VIZULO Shell Basic User guide

1/8
VIZULO Shell Basic LED luminaire
Monteringsanvisning Mounting instruction Montāžas instrukcija Mонтажная инструкция
09-01-2020
SIA VIZULO
Laucu Lejas, Iecava, Latvia, LV-3913
www.vizulo.com
IEC
EN 60598 IP44 220 V
240 V
min
+10°C
max
+ 35°C

2/8
Mått
Izmēri
Размеры
Dimensions
Nettovikt
Neto Svars
Нетто Вес
Netto Weight
0.64 kg
VARNING!
• Rör inte LED-modulerna!
• Placera inga verktyg eller andra föremål på LED-moduler!
• Om någon LED är fysiskt skadad (exempel visas nedan) är garantin ogiltig.
BRĪDINĀJUMS!
• Neaiztikt LED moduļus!
• Nenovietot instrumentus vai citus priekšmetus uz LED moduļiem!
• Mehānisku LED bojājumu gadījumā (skatīt piemēru zemāk) apmaiņas garantija nav spēkā.
ВНИМАНИЕ!
• Не прикосаться к LED модулям!
• Не ставить на LED модули инструменты или другие предметы!
• В случае механических повреждений LED (см. ниже) гарантийный обмен не осуществляется.
WARNING!
• Do not touch LED modules!
• Do not put any tools or other items on LED modules!
• In case any LED is physically damaged (example shown below) the warranty is void.
100
300
352
248,7
Mounting hole location

3/8
1
1 2 3
~1/8 turn
Vid installation av LED-armaturen skall det vara rent i rummet och handskar skall användas!
Bländskydd kan ackumulera små elektrostatiska laddningar som gör att den är mottaglig för damm och andra små partiklar.
Det ska endast rengöras med torr mikrokylduk eller tryckluftsdammare.
LED gaismekli uzstādīt tikai tīrā telpā, izmantojot cimdus!
Difuzora pārsegs var uzkrāt nelielus elektrostatiskos lādiņus, kā rezultātā uz tā uzklākjas putekļi un citas sīkas daļiņas;
To būtu jātīra tikai ar sausu mikrošķiedras audumu vai saspiesta gaisa plūsmu.
Установить светодиодный светильник только в чистом помещении, используя
перчатки!
Kрышка диффузорa может накапливать небольшие электростатические заряды, что делает её восприимчивым к
воздействию пыли и других мелких частиц;
Это должнo быть очищено только сухой тканью из микроволокна или потоком сжатого воздуха.
Install LED luminaire only in a clean room using gloves!
2

4/8
3 4
5A
6
21
~1/8 turn
1
Class I + DALI
1
5B Class II + DALI
L
N
L
L
D- D+
2.1
1.2
L
NL
1.1 2.2
1.1
L
N
2.1
L
NDA
DA
1.2 2.2

5/8
User manual of microwave motion sensor
Settings:
1. Sensitivity
Sensitivity can be adjusted by selecting the combination-100%
2. Hold-time
Hold-time refers to the time period that the light
remains 100% on if no more movement is detected.
4
3
5s
90s
5min
15min
-5s
3. Daylight sensor
Light will always turn on upon movement if daylight sensor
is disabled.
6
5
Disable
50Lux
10Lux
2Lux
-Disable
Mikrovågsensor instruktion
Inställningar:
1.Känslighet
Känsligheten kan justeras genom att välja kombinationen på
DIP-omkopplarna för olika applikationer.
2
1
100%
75%
50%
10%
-100%
2. Hålltid
Hålltid avser den tidsperiod som ljuset förblir 100% om
ingen rörelse Avkänas.
4
3
5s
90s
5min
15min
-5s
3. Dagsljus-sensor
Olika dagsljusgränser kan vara närvarande påDIP-omkopplare.
Ljuset slår alltid på vid rörelse om dagsljussensorn är inaktiverad.
6
5
Disable
50Lux
10Lux
2Lux
-Disable
2
1
100%
75%
50%
10%

