Vollrath MIX1007 User manual

Item No. 2350045-1 en Rev 05/14
ENGLISH
Operator’s Manual
Countertop Mixer
Floor/Bench Mixers
Thank you for purchasing this Vollrath Food Processing Equipment. Before operating the equipment, read and familiarize yourself with the
following operating and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging.
Use this packaging to ship the equipment if repairs are needed.
Item Model Description Voltage HP Amp Hz Plug
40755 MIX1007 7 Quart Countertop Mixer 110V-120V 1/3 6 60 5-15P
4075503 MIX1007CE 7 Quart Countertop Mixer 220-230V 1/3 3 50 UK-15P (BS546)
4075502 MIX1007CE 7 Quart Countertop Mixer 220-230V 1/3 3 50 Schuko CEE7-7
4075505 MIX1007CE 7 Quart Countertop Mixer 220-230V 1/3 3 50 AU2-15P
40756 MIX1010 10 Quart Countertop Mixer 110V-120V 1/3 6 60 5-15P
4075603 MIX1010CE 10 Quart Countertop Mixer 220-230V 1/3 3 50 UK-15P (BS546)
4075602 MIX1010CE 10 Quart Countertop Mixer 220-230V 1/3 3 50 Schuko CEE7-7
4075605 MIX1010CE 10 Quart Countertop Mixer 220-230V 1/3 3 50 AU2-15P
40757 MIX1020 20 Quart Bench Mixer 110V-120V 1/2 10 60 5-15P
4075703 MIX1020CE 20 Quart Bench Mixer 220-230V 1/2 4 50 UK-15P (BS546)
4075702 MIX1020CE 20 Quart Bench Mixer 220-230V 1/2 4 50 Schuko CEE7-7
4075705 MIX1020CE 20 Quart Bench Mixer 220-230V 1/2 4 50 AU2-15P
40758 MIX1030 30 Quart Floor Mixer 110V-120V 1 16 60 5-20P
4075803 MIX1030CE 30 Quart Floor Mixer 220-230V 1 8 50 UK-15P (BS546)
4075802 MIX1030CE 30 Quart Floor Mixer 220-230V 1 8 50 Schuko CEE7-7
4075805 MIX1030CE 30 Quart Floor Mixer 220-230V 1 8 50 AU2-15P
40759 MIX1040 40 Quart Floor Mixer 208-240V 1-1/2 12 60 6-15P
4075903 MIX1040CE 40 Quart Floor Mixer 220-230V 1-1/2 11 50 UK-15P (BS546)
4075902 MIX1040CE 40 Quart Floor Mixer 220-230V 1-1/2 11 50 Schuko CEE7-7
4075905 MIX1040CE 40 Quart Floor Mixer 220-230V 1-1/2 11 50 AU2-15P
40760 MIX1060 60 Quart Floor Mixer 208-240V 2 16 60 6-20P
4076003 MIX1060CE 60 Quart Floor Mixer 220-230V 2 16 50 --
4076002 MIX1060CE 60 Quart Floor Mixer 220-230V 2 16 50 Schuko CEE7-7
4076005 MIX1060CE 60 Quart Floor Mixer 220-230V 2 16 50 AU2-15P

OperatOr’sManual
2
ENGLISH
Function and PurPose
Intended for mixing batters, doughs, cake mix, etc. It is not intended for
household, industrial or laboratory use.
Features and controls
5
4
3
2
1
SPEED
TIMER
ON/
OFF
A
E
G
F
H
I
B
C
D
Figure 1. 7 Quart. and 10 Quart. Mixer, Features and Controls.
A
B
C
D
E
F
G
H
I
J
K
Figure 2. 20 Quart and 30 Quart Mixers, Features and Controls.
saFety Precautions
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
WARNING
Warning is used to indicate the presence of a hazard that can cause
severe personal injury, death, or substantial property damage if the
warning is ignored.
CAUTION
Caution is used to indicate the presence of a hazard that will or can
cause minor personal injury or property damage if the caution is
ignored.
NOTE
Note is used to notify people of installation, operation, or maintenance
information that is important but not hazard-related.
For Your Safety!
These precautions should be followed at all times. Failure to follow
these precautions could result in injury to yourself and others or
damage the equipment.
