Vivitar DVR 506 User manual

DVR 506
Digital Video Camcorder
User‟s Manual
© 2010 Sakar International, Inc. All rights reserved.
Windows and the Windows logo are registered trademarks of Microsoft Corporation.
All other trademarks are the property of their respective companies.

1
Table of Contents
Introduction............................................................................................................3
Key Features..........................................................................................................3
What‟s Included .....................................................................................................4
Computer System Requirements for Windows OS................................................5
Computer System Requirements for Macintosh OS ..............................................5
A Quick Look at your Digital Camera.....................................................................6
Inserting Batteries..................................................................................................7
Inserting an SD Memory Card................................................................................8
Maintenance and Care...........................................................................................9
Starting Your Camera..........................................................................................10
Capturing Videos .................................................................................................12
Video Setting options...........................................................................................14
Taking Photos......................................................................................................19
Photo Capture Settings options ...........................................................................23
Audio Mode..........................................................................................................30
Playback mode ....................................................................................................32
Camcorder Setup Mode.......................................................................................46
Connecting the Camcorder to a TV......................................................................52
Install the Vivitar Experience Image Manager Software.......................................53
Connect your camcorder to the computer............................................................56
Get photos and videos from your camcorder to your computer ...........................57
Get started!..........................................................................................................58
Transfer media from my camcorder to my computer manually (Using
Windows).............................................................................................................59

2
Transfer media from my camcorder to my computer manually (Using
Macintosh) ...........................................................................................................60
Sakar Warranty Card ...........................................................................................61
Technical Support................................................................................................62
Technical Specifications ......................................................................................63
Frequently Asked Questions................................................................................64
Trouble Shooting..................................................................................................65

3
Introduction
Thank you for purchasing the DVR 506 Digital Video Camcorder. Everything you need to shoot
video clips, take quality digital photos and record audio files is included with your device.
In addition, an SD compatible memory card of up to 16GB (not included) needs to be inserted in
order to use the camcorder normally.
Please read this manual carefully FIRST in order to get the most out of your digital video camcorder.
Key Features
5 modes –Video, Photo, Audio, Playback and Set Up
Digital Video resolutions –1280x720 (HD), 720x480 , 640x480 (VGA), 320x240 (QVGA)
5 digital camera resolutions - 5M(2592X1944); 3M(2048X1536); 2M(1600X1200);
1M(1280X960); VGA(640X480)
1.8” TFT LCD
4 X Digital Zoom
Supports external SD/SDHC memory cards up to 16GB
Built-in Microphone
Delete, rotate, protect, crop and print photos directly on and from your camcorder
Vivitar Experience Image Manager software for uploading and managing photos and videos to
or from the most popular photo sharing and social network websites
Get photos and videos from your camera, manage and organize your images by creating
albums, edit images using automatic and manual tools and more...

4
What’s Included
Digital Video Camcorder
Vivitar Experience Image Manager software Installation CD
Quick Start Guide
USB cable
TV Out cable
Carry Case
Wrist Strap

5
Computer System Requirements for Windows OS
To be able to download photos and videos to your PC, you will need the following minimum
configuration:
Pentium 4 processor or above with Windows XP service pack 2, Windows Vista or Windows 7
512 MB RAM, with 100MB of free disk space
1024 x 768 Recommended screen resolution
16-bit color or higher display adaptor
CD-ROM Drive
QuickTime 6 or higher
Microsoft Internet Explorer 7 or higher
Windows Media Player 10 or higher
Internet connection required
Computer System Requirements for Macintosh OS
Macintosh with Intel processor running Mac OS X v10.5 or later
256 MB RAM, 100 MB free disk space
Display: 1024 x 768 or higher-resolution monitor
QuickTime 6 or higher
Internet connection required

6
A Quick Look at your Digital Camera
1: Lens
2: Microphone
3: Compensating lamp
4: Self-Timer LED
5: Delete
6: Playback
7: Mode
8: TFT LCD Screen
9: Left /Self-Timer
10: Power
11: Down
12: Menu
13: AV Out jack
14: USB jack
15: Right /LED on or off
16: OK
17: Shutter
18: Up /Display
19: W/Zoom out button
20: T/Zoom in button
21: Speaker
22: Tripod socket
23: Card slot
24: Battery cover

7
Inserting Batteries
Your camcorder requires three (3) AAA batteries. Insert the batteries into the camcorder:
1. Lift and open the cover of the battery compartment on the side of the camcorder.
2. Insert the batteries according to the polarities (+ and -) indicated on the inside of the battery
cover.
3. Replace and close the battery cover.
The battery icon on the bottom left of the LCD will turn red and flash when your batteries are
running low, in which case you will need to replace your camera‟s batteries. When battery voltage
drops to 2.2V, a “Battery Low” message will appear on the LCD and the camera will turn off
automatically.
Note: If you do not intend to use your camera for an extended period, remove the batteries to avoid
battery leakage and corrosion.

