Vitek VTC-LED697HRCB User manual

4
LIMITED LIABILITY WARRANTY
Your new Camera is guaranteed to be free from defects in materials
and workmanship for a period of two years from the date of
purchase.
The product must have been used only for its intended purpose, and
not been subjected to damage by misuse, willful or accidental
damage, caused by excessive voltage or lightning.
The product must not have been tampered with in any way then the
guarantee will be considered null and void.
This guarantee does not affect your statutory rights.
Contact an Authorized VITEK reseller for all servicing needs.
28492 CONSTELLATION ROAD VALENCIA, CA 91355
WWW.VITEKCCTV.COM | 888-VITEK-70
BLACK
VITEK
•1/3" High Resolution Color CCD image sensor
•480 TV Lines
•1 Lux / F2.0, 0 Lux (IR ON)
•12 Infrared LEDs
•Effective IR Range: Over 32 Feet (10 Meters)
•Automatic IR triggers On under low illumination / Off
under Normal Illumination
•Sun Shroud to reduce glare and dissipate heat
VTC-LED697HRCB
High Resolution Color Bullet
Camera w/12 IR LEDs

2
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
1. Unit contains uninsulated dangerous
voltage within the enclosure that may
be of sufficient magnitude to
constitute a risk of electric shock to
persons
2. Only use DC Power Supply
3. Read & Keep these instructions.
4. Heed to all warnings and follow all
instructions carefully.
5. Do not use near water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. install in accordance with
the instructions.
8. Do not install near any heat source
such as radiators, heat resisters,
stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has to blades with
one wider the other. A grounding type
plug has to blades and a third
grounding plug. The wide blade or
the third prong are provided for
safety. if the provided plug dose not
fit into your into your outlet, consult
an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being
walked on a pinched particularly at
plugs, convenience receptacle, and
the point where they exit from the
apparatus.
11. Only use attachment/accessories
specified by VITEK.
12. Use only with cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the Unit,
13. Unplug this unit during lightning
storms or when unused for long
periods of time.
14. Refer all servicing to qualified service
personnel, Servicing is required
when the unit has been damaged in
any way, such as power-supply cord
or plug is damaged, liquid has been
spilled or objects have fallen into the
unit, the unit has been exposed to
rain or moisture, does not operate
normally or has been dropped.
15. Do not attempt to service this
product yourself as opening or
removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualified service
personal.
CAUTION - To reduce the risk of electric
shock, do not perform any servicing
other than contained in these operating
instructions unless you are qualified to
do so.
BBLLAACCKK
BLACK
3
Pick up Element
Number of Pixels
Resolution
Min. Illumination
S/N Ratio
IR LED
Electronic Shutter
Lens
Iris Mode
AGC
White Balance
Video Output
Power Source
Current Consumption
Water Resistance
Dimensions
Weight
1/3" Color CCD image sensor
768(H)x494(V)
480 TV lines
1Lux / F2.0; 0Lux (10 meter IR ON)
More than 45dB (AGC Off)
12 units with an effective range of over 32 feet
1/60 (1/50) to 1/100,000 second
3.6mm Standard / Optional 4.0, 6.0, or 8.0mm
AES
Auto
ATW
1.0Vp-p composite, 75 Ohms
DC12V ± 10%
IR Off: 80mA / IR On: 260mA (*At Power Input)
IP57
2.48" x 2.28" x 4.06" (63 x 58 x 103.2mm)
12.17 Oz. (345g)
VTC-LED697HRCB
SPECIFICATIONS
* Remember to consider
the factors that effect
Voltage Drop including
wire gauge, quality,
interference and cable
length.
