VK MOBILE VK900 User manual

1
Hello,
Thank you for purchasing VK cellular phone.
Vk900 is a fabulous sliding type camera MP3 phone only for brilliant people. 2.6 million TFT LCD allows you to
enjoy multimedia functions through clear and precise screen. The 40 poly brings you incredible sound that is
almost similar to that of the original sound quality and it will be your take-out audio system. Vk900 is
embedded with cutting edge camera that features 1.3 mega pixels, 4x digital zoom, self-timer function, and
movie clip recording function. Memory card (Mini SD type) is adopted so that still photos and movie clips can
be stored in additional memory. Take out your Vk900 to anywhere you go and take as many pictures as you
like. You won’t have to worry about storing the pictures you have shot ever again. Beautiful and convenient
sliding phone with MP3 and perfect digital camera, there is virtually no competitor for Vk900.
Thank you again for choosing VK product and we hope you have greatest success in your business with Vk900.
Please read Safety Precaution prior to use.
The content of this manual and functions of cellular phone are subject to change depending on the
software version and conditions in business.

2
Contents
7
PRIOR TO USE
Prior to Use
Safety Precaution
Unpacking
Phone Layout and Keys Function
Key Description
LCD Icon Description
Inserting SIM Card and Battery
Charging a Battery
7
7
11
12
13
16
17
18
21
BASIC FUNCTIONS
Basic Operation
Switching On/Off
Making Call
Answering a Call
Hanging up
Making Call
Missed Calls
Volume Adjustment
Silent Mode
Using Ear-microphone
Standby Screen Function
Contacts
Storing Phone Numbers
Search Phone Number
21
21
22
24
25
26
28
28
29
30
31
32
32
37
BASIC FUNCTIONS
Contacts Menu Function
Menu Function of Selected Items
Character Input Method
eZi English Mode
ABC Mode
Changing Text Input Mode
Numeric Mode
Symbolic Mode
42
48
51
51
55
58
59
59
CONTENTS
61
MENU FUNCTIONS
Menu Tree
Message
New
Inbox
Outbox
Voice Mail
Information Msg.
Settings
Memory Status
Calls
Call History
Network Services
61
67
67
71
75
78
79
81
83
84
84
89
3

Contents
CONTENTS
MENU FUNCTIONS
Display
Sound
Phone Setting
Security
Infrared Receive
Organizer
Calendar
Alarm
Memo
Calculator
World Time
Unit Converter
MP3 Player
123
126
130
135
138
139
139
144
148
149
150
150
151
MENU FUNCTIONS
MP3 Player
Edit Play list
Joy World
Internet
Games
Funny Face
Remote Controller
151
154
156
156
161
163
164
167
OTHER FUNCTIONS
MP3 Editing Tool Installation Guide
PCSync Installation Guide
Safety Information
Using the Batteries
Safety Information
Care and Maintenance
Glossary
167
168
170
173
175
180
181
MENU FUNCTIONS
Gallery
Video-Clip
Images
Animation
Music
Sound
Mini SD Manager
Camera
Video-Clip
Settings
Settings
93
93
98
101
104
107
110
113
116
117
119
120
123
54

7
PRIOR TO USE
Safety Precaution
Please read safety precaution before using your cellular phone. Precaution contains contents that
prevent users from potential health and financial hazards. Read carefully and use the product
accordingly. If the following regulation stated in precautions is not followed, you may be subject
to penalties or may cause illegal conditions. For more information, refer to Health and Safety
Precaution described in the appendix of this manual.
Traffic Safety
Do not use a hand-held mobile phone while driving a vehicle. Follow traffic related regulations
while driving. Using hand-held device while driving can be direct and indirect cause of accidents. If
it is necessary to use a hand-held phone, park the vehicle before conversing or use hands-free/ear-
microphone.
Potentially Explosive Atmosphere
Switch off your phone when in any area with a potentially explosive atmosphere and obey all
signs and instructions.
PRIOR TO USE
PRIOR TO USE
Safety Precaution
Unpacking
Phone Layout and Keys Function
Keys Description
LCD Icon Description
Inserting SIM Card and Battery
Charging Battery