8
Inserting an SD Memory Card
An SD/SDHC compatible memory card of up to 16GB (not included) needs to be inserted into your
DV camcorder in order to save the videos, photos and audio that you capture with your camcorder
before transferring them to a computer.
Note: Media sitting on the memory card is not lost when your camcorder‟s power runs low or on
replacing the batteries.
1. Locate and lift the SD Card cover to reveal the SD card slot on the bottom of the camcorder.
2. Insert an SD memory card correctly in the direction shown.
3. Press the memory card until you hear a “Click”sound. The memory card when properly inserted
will sit flush with the camcorder.

9
Note: After you insert the SD memory card, the SD card icon will appear on the bottom left side of
the LCD, indicating that your SD memory card has been installed successfully. The media you
capture will now be stored on the card.
This product supports SD cards of up to 16GB.
Formatting will delete all data on the SD Memory Card including protected data.
Do not remove the SD memory Card during formatting as this may damage the card and
render it unusable.
Before using the camcorder, be sure to format the card with the camcorder (see the Setup
section further on in the manual for instruction on how to format the card).
Maintenance and Care
Before using the video camcorder, please ensure that you read and understand the safety
precautions described below:
Do not try to open the case of the video camcorder or attempt to modify this video camcorder
in any way. Maintenance and repairs should be carried out only by authorized service
providers.
Keep the video camcorder away from water and other liquids. Do not use the video camcorder
with wet hands. Never use the video camcorder in the rain or snow. Moisture creates the
danger of electric shock.

10
Use only the recommended power accessories. Use of power sources not expressly
recommended for this equipment may lead to overheating, distortion of the equipment, fire,
electrical shock or other hazards.
Starting Your Camera
Note: To easily download the photos and videos captured with this camera you need to install the
Vivitar Experience Image Manager software. See the “Install the Vivitar Experience Image Manager
Software” section of this manual to learn how to install the software on your computer.
To power on the camcorder you need to flip open the LCD Screen. The Power button is situated on
the inside of the camcorder.
Power on
Press the Power button to turn on your DVR.
The LCD monitor will light up indicating that your DVR is ready for use.
Power off
Press the Power button to turn your DVR camcorder off. The DVR camcorder will switch off.
Auto Power Saving
If the DVR is not in use or in an operation mode for 60 seconds it will switch off automatically.

11
When there is insufficient battery power, a “Low Battery”message will appear on the LCD screen.
The camcorder will automatically power off a few moments later.
Setting the Language
When using the video camcorder for the first time after purchasing it, be sure to choose a language
and set the date & time before using the video camcorder.
1. Turn the Power on.
2. Press the MENU button.
3. Press the Right button on the OK dial to open the Setup menu.
4. Press the Up/Down button on the OK dial and select the Language option.
5. Press the Right button to enter the Language submenu.
6. Press the Up/Down button to highlight and select the language you desire.
7. Press the OK button to save your choice and for the language interface of the camcorder to
change to the language you selected.
8. Press the MENU button to close the menu and exit the Setup function.
Change the camcorder`s mode
There are four modes in this DVR camcorder.
1. Press the POWER button to turn on the camcorder.

12
2. The video default capture mode appears on the LCD.
3. Press the MODE button on the bottom left of the LCD screen to change the mode.
4. Each time the MODE button is pressed the mode icon is changed.
Capturing Videos
In order to capture videos (with audio) using your camcorder you need to select the Video mode.
On turning on your camcorder the first mode Video mode appears and is active. To change
between the function modes on your DVR, press the MODE button on the bottom left of the LCD
screen.
A compatible SD card of up to 16GB is needed to capture and save videos.
The video icon will now appear on the top left corner of the LCD.
Display
Title
Description
Video mode
For recording movie clips.
Capture mode
For taking still photos.
Audio mode
For recording audio files.

