Viz-Art Automation LEO User manual

LIST OF ITEMS::
Mount
Mounting set
Installation manual
1. Installation & Adjusment:
A. Prepare an installation place on the ceiling. Element A
install on a ceiling. Then install element C. On expected height
install element D(according to picure below). Use mounting
screws from mounting set.
.
B. Using screws E adjust proper height of the mount.
C. mounting arms B attach do back side of display/TV, using
mounting screws from mounting set.
D. On a element D hang Flat screen with already mounted
arms B. Tighten the locking screws until you feel resistance
WARNING! Correct mounting of elements is required for
safety usage (as on piture below)
LEO/LEO2 Plasma Mount
Ceiling mount for flat displays and TV
1/2

E. Tighten the locking screws until you feel resistance.
Ensure that monitor/TV is stable on mount
F. Comfort adjustment
Tilt properly monitor/TV to have a comfort view TV. Lock
position after adjustment.
2. Technical Specification:
Product model:
LEO/LEO2 Plasma Mount
Adjustment:
Up-Down –31 degree
Rotation –360 degree
Range of adjustment –200 mm
Weight:
LEO Plasma Mount 15 kg
LEO2 Plasma Mount 16,5 kg
Capacity:
75 kg
3. Mounting kit set :
bolts:
M5x35 –8 pcs.; M6x36 –8 pcs.
M6x50 –8 pcs.; M8x50 –8 pcs.;
M12x60 –1 pcs.; M8x20 –8 pcs.
screws:
Ø 10x18 – 4 pcs.
washers:
Ø 8x50 – 8 pcs.; Ø 6x18 – 8 pcs.
Ø 10x20 – 4 pcs.; Ø 12x50 – 1 pcs.
spacers:
Ø 6x10 – 8 pcs.; Ø 8x18 – 8 pcs.
tools:
Hex tool 4 –1 pcs.
Hex tool 5 –1 pcs.
Hex tool 6 –1 pcs.
dowels:
Ø 10x20 – 4 pcs.
Produced by: VIZ-ART Automation
tel.[phone] www.viz-art.pl
2/2
