Vitek VT-TPTZ25HRAN-8PNL User manual

VITEK
VITEK
VT-TPTZ25HRAN-8PNL
Transcendent Gen. IV
8 MegaPixel [4K] 25×
IP PTZ with A.I.
QUICK START GUIDE
FEATURES
• 1/2.8” Sony STARVIS®* 8 MegaPixel [4K] Progressive Scan CMOS STARLIGHT Sensor
•Up to 8 MegaPixel (3840 × 2160) Max Resolution @ 30fps
•Ultra High-Speed Pan / Tilt / Zoom with 25× Optical Zoom Lens (4.8-120mm Focal
Length)
•3.6s Zoom Speed (Optical, Wide-Tele), F1.65~F3.8 Aperture Range
•Smart IR with up to 492’ (150m) IR Range
•Smart H.265+/H.265/H.264+/H.264/MJPEG Compression
•Real-Time Auto Zoom Tracking: Transcendent Gen. IV IP PTZ Cameras Feature the Most
Advanced PTZ Auto-Tracking Available, Powered by A.I.
•Gen. IV Advanced Analytics: Intrusion Detection, Line Crossing, Region Entrance / Exit,
Target Counting [All by Human / Vehicle Classification] Scene Change, Face Detection /
Capture
•Backlight / Highlight Compensation, Auto-White Balance, Gain Control, Day / Night
•True 120dB WDR (Wide Dynamic Range)
•360 Presets, 8 Cruises, up to 16 Presets / Cruise + 4 Tracks (3+ Min. Recording / Track)
•1 Ch. Audio In + Out**, 1 Ch. Alarm In + Out
• Advanced Starlight Technology
•True Day/Night with ICR Cut Filter with Auto/Manual Gain Control
•360° Endless Pan Range, Configurable Speed: .1~200°/s + 240°/s Preset
•Built-in MicroSD Card Slot, Supporting Local Recording up to 256GB
•IP66 Ingress Protection + IK10 [Excluding Glass] Impact Rating
•12VDC Power or PoE+ (802.3.at, class 3)
*12VDC 3Amps Power Supply Included, **PoE Injector Required for PoE Power: VT-POE60 / VT-POE95 [see pg. 13]
•Reset Button, Heater, Fan, Water Removal with Quick Spinning
•1 RJ45 10M/100M Adaptive Ethernet (Supports PoE 802.3.at)
•Wall Mount, Pendant Mount, Semi-Flush Mount, Corner Mount Adapter and
Pole Mount Adapter Sold Separately [see pg. 13]
•3-Year Warranty
* SONY™ is an independent and wholly owned corporation
** Please research local, state and federal laws regarding the implementation of audio surveillance
PLEASE NOTE:
Complete User Guide, Software, Tools, and Updates are
available online. Scan the QR Code or visit:
http://www.vitekcctv.com/Downloads
*Shown with wall mount
VT-TPT23HR-WM
[SOLD SEPARATELY]

2 3
Cable Connections
Overview
First connect the Weather Resistant Cap to an Ethernet patch cable, then connect
cameras’ ethernet adaptor. If not powering the camera with PoE+, also connect the
power cable to an approved 12VDC Power Supply.
Weather Resistant Network Coupler
1. Loosen the nut from the Weather Resistant Network Coupler.
2. Run ethernet cable through coupler, then attach a RJ-45 connector.
3. Tighten the nut and coupler for a weather resistant seal.
1. LAN
2. HP Audio Out
3. MIC In
4. Alarm In / Alarm Out
5. Power
6. Grounding Wire
7. Safety Cable

3
Installation
Alarm Connections
Before beginning, make sure that the wall or ceiling is strong enough to
1. Alarm Input
a) There is one independent alarm input
port (ALM-IN1), and one grounding port (ALM-GND).
b) Alarm input (NO type): Connect DC5V~DC12V voltage between
the alarm input port (ALM-IN1) and the grounding port (ALM-GND).
c) Alarm input (NC type): DIsconnect the voltage between the alarm input port
(ALM-IN1) and the grounding port (ALM-GND)
2. Alarm Output
a) Supports 1CH alarm output including OPEN, COM connections.
b) Alarm output: One passive switch for a user to connect alarm devices:
the alarm output state will be on / off according to your users’ setting.
withstand the weight of the camera, and that the power is off.*Wall mounting
instructions are below, followed by ceiling mounting and semi-ush mounting.
MicroSD Card
Installation
1. Loosen the cover’s 4 screws
and remove it.
2. Insert a microSD card as
indicated (right) and re-install
the cover.
Insert a
MicroSD

4 5
1. Install the ceiling mount according to the following diagram:
3. Attach the bracket
to the wall with four
screws.
4.Hook the safety wire to the bracket.
Then connect the cables. After that,
attach the speed dome to the bracket
with the screws.
Installation Using Wall Mount VT-TPT23HR-WM
*see page 10 for mount dimensions
(mount sold separately)
1. Fasten the adapter to
the bracket.
2. Drill the screw holes in the
wall according to the template.
Then insert the plastic plugs
into the holes.
.32”
3.10”
3.94”

5
Installation Using Semi-Flush Ceiling Mount VT-TPT20HR-FM
*see page 10 for mount dimensions (mount sold separately)
*The following illustrations are for
demonstration purposes only, and depictions
of the PTZ camera used as an example
will dier from the actual camera.
4. Connect cables, then hook the
safety wire to the adapter stem.
5. Securely attach the camera
to the adapter stem with screws.
Adapter tube
2. Mount the adapter tube to the
bracket and secure it with a screw.
3. Secure the pendent mounting
bracket to the ceiling.

