Fixed Dome
Network Camera
FD8131/31V
1MP •Vari-focal Lens •
Compact Design
VIVOTEK FD8131/31V are easy-to-use fixed dome network
cameras specifically designed for indoor security applications.
Equipped with a 1MP sensor enabling viewing resolution of
1280x800 at 30 fps, users need to look no further for an all-in-one
camera capable of capturing high quality HD video.
With the vari-focal lens, the FD8131/31V provide users the freedom
to adjust the field of view in accordance with their applications. The
IP66-rated housing of FD8131V protects the camera body against
rain and dust and ensures operation under poor weather conditions.
Furthermore, the metal vandal-proof housing effectively provides
robust protection of FD8131V from vandalism.
Also included are a number of advanced features standard on
VIVOTEK cameras, including tamper detection, MicroSD/SDHC
card slot, 802.3af compliant PoE, and VIVOTEK's 32-channel
recording software. With all of these capabilities, the FD8131/31V
present the best value in IP surveillance for indoor applications.
● 1-Megapixel CMOS Sensor
● 3 ~ 12 mm Vari-focal Lens
● Real-time H.264, MPEG-4 and MJPEG Compression
(Triple Codec)
● Built-in 802.3af Compliant PoE
● Built-in MicroSD/SDHC Card Slot for On-board Storage
● 3-axis Mechanical Design for Ceiling and Wall Mount
Installation
● Easy and Flexible Installation
● Compact, Elegant Design
● Vandal-proof IK10-rated and Weather-proof IP66-rated
Housing (FD8131V)
Features
Restaurant
Hotel
Store
On-board Storage

All specications are subject to change without notice. Copyright © 2012 VIVOTEK INC. All rights reserved.
Ver 1.0
Distributed by:
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T:[phone]|F:[phone]|E:[email protected]
VIVOTEK USA, INC.
2050 Ringwood Avenue, San Jose, CA 95131
|T: 408-773-8686|F: 408-773-8298|E: [email protected]
AM-214
L shape bracket
Mounting Kits
AM-517
Adaptor ring
AM-518
Dome adapter
MS-POE-IJAF
PoE injector, 802.3af compliant
PoE KitsPower Adapter
Alarm Triggers
Alarm Events
Connectors
LED Indicator
Power Input
Power Consumption
Dimensions
Weight
Safety Certifications
Operating Temperature
Warranty
Operating System
Web Browser
Other Players
CD
Others
Alarm and Event
General
System Requirements
Included Accessories
Video motion detection, manual trigger, digital input,
periodical trigger, system boot, recording notification,
camera tampering detection
Event notification using digital output, HTTP, SMTP,
FTP and NAS server
File upload via HTTP, SMTP, FTP and NAS server
RJ-45 cable connector for Network/PoE connection
Digital input*1
DC 12V power input
System power and status indicator
DC 12V
IEEE 802.3af PoE Class 1
Max. 3.84 W
Ø: 110 mm x 91 mm (FD8131)
Ø: 133 mm x 94 mm (FD8131V)
Net: 500 g (FD8131)
Net: 589 g (FD8131V)
CE, LVD, FCC Class B, VCCI, C-Tick
Start Temperature: -10°C ~ 50°C (14°F ~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F ~ 122°F)
24 months
Microsoft Windows 7/Vista/XP/2000
Mozilla Firefox 7~10 (streaming only)
Internet Explorer 7.x or 8.x
VLC: 1.1.11 or above
Quicktime: 7 or above
User's manual, quick installation guide, Installation
Wizard 2, ST7501 32-channel recording software
Quick installation guide, warranty card, alignment
sticker, screws, software CD, RJ45 female/famale
coupler, clamp core
screwdriver (FD8131V)
Models
CPU
Flash
RAM
Image Sensor
Maximum Resolution
Lens Type
Focal Length
Aperture
Field of View
Shutter Time
Minimum Illumination
Pan/tilt/zoom
Functionalities
On-board Storage
Compression
Maximum Frame Rate
Maximum Streams
S/N Ratio
Dynamic Range
Video Streaming
Image Settings
Users
Protocols
Interface
ONVIF
Video Motion Detection
System Information
Camera Features
Video
Network
Intelligent Video
FD8131
FD8131V
Multimedia SoC (System-on-Chip)
128 MB
256 MB
1/4" Progressive CMOS
1280x800
Vari-focal
f = 3 ~ 12 mm
F1.4 (wide), F2.0 (tele) (FD8131)
F1.4 (wide), F3.2 (tele) (FD8131V)
FD8131:
61.34° ~ 24.13° (horizontal)
37.56° ~ 15.08° (vertical)
72.85° ~ 28.18° (diagonal)
FD8131V:
60.06° ~ 20.26° (horizontal)
37.14° ~ 12.70° (vertical)
71.51° ~ 22.75° (diagonal)
1/5 sec. to 1/32,000 sec.
0.38 Lux @ F1.4, 50 IRE (FD8131)
0.5 Lux @ F1.4, 50 IRE (FD8131V)
ePTZ: 16x digital zoom (4x on IE plug-in, 4x built-in)
MicroSD/SDHC card slot
H.264, MJPEG & MPEG-4
H.264:
30 fps at 1280x800
MPEG-4:
30 fps at 1280x800
MJPEG:
30 fps at 1280x800
4 simultaneous streams
Above 53 dB
47 dB
Adjustable resolution, quality and bitrate
Configurable video cropping for bandwidth saving
Adjustable image size, quality and bit rate
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast, saturation,
sharpness, white balance, exposure control, gain,
backlight compensation, privacy masks
Scheduled profile settings
Live viewing for up to 10 clients
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP,
DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
10Base-T/100 BaseTX Ethernet (RJ-45)
Ver. 1.02
Triple-window video motion detection
Technical Specifications
Compatible Accessories
Dimensions
Ø110 mm Ø133 mm
94 mm
91 mm
AA-221
DC 12V Power Adapter
•FD8131
•FD8131V
