We/come/
Dear Customer:
thank you for choosing , r.y, product.
I"Íf,i*
The Eclipse apparatus are in fact the best on the ínternational
market to become your performance's reliable partner.
we have taken great care for better interfacing with all the musical
instruments.
The Eclipse series models guarantee constant time performances
without any particular apparatus maintenance.
We advise you to read carefully this manual before the use.
I
L
J
o
z
IJJ
'13
Enjoy yourse/f with ECLIPSE/

YCeq- r+c Amplified Processed SubwooÍeÍ
Your ECLIPSE subwoofer is a choice of style and
state of the art technology: here all the benefits
you will get with.....a good choice indeed!
REFLEX IMPROVED COOLING SYSTE]II (RICS)
With the exclusive RICS project, the Eclipse series speaker
systems perform a forced cooling of the internal amplifier,
with a special circulation of the internal air. RICS allow an
improved performance of the bass reflex system: The
stronger you play, more efficient the internal cooling will be.
12" SPEAKER
The speaker used is custom Voice System project.
HDPE CABINET
The new cabinet with HDPE technology gives maximum
robustness and ease of transport thanks to the reduced
weight (only 21 Kg!). The cabinet is identical to the one of
the ECLIPSE speaker.
This gives an extra ease of transport, and allow the
revolutionary option of mounting the subwoofer directly
under the speaker, without using extra accessories.
MULTICOMP
The Multicomp circuitry compress the signal that is too loud
at the input, with a special progressive mode, avoiding the
annoying "cuts" obtained with a traditional limiter.
ANTIDUITIP
At the power on the special Antidump stage eliminates every
risk of impulsive noises that can damage the drivers.
14

User man ua/ informa tions
This instruction manual is an integral part of the apparatus.
Descriptions and illustrations of this publication are not binding.
Manufacturer reserves the right to carry out any possible
modifications of parts or details for the improvement of the product
or for commercial or constructive requirements, at any time and
without any engagement to update this publication.
All rights are reserved; the reproduction of any part of this manual
is forbidden in every form without expressed
written permission,
The contents of this guide may be modified without notice.
Maximum care has been taken in the collecting and verification of
the documentation for a better, complete and comprehensible guide.
GCUPSe SUB
Ampl ified Processed Subwoofer,t 4 5 OW
= Reflex lmproved Cooling System tj HDPE
:l Stereo cross-over (í Boost A phase
ZÍ Anttdump .É Multicomp
E
o
f
o
z
u.l
15

,V
Grcli?s€ Amplified Processed Subwoofer , y _,_
I'?1.!.{
Product care
. Do not apply excessive force to the structures and
controls (knobs and switches).
o Avoid the system being subjected to strong impact both
during transportation and while in use.
. Do not place the equipment near heat sources, in damp
or dusty places or near magnetic fields.
. Wherever possible, do not place the system near
equipment likely to produce strong interference such as
radios - TVs, monitors, etc...
. On no account allow any foreign objects or any kind of
liquids to enter the equipment.
. For cleaning operations use only a soft cloth or
compressed air, never use detergents, solvents or spirits'
. When unplugging cables always hold them by the plug
and not by the lead itself; when winding them up, avoid
knots and twists.
. Do not expose the equipment to direct sunlight.
. In order to avoid the risk of electric shock never make
power connections with wet hands.
. Make sure that the mains voltage corresponds with that
shown on the inside of the amplifier panel.
. Connect the AC IN socket to a properly earthed power
supply.
. Always use good quality screened cables.
16

ne ,ontfot panA
Eclipse is a powered subwoofer electronically controlled via a Multicomp
processor. The control of the Multicomp processor is very simple and
completely automatic.
ïhe first key on the left side of the control panel is the Multicomp insert
key. Pressing this key it is possible to disable the controller that is normally
ON as a factory preset. We
suggest of course always to
use the Multicomp controller,
The Clip LED is active when
the compressor is on.
On the left side of the Clip LED
a ON LED display when your
ECLIPSE subwoofer is switched
on; while on the right side of
the Clip LED a green LED of
audio signal presence is
located.
GND Lift
Lffi
rdwÀ
§*
§ ; Í77'1 Pr'ï\/
§ 'i; "Ji.
% o--".r-ri*..,1* r'.,ïi
'... *'
;-'t t:', ;^. l, r,.: r"j ! :,.'.,
li i lf.,,rilií.r.j I': i,r, l,'."t',.'..;'.. . r
L
With this key it is possible to
''i -* I i ' *i. .:-L -: J _' common mode when the key
í:ï r**ï i Í if e 3, is not pressed (OFF). Pressing
\*À c**,f L*{ 1§"-rr the key the grounds are lifted
. (oN).
l,:: .r,. :, ;iil ":__::i,;i BOOST
ti:.::. r. ,:r .: ..,.. .:;..,it:..i .,: Eclipse sub works with a eq
i . .,uul ,. I ir::::::. : : ,. :, circuitry to improve the low
flï ï*.$ ,**, end response of the system.
fl*-*B et *.:j Pressing the key the eq is
inserted. The use of boost may
be avoided Íf it is preferred to use an external Ee.
Level
Volume control.
I.
@
J
o
z
IJJ
11

