VIZON AF-10 User manual

Instruction
Manual
AF-10
Digital Air Fryer
Please read this instruction carefully before using.
Please make sure to keep this instruction properly
so that it can be consulted at any time in the future.
Please use it properly on the basis understanding of this instruction.
°C
MIN

Important SafeguardsTable of Contents
1-2
2
3-4
5
5-6
6-7
7-9
9
10
11
Important Safeguards
Product Introduction
General Description
Before First Use
Using the Appliance
Cleaning
Settings
Making Home – Made Fries
Troubleshooting
Warranty
………………………...............………………............................………....
………………………...............……………………...........................………
………………………...............…………….............................………………
………………………...............……………….......................................……………
………………………...............….............................…………………………
………………………...............……………………..........................................................………
………………………...............…...........................................................…………………………
……………….........………...............……………………………
………………………...............…......................................…………………………
………………………...............……….........................................................……………………
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons, do not immerse cord or
plugs in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair or adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer
may result in fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution needed when moving an appliance containing hot oil
or other hot liquids.
12. Always attach plug to appliance first, then plug cord into the wall outlet.
13. Do not use appliance for other than intended use.
14. Never fill the pan with oil. Filling the pan with oil may cause a fire hazard.
15. This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug is only intended to fit into a polarized
outlet in one way. If the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician.
Do not attempt to modify the plug in any way.
16. (a) A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or
tripping over a longer cord.
1

(b) Longer detachable power supply cords or extension cords are available and
may be used if care is exercised in their use.
(c) If a long detachable power-supply cord or extension cord is used,
1. The marked electrical rating of the cord set or extension cord should be
at least as great as the electrical rating of the appliance:
2. The cord should be arranged so that it will not drape over the counter top or
tabletop where it can be pulled on by children or tripped over unintentionally, and
3. If the appliance is of the grounded type, the cord set or extension cord
should be agrounding-type-3-wire cord.
SAVE THESE INSTRUCTIONS.
General Description
Product Introduction
Important Safeguards
This air fryer uses Rapid Air Technology to prepare food that usually needs to be
dunked in oil and fried. Rapid Air Technology works by quickly circulating hot air
around a pan, the best part about the air fryer is that it heats food in all directions
and most dishes do not require oil. It has 7 built-in smart programs, such as
"Chips", "Meat" , "Chicken" , "Steak" , "Cake", "Pizza", and "Fish". It also has a
wide temperature range from 80° - 200°C, and timer up to 30 minutes.
This air fryer is an easy and healthy way to prepare your favourite fried foods.
Basket
Unit
Structure
Temperature/
Timer Control
Pan
Please read this manual carefully before using the appliance as danger may
occur under incorrect operation. Keep it for future reference.
Significance:
- Do not immerse the housing in water or rinse under the tap due to the
Multi electrical and heating components.
- Avoid any liquid to enter the appliance to prevent from electric shock or short-circuit.
- Keep all ingredients in the basket to prevent any contact from heating elements.
- Do not cover the air inlet and the air outlet when the appliance is working.
- Fill the pan with oil may cause a fire hazard.
- Do not touch the inside of the appliance while it is operating.
Danger:
- Check if the voltage indicated on the appliance fits the local mains voltage.
- Keep the mains cord away from hot surfaces.
- Do not plug the appliance or operate on the control panel with wet hands.
- Make sure that the appliance is plugged to an earthed wall socket. Always make sure
that the plug is inserted into the wall socket properly.
- Do not connect appliance to an external timer switch.
- Do not place the appliance on or near combustible materials such as a
tablecloth or curtain.
Warning:
2 3

