The VTD-VPH Vandal Resistant Dome Camera is a
smaller, more attractive camera ideal for use in
commercial or residential applications. It measures
only 5” in diameter and comes with a 24 Volt AC
power input for easy integration with standard
cameras and power systems. Versatile mounting and
lens options allow you to achieve perfect video
images in virtually any environment. All VTD-VPH
domes feature Sony Super-HAD and/or
Ex-View Technology with Hi-Resolution of 480
Television Lines.
VTD-VPH SERIES
VTD-VPH SERIES Vandal Resistant Color
Dome Cameras
Vandal Resistant Color
Dome Cameras
•480 TV Lines Resolution
•Patented 3-Axis Mount
•Compact 5” Diameter Dome May Be Surface or
Semi Flush Mounted (Adapter Included)
•Weather Resistant
•Several Design Options to Meet Every Application
Including Fixed, Auto Iris Varifocal, and Day Night.
•Dual Voltage: 12VDC / 24VAC
FEATURES
Removable Dome Ring For Recessed Mounting Applications
Inside Dome 3-Axis Camera Mounting
System

(888) VITEK-70 | WWW.VITEKCCTV.COM
9970 Glenoaks Blvd. Sun Valley, CA 91352 | Local: [phone] Fax: [phone]
BBLLAACCKKYYEELLLLOOWWMMAAGGEENNTTAACCYYAANN
VTD-VPH SERIES
VTD-VPH SERIES Vandal Resistant Color
Dome Cameras
Vandal Resistant Color
Dome Cameras
Detailed Specifications VTD-VPH/FIXED VTD-VPH266 VTD-VPH412 VTD-VPH922
Image Device
Effective Pixels
Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
AGC
Lens
Video Output
White Balance
Power Source
Weight
Dimensions
Construction
IP Rating
Operation Temperature
1/3” High Resolution Super HAD Color CCD
768 x 494
480 TV Lines
0.7 Lux / F1.2 (AGC On)
More than 48dB (AGC off)
1/60 to 1/100,000 Sec.
Built-In (On)
3.6mm Fixed Iris * 2.6-6.0mm Varifocal 3.7-12mm Varifocal 9.0-22mm Varifocal
Composite: 1.0 Vp-p / 75 Ohm
Auto White Balance (AWB)
Dual Voltage: 12VDC / 24VAC
750 g. / 26.46 Oz. / 1.65 Lbs.
160mm x 99mm / 6.29” x 3.89” (D x H)
Aluminum/Tin Base - Polycarbonate Bubble
IP66/68
14˚ ~ 122˚ Fahrenheit
Image Device
Effective Pixels
Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
AGC
Lens
Video Output
White Balance
Power Source
Weight
Dimensions
Construction
IP Rating
Operation Temperature
1/3” High Resolution Super HAD Color CCD
768 x 494
480 TV Lines
0.03 Lux / F1.2 (AGC On) With Day/Night Function
More than 48dB (AGC off)
1/60 to 1/100,000 Sec.
Built-In (On)
2.6-6.0mm Varifocal 3.7-12mm Varifocal 9.0-22mm Varifocal
Composite: 1.0 Vp-p / 75 Ohm
Auto White Balance (AWB)
Dual Voltage: 12VDC / 24VAC
750 g. / 26.46 Oz. / 1.65 Lbs.
160mm x 99mm / 6.29” x 3.89” (D x H)
Aluminum/Tin Base - Polycarbonate Bubble
IP66/68
14˚ ~ 122˚ Fahrenheit
Detailed Specifications VTD-VPH266DN VTD-VPH412DN VTD-VPH922DN
* 3.6mm Lens Is Standard (2.9, 6.0, 8.0, 12mm Available By Special Order)