To reduce risk of injury or damage to the equipment:
Plug only into grounded electrical outlets matching the nameplate rated
voltage.
Do not modify or tamper with safety switches.
Do not operate unattended.
Do not operate equipment in public areas and/or around children.
Do not use an extension cord with this equipment. Do not plug this
equipment into a power strip or multi-outlet power cord.
For best results, Vollrath attachments are recommended.
Check equipment before each use to insure the equipment is clean.
Do not use a hose to clean mixer. Use a damp cloth to wipe down the
exterior of the mixer.
Wear proper apparel. Do not wear loose tting or hanging garments while
operating this equipment.
Have equipment installed by a qualied personnel in accordance with
local codes and ordinances.
Use equipment in a at, level position.
Unplug equipment, turn off and let it cool before cleaning or moving.
Do not spray controls or outside of equipment with liquids or cleaning
agents.
Do not clean the equipment with steel wool.
Keep equipment and power cord away from open ames, electric burners
or excessive heat.
Do not operate if equipment has been damaged or is malfunctioning in
any way.
Do not use the attachments on hub while mixing.

3
ENGLISH
OperatOr’sManual
H
A
B
C
D
E
F
G
I
J
K
Figure 3. 40 Quart Mixer, Features and Controls.
A
B
C
D
E
F
G
H
I
J
K
Figure 4. 60 Quart Mixer, Features and Controls.
ACONTROL PANEL. Includes the On/Off Button, Speed Control,
Timer Controls, Timer Display and Emergency Stop (some
models).
BBOWL LIFT. Used to lower and raise the bowl cradle.
CBOWL. Holds the food product mixing contents.
DBOWL CLAMP. Secures the bowl to the bowl cradle.
EBOWL CRADLE. Holds the bowl.
FMIXING SHAFT. Holds the mixing attachment.
GBOWL GUARD. Helps prevent injury or contact with mixing
shaft or attachment. This guard needs to be closed for
operation.
HSPLASH GUARD. Helps prevent spillage of mixing contents.
Helps prevent injury or contact with mixing shaft or attachment.
IBASE. Supports the mixer.
JATTACHMENT HUB (some models). Used to locate an
attachment to the mixer.
KATTACHMENT HUB THUMBSCREW (some models). Secures
the attachment to the mixer.
unPacking the equiPment and initial setuP
Carefully remove crating or packaging materials from the equipment. Models
shipped on pallets are bolted to the pallet. Bolts must be removed to safely
separate the equipment from the pallet. When no longer needed, dispose of
all packaging, materials in an environmentally responsible manner.
Place the equipment on a at surface with sufcient space around the mixer
to allow for safe cleaning and service.
Plug only into grounded electrical outlets matching the nameplate rated
voltage. Do not use an extension cord with this equipment. Do not plug
this equipment into a power strip or multi-outlet power cord. Some models
require electrical connection to be installed by a qualies service personal in
accordance with local ordinances.

OperatOr’sManual
4
ENGLISH
oPeration
WARNING
Entanglement Hazard.
Rotating shaft or attachments can cause traumatic
amputations or sever lacerations. To avoid injury,
keep hands and clothing away from rotating parts.
Do not operate with guards modied or missing.
WARNING
Electrical Shock Hazard.
Keep water and other liquids from entering the
inside of the equipment. Liquid inside the equipment
could cause an electrical shock.
Do not spray water or cleaning products. Liquid could contact
the electrical components and cause a component failure or an
electrical shock. Do not use equipment if power cord is damaged or
has been modied.
Prior to rst use, it is important to clean the equipment. Wash new the
attachments, bowl, guards and other parts with warm soapy water and rinse
thoroughly to remove the thin protective oil lm.
The safety guard must be in the fully closed position in order to activate the
mixer. If the safety guard is not closed properly then the mixer will not start. If
the safety guard is opened during use then the mixer will switch off. In order
to restart the mixer the safety guard must be closed.
20 qt., 30qt., 40qt. and 60qt. mixers: The motor is tted with a safety shut
off device which will automatically turn off the mixer if the temperature of
the motor exceeds the manufacturers recommended operating limits. The
overload protection switch which will trip if the batch size being mixed is too
heavy. If this happens allow the mixer to cool for minimum of 30-60 minutes
and reduce the batch size by 10-15%.