8
Switch Off While Refueling
Users are advised to switch off the phone while at a refueling point (gas station).
Switch Off in Aircraft
Electronic frequency generated from your cellular phone can influence electronic equipments that
are not radio frequency shielded on an airplane and cause dangerous conditions.
Switch Off in Hospitals
Follow any regulations or rules in force. Switch off your phone near medical equipment. All
wireless phones may be subject to interference that can influence the performance of medical
equipment. Consult with the medial equipment manufacturer to assure the equipment is safe
from high-frequency energy.
Special Regulations
Meet any special regulations in force in any area and always switch off your cellular phone
whenever the use if forbidden such as concert hall, public area, and etc. Also, avoid using your
phone where the use of phone can cause serious danger (hospital, potentially explosive area,
while driving).
9
PRIOR TO USE
Effective Phone Usage
Please use your cellular phone for proper purpose. Avoid unnecessary contact with the antenna when the
phone is switched on. It may deteriorate the conversation quality and may incur extra power usage.
Backup Data from Cellular Phone
Phone numbers, message and data stored in the phone book can be lost due to user s negligence. When
cellular phone may be damaged and your data may be lost while repairing. Back up important data in safe
medium. We do not take responsibility for damages incurred due to data loss.
Keep Cellular Phone in Dry Place
This cellular phone is not water-proof. Keep it in dry place.
Cellular Phone and Frequency Interference
All cellular phone are subject to radio frequency interruption. Radio frequency interference may influence the
performance of your cellular phone.
Accessories and Batteries
Use only VK-approved accessories and batteries. If original accessories are not used, battery can explode or
damage your cellular phone.

10
Approved Service Center
When repairing your cellular phone, use only VK approved service centers.
Emergency Calls
The cellular phone needs to be switched on and had to be in service area. If other functions are in use, finish
the other function by pressing END key. Then, press emergency number and press CALL button. Describe your
location and the emergency condition. Emergency call does not end until you hang up.
11
PRIOR TO USE
Actual product may look different from the above picture.
Cellular Phone Battery Desktop Charger Travel AdapterUser’s Manual
Hand Strap Ear-microphone PC Sync CD Mini SD Card HolderData Cable
Unpacking

12 13
PRIOR TO USE
Left soft key menu
Talk key
Make/answer calls.
When this button is pressed in standby mode, the last number you dialed will be
redialed.
Change character input method in character input mode.
Display call record.
Function key
Up : MP3 Down : lrRC Remote Controller
Left : Enter message in standby mode Right : Bookmarks
WAP/OK key
Enter WAP from standby mode, OK function.
Earpiece
Alphanumeric
Keys
Special function keys
Left soft key
Navigation key
Send / Dial /
Speed-eZi key
Mouthpiece
Right soft key
End / Power
0n-off key
CLR key
Front Cover
Display
WAP / OK key
Slide
Antenna
Mirror
Speaker
Volume Keys
IrDA port
Ear-microphone Jack
Camera
Flash
Camera Keys
Mini SD card
port
Charger connection Cover
Phone Layout and Keys Function Keys Description

14 15
PRIOR TO USE
Camera key
Enter camera mode.
Right soft key
Enter the left-bottom menu on LCD enter Contacts from standby mode.
End key
Switch on/off, end call function end the selected function and return to the initial
screen.
Dial key
Enter number and characters.
key
Silent mode on/off.
key
Lock mode on/off.
Cancel key
Delete number or characters return to the previous menu level.
Volume key
Adjust the button volume from standby mode Conversation volume adjustment while
speaking on the phone While slide is closed. (Up key-pressing for 2 seconds turns on
LCD, Down key-pressing for 2 seconds turns on flash)

16 17
PRIOR TO USE
1. Turn off the power of
cellular phone.
2. Remove battery as shown
in the figure below.
3. Face the gold color contact
point of SIM card towards
the cellular phone and push
in the SIM card into the
slot.
4. Push in the battery as
shown in the figure below.
1) Align the battery as shown
in the figure.
2) Push in the battery until it
makes Click sound.
5. Switch on the cellular
phone.
Shows the received signal strength. [Strong Weak ]
Appears when a call is in progress.
Appears when you are out of a service area.
Appears when roaming service is enabled.
Appears when your message box is full.
Appears when you have new or unread message.
Appears when you set the alert type for incoming calls to vibration.
Appears when you set the alarm to ring at a specific time.
Shows the level of your battery.
Appears in GPRS Service.
LCD Icon Description Inserting SIM Card and Battery

