picture Elements 512H x 492V (EIA)
Resolution 400 TV Lines
Scanning System 525 Line / 60 Fields (EIA)
SYNC. System Internal SYNC.
S/N Ratio Better than 46dB (AGC OFF)
.45
Automatic
White Balance
Gamma Correction
Color Black/White (IR on) Color (IR off)
Backlight Compensation Automatic
Shutter Control 1/60 To 1/10000 SEC
Video Out 1.OV P-P / 75 OHM
Lens Mount Type Board Lens Mount 6mm F1.8 Standard
LED Lifetime Approximately 6000 hours
Heat Dissipation Built-In fan / Ventilation Holes / Aluminum Construction
Wave Length 840nm
Beam Spread 56˚
Range 50 Feet
Min. Illumination 0 LUX (illuminator on) 3 LUX (illuminator off)
Power Source 24 VAC / 12 VDC (Model VT-IR1C/12)
Power Consumption
Power on
Dimensions
Weight
650 mA
CCD Camera Direct From Power Supply
IR Illuminator From CDS Control
4.1”W x 5.1”H x 6.3”L
1.93 lbs
BLK PMS 356
S
WWANN
G
R AP HIC S
17185 McKeever St.
Granada Hills, CA 91344
Tel [phone]
Fax [phone]
VT-IRMT
OPTIONAL WALL MOUNT
