Vivotek IP8132 Operator's manual

EN - 1
English
Power off the Network Camera as
soon as smoke or unusual odors are
detected.
Contact your distributor in the event of
occurrence.
Keep the Network Camera away
from water. If the Network Camera
becomes wet, power off immediately.
Do not place the Network Camera
around heat sources, such as a
television or oven.
Refer to your user’s manual for the
operating temperature.
Keep the Network Camera away from
direct sunlight.
Do not place the Network Camera in
high humidity environments.
Contact your distributor in the event of
occurrence.
Warning Before Installation

EN - 2
Do not place the Network Camera on
unsteady surfaces.
Do not touch the Network Camera
during a lightning storm.
Do not disassemble the Network
Camera.
Do not drop the Network Camera.
Do not insert sharp or tiny objects
into the Network Camera.

EN - 3
English
Camera Stand
IP8132
Warranty Card
Screws
Quick Installation Guide
Power Adapter
Package Contents
1
Software CD
5
1
0
0
0
0
2
0
2
G

EN - 4
Network Deployment
3
Physical Description
2
Front Panel
Back Panel
Status LED
Privacy Button
Lens
Built-in Microphone
MAC:0002D132C353
IP8132
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
General I/O Terminal Block
Recessed Reset Button Power Cord Socket
Ethernet 10/100 RJ45 Socket
MAC:0002D132C353
IP8132
Thisdevice complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)Thisdevice may not cause harmful interference, and
(2)this device must accept any interference received, including interference that may cause undesired operation.
Pat.6,930,709
POWER COLLISION
LINK
RECEIVE
PARTITION
12345
3. Connect the supplied
power cable from the
camera to a power
outlet.
2. Connect the camera to a switch
via Ethernet cable.
●Use Category 5 Cross Cable
when Network Camera is directly
connected to PC.
1. If you have external devices such as sensors and alarms, make connections from
general I/O terminal block. 4: Power
3: Digital output
2: Digital input
1: Ground

EN - 5
English
MAC:0002D132C353
IP8132
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
1. Install “Installation Wizard 2” from the Software Utility directory on the software CD.
2. The program will conduct an analysis of your network environment. After your network is
analyzed, please click on the “Next” button to continue the program.
3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network
Cameras on the same LAN.
4. After searching, the main installer window will pop up. Click on the MAC that matches the
one labeled on the bottom of your device to connect to the Network Camera via Internet
Explorer.
0002D132C353
Installation
Wizard 2
Assigning an IP Address
4
5. Retrieve live video through a web browser or recording software.
2011/01/05 01:50:28