Mode
ïhis key select the working mode: Stereo (not pressed) allow the use of a
single subwoofer with a stereo speaker system, connecting both LEFT and
RIGHT mixer cables to the subwoofer.
A perfect audio spectrum is guaranteed
l-: 1:^ t-r--
{..§ll-}
U ïJ J-"t
from the omnidirectivity of the
frequencies below 2OO Hz.
Pressing the Mode key the
Mono working mode is
selected. This mode requires
the use of two separate
subwoofers for the LEFT and
RIGHT channel.
Phase
Inverts the signal phase.
This control has to be used
if a very low efficiency in the
lower frequency range is
detected. This can depend
from a phase reversal. If
you do not possess a test
signal source, you can
detect the difference by
pressing it while playing.
Output
If not pressed (Xover
position) the outputs of the
subwoofer are filtered below
2OO l1z.
If pressed (Flat position) the
subwoofer outputs sends to
the satellites the entire
LJ
..r .... i.. . i:::.:
È*t
**Í
l/' .: n.:
$_..i
L...i [- *9
audio spectrum, enhancing the lower frequency range.
Input RIGHT output output LEFI lnpirt
@e@@
On the lower part of the control panel are located the Combo XLR/Jack for
the audio input and the male XLR connector to the Eclipse satellites.
'18

Amplified Processed Subwoofcr
Conflguration
The Voice Systems ECLIPSE subwoofer is built in a very light and
easy to use case: professional handles are located both on top and
on the sides of the system.
On the top of the case four circular
slots are built to ease the stacking
of the ECLiPSE speakers directly
above the ECLIPSE SUB subwoofer.
This way it is possible to create a
multiple system without using
speaker stands.
Four rubber feet are provided on
the case bottom to surely install
the speaker reducing stage noise.
On one side of the Eclipse speaker
four small plastic feet allow an
installation as a stage monitor.
Finally, we would like to remind
you about the metal front grid and
the BLUE ON LED on the front
panel.
-
I
o
z
UI
19

Power supply
On the bottom part of the control panel the AC in cable connector is
located. This connector is completed with fuse protection.
At its side it is located the power on switch.
20

I
Mixer connection with jack or male XLnptLgs
giÈlrvè
!_"j ïie ::::.. , ffi, ,,
$tíng
r
J
t
ECLIPSE satellites connection with femaleXLR plug
:§, ,:.-i , ':1
;::-li : : i
o
J
(,
z
UI
21

(i:.-,ttt'', Amplif ied Processed Subwoofer
Technical specs
\MPLIFIER W IHF
(lkHz,THD 1%) 450 W
)ISTORTION (THD+N) Less than 0.1%
NPUT
MPEDANCE Balanced input: 20 Kohm
Unbal input: 10 Kohm
NPUT
SENSITIVITY LINE input: 0 dB (0,77sV)
DOWER SUPPLY For mains specifications
see oroduct labels,
SENSITIVITY (SPL) dB 98 1W1m
FREQUENCY
?ESPONSE Hz (-10d8) 40 200
)ISPERSI0N (OxV) 0mnl
}ROSSOVER
:REQUENCY 200H2 @ 24dB/p[.
]OMPONENTS 12' Woofer
]ONSTRUCTION
Ultra-light H DPE cabinet
Metal grid protection
three professional handles, stage
monitor configuration side shape
]ONTROLS Volume, Multicomp, GND Lift, Boost, Mode, Phase
}ONNECTORS LINE lnput: Combo XLR/Jack
Link: XLR
)lMENSIONS rm(WxHxD) 430x560x41 0
IUE!GHT Kq 21,0
?2

NorE: This equipment has been tested and Íound to comply with the limits Íor a class B
digital Device, persuant to Part 15 iÍ the FCC Rules. These limits are designed to provide
reasonable protection against harmful intederence in a residential installation. This equipmenl
generates, uses and can radiate radio Írequency energy and, iÍ not installed and used in
accordance with the instruction, may cause harmÍul interference to radio comunications.
However, there is no guarantee lhat the interference will not occur in a particular installation. If
this equipment does cause harmful interÍerence to radio ortelevision reception, whích can ba
determinated by turning the equipment oÍÍ and on, the user is encuraged to try to correct the
interference by one or more of the Íollowing measures:
- Reorient or relocate the receiving antenna.
- lncrease the separation between ihe equipment and receiver.
- Connect the equipment into an outlet on a circuit ditÍeíent from that to which the receiver
is connécted.
- Consult the dealer or an experienced Radioffv technician for help.
The user is cautioned that any changës or modiÍication not expressly approved by the party
responsable Íor compliance could voÍd lhe user,s authority opearate the equipment.
