GEM GEM L-NH2500 User manual

L-NH2500 Bracket
Out-swing narrow frame doors
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-L-NH2500 Ver. B Published on 2011.09.08
Unit:mm
Application for the Electromagnet:
EM-NH2500 Series
"L" brackets
Mounting Plate
EM-NH2500
L-150, L-EM150...
L-300,L-10001ST...
L-750, L-350,L-400...
L-500,L-600...
38mm
42mm
48mm
60mm
300 LBS
Magnet Grade Optional Brackets
600 LBS
800LBS
1200 LBS
48
8
75
40
40
71
533
533
1
4
2
5
3
6
16mm 8mm
Hollow Metal Door
6.8mm for M8-1.25 thread
Reinforced Door
12.7mm 8mm
Solid Door
36mm
Power Power
Finish
GIANNI INDUSTRIES, INC.
The A value in the table below shows the
minimum requirement distance of the door frame
for different electromagnetic lock model.
A Value
A s s e m b l e t h e
e le c t r o m a g n e t a n d L
bra c ket wit h a n Al len
wrench.
Turn on the power of
electromagnet. Let the
electromagnet and the
a r m a t u r e p l a t e b o n d
together. Press L bracket
against the door frame.
Fasten L bracket on the
door frame.
Test the unit. Tap the
p l u g s i n t o t h e
electromagnet
Drill a hole 8 mm in
diameter through the
doo r. En l arg e th e
hole to 16 mm from
outside.
Drill a hole 6.8 mm in
d i a m e t e r f r o m
inside. Screw with a
M8-1.25 thread.
F o l d t h e m o u n t i n g
template 90° angle along
the dotted line.
Drill a hole 8 mm in
diameter through the
d o o r. En l a r g e t h e
hole to 12.7 mm from
o u t s i d e . T h e
thickness of the door
is 36 mm.
Drill the holes marked on
the template.
Installation of L bracket on Out-swing Doors
Magnet
Armature
Door Frame
Door
Leaf
A
Out-swing
