Vitek VTC-EL52H User manual

black
VITEK
•1/3” Color CCD Image Sensor w/550 TV Lines
•Camera Mounted on a 3-Axis Adjustable Bracket to
Achieve the Perfect Viewing Angle
•2.97mm Fixed Iris Lens Included (Optional lenses
available)
•Minimum Illumination of 0.3 Lux
•Aluminum and Polycarbonate Vandal Resistant
Enclosure with IP-66 Weather Resistance
VTC-EL52H
Vandal/Weather Resistant
Corner Mount Camera w/550
TV Lines
All manuals and user guides at all-guides.com
all-guides.com

2
Camera adjustment
1) Remove the cover and adjust the camera to the desired position with the
adjustment screws
2) Adjust desired focus and scene by tilting and rotating the camera bracket
3) Replace the cover over the base and tighten the 4 safety screws with the included
wrench.
Power ConneCtion
1) A UL Listed 12VDC 300mA power supply is required to operate the camera
2) The camera is equipped with a center positive plug for connecting the power
supply.
All manuals and user guides at all-guides.com

black
3
sPeCiFiCations
Image Device
Effective Pixels
Resolution
Scanning System
Min. Illumination
Frequency
S/N Ratio
Lens
Video Output
White Balance
Shutter Speed
IP Rating
Operation Temperature
Power Source
Power Consumption
Weight
1/3” interline transfer CCD
768(H) x 494(V)
More than 550 TV Lines
2:1 Interlace
0.3Lux 40 IRE (F1.2)
Horizontal:15.734 KHz Vertical: 59.94 Hz
50dB (AGC Off)
2.97mm Fixed Iris (Optional lenses available)
1.0Vp-p composite, 75 Ohms
Auto / Fixed / Manual (1,800°K~10,500°K)
1/50~1/100,000
IP-66 Weather Resistance
14°F~122°F (-10°C ~ +50°C) / 30~90% RH
DC12V
Max.160mA
13.4 oz. (380g)
SPECIFICATIONS
All manuals and user guides at all-guides.com

Limited LiaBiLitY warrantY
Your new Camera is guaranteed to be free from defects in materials
and workmanship for a period of three years from the date of
purchase.
The product must have been used only for its intended purpose,
and not been subjected to damage by misuse, willful or accidental
damage, caused by excessive voltage or lightning.
The product must not have been tampered with in any way then the
guarantee will be considered null and void.
This guarantee does not affect your statutory rights.
Contact an Authorized VITEK reseller for all servicing needs.
28492 Constellation Road ValenCia, Ca 91355
WWW.ViteKCCtV.CoM