18 19
PRIOR TO USE
Charging with traveler s kit
Battery can be charged without desktop charger, thus, it is easier to take the
charger with you.
Charging through traveler s kit may take longer than using the desktop charger.
Connect traveler s kit to the external connector of cellular phone.
Connect the traveler s kit to the power outlet.
You can confirm the battery charging status with the LED color on the traveler s
kit.
Red : In charging
Yellow : Battery may not be properly connected to the battery. Make sure batter
is firmly connected to the charger
Green : Charging is complete
Using Desktop Charger
Align the better with the charger as shown in the figure.
Push in the better until it makes Click sound.
Connect the traveler s kit to the desktop charger.
Plug in the traveler s kit into the power outlet.
You can confirm the battery charging status with the LED color on the traveler s
kit.
Red : In charging
Yellow: Battery may not be properly connected to the battery. Make sure batter
is firmly connected to the charger
Green : Charging is complete
Charging Battery

21
BASIC FUNCTIONS
Switching On/Off
Switch On : Hold down button for 2 seconds or longer.
If no SIM card is inserted in the cellular phone, a message window that states no SIM card is inserted is
displayed.
In this case, only emergency call can be used and the rest of functions cannot be used.
If you are asked with password, enter the password and press OK button.
The default password is set to 0000 .
When your cellular phone is set to silent mode, the cellular phone vibrates as it is switched on.
Switch Off : Hold down button for 2 seconds.
BASIC FUNCTIONS
BASIC FUNCTIONS
Basic Operation
Contacts
Character Input Method
Basic Operation

22
Making Call
[Dialing]
1. Enter area code and phone number in standby mode.
2. Press button.
When you entered a wrong number, press button to erase one number at a time.
Hold down button for 2 seconds to erase all entered numbers.
When the call receiver is on the line or did not answer your call, the number is automatically redialed.
[Making a Call from Contacts]
You can make a call without entering phone number. Using phone numbers that are pre-stored, you can
make a call.
Press the right soft key to enter the contacts.
For more details on contacts, see page 32.
[Latest Call List]
You can make a call using the latest call list.
1. Press button shortly to display the latest call list in order of call time. Or, enter by accessing Menu
3. Calls 1. Call History
23
BASIC FUNCTIONS
2. Select desired phone number using up/down button of key.
3. Press button.
For more detail, refer to Call History on page 84.
[Speed Dialing]
You can make a call using speed dialing.
Using number keys from 2 to 9, hold down the pre-stored speed dial number for 2 seconds.
If the phone number is stored in your cellular phone hold down the speed dial number.
If the phone number is stored on SIM card press the speed dial number first, press key, and press key.
Speed dial number can be configured from 2 to 99.
For more detail, refer to Contacts on page 32.
[Making an International Call]
1. Holding down 0 button for 2 seconds displays symbol.
2. Enter the country code, area code, and phone number after symbol.
3. Press button.

24
Answering a Call
1. When there is an incoming call, either bell tone or vibration is activated depending on the configuration.
2. Open the slide or press button.
3. To hang up, either close the slide or button.
If a caller ID service is activated and if the incoming phone number is already stored in your contacts, the
name you have stored for the phone number is displayed.
If you do not wish to answer an incoming call, hold down button that is located on the side of your cellular
phone while the slide is closed. Silent mode is activated.
When you have equipped the ear-microphone, press a button on the ear-microphone to answer an incoming
call. You can use the same button on the ear-microphone to end a call.
25
BASIC FUNCTIONS
Hanging up
Close the slide or press button to hang up.
Options During a Call
You can use a variety of functions while talking on the phone.
[Call Standby]
This function is available only when a network service is provided. When this function is used, Using this
function, you can make a call or answer other calls during any time of call.
During a call, use either the right soft key or option key to enter the call option. Confirm that you have
flashed back to the previous call and press button to go back to the previous call.
[Ending a Call]
End a call during a Call : This function ends the current call.
End a call on hold : This function ends a call on hold.
End all calls : This function ends both the current call and the call on hold.
Add a call : With this function, you can make a new call during a call.