7 qt and 10 qt mixers have an overload protection device which will
automatically turn off the mixer if the resistance of the motor exceeds the
manufacturers recommended operating limits. An alarm will beep and the
display will ash. Pressing the OFF button will reset the mixer.
1. Before each use, check that the equipment is clean.
2. Before attaching the bowl select the mixing attachment you will be using.
Place your selected mixing attachment inside the empty bowl (C). Do not
attempt to t the mixing attachment onto the mixing shaft (F) before the
bowl is in position. See Figures 1, 2, 3 or 4.
3. Lower the bowl cradle to its lowest position by rotating the bowl lift (B).
4. Rotate the bowl clamp levers (D) to the out or back position.
5. Hold the bowl (C) so that the pin on the bowl is facing in towards the
mixer. Position the bowl so that the pin is lined up with the pin slot on the
bowl cradle (E). Slide the pin into the slot.
6. Align the holes on the bowl tabs with the pins on the bowl cradle (E).Set
the bowl (C) on the bowl cradle (E).
7. Rotate the bowl clamp levers (D) to the front over the bowl tabs to
secure the bowl (C) onto the bowl cradle (E).
8. Install the attachment to the mixing shaft (F). Ailing the grove on the
attachment with the pin on the mixing shaft. Push the attachment up and
rotate to lock onto the pin.
9. Raise the bowl (C) to its maximum height using the bowl lift (B) by
rotating in a counter clockwise direction until it snaps into place.
oPerating the 10 quart mixer.
5
4
3
2
1
SPEED
TIMER
ON/
OFF
D
G
FA
E
B
C
Figure 5. 7 Quart and 10 Quart Mixer Control Panel.
AON/OFF BUTTON. Switches the mixer on and off.
BDIGITAL DISPLAY. Displays the time remaining in a timed
operation cycle, displays “ON” when operating in an non-timed
cycle and displays “OFF” equipment is plugged in and not
operating.
CTIME UP BUTTON. Increases the time. Maximum time of
30 minutes.
DTIME DOWN BUTTON. Decreases the time.
ESPEED UP BUTTON. Increases the mixing speed.
FSPEED DOWN BUTTON. Decreases the mixing speed.
GSPEED NUMBERS AND LIGHTS. Numbers and lights
correspond to show the mixing speed. The larger the number
the faster the speed, the smaller the number the slower the
speed.
When mixing light batches it is recommended that the mixer is not used
continuously for a time period of more than 20 minutes and a brief cooling off
period of 10-15 minutes should be allowed between mixing cycles.
1. Close the bowl guard (G). See Figure 1. The safety guard must be closed
for the mixer to operate. If the safety guard is open or not closed properly
then the mixer will not operate.
2. Select the desired operating speed based on the ingredients. Use the
speed up (E) or speed down button (F) to program the speed. See
Figure 5.
Speed 1 – Use for slow mixing, mashing and kneading yeast dough.
Speed 2 – Use for mixing cookie and cake batters.
Speed 3 – Use for beating, creaming and medium fast whipping.
Speed 4 – For whipping heavy cream and egg whites.
Speed 5 – For whipping small amounts off heavy cream/egg whites.
3. Set the time cycle, if desired by using the time up button (C) and time
down button (D). The maximum time that can be set is 30 minutes.
4. To begin mixing cycle press the on/off button (A). The mixer will continue
to operate until the on/off button (A) is pressed again. Or, the mixer will
operate until the time cycle has been completed.

5
ENGLISH
OperatOr’sManual
oPerating the 20 quart and 30 quart mixers.
F
A
E
B
C
D
G
Figure 6. 20 Quart and 30 Quart Mixer Control Panel.
AON/OFF BUTTON. Switches the mixer on and off.
BDIGITAL DISPLAY. Displays the time remaining in timed
operation cycle, displays “ON” when operating in an non-timed
cycle and displays “OFF” equipment is plugged in and not
operating.
CTIME UP BUTTON. Increases the time. Maximum time of 30
minutes.
DTIME DOWN BUTTON. Decreases the time.
ESTOP BUTTON. Press the switch in to stop the mixer. Rotate
the switch in the clockwise direction to reset.