- Ensure that appliance is placed on a horizontal, even and stable surface.
- This appliance is designed for household use only. It may not suitable to be safety
used in environments such as staff kitchens, farms, motels, and other non-residential.
Caution:
- The guarantee is invalid if the appliance is used for professional or semi-professional
purposes, or it is not used according to instructions.
(Never use the appliance when the plug is damaged.)
- The appliance needs approximately 30 minutes to cool down for handle
or cleaning safety.
Environments:
The appliance has a build in timer, it will automatically shut down the appliance when
count down to zero. You can manually switch off the appliance by knobbing down
the cancel knob, it will automatically shut down the appliance in 20 seconds.
Automatic Switch-Off
- Do not place the appliance against a wall or against other appliance. Leave at least
10 cm free space on the back and sides and 10 cm free space above the appliance.
- Do not place anything on top of the appliance.
- Do not use the appliance for any other purpose than described in this manual.
- Do not let the appliance operate unattended.
- During hot air frying, hot steam is released through the air outlet openings. Keep your
hands and face at a safe distance from the steam and the air outlet openings.
Also be careful of hot steam and air when you remove the pan from the appliance.
Any accessible surfaces may become hot during use.
- Immediately unplug the appliance if you see dark smoke coming out of the appliance.
Wait for the smoke emission to stop before you remove the pan from the appliance.
Before First UseGeneral Description
1. Remove all packaging materials and stickers or labels.
2. Clean the basket and pan with hot water, with some washing liquid and a
non-abrasive sponge. These parts are safe to be cleaned in dishwasher.
3. Wipe inside and outside of the appliance with a clear cloth. And there is no need
to fill the pan with oil as the appliance works on hot air.
Using the Appliance
1. Place the air fryer on a flat and even surface.
DO NOT PLACE THE FRYER ON A SURFACE THAT IS NOT HEAT RESISTANT.
2. Put the basket in the pan.
DO NOT FILL THE PAIN WITH OIL OR ANY OTHER LIQUID.
3. Place the ingredients in the basket and put the basket into pan, then put the pan
into the appliance. The fryer LED should light up.
4. Set your cooking time and temperature by either choosing one of the 7 preset
or manually setting it with the "+","-" buttons. See "Settings" on page 7 determine
the right time and temperature.
NOTE: When setting the time manually, always add an extra minute or two to the
cooking time to allow the cooker to warm-up.
5. Once you have set your cooking time and temperature, press the power button
to begin the cooking cycle.
NOTE: To stop the cooking cycle or reset the fryer settings, press the power
button again. A red led flashing indicates that the fryer is starting the
cooking cycle. If there is not flashing, the cooker will go into standby mode.
6. There are some ingredients that you may need to shake halfway through the
cooking cycle (See "Settings" on page 7.) To do this, pull the pan out of the appliance,
the air fryer will automatically shut down. Shake the pan or flip the ingredients.
Then place the pan back into the air fryer and it will resume the cooking cycle.
The timer will reset to the original setting, so take note of the remaining time
before pulling the basket out of the air fryer.
4 5

7. When the cooking time turns to 0, the timer will beep 5 times, after the
timer beeps 5 times, the air blower will stop in 40 seconds.
8. Pull the pan out of the fryer and place it on a pot holder.
NOTE: Oil from the ingredients will gather in the bottom of the pan, so be careful
when pulling the pan out of the fryer.
9. Check if the food are ready, if they are not, simply slide the pan back into the fryer,
set your cooking time and temperature, and press power button for your air fryer to run.
10. To remove the ingredients, put handle into the basket, hold handle to remove basket
from pan.
NOTE: Do not turn the pan over, the oil collected at the bottom of the pan will
leak onto the ingredients.
11. Empty the contents into a bowl or plate.
TIP: You can remove the basket from the pan or use a pair of tongs to transfer
large or fragile ingredients from the basket.
12. If you would like to prepare more, you can instantly use the air fryer with another
batch of ingredients.
Using the Appliance
Cleaning
Clean the appliance after every use.
Do not clean the pan, basket and the inside of the appliance by metal kitchen
utensils or abrasive cleaning materials, as this may damage the
non-stick coating of them.
1. Remove the main plugs from the wall socket to allow the appliance to cool down.
NOTE: Remove the pan to let the fryer cool down more quickly.
2. Wipe the outside of the appliance with a moist cloth.
3. Clean the pan and basket with hot water, some washing-up liquid and a
non-abrasive sponge. You can remove any remaining dirt by degreasing liquid.
NOTE: The pan and basket are dishwasher proof.
Cleaning
Settings
TIP: If dirt is stuck to the basket or the bottom of the pan, fill the pan with hot water
with some washing up liquid. Put the basket in the pan and let the pan and the
basket soak for about 10 minutes.
4. Clean the inside of the appliance with hot water and non-abrasive sponge.
5. Clean the heating element with a cleaning brush to remove any food residues.
Storage
1. Unplug the appliance and let it cool down thoroughly.
2. Make sure all parts are clean and dry.
This table below will help you to select the basic settings for the ingredients.
Note: Keep in mind that these settings are indications. As ingredients differ in origin,
size, shape and brand, we cannot guarantee the best setting. Rapid Air Fryer Technology
reheats the air inside the appliance instantly, pull the pan briefly out of the appliance
during hot air frying barely disturbs the process.
TIPS:
- Small ingredients usually require a slightly shorter preparation time than
larger ingredients.
- A larger amount of ingredients only requires a slightly longer preparation time,
a smaller amount ingredients only requires a slightly shorter preparation time.
- Shaking smaller ingredients halfway during the preparation time optimizes the end
result and can help prevent unevenly fried ingredients.
- Add some oil to fresh potatoes and fry your ingredients for another few minutes
for a crispy result.
- Do not prepare extremely greasy ingredients such as sausages in the air fryer.
- Snacks that can be prepared in an oven can also be prepared in the air fryer.
- The optimal amount of potato for prepare crispy fries is 500 grams.
6 7

