Service Procedures for RAPTAIR60 Engine
First 50 Hour and Every 100 Hour Engine Service Kits A500007 (RAPTAIR60)
Engine Service Kit Contents
A 100 hour service kit will contain an engine oil filter, fuel filter, and 1.06 USG (4 liters) of 15W40 engine oil.
General Service Information
Safety and Service Precautions
Observe these precautions when performing any service:
Never attempt to clean the air filter element with compressed air. Remove the air filter element from the air cleaner body
and lightly tap or shake to remove any particulate or debris. Wipe out the inside of the air filter body with a dry cloth and
reinstall air filter element.
To prevent damage to the oil filter, always use a proper filter wrench. Never over-tighten the filter, as this may damage
the seal or the filter.
You must make sure that there is no pressure left in the system. If there is a pressure gauge, make sure that
it is at zero before commencing service. If you are not sure, attach a tool or air nozzle to the air outlet and
make sure that there is no pressure.
Observe all safety procedures relating to moving belts, hot oil and compressed air. Use all safety equipment to protect
yourself.
Check the old oil for any evidence of metal filings or contamination; if found, contact your local Kubota dealer.
100 Hour Service Procedures
For complete engine maintenance routines, refer to the Kubota Engine Manual supplied with the RAPTAIR60
(VMAC p/n: 1900919).
Follow all safety precautions outlined in the Kubota Engine manual and RAPTAIR60 manual when
performing any maintenance routines.
!

VMAC –Vehicle Mounted Air Compressors
Toll Free: 1-888-241-2289
Local: 1-250-740-3200
Fax: [phone]
2
1. Locate the Serviceable Components.
Locate the serviceable components in Figure 1, below.
Figure 1 –Raptair with Service Panel Removed
2. Replacing the Fuel Filter
For your convenience, we have supplied a replacement fuel filter
element. Replace the old fuel filter element and install the new one as
seen in figure 2 below. Refer to the Kubota Engine Manual for
complete disassembly and reassembly instructions.
1. O Ring
2. Filter element
3. Spring
4. Filter bowl
5. Screw ring
Please note the orientation of the fuel filter. Ensure the open
end is oriented towards the top cap.
Figure 2: Fuel Filter Assembly
Engine Oil Filter
Fuel Filter Assembly
Oil Drain Spigot
Air Filter Body
Alternative Oil Fill
System ID

VMAC –Vehicle Mounted Air Compressors
Toll Free: 1-888-241-2289
Local 1-250-740-3200
Fax: [phone]
3
3. Draining Engine Oil
Locate the drain port inside the rectangular tube below the radiator, and behind the bottom left corner, of the front
service panel (Figure 3).
Insert a hose over the drain valve outlet and open the valve to drain the oil into a container large enough to hold at
least 1-1/2 US Gallons (6 liters). After the oil has drained, close the valve.
Figure 3: Engine Oil Drain Valve
4. Replacing the Engine Oil Filter.
Locate and remove the old engine oil filter by turning counter clockwise (Figure 4). Replace with the new filter
provided.
Figure 4: Engine Oil filter Removal
5. Adding Engine Oil
Oil can be added using an accordion funnel with the engine’s fill cap on the top of the engine. If an appropriate funnel is
not available, the oil can be added using the dipstick port above the battery.