FSPEED SELECT LEVER. Used to change the mixer speed.
GINDICATOR LIGHTS. Illuminates when the mixer in operating
or time has been programmed.
NOTE:
Turn the mixer off before switching from one speed to another. Failure to stop
the mixer before changing speeds may damage the gearbox and void the
warranty.
1. Close the bowl guard (G). See Figure 2. The safety guard must be
closed for the mixer to operate. If the safety guard is open or not closed
properly then the mixer will not operate.
2. Select the desired operating speed based on the ingredients. Use the
speed select lever (F) to set the speed. See Figure 6.
Speed 1 – Use for mixing heavy dough with an absorption ratio of 50%
or less.
Speed 2 – Use for mixing cakes, batters or heavy dough with an
absorption ratio of more than 50%.
Speed 3 – Used for mixing egg whites.
NOTE:
The moisture content of heavy dough is critical when selecting the
proper mixing speed. Do not use speed 2 when mixing heavy dough
with an absorption ratio of 50% or less.
3. Once the speed has been selected, press the on/off button to start the
mixer. Or, select a time by pressing the time up button (D) or time down
button (C). Press the on/off button.
4. To change speeds, press the red button to stop the mixer. Once the
mixing attachment has stopped rotating then change the speed using the
speed control knob. Once the new desired speed has been selected then
press the on/off button to reactivate the mixer.
5. The mixer will stop and the timer will beep three times after the time
cycle has ended.
NOTE:
Turn the mixer off before switching from one speed to another. Failure
to stop the mixer before changing speeds may damage the gearbox
and void the warranty.
oPerating the 40 quart and 60 quart mixers.
E
B
A
C
G
D
F
Figure 7. 40 Quart Mixer Control Panel.
E
B
A
C
G
D
F
Figure 8. 60 Quart Mixer Control Panel.
AON BUTTON. Switches the mixer on.
BDIGITAL DISPLAY. Displays the time remaining in timed
operation cycle, displays “ON” when operating in an non timed
cycle and displays “OFF” equipment is plugged in and not
operating.
CTIME UP BUTTON. Increases the time. Maximum time of 30
minutes.
DTIME DOWN BUTTON. Decreases the time.
ESTOP BUTTON. Press the switch in to stop the mixer. Rotate
the switch in the clockwise direction to reset.
FSPEED SELECT LEVER. Used to change the mixer speed.
GSTOP BUTTON. Switches the mixer off.
NOTE:
Turn the mixer off before switching from one speed to another. Failure
to stop the mixer before changing speeds may damage the gearbox
and void the warranty.

OperatOr’sManual
6
ENGLISH
mixing caPacity chart
1. Close the bowl guard (G). See Figures 3 or 4. The safety guard must be
closed for the mixer to operate. If the safety guard is open or not closed
properly then the mixer will not operate.
2. Select the desired operating speed based on the ingredients. Use the speed
select lever (F) to set the speed. See Figures 7 or 8.
Speed 1 – Use for mixing heavy dough with an absorption ratio of 50% or
less.
Speed 2 – Use for mixing cakes, batters or heavy dough with an absorption
ratio of more than 50%.
Speed 3 – Used for mixing egg whites.
NOTE:
The moisture content of heavy dough is critical when selecting the proper
mixing speed. Do not use speed 2 when mixing heavy dough with an
absorption ratio of 50% or less.
Product Agitator Speed 7 Quart
Mixer
10 Quart
Mixer
20 Quart
Mixer
30 Quart
Mixer
40 Quart
Mixer
60 Quart
Mixer
Bread and Roll Dough – 60% AR Dough Hook 1st speed only 4 lbs. 5 lbs. 25 lbs. 45 lbs. 50 lbs. 90 lbs.
Heavy Bread Dough – 55% AR Dough Hook 1st speed only 2 lbs. 3 lbs. 15 lbs. 30 lbs. 40 lbs. 70 lbs.
Pizza Dough, Thin – 40% AR Dough Hook 1st speed only 2 lbs. 3 lbs. 9 lbs. 14 lbs. 25 lbs. 40 lbs.
Pizza Dough, Medium – 50% AR Dough Hook 1st speed only 3 lbs. 4 lbs. 10 lbs. 20 lbs. 32 lbs. 60 lbs.