26
Making Call
[Flash]
When there is a new incoming call, you can either answer the call or put it on hold. Also, you can switch the
current call with the new incoming call.
[DTMF Function]
You can enter numbers and send it during a call.
In case where you need to enter a long sequence of numbers such as paging, ARS, or Telebanking, you can
store the frequently used numbers (social security number or bank account number) to send them with
greater convenience.
[Switching Microphone Off]
You can turn off the microphone so that the caller on the other side cannot hear you.
Select a call list and select Turn Mic Off .
When a call is ended, Turn Mic Off function is automatically released.
[Contacts]
You can search the contacts during a call.
27
BASIC FUNCTIONS
[SMS Function]
When this function is used during a call, you can send/receive SMS without handing up a call.
[Conference Call]
This function is available when a network service is provided.
Up to 6 people can talk at a time.
For more detail, please contact your service provider.
[Private Call]
While using Conference Call function, you can use this function to talk to a specific person.
[Sending Out My Phone Number]
This function comes very convenient when you need to enter your phone number for paging or ARS calls.
[Using Menu Function]
Menu function can be used during a call. However, the available menu function during a call is limited.
For more detail, refer to Menu Tree on page 61.
[Volume Adjustment During a Call]
You can adjust the volume during a call using button located on the side of your cellular phone.
The volume can be adjusted in five steps.

28
Missed Calls
Missed calls are displayed with the Caller s phone number and how many times the caller had called you.
Press key to exit Missed Call window.
Missed call phone number can be edited, stored or deleted.
For more detail, refer to Call History on page 84.
29
BASIC FUNCTIONS
Silent Mode
This function puts the cellular phone into Silent mode. Bell tone and button sound are changed to vibration,
ramp blinking and silent mode.
In areas where etiquette is required, such as public area, concert hall, lecture hall and conference room, this
function is convenient.
Hold down key to setup Silent Mode.
Hold down button again to release Silent Mode.
When Silent Mode is configured, icons is displayed on the screen.
When Silent Mode is set up, schedule/anniversary/alarm/message are notified through vibration.
When the cellular phone is turned off in Silent Mode, the cellular phone stays in Silent Mode when it is turned
on later.
Volume Adjustment
You can adjust the conversation volume using button located on the side of your cellular phone during a
call.
Open the slide in standby mode and press button on the side of the cellular phone to adjust the button
volume.
Press UP button of key to increase the volume. Press down button of key to decrease the volume.
For more information on opening/closing slide, power on/off, and volume, refer to phone settings on page
130.

30
Using Ear-microphone
Ear-microphone frees your hand during a call.
To use ear-microphone, insert the ear-microphone into ear-microphone slot on the side of the cellular phone.
When there is an incoming call, press located on the side of cellular phone, or press button on the ear-
microphone to answer the call.
31
BASIC FUNCTIONS
Standby Screen Function
Run the standby screen function using and keys.
The left soft key executes
function that left bottom
line of the display.
In standby mode, pressing
this key enters menu.
The right soft key executes
fwhat that right bottom
line of the display.
In standby mode, pressing
this button enters menu.

32 33
BASIC FUNCTIONS
3. Confirm the entered phone number and press key to save.
When you entered incorrect number, press key to erase.
Press key once to erase one number at a time. Hold down key for longer than2 seconds
to erase all entered number.
4. Select whether to save on your cellular phone or on SIM card.
5. Set up the type of phone number.
Phone number types such as office phone number, cellular phone, house phone number can be saved on
the cellular phone.
When the phone number is stored on SIM card, only one representative phone number for the individual
can be saved.
6. Enter the name.
Press key to enter character edit window.
Confirm the entered name and press key to save.
For more details on character editing, refer to Character Input on page 51.
7. Set up the group type.
You can store phone numbers and name in the contacts and retrieve to make a call. Data can be stored both
in SIM card and your cellular phone, while you can search through one contacts list for data.
Note that the maximum amount of data stored depends on the type of SIM card.
When you purchase a new cellular phone, the phone numbers stored on SIM card can be inserted into the
new cellular phone and retrieved.
Contacts
Storing Phone Numbers
Phone numbers can be stored using either of two methods.
Directly Entering Phone Number.
Access Contacts and store a new phone number.
[Directly Entering Phone Number]
1. First, enter the phone number you want to store in the standby screen.
2. Save is displayed on the left-bottom of the screen.

