Volfoni ACTIV HUB RF50 User manual

1. PRODUCT OVERVIEW
1.1 DESCRIPTION
1.2 CONTENT OF THE ACTIVHUB RF50 SYSTEM
1.3 CONNECTORS AND FUNCTION
1.4 REQUIREMENT
2. COMPATIBILITY
3. USING YOUR ACTIVHUB RF50
3.1 POWERING YOUR ACTIVHUB RF50
3.2 SELECTING THE SYNCHRONIZATION SOURCE
3.3 SELECTING THE EMISSION CHANNEL
3.4 EXAMPLES OF SETUPS
4. ADVANCED USES
5. LED SIGNIFICANCES
6. SOFTWARE UPDATES
7. TECHNICAL SPECIFICATIONS
8. IMPORTANT SAFETY RECOMMENDATIONS
9. MAINTENANCE OF THE ACTIVHUB RF50
10. WARRANTY
11. CONTACT
12. REGULATORY STANDARDS
SUMMARY
Content Page
2.
2.
2.
3.
4.
5.
5.
5.
5.
5-6.
7.
7.
7.
7.
7.
8.
8.
9.
9.
1. PRODUCT OVERVIEW
1.1 Description
The ActivHub RF50 is an emitter used to wirelessly synchronize
3D glasses with a 3D display system.
It can receive 3D synchronization via
- Wired link, typically VESA-DIN3 or BNC connectors
- Infra-Red link, from a wide varietyof sources like 3DTVs and
3D IR emitters
- DLP-link embedded in the 3D imagesof a 3D-ReadyTM projector
It can transmit 3D synchronization via
- RF link from any 3D source.
Its intelligent core allows it to be
-Automatically compatible with most 3D display brands using
IR synchronization
- Upgraded to new functions via volfoni's website
-Loaded with custom-made software for specific applications
It is especially suitable for
- Virtual Reality centers, thanksto its omnidirectional, interference
-free RF link
- Digital Content Creators, thanksto its selectable 12-channels RF Link
- 3D professionals, thanksto its industry-wide multi-brand compatibility
1.2 Content of the ActivHub RF50 Kit
Your ActivHub RF50 kit includes;
- an ActivHub RF50 3D emitter
- a VESA-DIN3 to Jack 3.5 connection cable
- a BNC & USB to Jack 3.5 connection cable
- a USB A to micro-USB cable for maintenance and power
- a USB universal power adapter
1.3 Connectors and Functions
1. USB connector
2. Jack 3.5 connector
3. IR reception window
4. DLP-LinkTM reception window
5. Function selector
6. Power and Function LED
1.
6.
4.
3.
5.
2.
1.4 Requirements
The ActivHub RF50 is a 3D signal emitter to be used with active
glasses to view 3D contents played on an active 3D display
like 3D monitors, 3DTV or 3D projectors.
The ActivHub RF50 should receive the 3D synchronization
signal from an Infra-Red source, a DLP-linkTM compatible 3D
projector, or a VESA-DIN3 or BNC connector. It can transmit
the 3D signal RF, in the following configurations.
The ActivHub RF50 can transmit RF synchronization when
connected to a VESA or BNC cable
The ActivHub RF50 can transmit RF synchronization when
receiving an IR 3D signal.
The ActivHub RF50 can transmit RF synchronization when
receiving a DLP-Link 3D signal.
3D Content
Movie, sports...
Active 3D
display
RF glasses
ActivHUB
3D Player
Computer, Blu-Ray...
In=Wire, Out=RF
3D Content
Movie, sports...
RF glasses
ActivHUB
In=DLP, Out=RF
3D Content
Movie, sports...
Active 3D
display
RF glasses
ActivHUB
3D Player
Computer, Blu-Ray...
In=Wire, Out=RF
2. 3.
RF50
User Guide
model
VPES-04000
ActivHub RF50 User Manual V1 January 2013

- Certain types of TV images or video games that
contain flashing patterns of light may cause epilepsy
symptoms for some viewers. If you or any member of
your family has a history of epilepsy, Volfoni strongly
recommends that you consult a physician before the
use of this product.
- Be aware of young children, especially those under six
years old. Because their vision is still under development,
consult a doctor (such as pediatrician or eye doctor)
before allowing young children to watch 3D. Not for
children’s use without proper adult supervision.
- If the product is broken, please keep broken pieces
away from mouth and eyes. Dispose of pieces responsi-
bly.