Pizza Dough, Thick – 60% AR Dough Hook 1st speed only 4 lbs. 5 lbs. 20 lbs. 40 lbs. 50 lbs. 70 lbs.
Raised Donut Dough – 65% AR Dough Hook 1st speed only 2 lbs. 2 lbs. 9 lbs. 15 lbs. 25 lbs. 40 lbs.
Pie Dough Flat Beater All Speeds 4 lbs. 4 lbs. 18 lbs. 30 lbs. 35 lbs. 60 lbs.
Mashed Potatoes Flat Beater All Speeds 4 lbs. 5 lbs. 15 lbs. 23 lbs. 30 lbs. 45 lbs.
Cake Flat Beater All Speeds 6 lbs. 8 lbs. 20 lbs. 30 lbs. 12 lbs. 60 lbs.
Wafe or Hot Cake Batter Flat Beater All Speeds 3 qts. 4 qts. 8 qts. 12 qts. 16 qts. 24 qts.
Egg Whites Wire Whisk All Speeds 3/4 pt. 1 pt. 1 qts. 1-1/2 qts. 2 qts. 3 qts.
Meringue Wire Whisk All Speeds 1/2 pt. 3/4 pt. 1 qts. 1-1/2 qts. 2 qts. 3 qts.
Whipped Cream Wire Whisk All Speeds 1-3/4 qts. 2 qts. 4 qts. 6 qts. 8 qts. 12 qts.
Cake, Pound Flat Beater All Speeds 6 lbs. 8 lbs. 20 lbs. 30 lbs. 40 lbs. 60 lbs.
When mixing dough check the “AR” (Absorption Ratio) = Water weight divided by our weight.
The capacities listed above are based on 12% our moisture at 70°F (21° C) water temperature. If high gluten our is used reduce batch
size by 10%.
1 gallon of water = 8.3 lbs.
1 quart of water =2.1 lbs.
Example:
If a recipe calls for 5 lbs. of water and 10 lbs. of our, then 5 divided by 10 = 0.50 x 100 =50% AR.
Do not use 2nd speed with mixtures with below 50% AR.
3. Once the speed has been selected, press the on/off button to start
the mixer. Or, select a time by pressing the time up button (D) or time
down button (D). Press the on/off button.
4. To change speeds, press the red button to stop the mixer. Once
the mixing attachment has stopped rotating then change the speed
using the speed control knob. Once the new desired speed has been
selected then press the on/off button to reactivate the mixer.
5. The mixer will stop and the timer will beep three times after the time
cycle has ended.
NOTE:
Turn the mixer off before switching from one speed to another. Failure to
stop the mixer before changing speeds may damage the gearbox and void
the warranty.

7
ENGLISH
OperatOr’sManual
using the attachment hub
The mixer is tted with a standard No. 12 mixing hub attachment. It is
recommended that original Vollrath attachments be used. To use the attachment
hub:
NOTE:
Turn the mixer off before switching from one speed to another. Failure to
stop the mixer before changing speeds may damage the gearbox and void
the warranty.
1. Turn the mixer off
2. Loosen the hub attachment thumbscrew (K). It is not necessary to fully
remove the screw. See Figures 2, 3, and 4.
3. Remove the attachment hub cover.
4. Insert the shaft of the attachment into the attachment hub (J).
5. Align the pin on the attachment shaft with the pin receptor inside the hub.
6. Slide the attachment in as far as it will go. Secure the attachment with the
thumbscrew (K).
7. Use the speed control knob to select the required hub operating speed:
Speed 1 – recommended for slicing vegetables or grinding meat
Speed 2 – recommended for grating cheese
8. Press the On/Off or On button to operate the hub and attachment the hub.
The mixer bowl must be in the up position and the safety guard must be in
the closed position in order for the hub to operate. The hub assembly and
the mixer cannot be used simultaneously.
9. To change speeds, press the red button to stop the mixer. Once the mixing
attachment has stopped rotating then change the speed using the speed
control knob. Once the new desired speed has been selected then press
the on/off button to reactivate the mixer.
Speed 3 is not recommended for use with attachments.
troubleshooting
Problem It might be caused by Course of Action
No lights on Display Panel.
The equipment is not plugged in. Plug equipment in.