- Use pre-made dough to get snacks quickly and easily. Pre-made dough also
requires a shorter preparation time then home-made dough.
- Place a baking tin or oven dish in the fryer basket if you want to bake a cake or
quiche or if you want to fry fragile ingredients or filled ingredients.
- You can also use the air fryer to heat ingredients. To heat ingredients, set the
temperature to 150°C for up to 10 minutes.
Settings Settings
Making Home - Made Fries
Ingredient Amount Min
to Max (g)
Time
(minute)
Temperature
(°F)
POTATOES & FRIES
MEAT & POULTRY
Shake Extra
Information
Thin Frozen
Fries 300-700 9-16 400°F/200°C Shake
Thick Frozen
Fries 300-700 11-20 400°F/200°C Shake
Home-made
Fries (8x8mm) 300-800 10-16 400°F/200°C Shake Add 1/2 tbsp of oil
Home-made
Potato Wedges 300-800 18-22 360°F/180°C Shake Add 1/2 tbsp of oil
Home-made
Potato Cubes 300-750 12-18 360°F/180°C Shake Add 1/2 tbsp of oil
Ingredient Amount Min
to Max (g)
Time
(minute)
Temperature
(°F)
SNACKS
BAKING
Shake Extra
Information
Rosti 250 15-18 360°F/180°C Shake
Steak 100-500 8-12 400°F/200°C Flip
Pork Chops 100-500 10-14 360°F/180°C Flip
Hamburger 100-500 7-14 360°F/180°C
Sausage Roll 100-500 13-15 400°F/200°C Flip
Drumsticks 100-500 18-12 400°F/200°C Flip
Chicken Breast 100-500 10-15 360°F/180°C Flip
Spring Rolls 100-400 8-10 400°F/200°C Shake Use oven-ready
Frozen Chicken
Nuggets 100-400 6-10 400°F/200°C Shake Use oven-ready
Frozen Fish
Fingers 100-400 6-10 400°F/200°C Use oven-ready
Frozen Bread
Cheese Snacks 100-400 8-10 360°F/180°C Use oven-ready
Cake 300 20-25 320°F/160°C Just use pan
Quiche 400 20-22 360°F/180°C Just use pan
Muffins 300 15-18 400°F/200°C Just use pan
Sweet Snacks 400 20 320°F/160°C Just use pan
Stuffed
Vegetables 100-400 10 320°F/160°C
Potato Gratin 500 15-18 360°F/200°C Shake
To make home-made fries, follow the steps below:
1. Wash the potatoes in water then peel and slice the potatoes.
2. Wash the potato sticks thoroughly and dry them with paper towel.
3. Pour 1/2 tablespoon of olive oil in a bowl, put the sticks on top and mix until the
sticks are coated with oil.
4. Remove the sticks form the bowl with your fingers or a kitchen utensil, so that the
excess oil stays behind in the bowl. Put the sticks in the basket.
5. Fry the potato sticks according to the cooking guide above.
8 9

Troubleshooting
PROBLEMS POSSIBLE CAUSE SOLUTIONS
Make sure the fryer is plugged in.
Set the cooking time.
The Air Fryer does not work The fryer is not plugged in.
The cooking time was not set.
Use smaller batches of ingredients
in the basket as they fry more evenly.
The ingredients cooked with
air fryer are not done
The basket is too full.
The set temperature is too low.
Increase the temperature by using
the "+" or "–" buttons.
(See "How to use your Air Fryer")
When greasy ingredients are fried
in the air fryer, a large amount
of oil will leak into the pan,
the oil produces white smoke
and the pan may heat up more
than usual. This does not affect
the fryer or end result.
White smoke is coming out
of the fryer
The pans still contains grease
residues from previous use.
White smoke is caused by grease
heating up in the pan.
Make sure you clean the pan
properly after each use.
Ingredients that lie on top of or
across each other, for example
fries, need to be shaken halfway
through the cooking time
(See "How to use your Air Fryer")
The ingredients are fried
unevenly
Certain types of ingredients
need to be shaken halfway
through the cooking time.
Use oven snack or lightly brush
some oil onto the snacks
for a crispier result.
Fried snacks are not crispy when
they come out of the air fryer
The type of snack used was
meant to be prepared in a
traditional deep fryer.
Do not fill the basket beyond
the "Max" indication
I cannot slide the basket into
the appliance properly The basket is too full.
You are preparing greasy
ingredients.
Warranty Information
The manufacturer provides a 1 year warranty in accordance with the legislation
of the customer's own country of residence, starting from the date on which the
appliance is sold to the end user.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service centre.
When making a claim under the warranty, the original bill of purchase
(with purchase date) must be submitted.
The warranty will not apply in cases of:
- Normal wear and tear
- Incorrect use, e.g. overloading of the appliance, use of non-approved accessories
- Use of force, damage caused by external influences
- Damage caused by non-observance of the manual, e.g. connection to an unsuitable
mains supply or non-compliance with the installation instructions
- Partially or completely dismantled appliances
Guarantee and Service
If you need service or information or if you have any problems, please visit our website.
10 11
