VIZIO L37 HDTV User Manual
Dear VIZIO Customer,
Congratulations on your new VIZIO L37 High
Definition LCD Television purchase.Thank you for your
support. For maximum benefit of your set, please read
these instructions before making any adjustments, and
retain them for future reference. We hope you will
experience years of enjoyment from your new VIZIO
L37 High Definition Television.
For assistance, please call 714-668-0588 or email
us at [e-mail].
To purchase or inquire about accessories and instal-
lation services for your VIZIO LCD TV, please visit
our website at www.vizioce.com or call toll free at
1-888-VIZIOCE (1-888-849-4623).
We recommend you register your VIZIO L37 HDTV
either at our website www.vizioce.com or fill in your
registration card and mail it in. For peace of mind and
to protect your investment beyond the standard war-
ranty, VIZIO offers on-site extended warranty service
plans. These plans give you additional coverage during
the standard warranty period. Visit our website or call
us to purchase a plan.
Write down your Serial Number located on the back
of your L37.
Purchase Date _________________
___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___
A H L

WWW6):)/#%COM
Version- 02/27/06
4
VIZIO L37 HDTV User Manual
This product is designed and manufactured to operate within defined design limits, and misuse may
result in electric shock or fire.To prevent the product from being damaged, the following rules should be
observed for the installation, use and maintenance of the product. Read the following safety instructions
before operating the display. Keep these instructions in a safe place for future reference.
• To avoid the risk of electric shock or component damage, switch off the power before connecting other components to the LCD TV.
• Unplug the power cord before cleaning the LCD TV. A damp cloth is sufficient for cleaning the LCD TV. Do not use a liquid or a spray cleaner
for cleaning the product. Do not use abrasive cleaners.
• Always use the accessories recommended by VIZIO to insure compatibility.
• When moving the LCD TV from an area of low temperature to an area of high temperature, condensation may form on the housing. Do not
turn on the LCD TV immediately after this to avoid causing fire, electric shock or component damage.
• Do not place the LCD TV on an unstable cart, stand, or table. If the LCD TV falls, it can injure a person and cause serious damage to the
appliance.
• A distance of at least 3 feet should be maintained between the LCD TV and any heat source, i.e. radiator, heater, oven, amplifier etc. Do not
install the product close to smoke. Operating the product close to smoke or moisture may cause fire or electric shock.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation.To ensure reliable operation of the LCD TV and
to protect it from overheating, be sure these openings are not blocked or covered. Do not place the LCD TV in a bookcase or cabinet unless
proper ventilation is provided.
• Never push any object into the slot on the LCD TV cabinet. Do not place any objects on the top of the product. It could short circuit parts
causing a fire or electric shock. Never spill liquids on the LCD TV.
• The LCD TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to
your home, consult your local power company.
• The power cable must be replaced when using different voltage from that specified in the User Manual. For more information, contact VIZIO.
• The LCD TV is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin.This plug will fit only into a grounded power
outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet, or use an
adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug.
• Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
• The wall socket should be installed near the equipment and should be easily accessible.
• Do not touch the power cord during lightning.To avoid electric shock, avoid handling the power cord during electrical storms.
• Unplug the unit during a lightening storm or when it will not be used for long period of time.This will protect the LCD TV from damage due
to power surges.
• Do not attempt to repair or service the product yourself. Opening or removing the back cover may expose you to high voltages, the risk of
electric shock, and other hazards. If repair is required, please contact VIZIO and refer all servicing to qualified service personnel.
• Keep the product away from moisture. Do not expose this appliance to rain or moisture. If water penetrates into the product, unplug the
power cord and contact VIZIO. Continuous use in this case may result in fire or electric shock.
• Do not use the product if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact VIZIO
immediately. Do not try to repair the product yourself.
• Avoid using dropped or damaged appliances. If the product is dropped and the housing is damaged, the internal components may function
abnormally. Unplug the power cord immediately and contact VIZIO for repair. Continued use of the product may cause fire or electric
shock.
• Do not install the product in an area with heavy dust or high humidity. Operating the product in environments with heavy dust or high
humidity may cause fire or electric shock.
• Hold the power connector when removing the power cable. Pulling the power cable itself may damage the wires inside the cable and cause
fire or electric shock. When the product will not be used for an extended period of time, unplug the power connector.
• To avoid risk of electric shock, do not touch the connector with wet hands.
• Insert batteries in accordance with instructions while using the remote control. Incorrect polarities may cause damage and leakage of the
batteries, operator injury and contamination of the remote control.
• If any of the following occurs, please contact VIZIO:
º The power connector fails or frays.
º Liquid sprays or any object drops into the LCD TV.
º The Display is exposed to rain or other moisture.
º The Display is dropped or damaged in any way.
º The performance of the Display changes substantially.
• Operating environment:Temperature: 40°F ~ 95°F, Humidity: 10% to 90% non-condensing, Altitude: 0~10,000 ft.
THIS PRODUCT HAS BEEN TESTED AND FOUND TO COMPLY WITH REGULATORY SAFETY CERTIFICATIONS.