13
1. The amount of time left at that resolution and memory appears on the top right of the LCD.
2. Aim the camcorder at the subject or object you wish to capture.
3. Press the Shutter button on the top of the camcorder to start shooting.
4. The elapsed time of the video will appear on the top right on the LCD.
5. Press the Up button if you wish to Pause the recording in the middle and again to resume
recording.
6. Press the T(Zoom In) or W(Zoom Out) buttons located on the top of the camcorder to
digitally zoom into and back out of the object.
7. Press the Shutter button again to stop the recording.
8. The recorded file will be saved in AVI format.
Note:
1. You can view the AVI files in playback mode.
2. Once they are downloaded to the PC view them using QuickTime and Windows Media Player.
3. When the memory is full, a “Memory Full”message will flash on the LCD screen when you
attempt to shoot further videos.
LED Lamp
When light conditions are poor, press the LED / Right button.

14
Two LED white lamp lights will light up (like a torch) in the front of the camcorder to offer better
lighting.
To turn off the LED light, press the LED / Right button again.
Digital Zoom function
You can magnify your subject up to 4 times using the digital zoom.
1. Press the Tbutton on the top of the camcorder to Zoom In into the object.
2. Press the Wbutton to Zoom back out.
3. The digital zoom digit icon appears on the bottom right corner of the LCD screen.
Video Setting options
In Video mode there are four video resolutions for you to choose from:
[HD] 1280x720, [D1] 720x480, [VGA] 640x480, [QVGA] 320x240 pixels
The higher the resolution selected the better the quality of the video, however higher quality
videos use up more memory. You can also change the Frame Rate, Metering and White
Balance.

15
To enter the Settings options for the Video mode:
1. Press the MENU button.
2. Press the Up/Down button to select the Setting you wish to change from the menu that
appears.

16
Movie Size
You can select different Video resolutions
1. Press the Up/Down button to select the Movie Size menu.
2. Press the OK button to open the Movie Size submenu.
3. Press the Up/Down button to highlight and select the resolution option:
[HD] 1280x720, [D1] 720x480, [VGA] 640x480, [QVGA] 320x240
4. Press the OK button to confirm, save your choice and exit to the Setting menu.
5. Press the MENU button to revert back to the Video capture mode to start capturing videos with
the new resolution selected.
Note:
After selecting your resolution, the corresponding icon will appear on the top of the LCD.

17
Frame Rate
This setting allows you to control the frame rate for video capture.
1. Press the Up/Down button to select the Frame Rate menu.
2. Press the OK button to open the Frame Rate submenu.
3. Press the Up/Down button to highlight and select the rate option:
30fps High, 15fps Low
4. Press the OK button to confirm, save your choice and exit to the Setting menu.
5. Press the MENU button to revert back to the Video capture mode to start capturing videos with
the new frame rate selected.
Metering
This setting allows you to change the brightness of the video.
1. Press the Up/Down button to select the Metering menu.
2. Press the OK button to open the Metering submenu.
3. Press the Up/Down button to highlight and select the metering option:
[Center]: The exposure will be calculated based on light in the center area and this is
suitable for general use.
[Multi]: The exposure will be calculated based on the average light.
[Spot]: Only the spot in the center of the LCD screen will be metered for light.

18
4. Press the OK button to confirm, save your choice and exit to the Setting menu.
5. Press the MENU button to revert back to the Video capture mode to start capturing videos with
the metering selected.
White Balance
This setting is used to adjust the color balance of your videos as per your light source.
1. Press the Up/Down button to select the White Balance menu.
2. Press the OK button to open the White Balance submenu.
3. Press the Up/Down button to highlight and select the White Balance option:
Auto, Daylight, Cloudy, Fluorescent, Bulb
4. The White Balance choice selected automatically appears on the LCD.
5. Press the OK button to confirm, save your choice and exit to the Setting menu.
6. Press the MENU button to revert back to the Video capture mode to start capturing videos with
the new white balance selected.

19
Taking Photos
After you power on your camcorder, press the MODE button on the bottom left of the LCD screen.
The camera icon appears in the top left corner of the screen.
Insert a compatible SD memory card of up to 16GB in order to expand capture many more
memorable photos.
Use the image that appears in the LCD to compose your shot.
1. Hold the camcorder steady and press the Shutter button on the top of the camcorder.
2. Press the T(Zoom In) or W(Zoom Out) buttons located on the top of the camcorder to digitally
zoom into and back out of the object.
3. A capture clicking sound will be heard and the jpeg picture that is taken is saved to the memory
card.
4. The number of photos that can be taken for each resolution and per the memory card inserted
appears on the top right of the LCD screen.
5. After the shot is taken the number is reduced by one.
6. When the SD memory card is full, “Memory Full”will appear on the LCD screen when you
attempt to press the Shutter button to take a photo. Either download the photos to your
computer using the Vivitar Experience Image Manager software as described below in the
section “Transfer photos and videos to your computer” or insert another SD card to continue
taking more photos and videos.
