Vitek VTD-A2812 User manual

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTD-A2812/I Indoor High Resolution WDR
Varifocal Dome Camera
•620 TV Lines of Resolution
•1/3” Sony SuperHAD II CCD
•Hercules DSP Engine
•2.8~12mm Vari-Focal Auto-Iris, IR Corrected
Lens
•Advanced OSD Functions: WDR, 3D DNR,
DSS, DIS, Sens-up, Motion Detection, Privacy
•Secondary Video Output (Cable Included)
•3-Axis Mount for Optimum Viewing Angle
•Dual Voltage 12VDC/24VAC Operation
FEATURES
Internal Mechanism
Conventional Camera
VTD-A2812/I
3.7”
1.6”
.4”
5.4”
1.6”
3.7”
5.4”
3.9”
5.4”
5.4”
Original Measurements in mm

BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
VTD-VS48B2 1/4” 4mm-8mm Varifocal Color
Dome Camera w/420 TVL
BLACKYELLOWMAGENTACYAN
VTD-A2812/I Indoor High Resolution WDR
Varifocal Dome Camera
Detailed Specifications
Resolution
Sensor
Total Pixels
Effective Pixels
Scanning System
S/N (Y Signal)
Frequency
Video Output
Min. Illumination
White Balance
Standard Lens
Electronic Shutter Speed
WDR (Long and Short Exposure)
O.S.D.
Backlight Compensation
AGC (Auto Gain Control)
3DDNR (3D Digital Noise Reduction)
Day & Night
Privacy
Motion Detection
Image Conversion
DIS (Digital Image Stabilizer)
LSC (Lens Shading Compensation)
Digital Zoom
Sharpness
Operating Temperature/Humidity
Storage Temperature/Humidity
Power
Dimensions (Dia. X H)
620 TV Lines
1/3 Inch Sony SuperHAD II CCD
811(H) x 508(V) 410K pixels 795(H) x 595(V) 470K pixels
768(H) x 494(V) 380K pixels 752(H) x 582(V) 440K pixels
2:1 Interlace
More than 52 dB (AGC Off)
Horizontal: 15.734KHz / Vertical: 59.94Hz Horizontal: 15.625KHz / Vertical: 50.00Hz
CVBS: 1.0Vp-p / 75ohm
0.1 Lux at F1.2 (Color) / 0.0001Lux (Sense up x256)
ATW / AWC / PUSH / MANUAL Adjustable
2.8-12mm DC Auto Iris Lens
AUTO / MANUAL (1/60sec ~ 1/100,000sec)
ON, OFF adjustable
Built-in
BLC (LOW, MIDDLE, HIGH, OFF Selectable) / HLM (Adjustable)
LOW, MIDDLE, HIGH, OFF Selectable
LOW, MIDDLE, HIGH, OFF
AUTO (Day <--> Night time Change), CDS, COLOR, B/W
OFF / ON (6 Zone)
OFF / ON (240 Zone)
FREEZE / V-FLIP / H-FLIP / ROTATE / NEGA: All ON/OFF Adjustable
ON / OFF
ON / OFF
ON (X1 ~ 10) / OFF
ADJUSTABLE
14’F ~ 122’F (-10’C ~ 50’C) / 30% ~ 80% RH
4’F ~ 140’F (-20’C ~ 60’C) / 20% ~ 90% RH
AC24V / DC12V DualPower
5.44” X 3.7” / 138.30mm X 93.76mm
NTSC PAL