9. MAINTENANCE OF THE ACTIVHUB
RF50
- Protect the 3D system from direct sunlight, heat, or
water. Extreme conditions may alter the product's
abilities.
- Do not drop or modify the electrical or mechanical
components of the 3D system.
- Do not apply force to the ActivHub RF50.
- Do not submerge the ActivHub RF50 in water.
10. WARRANTY
The ActivHub RF50 is warrantied to the original purchaser
for three to twelve months according to local legislation.
The system should be returned in this original box with
original proof of purchase. Volfoni does not warrant
uninterrupted or error-free operation of the product.
4. ADVANCED USES
Special configurations
More 3D functions can be added to your Activhub
RF50 systems, using specific software or hardware.
Volfoni team can provide custom-maid solutions for
special projects like museographic installations, Virtual
Reality centers or even technological art pieces
Contact us via our website if you have special 3D
synchronization needs.
5. LED SIGNIFICANCES
LED OFF: no power
Continuous light: The ActivHub RF50 is powered but there is
no 3D source.
LED blinks once: 3D input OK, and the ActivHub emits in IR
mode.
LED blinks twice: 3D input OK, and the ActivHub emits in RF
mode.
6. SOFTWARE UPDATES
You may want to update your ActivHub RF50. This
operation is possible on our website www.volfoni.com,
section support.
7. TECHNICAL SPECIFICATIONS
These technical specifications are effective when
using VOlfoni 3D glasses.
Radio Frequency
- RF frequency: 2.4 GHz (ISM band)
- Emission power: Adjustable from -20 to 10 dBm
8. IMPORTANT SAFETY RECOMMENDA-
TIONS
- If you are unsure about your vision, take a test to
verify your ability to see stereoscopic 3D images.
- Do not sit too close to the screen when watching 3D
images.
- Watching 3D may cause discomfort (such as eye
strain, altered vision, fatigue, nausea, lightheaded-
ness, dizziness, confusion, loss of awareness, convul-
sions, cramps and/or disorientation) for some people.
Volfoni recommends that you take regular breaks
when watching 3D content or playing 3D video
games until the discomfort ends. If the discomfort
persists, consult a doctor.
3. USING YOUR ACTIVHUB RF50
3.1 Powering the ActivHub RF50
The ActivHub RF50 gets its power either from the Jack or
micro-USB ports. Do not plug both inputs to power-
providing devices at once, this may damage the
ActivHub or the host systems.
The VESA port should be powered with either 5v or 12v. If
your VESA is not powered, then the ActivHub RF50 can
be powered via its USB port. In this case, make sure to
use the included universal adapter rather than a
powered USB port on an electronic device.
3.2 Selecting the synchronization source
Synchronization source selection is automatic on the
ActivHub RF50.
At power-on, synchronization sources like Vesa,
DLP-LinkTM and IR, are automatically checked by the
ActivHub. As soon as any of these three signals is
detected, the ActivHub will focus exclusively on it until its
next full power cycle. To switch to another synchroniza-
tion source, you need to power off the ActivHub RF50.
The scan priority order is :
1.Wired 3D signal
2.DLP-link 3D signal
3.IR 3D signal
3.3 Selecting the emission channel
The emission mode is selected by the function selector:
0 : Autotest mode
3 to E: RF channels
F: not used
Please note that the position 1 and 2 are not to be used
in the ActivHub RF50.
3.4 Examples of setups
1.VESA-DIN3 > RF mode
1. Set the function selector to position 3.
2. Plug the Vesa or BNC connector to your 3D source
3. If using the BNC cable, plug its USB connector to a
power source.
4. Plug the Jack 3.5 connector to the ActivHub RF50.
5. Check the blue LEDs lighting up to means power on.
6. Check the blue LEDs starts blinking twice every 3 sec.
Notes
• The ActivHub RF50 twice blink signals a functional 3D
sync input and its RF transmission.
• If you experience interferences, or if you are using
many ActivHub RF50 in a single room or building, you
may choose another channel between 4 and 14.
2. COMPATIBILITY
Active 3D TV brands compatible with ActivHub RF50 in
IR mode :
Sony®, Panasonic®, LG®, Samsung®, Konka®, Hinsen®,
Arcelik®.
Computer 3D displays and systems compatible with
ActivHub RF50 in IR mode : Nvidia®, NuVision®, Volfoni®.