Circuit breaker is in the “OFF” position. Switch circuit breaker to “ON” position.
Stop switch in the “in/stop” position. Rotate the stop switch to the “out/run” position.
Power and time lights on but mixer does not operate. Bowl guard not completely closed. Close bowl guard completely.
Bowl not lifted into operating position. Raise bowl completely.
7 quart and 10 quart mixers only: Mixer attachment stops
moving, alarm beeps and display ashes. Mixer is overloaded. Press the off button to reset mixer. Reduce the batch size by 10-15%.
20 quart, 30 quart, 40 quart and
60 quart: Mixer attachment stops. Thermal overload protection activated. Allow the mixer to cool for 30-60 minutes. Reduce the batch size by 10-15%.
cleaning
WARNING
Electrical Shock Hazard.
Keep water and other liquids from entering the
inside of the equipment. Liquid inside the equipment
could cause an electrical shock.
Do not spray water or cleaning products. Liquid could contact
the electrical components and cause a component failure or an
electrical shock. Do not use equipment if power cord is damaged or
has been modied.
WARNING
Entanglement Hazard.
Rotating shaft or attachments can cause traumatic
amputations or sever lacerations. To avoid injury,
keep hands and clothing away from rotating parts.
Do not operate with guards modied or missing.
To maintain the appearance and increase the service life, clean your
equipment daily.
NOTE:
Do not clean the equipment with steel wool. Do not hose
down or submerge electrical controls or components in
water. Do not store attachment on attachment hub.
1. Switch off the mixer.
2. Unplug the mixer from the power supply before cleaning. If the mixer
is hard wired to the electrical outlet then the power should be turned
off at the circuit breaker.
3. Remove the bowl and attachment after each use and clean with
warm water and food safe cleaning detergent. Failure to remove
the attachment from the mixing shaft may result in the attachment
becoming stuck onto the mixing shaft.
4. Remove the attachment and clean with a damp cloth and mild food
safe cleaning detergent. Dry the attachment thoroughly.
5. To clean the exterior of the mixer, wipe with a damp cloth and mild
food safe cleaning detergent.

The Vollrath Company, L.L.C.
1236 North 18th Street
Sheboygan, Wisconsin
53081-3201 USA
Main Tel: [phone]
Main Fax: [phone]
Service Tel: [phone]
Service Fax: [phone]
Vollrath Europe BV
Beneluxbaan 7
5121 AD RIJEN
The Netherlands
[phone]
Vollrath of China
Vollrath Shanghai Trading Limited
29D, 855 South Pu Dong Road
Shanghai, China 200120
Tel: [phone]
Vollrath de Mexico S. de R.L. de C.V.
Periferico Sur Edicio 2-C
Col. Santa Maria Tequepexpan
45601 Tlaquepaque, Jalisco Mexico
Tel: [phone]
Tel: [phone]
Fax: [phone]
www.vollrath.com
Item No. 2350045-1 en Rev 5/14
service and rePair
There are no user serviceable parts within this appliance. To avoid serious injury or damage, never attempt to repair the equipment or replace a damaged power cord
yourself. Do not send equipment directly to The Vollrath Company. Please contact Vollrath Technical Service from the list below..
VOLLRATH Technical Service • 1-800-628-0832 • 920-457-4851
• Email: [email protected]
When contacting Vollrath Technical Service, please be ready with the item number, model number (if applicable), serial number, and proof of purchase showing the
date the unit was purchased.
Warranty statement For the vollrath co. l.l.c.
This warranty does not apply to products purchased for personal, family or household use, and The Vollrath Company LLC does not offer a written warranty to
purchasers for such uses.
The Vollrath Company LLC warrants each of its products listed below against defects in materials and workmanship for the applicable period provided below. All
other products manufactured or distributed by The Vollrath Company LLC are warranted against defects in materials and workmanship for a period of one year. In
all cases, the warranty runs from the date of the end user’s original purchase found on the receipt. Any damages from improper use, abuse, modication or damage
resulting from improper packaging during return shipment for warranty repair will not be covered under warranty.
Mixers – The warranty period is 2 years, except that on belts the warranty period is 5 years.
Replacement parts – The warranty period is 90 days.
For complete warranty information, product registration and new product announcement, visit www.vollrath.com.