WWW6):)/#%COM
Version- 02/27/06
5
VIZIO L37 HDTV User Manual
Note: In some countries or regions, the shape of the power plug and power outlet may sometimes differ
from that shown in the explanatory drawings. However, the method of connecting and operating the unit
is the same.
4ELEVISION!NTENNA#ONNECTION0ROTECTION
%XTERNAL4ELEVISION!NTENNA'ROUNDING
If an outside antenna/satellite or cable system is to be connected to the LCD TV, make sure that the
antenna/satellite or cable system is electrically grounded to provide some protection against voltage surges
and static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit,
size of the grounding conductors, location of antenna discharge unit, connection to grounding electrodes,
and requirements of the grounding electrode.
,IGHTNING0ROTECTION
For added protection of your LCD TV during a lightning storm or when it is left unattended or unused for
long periods of time, unplug the LCD TV from the wall outlet and disconnect the antenna/satellite or cable
system.
0OWER,INES
Do not locate the antenna near overhead light or power circuits, or where it could fall into such power lines
or circuits.
ELECTRIC SERVICE EQUIPMENT
GROUND CLAMP
GROUND CLAMPS
ANTENNA LEAD-IN WIRE
ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)
GROUNDING CONDUCTORS (NEC SECTION 810-21)
POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

WWW6):)/#%COM
Version- 02/27/06
6
VIZIO L37 HDTV User Manual
/PENINGTHE0ACKAGE
Your VIZIO L37 HDTV is packaged in a carton together with other standard accessories. Any optional
accessories would be packed separately in another carton.
The weight of the LCD display is approximately 55 lbs. Due to the size and weight of the product, it is
suggested that it be handled by a minimum of 2 persons.
Since the glass can be easily scratched or broken, please handle the product gently. Never place the unit on
a surface with the glass facing downwards unless it is on protective padding.
When opening the carton, check that the product is in good condition and that all standard accessories and
items are included.
IMPORTANT: Save the original box and all the packing material for future shipping needs.
 
0ACKAGE#ONTENTS
VIZIO L37 HDTV
VIZIO Remote Control by Universal Electronics
Audio Video Cable (yellow, red and white connectors)
Power Cord
This User Guide
Quick Setup Guide
Registration Card
VIP Services Brochure
Note: Optional components sold separately.