34 35
BASIC FUNCTIONS
8. Two more phone numbers other than the first phone number you have saved, can be stored.
Enter the related phone numbers next to each icon.
Note that only one phone number can be saved for the individual on SIM card.
9. Set up the default phone number.
10. Configure the speed dial number. The speed dial number can be configured form 2 to 99.
11. Configure the image to be displayed for the phone number.
Press key to enter the gallery.
Select one of stored images from the gallery and press to save.
12. Enter e-mail address.
13. Enter homepage address.
14. Enter fax number.
15. Enter house address.
16. Configure special bell tone.
When this bell phone is configured, an incoming call from the configured phone number plays the
selected number.
17. Enter occupation.
18. Enter name of company.
19. Enter note.
20. Confirm all the entries and press key to save.
Functions from 9 to 19 can only be used when the phone number is stored on the cellular phone. Only
name, phone number, and group type can be configured on SIM card.
For more details on character editing, refer to character input on page 51.
[Access Contacts and store a new phone number]
1. Press key in standby mode to enter contacts.
2. The entire phone list is displayed.
3. Enter menu screen by pressing key.
4. Press 1 to enter New screen.
5. Select whether to store phone number on the cellular phone or SIM card.
6. Enter the name.
Pressing key enters the character edit window.
Confirm the entered name and press key to save.
For more details on character editing, see ‘Character Editing on page 51.

36 37
BASIC FUNCTIONS
7. Configure group type.
8. Enter phone number and relevant phone number into fields located next to each icon.
Note that only one phone number can be stored on SIM card.
9. Configure the default phone number.
10. Configure speed dial number. Speed dial numbers can be configured from 2 to 99.
11. Configure the image to be displayed for the phone number.
Press key to enter the gallery.
Select one of stored images from the gallery and press to save.
12. Enter email, homepage URL, fax number, home address.
13. Configure the bell tone.
14. Enter occupation, name of company, and etc.
15. Confirm all the entries and press keys to save.
Functions from 0 to 15 can be used only when the phone number is stored on the cellular phone. Only
name, phone number, and group type can be configured on SIM card.
For more detail, refer to Directly Entering Phone Number on page 32.
In addition, for more information on character input, refer to character input on page 51.
Search Phone Number
You can search phone number from the entire contacts list or perform selective search using various methods.
(name, phone number, speed dial, group, and etc.)
[Search All]
This function displays all phone numbers stored in the contacts. (The list include both numbers stored in the
cellular phone and SIM card)
1. Press key in standby mode to enter the contacts.
2. The entire contacts list is displayed.
3. Select a phone number and press key to make a call to the selected individual.
[By Name]
1. Press key in standby mode to enter contacts.
2. Press key to enter the search option.
3. Select 1 to enter By Name .
4. When an edit window is displayed, enter the name of individual and press key.
Entering only one character searches all names that contains the entered character.
For more details, refer to Character Input on page 51.
5. Press key to make a call to the selected individual.

38 39
BASIC FUNCTIONS
[By Group]
1. Press key in standby mode to enter the contacts.
2. Press key to enter the search option.
3. Select 2 to enter Group .
4. Using left and right button on key to select a group.
5. Search a phone number from the selected group.
6. Press key to make s call to the selected individual.
[By Speed Dial]
You can save the phone number and then dial them easily whenever you want, simply by pressing the
associated number key.
1. Press key in standby mode to enter the contacts.
2. Press key to enter the search option.
3. Select 3 to enter By Speed Dial .
4. The entire speed dial number list is searched.
Using key, either select or enter the speed dial number to be searched.
5. Press key to make a call to the selected individual.
[By Phone No.]
1. Press key in standby mode to enter the contacts.
2. Press key to enter the search option.
3. Select 4 to enter By Phone No. .
4. Enter the number to search.
Entering only one number searches all phone numbers that contains the entered number.
5. Press key to make a call to the selected individual.
