Vitek VTD-MD2-4 User manual

VITEK
VTD-MD2-4
2.1 Megapixel 4-in-1 HDA
Angled Mini Dome Cameras
FEATURES:
• 1/2.8” Sony STARVIS CMOS Sensor
• HD-TVI / AHD / CVI / CVBS Video Output
• Advanced Starlight Technology Offers Dramatically Higher
Sensitivity to Light Producing Color Images in Very Dark &
Night Scenes
• 3.0mm Lens Included
• Included tilted surface mount allows for more versatile camera
angle
• Digital Wide Dynamic Range (D-WDR)
• 3D-DNR - Three Dimensional Motion Adaptive Noise Reduction
• External OSD Joystick Controller
• Advanced OSD Functions: BLC/HLC, D-WDR, Motion detection,
Privacy mask, Flip, DeFog
• CoC (Control Over COAX)
• Over 1500’ HD Video Transmission (Depending on cable
characteristics and integrity)
• Can be Semi-Flush or Surface Mounted
• Available in Ivory (VTD-MD2-4I) or Chrome (VTD-MD2-4CH)
• 12VDC Operation
• 3 Year Warranty

1
INSTALLATION / SETUP
1) Attach the surface mount bracket to
the wall or ceiling with the included
screws.
2) Attach the camera to the surface
mount bracket with the included
screw.
3) Attach the dome cover to the camera
by turning clockwise.
4) Secure the dome cover to the camera
with the Included L-Wrench.
5) Connect 12VDC Power & Video
Cables.
INSTALLATION:
INCLUDED IN THE BOX:
1) Mini Dome Camera
2) Mounting Base
3) Wall Mount & Camera Mount Screws
4) L-Wrench.
SELECT MODE WITH ON-CABLE OSD JOYSTICK:
CVBS Mode: Push joysick LEFT for 5 seconds
AHD Mode: Push joysick RIGHT for 5 seconds
CVI Mode: Push joysick UP 5 seconds
TVI Mode: Push joysick DOWN for 5 seconds

2
SPECIFICATIONS
BLACKYELLOWMAGENTACYAN
(888) VITEK-70 | WWW.VITEKCCTV.COM
28492 Constellation Road Valencia, CA 91355
Detailed Specifications
Image Sensor
Active Pixel
Resolution
Lens
Min. Illumination
Scanning System
Video Output
S/N Ratio
AGC
Shutter Speed
SENS-UP
Brightness
Backlight
D-WDR
DNR
Defog
Day & Night
White Balance
Mirror
Sharpness
Privacy Mask
Motion Detection
Communication
Power Source
Power Consumption
Operating Temperature
Operating Humidity
Weight
Dimension (W x H x Dia.)
1/2.8” Sony STARVIS CMOS Sensor
1920(H) x 1080(V)
1080p @ 30fps (AHD / TVI / CVI) / 960H: CVBS
3mm/F=1.6
0.001 Lux (F=1.2)
Progressive
AHD / TVI / CVI / CVBS
More than 50dB (AGC off)
Off/0 - 15
AUTO/MANUAL(1/50(60) ~ 1/50,000 sec)
Off/X2 – X30
0 - 100
Off/BLC/HSBLC
Off/0 ~ 8
3D-DNR
Off/Auto
Auto/Color/B&W/EXTERN
ATW/AWC/INDDOR/OUTDOOR/Manual/AWB
Off/MIRROR/V-FLIP/ROTATE
0 -10 steps
4 Masks
Off/On
COC (Control Over Coax)
DC12V ±10%
180mA (Max)
14~122 / 10%~85% Humidity
10% to 85%
10.58 oz. (300 g.)
Semi-Flush Mount: 2.36” x 2.36” x 2.36” / Surface Mount: 3.38” x 3.04” x 2.36”
VTD-MD2-4I 2.1 Megapixel 4-in-1 HDA Angled Mini Dome Camera
VTD-MD2-4CH
VTD-MD2-4I
2.1 Megapixel 4-in-1 HDA Angled Mini Dome Camera - Chrome
2.1 Megapixel 4-in-1 HDA Angled Mini Dome Camera - Ivory
AVAILABLE CONFIG URATIONS: BREAKDOWN OF MODEL NUMBER: VTD-MD2-4CH
{VTD}
VITEK Dome
{MD2}
Miniature -
Dome - 2.1MP
{4}
4-IN-1
{CH}
Chrome

WWW.VITEKCCTV.COM
LIMITED LIABILITY WARRANTY
VITEK products carry a three (3) year limited warranty. VITEK warrants
to the purchaser that products manufactured by VITEK are free of any
rightful claim of infringement or the like, and when used in the manner
intended, will be free of defects in materials and workmanship for a
period of three (3) years, or as otherwise stated above, from the date of
purchase by the end user. This warranty is nontransferable and extends
only to the original buyer or end user customer of a Vitek Authorized
Reseller.
The product must have been used only for its intended purpose, and
not been subjected to damage by misuse, wilful or accidental damage,
caused by excessive voltage or lightning.
The product must not have been tampered with in any way or the
guarantee will be considered null and void.
This guarantee does not affect your statutory rights.
Contact your local VITEK Reseller should servicing become necessary.
VITEK makes no warranty or guarantee whatsoever with respect to
products sold or purchased through unauthorized sales channels.
Warranty support is available only if product is purchased through a
VITEK Authorized Reseller.
Version 1.0
November 2017