6 7
Attach
8.35”
s Thr
8.35
LAN Configuration
The camera can be accessed on the local network either using the
IP-Tool or directly in a web browser.
Accessing the Camera Using the IP-Tool
1. Make sure the camera and PC are connected to the LAN.
2. Locate the IP-Tool installer at www.
vitekcctv.com/Downloads/Soft-
ware/Transcendent-IPTool_v2.0.2.zip
, then install on the PC. Open
the installed application.
3. Modify the IP address. The default IP address is 192.168.226.201.
Click the information of the camera listed in the above table to show
the network information on the right side. Modify the IP address and
gateway of the camera and make sure its network address is in the
same local network segment as the computer’s. Please modify the
IP address of your device according to the practical situation.
For example, the IP address of your computer
is 192.168.13.4. So the IP address of the
camera shall be changed to 192.168.13.X.
After modification, please input the password
of the administrator and click “Modify” button
to modify the setting.
** Default admin password: “123456".
MENU
N etwor k C abl e N etwor k C a bl e
Switch
R outer C omputer
P T Z C a mer a

7
LAN Configuration
The camera can be accessed on the local network either using the
IP-Tool or directly in a web browser.
Accessing the Camera Using the IP-Tool
1. Make sure the camera and PC are connected to the LAN.
2. Locate the IP-Tool installer at www.
vitekcctv.com/Downloads/Soft-
ware/Transcendent-IPTool_v2.0.2.zip
, then install on the PC. Open
the installed application.
3. Modify the IP address. The default IP address is 192.168.226.201.
Click the information of the camera listed in the above table to show
the network information on the right side. Modify the IP address and
gateway of the camera and make sure its network address is in the
same local network segment as the computer’s. Please modify the
IP address of your device according to the practical situation.
For example, the IP address of your computer
is 192.168.13.4. So the IP address of the
camera shall be changed to 192.168.13.X.
After modification, please input the password
of the administrator and click “Modify” button
to modify the setting.
** Default admin password: “123456".
MENU
N etwor k C abl e N etwor k C a bl e
Switch
R outer C omputer
P T Z C a mer a

8 9
4. Double-click the IP address and then the system will pop up the
web browser to connect IP-CAM. Edge in IE mode / IE browser
will download the Active X. control. After downloading, a login
window will pop up as shown below:
Input the user name and password to log in.
Default user name: admin / Default password: 123456.
Directly Access Through a Web Browser
The default network settings are as shown below:
IP address: 192.168.226.201 HTTP: 80
Subnet Mask: 255.255.255.0 Data Port: 9008
Gateway: 192.168.226.1
You may use the above default settings when you log in the camera for
the first time.
1. Manually set the IP address of the PC. The network segment should
be the same as the default settings of IP-CAM. Open the network
and share center. Click “Local Area Connection” to pop up the
following window.
Select “Properties” and then select Internet protocol according to the
actual situation (for example: IPV4). Next, click “Properties” button to
set the network of the PC.
2. Open Edge in IE mode / IE browser and input the default address
of IP-CAM and confirm. Edge in IE mode / IE browser will
download Active X control.
3. After downloading Active X control, the login dialog box will pop up.
4. Input the default username and password and then enter to view.
WAN Configuration
Access the camera by the router or virtual server for example.
1. Make sure the camera is connected to the LAN; Then log into the
menu to set up the port number.
the IP address.
4. Open the web browser and input its WAN IP and HTTP port to
access the IP-CAM.
3. Go to the router’s management interface through IE browser to
forward the IP address and port of IP-CAM in the “Virtual Server”.

9
2. Open Edge in IE mode / IE browser and input the default address
of IP-CAM and confirm. Edge in IE mode / IE browser will
download Active X control.
3. After downloading Active X control, the login dialog box will pop up.
4. Input the default username and password and then enter to view.
WAN Configuration
Access the camera by the router or virtual server for example.
1. Make sure the camera is connected to the LAN; Then log into the
menu to set up the port number.
the IP address.
4. Open the web browser and input its WAN IP and HTTP port to
access the IP-CAM.
3. Go to the router’s management interface through IE browser to
forward the IP address and port of IP-CAM in the “Virtual Server”.

10 11
Installation Mount Dimensions
VT-TPT20HR-FM
VT-TPT20HR-PM
VT-TPT23HR-WM
10.07”
5.32”
3.94”
7.22”
2.48”
3.51”
2.48”
2.54”
9.17”
9.17”
5.10”
4.27”