This includes selected ACER®and ASUS®3D monitors
and laptops
Your ActivHub RF50 uses Volfoni's proprietary RF 3D
mode
The ActivHub RF50 is not compatible with 3D systems
using Bluetooth, RF4CE or ZigBee RF protocols, like the
Samsung Bluetooth Displays and Glasses, or the
BitCaldron RF Products
Using your ActivHub RF50 in DLP-Link 3D mode
The ActivHub RF50 is compatible with all 3D-ReadyTM
projectors with an active DLP-link function. The DLP-link
3D signal is an invisible light pulse embedded into the
3D image projection. Refers to your projector user
manual regarding the procedure to activate the
DLP-link signal. Most DLP-based rear-projection 3DTV
sold after 2005 are DLP-link compatible.
Compatible 3D Glasses
The ActibHub RF50 is compatible with Volfoni 3D
glasses. The ActivHub RF50 is specifically adapted to
Volfoni 3D glasses. You may find more information
about this glasses on our website www.volfoni.com.
Using seemingly compatible, yet non-Volfoni, glasses
with the ActivHub RF50 will most likely generate timing
issues and degrade the 3D image quality, color
fidelity, sharpness and brightness. This may cause
unwanted eyestrain or fatigue.
These compatibility lists are indicatives. Due to possible
changes of protocol by manufacturers, Volfoni
cannot warranty compatibility with products
previously cited.
2. IR > RF mode
1. Set the function selector to position 3.
2. Plug the USB connector to a powered socket or the
included adapter.
3. Plug the micro-USB connector to the ActivHub RF50.
4. Check the blue LEDs lighting up to signal power on.
5. Turn the IR reception window towards the IR 3D
source like the 3DTV.
6. Check the blue LEDs starts blinking twice every 3 sec.
7. Make sure you keep the IR reception window turned
toward the 3D source.
Notes:
•The ActivHub RF50 twice blink signal a functional 3D
sync input and its RF transmission.
• IR receiving mode requires a clear line-of-sight
between the ActivHub RF50 and the 3D source.
• If you experience interferences, or if you are using
many ActivHub RF50 in a single room or building, you
may choose another channel between 4 and 14.
3. DLP®-link™ > RF mode
1. Set the function selector to position 3.
2. Plug the USB connector to a powered socket or the
included adapter.
3. Plug the micro-USB connector to the ActivHub RF50.
4. Check the blue LEDs light up to signal power on.
5. Turn the DLP-link reception window towards the
screen or the projector.
6. Check the blue LEDs starts blinking twice every 3 sec.
7. Make sure you keep the DLP-linkTM reception window
turned toward the 3D image or source.
Notes :
• The ActivHub RF50 twice blink signal a functional 3D
sync input and its RF transmission.
• DLP-linkTM receiving mode requires a clear line-of-
sight between the ActivHub and the 3D image or
source.
• Because DLP-link signal is in the visible light spectrum,
it is very sensitive to ambient light. Optimal positions for
the ActivHub are:
-Close to the projector, turned toward the
output lens
-Close to the projector, turned toward the
screen
-Close to the screen edge, turned toward the
projector
• If you experience interferences, or if you are using
many ActivHub RF50 in a single room or building, you
may choose another channel between 4 and 14.
Note: Using Volfoni Rf glasses require to update them
with a RF software. It can be downloaded form volfoni
website: www.volfoni.com.
11. CONTACT
Made and distributed in France by Volfoni SAS.
49 Avenue Pierre Grenier 92517 Boulogne-Billancourt,
France
Distributed in Americas by Volfoni Inc.
3450, Cahuenga Bd West, Unit 504, Los Angeles, CA90068
USA
Distributed in Germany by Volfoni GmbH.
Erzgießereistraße 38, 80335 München, GERMANY
Distributed in Spain by Volfoni S.L.
Ronda Guglielmo Marconi, 4 46980 Paterna (Valencia)
Spain
Distributed in UK by Volfoni Ltd.
90 Long Acre, Covent garden, WC2E 9RZ, London,
United Kingdom
Distributed in China by VOLFONI Ltd
2101, Tower One, Lippo Center, 89, Queensway, Hong
Kong
For further information, visit Volfoni's website at
www.volfoni.com
12. REGULATORY STANDARDS
European Union - Disposal information :
This symbol means that according to local laws and
regulationsyour product should be disopsed of separately
from household waste. When this product reaches its end
of life, take it to a collection point designated by local
authorities. Some collection points accept product for free.
The separate collection and recycling of your product at
the time of disposal will help conserve natural resources
and ensure that it is recycled in a manner that protects
human health and the environment.
FCC Compliance Statement :
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interferences that may cause undesired operation.
8. 9.
4. 5. 6.
7.