Settings (Remote Control)
Permanent ON/OFF function
Press button “ON/OFF” to select permanent ON or permanent OFF mode.
*Press button “AUTO”, “RESET” to quit this mode.
ON/
OFF
AUTO mode
Press button “AUTO” to initiate automatic mode. The sensor starts working and all
settings remain as before the light is switched ON/OFF.
SEMI-AUTO mode
manually on by push-switch and automatically o in this mode.
Press the buttons to select light output at 80% (at initial 10,000 hours) or 100%.
Note: “Sensor o” and“Twilight” functions are disabled.
Power output
Press the buttons to adjust the light brightness during hold-time.
Brightness +/-
Detection range (valid for master only)
Scene program - 1-key commissioning
1. Press button “Start” to program.
2. Select the buttons in “Detection range”, “Daylight threshold”, “Hold-time”, “Stand-by time”, “Stand-by dimming level” to set all
parameters.
3. Press button “Memory” to save all the settings programmed in the remote control.
4. Press button “Apply” to set the settings to each sensor unit(s).
For example, to set detection range 100%, daylight thresholdDisable, hold-time 5min, stand-by time +∞, stand-by dimming level 30%, the steps should be:
Press button “Start”, button ”100%”, “Disable”, “Shift”, “5min”, “Shift”, “+∞”, “30%”, “Memory”. By pointing to the sensor unit(s) and pressing “Apply”, all
settings are passed on the sensor(s).
Press buttons in zone “Detection range” to set detection range at 100% / 75% / 50% / 10%.
Press button “RESET”, all settings go back to default settings.
Reset Settings
&
A
Remote control
Press button “Shift”, the LED on the top left corner is on to indicate mode selection.
All values / settings in RED are valid for 20 seconds.
Shift Button
Press buttons in zone “ Daylight threshold” to set daylight sensor at 2Lux / 10Lux /50Lux / 100Lux / 300Lux / 500Lux / Disable.
2. These buttons are invalid for HC034RF.
Daylight threshold
6/8

RF grouping
2. Press button “Ambient”, the surrounding lux level is sampled and set as the new daylight threshold.
Ambient daylight threshold
Dual tech & RF mode
Hold-time
Stand-by dimming level
Stand-by time (corridor function)
Press buttons in zone “hold-time” to set the hold-time at 2s / 30s / 1min / 5min / 10min / 15min / 20min / 30min.
2. 2s is for testing purpose only, stand-by period and daylight sensor settings are disabled in this mode.
*To exit from Test mode, press button “RESET” or any button in “Hold-time”.
Press buttons in zone “stand-by time” to set the stand-by period at 0s / 10s / 1min / 5min / 10min / 30min / 1h / +∞.
motion detected,and remains at the stand-by dimming level after motion hold-time.
Press the button in zone “stand-by dimming level” to set the stand-by dimming level at 10% / 20% / 30% / 50%.
“HF”,”PIR”, “HF+PIR”, “HF/PIR” are disabled.
For RF grouping via remote control, please refer to steps below:
Short press “Learn/Erase” button on RC to activate pairing mode, and the
receiver unit starts to beep once every second for 3min.
Note: the unit can only pair up to 30 units.
Step1
The receiverunit (slave)
Beeper is on for 3minShort press “Learn
/Erase” button
Step3
The receiverunit(slave)
Beeper is on
Erase:
Long press “Learn/Erase” button for 3s to the sensor unit. The beeper
beepsrapidly for about 5s. All commands received before are erased.
Step2
The transmitter unit (master)
The beeper beeps one time
Beeper beeps rapidly
when RF signal is received
Short press “Transmit” buttonon RC, the commander unit (master unit)
beepsone time to send the transmissionsignal.
Upon receiving the transmissionsignal, the receiver unit (slave unit) rapidly
beeps3 times in1s to indicate the success ofpairing. Repeat this
step to pair more units.
One moreshort press on“Learn/Erase” buttonto the receiver unit to
completethe pairing process, the receiver unit will quit the pairing mode.
Note: Press button RX100%, the light on receiver unitis 100% on upon receiving
RF onsignal;Press “RX STBY%” button, the light(s) goes to preset stand-by
dimming level directly. The receiverunit(slave)
Short press “Transmit” button
Short press “Learn
/Erase” button to
quit pairing mode.
All buttons in this zone are disabled.
7/8

Конфигурация ведущий / ведомый
Master Slave 1
...
Slave N
L
PE
N
2
PE
N
1
PE
N
1
PE
N
2
PE
N
Master must include
microwave motion sensor!
Tridonic LED driver
MCB/Inrush current table
Power range Dimming
In-rush current
(peak/dura on)
B10A B13A B16A B20A C10A C13A C16A C20A
DALI 15 A (243 s) 24 31 38 48 40 56 64 80
Non dimmable 17 A (231 s) 23 30 37 47 38 50 61 78
DALI 18 A (140 s) 22 30 36 46 36 50 60 76
Non dimmable 15 A (204 s) 25 33 40 50 41 55 66 83
DALI 25 A (141 s) 19 24 31 40 31 40 51 66
Non dimmable 16 A (229 s) 25 32 39 50 41 53 65 83
OSRAM LED driver
MCB/Inrush current table
Power range Dimming
In-rush current
(peak/dura on)
B10A B13A B16A B20A C10A C13A C16A C20A
DALI 8 A (150 µs) 38 60
Non dimmable 5 A (45 µs) 82 130
DALI 13 A (225 µs) 20 30
Non dimmable 20 A (50 µs) 50 80
7 - 10 W
11 - 17 W
18 - 28 W
7 - 15 W
16 - 28 W
