Vjoycar S98 User manual
User Manual
Vehicle-mounted GPS S98
Vehicle-mounted GPS S98
请保存此说明书
电源
DC 5V 工作温
电池 400MA 太阳能充电
海拔误差 1－80M 外壳材质
产品尺寸 70*59*59（mm）重量
-40℃ ~ +80℃
100MA
ABS+PC耐高温材料
203g
产品简介
S98是一款多功能车载GPS产品，产品配置了太阳能充电，500MA电池，高清
显示屏，耐高温材质。该产品适用于市场所有车型（包括大卡车，大巴车，
商务车，小轿车)，产品通过GPS／北斗卫星双通道模块获取卫星信号数据，
双信号更稳定。产品功能特点速度显示，时间显示，太阳能充电待机时间更
长，车内温度显示，海拔显示，疲劳驾驶提醒，超速报警，随车启动等优
势，炫酷迷你机身设计，占用空间小，也是一款车内装饰品，您值得拥
有。
特点主要功能
1*车速显示
2*时间显示
3*太阳能充电
4*车内温度显示
5*海拔显示
主要特点
1*采用博世进口芯片
2*太阳能充电功能
3*迷你炫酷机身设计
4*高清显示屏
5*显示亮度自动调节
6*随车启动
报警提示功能
1.超速报警
2.整点报时半时报时
3.疲劳驾驶提醒
工作环境及技术指标
2
整机结构
显示界面及功能介绍
A-速度显示。
B-报警提示。
C-疲劳驾驶提醒。
D-时间显示。
E-电量显示。
F-太阳能充电提示。
G-KM/MPH单位。
H-车内温度海拔显示，
海拔显示。（10S自
动切换）
3
按键功能介绍
设置功能介绍
4
1-时间设置。
2-速度补偿设置。
3-疲劳驾驶设置
1-太阳能充电板。
2-显示屏主界面。
3-左开关键。
4-“SET”功能键，左开关键，右下档键。
5-右下档键。
6-ABS材质外壳。
7-USB接口，电量补偿。
1*左键 2*SET键 3*右键
正常模式
1-左键短为开关键 2-SET键短为无效 （长按5S进入设置模
式） 3-右键短为声音开机键
设置模式
1-左键短按为加
2-SET键短按为设置切换（长按5s保存进入正常模式）
3-右键短按为减
4-超速报警设置。
-
-KM-温度，MPH-华氏度按左右键切换
长按SET键5S设定保存退出
-
器
控台无遮挡位
采光
太阳
充
-选
位
防滑垫
选
位
器
防滑垫
6
尺寸
5
12
Copyright! No company or individual may copy or back up this specification in
any form (electronic, mechanical, photocopying, recording or other forms)
without the written consent of the company. This manual is specially designed
for the use of the Company's products, and the Company does not assume any
responsibility for all kinds of consequences caused by using it to guide the
operation of other equipment.
The Company and its branches shall not be responsible for the expenses and
expenses incurred by the Company and its branches for the abuse, misuse, self-
modification or repair of the Equipment due to the accidental reasons of the user
or a third party, or the damage or loss of the Equipment due to failure to comply
with the Company's operation and maintenance requirements.
Official Statement: The purpose of other product names mentioned in this
specification is to explain how the equipment is used, and the ownership of its
registered trademark still belongs to the original company.
Please save this manual
Product Profile
S98 is a multi-functional vehicle-mounted GPS product, which is equipped with
solar charging, 500MA battery, high-definition display screen and high-
temperature resistant materials. This product is suitable for all models in the
market (including large trucks, buses, commercial vehicles and cars). The
product obtains satellite signal data through GPS/Beidou satellite dual-channel
module, and the dual signals are more stable. The product features speed
display, time display, longer standby time for solar charging, temperature
display in the car, altitude display, fatigue driving reminder, speeding alarm,
starting with the car and other advantages. The cool mini body design takes up
less space and is also an interior decoration, which you deserve.
Features Main Functions
1* Speed Display
2* Time Display
3* Solar Charging
4* In-car Temperature Display
5* Altitude Display
Main Features
1* Adopt Bosch imported chips
2* Solar Charging Function
3* Mini Cool Body Design
4* High Definition Display
5* Display Brightness Automatic Adjustment
6* On-Board Start-Up
Alarm function
1. Overspeed alarm
2. The hour is the hour and the half is the hour
3. Tired driving reminder
Working Environment and Technical Indicators
Power Supply DC5V Working temperature -40℃~+80℃
Battery 400MA Solar charging 100MA
Altitude error 1-80M Product Size 70*59*59（mm）
Weight 203g
Shell material ABS + PC High Temperature Resistant Material
34
Complete Machine Structure
1-Solar charging panel.
2-The main interface of the display screen.
3-Left key.
4-"SET" function key, left is the power key, and the right is lower key.
5-Right lower key.
6-ABS housing.
7-USB interface, power compensation.
Introduction of Display Interface and Function
A-Speed Display.
B-Alarm.
C-Tired Driving Reminder.
D-Time Display.
E-Electricity Display.
F-Solar Charging Prompt.
G-KM/MPH units.
H-In-Car Temperature altitude display, altitude display. (10S automatic switch)
Introduction to Key Functions
1*Left, 2*SET, 3*Right
1-Left key is on key
2-SET key short is invalid (long press 5S to enter setting mode)
3-Right key short for sound startup key
Set Mode
1-Left key short press to add The short press of the
2-SET key switches to the setting (long press for 5s to save and enter the
normal mode)
3-Right-click short to minus
Introduction to Setting Function
1-Time Setting.
2-Speed Compensation Setting.
3-Fatigue Driving Setting
56
4-Overspeed alarm setting.
5- KM-temperature, MPH-Fahrenheit press left and right key switch.
Press SET key 5S for a long time to set save and exit
Equipment Sizes
Installation Steps
1-Please place the machine in an unobstructed position in the center console of
the car to ensure normal lighting so that solar energy can be charged.
2-After selecting the position, place the anti-skid pad on the selected position and
place the machine on the anti-skid pad.
After-sales service
After-sales warranty
The whole machine enjoys a 3-year warranty period from the date of receipt by the
customer, and the attachment has a 1-year warranty period.
Warranty Method
*Repair or replace the equipment according to the specific fault conditions;
*We guarantee that all replaced parts, accessories or equipment are brand new.
*If the customer fails within 90 days after receiving the product, we will provide
video and pictures at the same time. We will bear the freight and provide the
corresponding accessories for the customer to replace free of charge. After
receiving the product for more than 90 days, the customer will bear the
corresponding expenses, and we will provide spare parts for the customer to
replace free of charge.
The following conditions are no longer covered by free
warranty.
* Products purchased through informal channels;
*Damage caused by not using and maintaining according to the requirements of
the product specification;
*Statement: The Company reserves the right to change the product design and
specifications without prior notice. The appearance and color of the physical
object may differ from those shown in the instructions. Please refer to the physical
object. We have tried our best to make all the descriptions in the manual accurate,
but there are still some irregularities. In case of doubt, please contact the
distributor or after-sales service center. The company has the final right to
interpret theproducts and will not bear any consequences arising from
misunderstanding.
