Quick Installation Guide
Wireless Wall Controller
1. WIRE FAN AND MODULE
READ AND SAVE THESE INSTRUCTIONS
WARNING: Disconnect power to the installation locations before installing the fan and controller.
WARNING: Installation work and electrical wiring must be done by qualified person(s) in accordance with all
applicable codes and standards, including fire-rated construction. Incorrect assembly can cause electric shock
or damage the motor and the controller.
CAUTION: The Big Ass Fans product warranty will not cover equipment damage or failure that is caused by
improper installation or use.
CAUTION: Do not mount the wireless wall controller outdoors or in a location where it may come into contact
with water.
120–240 VAC Mains Input
L1 L2/N GND
North America
100–120 V Black White Green
or Bare
Copper
North America
208–240 V
Black, Red,
or Blue
Red, Blue,
or Black
Australia Brown or
Red
Black or
Light Blue
Green
with
Yellow
Tracer
All Other
Regions Brown Blue
Fan Power Cable
L1: Black or Brown
L2/N: White or Blue
GND: Green or Green/Yellow
Fan Controller Input Cable
See table below.
Fan Controller Input Cable
1 White +0–10 VDC Speed Ref.
2 Brown Not Used
3 Orange Status LED (+)
4 Yellow Run Enable Closed: Enable
5 Blue Open: Disable
6 Green Status LED (-)
7Red +10 VDC Supply
8 Black DC Common
If a wall controller is already installed with the fan, uninstall it before beginning wireless wall controller installation.
Black: L1 White: L2/N Green: GND
Red: LOAD (Not used, cap o)
120–240 VAC Mains Input
See table below.
Black and Pink: 0 VDC
White and Violet: 0–10 VDC Ref.
Fan Blue and Yellow: Run Enable
Consult fire alarm interface instructions if
applicable.
Brown, Orange, Green, Red:
Not used, cap individually
Online Wiring
Diagram

TM
lutron.com
1.844.LUTRON1
M é xi co :
1. 888. 235. 2910
®
LUTRON
PowP ak
UL2043
Ple num Rated
®
FCJS-010
120-277 V 50/60 Hz 1 A
~
12V 25mA
IEC SELV / NEC Class 2
Sen sor | Dét ect eur
®
TM
lutron.com
1.844.LUTRON1
M é xi co :
1. 888. 235. 2910
®
LUTRON
PowP ak
UL2043
Ple num Rated
®
FCJS-010
120-277 V 50/60 Hz 1 A
~
12V 25mA
IEC SELV / NEC Class 2
Sen sor | Dét ect eur
®
LUTRONLUTRON
TM
lutron.com
1.844.LUTRON1
M é xi co :
1. 888. 235. 2910
®
LUTRON
PowP ak
UL 2043
Plenum Rated
®
FCJS-010
120 -277 V 50/60 Hz 1 A
~
12V 25mA
IEC SELV / NEC Class 2
Sen sor | Détect eu r
®
TM
lutron.com
1.844.LUTRON1
M é xi co :
1. 888. 235. 2910
®
LUTRON
PowP ak
UL 2043
Plenum Rated
®
FCJS-010
120 -277 V 50/60 Hz 1 A
~
12V 25mA
IEC SELV / NEC Class 2
Sen sor | Détect eu r
®
LUTRONLUTRON
2. PAIR MODULE AND WALL CONTROLLER
1. Apply power to fan. Press and hold center
button on module for approximately six
seconds until LEDs flash. Release button.
2. Press and hold O button on wall
controller for approximately six seconds
until LED flashes. Release button. Pairing
is complete.
This procedure can be used to add multiple
wall controllers and/or modules to a group of
up to ten devices.
Center
Module
Button
Fan O
3. MOUNT WALL CONTROLLER AND ADJUST SETTINGS
Mount Wall Controller
Mount wall controller according to the mounting instructions packaged with the controller.
Adjust Low-End Trim
The fan requires a minimum of 1 V to turn on. To adjust the module’s low-end trim to at least 1 V:
1. Press wall controller O button.
2. Press and hold On button and Increase Speed button simultaneously for approximately six seconds until LED
flashes.
3. Slowly tap Increase Speed button nine times to set low-end trim to approximately 1.1 V.
4. Press and hold O button for approximately six seconds until LED flashes to save the setting.
© 2021 DELTA T LLC ALL RIGHTS RESERVED.
ESS-INST-375-MUL-01 REV A 08/04/2021
The wall controller will not operate the fan(s). Release wire antenna from front of module and extend it away
from module to extend range of wall controller.
I need to reset the module to factory default
settings.
Quickly press center module button four times and hold button
on fourth press until LEDs flash. Release button. Within three
seconds, quickly press center module button four times and hold
button on fourth press until LEDs flash rapidly. The module is now
reset to factory default settings.
Set Preferred Speed Setting (Optional)
By default, pressing the center wall controller
button sets the fan speed to 50%. To program a
preferred speed setting:
1. Use speed adjustment buttons to select
desired fan speed.
2. Press and hold center button for
approximately six seconds until LED flashes
to save the setting.
Note: For systems with multiple wall controllers,
each controller can have a dierent preferred
speed setting.
Fan On (100% Speed)
Decrease Fan Speed
Fan O (0% Speed)
Increase Fan Speed
50% Speed (Default)
or Preferred Setting
TROUBLESHOOTING