WWW6):)/#%COM
Version- 02/27/06
7
VIZIO L37 HDTV User Manual
!DDITIONAL6):)/#ERTI¬ED!CCESSORIESFORTHE6):)/,
($46ARESOLDSEPARATELY
Wall Mounts
High Definition Cables
Extra or replacement Remote
VIZIO also offers Installation Services and Extended Warranty Services for your VIZIO L37 HDTV.
To purchase or inquire about additional accessories and services for your VIZIO product, visit our web site
at www.vizioce.com or call us toll free at 1-888-VIZIOCE (1-888-849-4623).
)NSTALLATION0REPARATION
Please read the user manual carefully before performing the installation.
The power consumption of the display is approximately 160 watts, please use the power cord designated for
the product. When an extension cord is required, use one with the correct power rating. The cord must be
grounded and the grounding feature must not be defeated.
The product should be installed on a flat surface to avoid tipping. Space should be maintained between
the back of the product and the wall for proper ventilation. If you would like to mount the TV to the wall,
please see “Preparing the LCD for Wall Mounting” below for additional information. Avoid
installing the product in the kitchen, bathroom or other places with high humidity, dust or smoke, so as not
to shorten the service life of the electronic components.
Please ensure the product is installed with the screen in landscape orientation. Any 90° clockwise or
counterclockwise installation may induce poor ventilation and excessive component damage.
VIZIO offers professional installation services. Please contact VIZIO for more information on these
services at 1-888-VIZIOCE (1-888-849-4623) or www.vizioce.com.
0REPARING9OUR,#$46FOR7ALL-OUNTING
The VIZIO L37 HDTV can either be kept on the stand base or mounted to the wall for viewing. If you
choose to mount the L37 HDTV to the wall, please follow the instructions below for removing the base
stand.

WWW6):)/#%COM
Version- 02/27/06
8
VIZIO L37 HDTV User Manual
4OREMOVETHESTANDBASE
1. Unplug all the cables and cords from your LCD TV.
2. Place the LCD TV face down on a soft and flat surface (blanket, foam,
cloth, etc) to prevent any damage to the display.
3. Remove the 6 screws on the back panel of the TV located near the bottom
so that the base stand can be removed. (see Figure 3.3a)
4. Gently pull the stand away from the display by grasping firmly to the base.
5. Now the display can fit securely to a mount (sold separately) by utilizing the
mounting holes in the center of the back panel of the display (see Figure
3.3b). Please make sure to read the directions of your specific wall mount to
properly hang the L37 HDTV. Make sure the wall mount is rated to support
at least 65 lbs.
To find the perfect mount for the VIZIO L37 HDTV,
browse VIZIO’s certified mount selection at www.vizioce.com
or call directly, 1-888-VIZIOCE (1-888-849-4623).
Figure 3.3b
Figure 3.3a

WWW6):)/#%COM
Version- 02/27/06
9
VIZIO L37 HDTV User Manual
#HAPTER"ASIC#ONTROLSAND#ONNECTIONS
1.1 – Front Panel Controls 10
1.2 – Side Panel Controls 10
1.3 – Rear Panel Connections 11
1.4 – VIZIO Universal Remote Control 12
1.4.1 – Insertion of Batteries in the Remote Control 15
1.4.2 – Remote Control Range 15
1.4.3 – Precautions for the VIZIO Universal Remote Control 15
#HAPTER#ONNECTING%QUIPMENT
2.1 – Which Video Connection Should I Use? 16
2.2 – Connecting your DVD Player 17
2.2.1 – Using HDMI (Digital HD) 17
2.2.2 – Using Component (Analog HD1) Video 19
2.2.3 – Using S-Video (AV3) 20
2.2.4 – Using Composite (AV) Video 21
2.3 – Connecting Your HDTV Set-Top Box 22
2.3.1 – Using HDMI (Digital HD) 22
2.3.2 – Using RGB Video 24
2.4 – Connecting Your VCR or Video Camera 25
2.5 – Connecting Coaxial (RF) 26
2.5.1 – Using Your Antenna or Digital Cable for DTV 26
2.5.2 – Using Your Antenna or Cable TV 27
2.5.3 – Using the Antenna through Your VCR 27
2.6 – Connecting an Amplifier or Speakers 28
2.7 – Connecting a Computer 29
#HAPTER3ETTING5PTO7ATCH46AND$46
3.1 – Basic LCD TV Start Up 30
3.2 – Watching a TV Program 32
3.3 – Adjusting Basic LCD TV Settings 32
3.4 – DTV Tuner Set Up 33
3.4.1 – Parental Controls for DTV 40
3.4.2 – DTV Channel Information 42
3.4.3 – Program Information 43
3.4.4 – Setting a Password 44
3.5 – Using the On Screen Display (OSD) 45
3.5.1 – OSD Menu Operations 45
3.5.2 – Picture Adjust 46
3.5.3 – Picture 46
3.5.4 – Temperature 47
3.5.5 – Audio Adjust 47
3.5.6 – TV Tuner Set Up for NTSC TV 47
3.5.7 – Parental Controls for TV 48
3.5.8 – PIP/POP Set Up 48
3.5.9 – Special Features 48
3.5.10 – Understanding Viewing Features 49
3.5.11 – Viewing Modes 49
3.5.12 – Picture in Picture (PIP)/Picture by Picture (POP) Mode 50
3.5.13 – Adjust Basic PIP/POP Settings 50
3.5.14 – Using the Parental Controls 51
3.5.15 – Setting the Sleep Timer 52
3.6 – Programming the VIZIO Universal Remote Control 53
3.6.1 – Programming for VCR 53
3.6.2 – Programming for Cable Box 54
3.6.3 – Programming for DVD Player 54
3.6.4 – Searching for Component Codes 55
3.7 – Using a Cable Box or Satellite Box Remote 55
#HAPTER-AINTENANCEAND4ROUBLESHOOTING
4.1 – Maintenance 56
4.2 – Troubleshooting Guide 56
4.3 – Telephone and Technical Support 58
4.4 – Compliance 59
4.5 – FCC Class B Radio Frequency Interference Statement 59
3PECI¬CATIONS 60
'LOSSARY3TANDARD$E¬NITIONS 61
)NDEX 62
!PPENDIX!,IMITED0RODUCT7ARRANTY 64
!PPENDIX"#OMPONENT0ROGRAM#ODES 65
4ABLE/F#ONTENTS 0AGE

WWW6):)/#%COM
Version- 02/27/06
10
VIZIO L37 HDTV User Manual
#HAPTER"ASIC#ONTROLSAND#ONNECTIONS
 
 
&RONT0ANEL#ONTROLS
1. OSD (On-Screen Display) – This button opens the TV OSD menu.
2. Mute/Exit – This button allows the user to turn off the sound on the LCD TV. Additionally, it functions as
the exit button for the OSD menu.
3. Volume (-/+) -- These buttons increase or decrease volume. When the OSD is active, these buttons adjust
the OSD options.
4. Channel (-/+) – These buttons increase or decrease the channels. When the OSD is active, these buttons
are used to select OSD options.
5. Input – This button switches between the available input sources in the following sequence: AV1 and AV2
(Video), AV3 (side panel connections – S-Video and Video), Analog HD1 and Analog HD2 (Y-Pb/Cb-Pr/
Cr), Digital HD (HDMI), RGB, TV and DTV (Digital TV and ATSC HDTV). Press the button repeatedly
to cycle through the available options.
6. Power Button - Switch the LCD TV on by pressing the button once. Press the button again to turn the
LCD TV off.
7. Remote Control Sensor – This is the window that passes all of the remote control signals to the TV.
Point the remote control directly at this window for the best response to the remote signal.
8. Power Indicator Light - If the light is solid yellow, then your LCD TV is turned off. If the light is
solid green, then your LCD TV is turned on. If the light is not lit, there is no AC power
detected and the power cord may not be connected properly. When turning the LCD TV on or off, wait
three seconds before pressing the power button again.
3IDE0ANEL#ONTROLS
1. Head Phone Jack - Connect external headphones (not included) to this port. Note: if headphones
are connected, the speakers will be disconnected.
2. Composite Video (V3) - Connect a source for composite devices, such as a VCR or video games.
Use the white (L3) and red (R3) connectors to connect the external audio from the same source.
3. S-Video (AV3) - Connect the primary source for S-Video devices, such as a VCR or video games.
Use the white (L3) and red (R3) connectors to connect the external audio from the same source.
21 3 4 5 6 7 8
